ITALEYE® START
ASSEMBLY SHEET
[e-mail] | T [phone]
Safety Device with Integrated
Temperature Detection Camera

ASSEMBLY SHEET ITALEYE® START
THERMAL CAMERA
The thermal camera is used for the automatic body temperature
measurement and the access control through facial recognition.
High performances hardware platform by RSM micro rk3288 /
rk3399 / Qualcomm msm8953, equipped by an industrial binocular
camera with human facial recognition and a thermal infrared
imaging module. It supports the facial masks detection, an SD card
reader, a fingerprint device and other devices.
It can be connected to the gate channel and to the access
control system to get a sure and ecient entrance check for the
personnel.
VIDEO TECHNICAL CHARACTERISTICS
Camera’s resolution: 2 Mega Pixel
Reading distance: 20 – 150 cm
Lighting: infrared, white light
Monitor: 8” IPS HD 800x1280
Day/night operation: auto adaptive
Measuring point: frontal
Error margin: +- 0,2 °C
Reading time: < 1 sec
Detection range: 10 • -42°C
Ideal operating temperature: - 10 • +60°C
Overheating alarm: supported
IDENTIFICATION
Recognition data: face, mask wearing
Detection: Biometric
Face identification precision: 99,5%
Identification time: < 1 sec
FUNCTIONS
Facial recognition: multiple
Faces database: 30.000 faces
Faces importation: single, in batch, in real time
Unknowns identification: supported
GENERAL PARAMETERS
Strength: IP65, outdoor dustproof and waterproof functions
Dimension: 238*128*25 mm
Weight: 1.45 kg
DO NOT EXPOSE THE CAMERA TO SUNLIGHT,
WOULD DAMAGE THE MEASURING SENSOR
OF THE TEMPERATURE.

SUPPORT PLATE VERTICAL BRACKET MAIN BODY
ITALEYE® START ASSEMBLAGE
The Italeye® START device kit consists of three separate elements to be assembled, the support plate, the
vertical bracket and the main body.
1. Connect the support plate to the vertical structural bracket by screwing the screws on the bracket from the
underside of the plate. Unscrew the screws on the bracket before placing it on the plate. Position the bracket
so that the hole remains on the back as shown in the photo below (PHOTO 01).
2. Unscrew the screws on the lower part of the main body and gently slide the frame onto the main bracket
until the end stop is reached. Then tighten the screws previously unscrewed from the main body.
3. Connect the power supply to the specific socket on the back of the device with the photo below (PHOTO
02). The thermal imaging camera and the sanitizing gel dispenser are immediately functional.
PHOTO 01
CORRECT POSITIONING OF THE BRACKET
ASSEMBLY SHEET ITALEYE® START
PHOTO 01
POWER SUPPLY CONNECTION

Safety Device with Integrated
Temperature Detection Camera
[e-mail] | T [phone]
01
UNLOCK THE DOOR
02
PULL TANK
03
RECHARGE
SANITIZING GEL REFILL
THERMAL CAMERA USER MANUAL
PLEASE CONNECT TO THE FOLLOWING LINK AND DOWNLOAD THE CAMERA’S USER GUIDE
OR USE THE QR CODE TO CONNECT TO THE DESTINATION PAGE
https://italeye.com/download/
IN THE WEB PAGE YOU WILL BE ABLE TO DOWNLOAD ADDITIONAL INFORMATION MATERIAL
