Itec C31POCKET4KDOCKPD User manual

P/N: C31POCKET4KDOCKPD
User guide • Gebrauchsanweisung • Mode d’emploi
Manual de instrucciones • Manuale • Uživatelská příručka
Instrukcje obsługi • Užívateľská príručka • Vartotojo vadovas
Handleiding
USB-C POCKET DOCK
4K HDMI OR VGA WITH PD

Quick Start / USB-C Pocket Docking Station
EN Please read the entire instruction manual carefully. Detailed
manual is available on our website www.i-tec.cz/en/ in the tab
„Manuals, drivers“. In case of any issues, please contact our technical
support at: [email protected]
DE Bitte lesen Sie das gesamte Handbuch sorgfältig durch. Die
ausführliche Gebrauchsanweisung ist auch auf unserer Webseite
www.i-tec.cz/de/ unter „Benutzerhandbücher, Treiber“ bei diesem
Produkt zu finden. Wenn Sie Probleme haben, kontaktieren Sie bitte
unser Support-Team unter: [email protected]
FR Veuillez lire attentivement le manuel dans son intégralité. Un
manuel détaillé est disponible sur notre site www.i-tec.cz/fr/ sous
l'onglet "Manuels, pilotes". Si vous avez des problèmes, veuillez
contacter notre équipe support à [e-mail]
ES Por favor, lea atentamente todo el manual. El manual detallado
está disponible en nuestro sitio web, www.i-tec.cz/es/ bajo la
pestaña "Manuales y controladores" de este producto. Si tiene algún
problema, póngase en contacto con nuestro equipo de soporte en
[email protected]
IT Leggere attentamente tutto il Libretto d’uso. Il Libretto d’uso è a
disposizione anche sulla scheda “Manuali e strumenti” del nostro
sito web: www.i-tec.cz/it/. In caso di problemi rivolgersi al supporto
tecnico: [e-mail]
CZ Prosíme o pečlivé přečtení celého manuálu. Podrobný manuál je
k dispozici na našem webu www.i-tec.cz v záložce „Manuály,
ovladače“ u tohoto produktu. V případě problémů se můžete
obrátit na naši technickou podporu: [e-mail]

Quick Start / USB-C Pocket Docking Station
PL Upewnij się, że uważnie przeczytałeś instrukcji obsługi.
Szczegółowy podręcznik jest dostępny na naszej stronie
internetowej www.i-tec.cz/pl/ w zakładce "Instrukcje, sterowniki".
W razie jakichkolwiek problemów, skontaktuj się z naszym
serwisem pod adresem: [e-mail]
SK Prosíme o dôkladné prečítanie celého manuálu. Podrobný manuál
je k dis pozícii tiež na našom webe www.i-tec.cz v záložke „Manuály,
ovladače“ pri tomto produkte. V prípade problémov sa môžete obrátiť
na našu technickú podporu: [e-mail]
LT Prašome įdėmiai perskaityti visą vadovą. Išsamų vadovą galite
rasti mūsų svetainėje www.i-tec.cz/en/ šio produkto skyrelyje
„Manuals, drivers“. Iškilus problemoms galite susisiekti su mūsų
technine pagalba: [email protected]
NL Wij vragen u vriendelijk om de volledige handleiding zorgvuldig
door te lezen. Een gedetailleerde handleiding van dit product is
beschikbaar op onze website www.i-tec.cz/nl/ onder het tabblad
"Handleidingen en drivers". Mochten er zich problemen voordoen
kunt u contact opnemen met ons supportcenter via
[email protected].

