ITD Food Safety Inc. Temp-Taker 3 Subway Edition User manual

2475 Palm Bay Road Suite 110
Palm Bay, FL 32905-2928
Office: 321.676.3194
Fax: [phone]
[e-mail]
ITDFoodSafety.com
Getting Started
T3GSSW-150826

Introduction
Installing the PC software
Logging into the software
Customizing the setup:
◦Setting up the Subway Temp Log
◦Setting reminder alarm times
◦Entering user names
Using the handheld device:
◦Logging in & logging out
◦Taking In-Range Temps
◦Taking Out-of-Range Temps
◦Taking a Temp of a product after corrective action is performed
◦‘Closing out an entry with an owner/manager signature’
◦Using Spot-Check Temps mode
Generating Subway Temp Log reports
Notes & Tips
Technical Support
© 2015 ITD Food Safety Inc. 2

Congratulations on your acquisition of the Temp-Taker® 3 –Subway Edition.
This edition automates the temperature-taking process while maintaining
full compliance with Subway’s operation guidelines, including the printing of
Subway’s Temp Log reports and the implementation of Subway’s Corrective
Action procedure.
This guide will assist store owners and managers in quickly setting up and
using the Temp-Taker® 3 –Subway Edition in their stores. For more detailed
technical information consult document T3UMGE Temp-Taker 3 - User
Manual (see last page in this document).
IMPORTANT NOTE: If you already have Temp-Taker® 3 installed on your
machine, it is important that you follow the instructions described in
document T3SUSW A Guide to Upgrading to the Subway Edition.
© 2015 ITD Food Safety Inc. 3

To perform a fresh installation of the Temp-Taker® software, please note the following:
You must be logged on your machine with an administrator account; this is because
Windows must install USB drivers.
You may also need to temporarily disable antivirus and/or other security software in
order to successfully perform the installation.
Insert the installation disc in your CD drive. On most systems, the installation will
automatically start; if it does not, simply browse to the contents of your CD drive and
double-click the Setup.exe file.
If you downloaded the executable, you may need to extract the file from the zipped
folder and then double-click it.
© 2015 ITD Food Safety Inc. 4
A setup window will appear displaying the
Software License Agreement (see figure). Check
the box to agree to the license terms and then
click the ‘Install’ button. If Windows or other
security software requests confirmation that you
wish to allow the installation, be sure to agree.

© 2015 ITD Food Safety Inc. 5
The store owner or a general manager should be the first to log into the
software. Click the ‘Log In’ button on the left vertical toolbar, select
Manager from the ‘Select User’ dropdown, and then log in (see figure
below).
Log in as Manager
Click Log In
Clicking this button
displays the Login dialog
PINs can be enabled
(see slide #17)

The figure below shows how to perform the one-time setup of the Subway
reporting features. Enter your Franchise Number and the AM/PM target times
for taking the temperatures that should appear in the Subway Temp Log reports.
Temps do not need to be taken precisely at these specified target times. They
may be taken at any time during the AM and PM.The target times entered here
are used by the software to select between multiple Temps taken for a particular
product during the AM or PM.In this case, the temperature closest to the target
time is used for the report.
© 2015 ITD Food Safety Inc. 6
Enter your target times
for the AM & PM Temps
Enter your Franchise #
Subway reporting is set up in
General Settings Printing tab
If this section is missing, refer to
the document entitled A Guide to
Upgrading to the Subway Edition

Take-Temps reminder alarms can optionally be set after
installing the software. This is done in the Take Temps 
Programs tab (see example in the figure below). Many
Subway stores set reminder alarm times that correspond
to the target AM and PM times entered in the General
Settings Printing tab (shown in the previous slide).
The figure below shows an example of two reminder
alarms programmed to activate everyday at 9AM and
5PM. The figure on the right illustrates the activation of a
Take-Temps reminder alarm.
© 2015 ITD Food Safety Inc. 7
Set reminder alarms
in Take Temps 
Programs tab Click here to expand section
Click cell to select
reminder alarm times

Users are added/deleted in General Settings Users tab (see figure below
on the right). If you would like user initials to appear in the Subway Temp
Log reports (see figure below on the left), make sure the first and last name
of each user is entered.
© 2015 ITD Food Safety Inc. 8
Add/delete users in
General Settings Users tab
An appropriate access level
may be assigned to each user
Subway Temp Log report
showing User initials
Add new user
User list will
download to
handheld device
Initials taken from first/last
name entered in Users tab