ENGLISH................................................... 08–11
DEUTSCH.................................................. 12–15
FRANÇAIS.................................................16–19
ESPAÑOL...................................................20–23
ITALIANO...................................................24–27
ČESKY........................................................ 28–31
POLSKI...................................................... 32–35
SLOVENSKY.............................................. 36–39
LIETUVOS................................................. 40–43
NEDERLANDS........................................... 44–47
WEEE......................................................... 48–49
Declaration of Conformity........................ 50–51
FCC...................................................................52
USB-C POCKET DOCK
4K HDMI OR VGA WITH PD

6
Quick Start / USB-C Pocket Docking Station
ENGLISH
1. Integrated cable with USB-C connector
2. VGA port
3. HDMI port
4. Ethernet GLAN RJ-45 port
5. USB 3.0 port
6. USB-C Power Delivery port
7. USB 3.0 port
DEUTSCH
1. Anschlusskabel mit USB-C Konnektor
2. VGA Port
3. HDMI Port
4. Ethernet GLAN RJ-45 Port
5. USB 3.0 Port
6. USB-C Power Delivery Port
7. USB 3.0 Port
FRANÇAIS
1. Câble de connexion avec le connecteur USB-C
2. Un port VGA
3. Un port HDMI
4. Un port Ethernet GLAN RJ-45
5. Un port USB 3.0
6. Un port USB-C Power Delivery
7. Un port USB 3.0

7
Quick Start / USB-C Pocket Docking Station
ESPAÑOL
1. Cable integrado con conector
USB-C
2. Puerto VGA
3. Puerto HDMI
4. Puerto Ethernet GLAN RJ-45
5. Puerto USB 3.0
6. Puerto USB-C Power Delivery
7. Puerto USB 3.0
ITALIANO
1. Cavo integrato con connettore
USB-C
2. Porta VGA
3. Porta HDMI
4. Porta Ethernet GLAN RJ-45
5. Porta USB 3.0
6. Porta USB-C Power Delivery
7. Porta USB 3.0
ČESKY
1. Integrovaný kabel s USB-C
konektorem
2. VGA port
3. HDMI port
4. Ethernet GLAN RJ-45 port
5. USB 3.0 port
6. USB-C Power Delivery port
7. USB 3.0 port
POLSKI
1. Kabel z konektorem USB-C
2. Port VGA
3. Port HDMI
4. Port Ethernet GLAN RJ-45
5. Port USB 3.0
6. Port USB-C Power Delivery
7. Port USB 3.0
SLOVENSKY
1. Pripájací kábel s USB-C
konektorom
2. VGA port
3. HDMI port
4. Ethernet GLAN RJ-45 port
5. USB 3.0 port
6. USB-C Power Delivery port
7. USB 3.0 port
LIETUVOS
1. Prijungimo kabelis su USB-C
jungtimi
2. VGA prievadas
3. HDMI prievadas
4. Ethernet GLAN RJ-45
prievadas
5. USB 3.0 prievadas
6. USB-C Power Delivery
prievadas
7. USB 3.0 prievadas
NEDERLANDS
1. Geïntegreerde kabel met USB-
C-connector
2. VGA-poort
3. HDMI-poort
4. Ethernet GLAN RJ-45-poort
5. USB 3.0-poort
6. USB-C Power Delivery poort
7. USB 3.0-poort

8
Quick Start / USB-C Pocket Docking StationEN
INTRODUCTION
Thank you for purchasing the i-tec docking station, our product allows
you to connect your favourite devices via a single USB-C connector to
a laptop, tablet or smartphone with a USB-C port. The docking station
provides 1x HDMI 4K port, 1x VGA Full HD port, 2x USB-A 3.0 port, 1x
Ethernet GLAN RJ-45 port, 1x USB-C Power Delivery port.
PACKAGE CONTENTS
• i-tec USB-C Docking Station with cable (24 cm)
• User Guide
SPECIFICATION
• Graphic interface: 1x HDMI (max. resolution 4K
3840x2160@30Hz, for connecting a HDMI monitor), 1x VGA
(max. resolution Full HD 1980x1080@60Hz, for connecting a
VGA monitor). It is not possible to use both graphic outputs
simultaneously, a single monitor only can be connected to the
docking station (HDMI or VGA).
• Mode: Extend, Mirror and Primary Display
• Supported colors 16 / 32 bit
• 2x USB-A 3.0 ports for connecting USB 3.1/3.0/2.0 devices for
high-speed data transmission up to 5 Gbps
• 1x USB-C Power Delivery Port (max. 85 W) for charging laptops,
tablets or smartphones with support for Power Delivery. To this
port you can connect an original or a universal AC power adapter
with USB-C connector, it ensures the constant charging of your
laptop, tablet or smartphone during your work.
• 1x Ethernet GLAN RJ-45 port for fast network and Internet
access with Gigabit Ethernet connection, it supports speeds of
10 / 100 / 1000 Mbps
• 1x integrated USB-C 3.1 cable for connecting the docking station
to laptop, tablet or smartphone
• Powered through USB bus (no power adapter is needed) or
through USB-C PD port
• Product dimensions: ø 90 x 22 mm
• Product weight: 98 g