Navigate to the Take Temps icon on the Main Menu and press the lkey to
log in (see example in the figure below).
When finished using the device, the user should manually log out by
navigating to the ‘Power Off’ __ or ‘Log Out’__ icons on the Main Menu and
pressing the lkey. Additionally, default settings automatically turn the
handheld device off after approximately 1½ minutes of inactivity. If this
happens while on the Main Menu, the currently logged-in user is logged out
automatically.
© 2015 ITD Food Safety Inc. 9
Navigate to Take Temps
icon then press the lkey
Select user then press
the lkey to log in
A list of Programs
is displayed

The figure below shows how to take In-Range Temps. The Temp-Taker® uses
a proprietary temperature-stability detection algorithm to determine when
the temperature of the probe’s tip has sufficiently stabilized before
producing the temperature reading. This contributes toward generating
fast/accurate Temps.
If the measured temperature is within the established safe zone, an In-Range
event is generated and the event details are saved into non-volatile memory.
At this point the device is ready to Temp another item.
© 2015 ITD Food Safety Inc. 10
Select a Program
then press the lkey
TIP: Zone-limit display may be
toggled on/off by pressing thekey
Press the lkey
to continue
The device is ready to
Temp the next item
Select item, insert probe
tip into product and press
the lkey to take Temp
The product that was measured is
checked off (i.e. removed from the
list); The list automatically resets
after all products are Temp’d

The figure below shows what happens when a Temp is Out of Range.
Appropriate Corrective Options are provided according to the product being
measured and the circumstances in which the product was measured (e.g. if
it’s an initial Temp or if the Temp was taken after corrective action had been
performed).
In the figure below, the PLACE IN WALK-IN COOLER option was selected.
This initiated a 30-minute Corrective Session in which the user must follow
through on the corrective action and then re-take the product’s Temp under
the Main Menu icon ‘Corrective Sessions’ (see next slide).
© 2015 ITD Food Safety Inc. 11
Press the lkey to
see Corrective Options
TIP: Use REMEASURE
to take another Temp
Insert probe tip into product;
press the lkey to take Temp
A 30-minute count-
down timer is started
5 minutes before the timer
expires an alarm will activate
Select desired option
and press the lkey

Insert probe tip into product;
press the lkey to take Temp
Before the Corrective Session countdown timer expires, another Temp of the
product should be taken under the Main Menu icon ‘Corrective Sessions’.
The figure below shows the Out-of-Range Turkey item (from the previous
slide) in Corrective Session. The user inserts the probe in the product and
takes an In-Range Temp. At this point Turkey is automatically removed from
Corrective Session.
If an Out-of-Range Temp is taken on an item in Corrective Session,
appropriate Corrective Options are provided. In accordance with Subway’s
operation guidelines, a 2nd Corrective Session automatically begins after the
1st session expires if the product’s temperature has not yet been recovered.
© 2015 ITD Food Safety Inc. 12
Navigate to Corrective Sessions
icon then press the lkey
If Temp is In Range, item is
removed from Corrective Session
Number of items in
Corrective Session
Time remaining in
session (mm:ss)

The figure below continues the example shown in the previous 2 slides.
Turkey was ‘in Corrective Session’ and after corrective action was performed
the temperature of the product was recovered. The figure below shows part
of the Subway Food Safety Temperature Action Log.
Note that Temp-Taker® automatically logged the required information except
for the ‘Owner/Manager Initials’, which may be handwritten after the page
has been printed. TIP: Enabling PINs in General Settings Security Options
tab will allow Temp-Taker® to automatically enter the ‘Owner/Manager
Initials’ (see Document #T3UPSW entitled Using PINs With Subway Edition).
© 2015 ITD Food Safety Inc. 13
When PINs are disabled,
manager handwrites initials
Sample Temp-Taker®
Action Log record
When PINs are enabled,
Temp-Taker®enters initials

Spot-Check Temps mode behaves essentially as a digital thermometer. In
this mode no Temps are recorded. To activate this mode, navigate to the
Spot-Check Temps icon on the Main Menu and press the lkey (see figure
below). Press thekey to exit Spot-Check Temps.
The figure also shows how to activate and use the temperature statistics
feature of Spot-Check Temps. When this feature is active, every time a new
maximum is ‘seen’ by the probe the LED will flash red and every time a new
minimum is ‘seen’ the LED will flash blue.
Pressing the key toggles the units between °F and °C. The pq keys adjust
the resolution of the display between 1°, 0.1°, and 0.01°. These settings are
independent of the settings used for Take-Temps mode.
© 2015 ITD Food Safety Inc. 14
Navigate to this icon and
press the lkey to enter
Press the lkey to
activate statistics
Elapsed time
(mm:ss)
Maximum, average, and
minimum Temp readings
are continuously updated
Press the lkey to
deactivate statistics
Continuous reading of
probe tip is displayed

© 2015 ITD Food Safety Inc. 15
Subway Temp Log reports may be generated from either the Report View or
Supervisor View tabs (see figure below). The report may be generated at
any time after the first Temp event has been uploaded for the selected
week. The Scope must be set to ‘Week’ (as shown in the figure). The cover
page of this document contains images of a sample Temp Log report.
Scope must be
set to ‘Week’
Subway Temp Log reports may
be generated from either tab
Click ‘Print’ then ‘SUBWAY’ to
generate the Subway Temp Log
The Data section is
used to view, print, &
export temperature data

All AM Temps must be taken between 12:00 AM and 11:59 AM. All PM Temps
must be taken between 12:00 PM and 11:59 PM.
You may take as many Temps as desired throughout the day. When generating
the Subway Temp Log report the software will automatically select the Temps
closest to the AM and PM Target Times entered in the General Settings 
Printing tab (see slide #6). The time of the first Temp taken in the series is
entered in the Subway Temp Log report.
The Sandwich Line, Equipment, and Checklist entries are configured to be
checked off (i.e. removed from the device’s display) as the items are Temp’d or
the questions are answered. These lists automatically reset after the last item
or question is checked off. Additionally, a list can be manually reset at any
time using the handheld device (see figure below).
© 2015 ITD Food Safety Inc. 16
Select desired Program
and press thekey
Press the lkey to reset
the ‘Sandwich Line’ listing
All Sandwich Line
items are now listed

Access to the software may be restricted to regular users by enabling PINs in
the General Settings Security Options tab. For more information see
document T3UPSW Using PINs With Subway Edition.
The very tip of the probe contains the temperature sensor. Therefore, when
probing a product, make sure the tip of the probe is inside the product. If the
tip exits the product on the other side, the temperature measurement may
not be accurate.
Target an area of the product close to the bottom of the food pan.
If an initial product Temp is slightly Out of Range, try waiting a few seconds
and then selecting REMEASURE without moving the probe from its position. If
it’s still Out of Range, try probing a different area of the product.
Do not use the probe as a general tool or an icepick, as this may cause
damage.
You may use rechargeable batteries in the Temp-Taker® 3 handheld device.
Always follow standard industry battery care instructions:
◦Do not mix alkaline batteries with zinc carbon or rechargeable batteries.
◦Replace all batteries at the same time.
◦Remove fully discharged batteries immediately.
© 2015 ITD Food Safety Inc. 17

Consider storing the handheld device in a highly visible location. For
example, it can be magnetized to a cooler or freezer door. This will make
the LED more visible when alarms are activated.
Also, the device may be kept in Clock mode when not in use. We
recommend using two pairs of rechargeable batteries when doing so. This
way one charged battery pair will always be available when the device’s
battery level gets low (see figure).
When swapping out batteries, first insert the charged batteries in the
open compartment and then remove the depleted batteries from the
other compartment. This will save you from having to connect the device
to the PC software to unlock it after it powers up.
© 2015 ITD Food Safety Inc. 18
Press the lkey to
enter Clock mode
Sample charger showing
two batteries charging while
two batteries are in use
Battery level almost critical;
swap-out batteries immediately
Default settings prevent auto-
power-off while in Clock mode

Multiple Temp-Taker® handheld devices may be used simultaneously in a
store. The software can upload data from any number of devices and
consider all the data when generating the Subway Temp Log report.
The Temp-Taker® software may be installed in more than one computer in
a store. However, when doing so, make sure to select the ‘Download
Temps Setup and Settings only’ option in the Station Functionality section
of the Security Options tab on all computers except one (see figure
below). This will ensure that data is uploaded to only one computer.
© 2015 ITD Food Safety Inc. 19
Select this option to prevent
device-generated data from
uploading to the computer
General Settings Security Options

Temp-Taker® technical support resources (including FAQs, technical
documents, and training videos) are available via the following website:
http://www.ITDFoodSafety.com/Food_Temperature_Management/Temp-Taker_3/Support/
If you see any errors in the Temp-Taker® device or computer software
application please email the following to [e-mail]:
Your full name, company name, and contact information
A brief description of how you became aware of the error; include (if
available) any screenshots of error messages, pictures you may have
taken, or other information relevant to the error
The files Error.log and TT3Database.sdf (see Appendix 10.9 of document
T3UMGE Temp-Taker 3 - User Manual)
If you need to speak with a Technical Support specialist, call [phone]
9AM –5PM Eastern Standard Time.
© 2015 ITD Food Safety Inc. 20