9
Quick Start / USB-C Pocket Docking Station EN
SYSTEM REQUIREMENTS
Hardware requirements: Requires USB-C interface with „DisplayPort
Alternate Mode“ and „Power Delivery“ support (not all devices
/ systems with USB-C interface support this as standard) or
Thunderbolt 3 port
Operating system: Windows 10 32/64bit, macOS X, Linux, Google
(Chrome OS and Android 6 and higher) with latest updates
DRIVER INSTALLATION
Windows 10 32/64bit: After connection, the drivers for the docking
station are installed automatically on the system. Before installation
make sure that your system has installed the latest drivers for your
device and updated BIOS.
macOS X: Installation of the drivers in macOS X is automatic. Before
installation make sure that your Mac has installed the latest OS for
your device.
CONNECTING A HDMI MONITOR
The docking station is equipped with 1x HDMI 4K Ultra HD port for the
connection of an external monitor or projector with a HDMI interface.
For displaying your images you can use a modern plazma or LCD
monitors and TVs. The graphic chip, which is the heart of the docking
station, supports up to 4K resolution 3840x2160@30Hz. Connect the
monitor to the docking station using a highquality HDMI cable. During
installation of an additional monitor the screen of the notebook or
tablet can icker which is a standard condition.
CONNECTING A VGA MONITOR
The docking station is equipped with 1x VGA Full HD port for the
connection of an external monitor or projector with a VGA interface.
For displaying your images you can use a plazma or LCD monitors
and TVs. Connect the monitor to the docking station using a VGA
cable. During installation of an additional monitor the screen of the
notebook or tablet can icker which is a standard condition.
It is not possible to use both graphic outputs simultaneously, a single
monitor only can be connected to the docking station (HDMI or VGA).

10
Quick Start / USB-C Pocket Docking StationEN
CONNECTING TO THE LAN
You can use the GLAN RJ-45 port for connecting the Ethernet to a
router / switch and to the internet, it supports speeds of 10 / 100 /
1000 Mbps.
CONNECTING USB DEVICES
You can use USB 3.0 ports for connecting your keyboard, mouse,
external hard drive, printer and other devices or you can use it for
connecting a USB HUB, which will give you more free USB ports.
CHARGING
The docking station supports charging of USB mobile devices, such
as smart phones, e-book readers, multimedia players, navigation
devices, and tablets.Simply connect the device that you want to
charge using the original cable to the USB port of the docking station.
If the device is not charged, connect the original USB-C power adapter
to the USB-C Power Delivery port of the docking station.
CHARGING THROUGH POWER DELIVERY
The docking station offers USB-C Power Delivery port (max.
85 W), designed for charging of the connected “host” device using
the original power adapter and for charging of devices connected
through the USB ports.
AUDIO
Audio output devices, for listening through graphic output, need to be
set / veried here: System Preferences-Sound-Output – select USB
Audio Device.Setting the audio output device to both the earphones
and the monitor simultaneously can be done in Open-Applications-
Utilities-Audio settings MIDI.app – click on „+“ on the left at the
bottom – Create device with multiple outputs and select the desired
outputs from the offered options on the Device with multiple outputs.
The majority of problems with the docking station and the connected
peripheral devices can be solved by disconnecting the USB-C cable of
the docking station from the USB-C port of the PC / Mac / smartphone
and reconnecting after approximately 10 s.
