iTechworld iTECH400X PRO User manual

1
X RANGE
WATERPROOF LITHIUM BATTERIES
USER GUIDE

2
Key Features
General Specications
Safety
Wiring Diagram
Discharge Curve
Optimising your Charging
Safe Mode
Storage
Installation
Transporting
Certications & Warranty
Contact Us
CONTENTS
3
4
5
6
7
8
8
10
10
11
11
Back page

3
KEY FEATURES:
The iTechworld X Range represents the pinnacle of deep cycle lithium battery
design. These batteries are equipped with a pre-installed Battery Management
System that enables compatibility with a wide range of charging systems, making
them well-suited for use in boats, caravans, motor-homes, RVs, and more. With
an IP67 rating, they are also waterproof and dustproof, making them suitable for
under-the-bonnet use.
• Australian Design and Development
• A Grade prismatic cells
• LiFePO4 Battery
• Compact and Lightweight
• IP67 Rated Waterproof and Dustproof
• Heavy Duty ABS Casing
• High Discharge Rate
• Battery Management System
• Over Discharge Protection (Safemode)
• Withstand Under the Bonnet Temperatures
• Long Cycle Life
• Australian Lithium
Long Cycle Life
Australian Lithium

4
GENERAL SPECIFICATIONS:
For more information on specications please visit our website
and select your iTechworld X Range battery.
Scan to visit our website
Battery Type LiFePO4
Voltage 12V
Nominal Voltage 12.8V
Short Circuit Protection Yes
Optimum Temperature Range +5*C-60*C
BMS Operational Temperature +5*C-80*C
Safety Protection Isolator 80*C
Recommended Charge Voltage 14.4V
BMS Charge Cut Off 15V
BMS Low Voltage Cut Off 8.5V-9V
Series Connection Up to 48V (4 x batteries)
Parallel Connection Unlimited
Life Cycles @ 80% Depth of Discharge 5,000
Life Cycles @ 40% Depth of Discharge 10,000+
Terminal Type M8
Case Material ABS

5
For safe operation and optimal performance, of your iTechworld X Range battery,
it must be operated correctly. Please carefully read, understand, and follow all
instructions and guidelines in this user guide. Failure to follow these instructions
may result in damage to the unit, property, death, or serious injury.
Disclaimer: While iTechworld has taken every precaution to ensure the
accuracy of the contents of this user guide, iTechworld assumes no
responsibility for any errors or omissions.
Furthermore, all specications and functionality may change at any time
without notice.
It is best to view our website for the most up-to date information.
DO'S & DON'TS
DO
• Read the user guide
• Monitor battery state of charge
• Protect from physical damage
• Use a battery heat shield if you are installing the battery under the bonnet
DON'T
• Don’t cross polarity the battery
• Don’t open the casing
• Don’t throw, squeeze, puncture, strike or disassemble the battery
• Don’t use this battery in series or parallel with another battery of different
chemistry or capacity
• Don’t leave the battery in safemode for longer than 7 days
• Don’t ignore warning signs (such as unusual heat or swelling)
SAFETY

6
COMPLETE LITHIUM CARAVAN KIT
WIRING DIAGRAM
Unregulated Solar
(Not Provided In Kit)
Cranking Battery
(Not Provided In Kit)
Cables used to link batteries and Cable B- to Battery 1 must be the same
guage (or better) as the cables used for connecting loads. E.g 3000W
Inverter requires 0 AWG, then all cables must be atleast 0 AWG.
All negatives from
load/chargers to P- (On Shunt)
3000W Inverter Cabling:
2 AWG if <1M
0 AWG if > 1M
iTECHDCDC40 Cabling:
>3M: 8 AWG
>6M: 6 AWG
>10M: 4 AWG
Cable B- to Battery 1 (Not Provided in Kit)
4
5
0
6
0
1
All positives from load
chargers to Battery 4
Battery 1
Battery 2
Battery 4
KEY
This wiring diagram is provided for professional installers only.
All work to be carried out by licensed professionals.
Negative
Positive
Fuse
(Not Provided in Kit)
Shielded Cable
Solar Input
Ground
(Not Provided in Kit)
Earth
Ignition
Override
Battery 3
Cranking Battery
Cranking Battery
COMPLETE LITHIUM CARAVAN KIT:
WIRING DIAGRAM

7
DISCHARGE CURVE
Please note that a lithium battery's discharge curve will differ from your previous
lead acid batteries. Please study the discharge curve to better understand how the
lithium battery will perform.
State of Charge Voltage under load 0.1C
100% 14.0V
100% 13.8V
100% 13.5V
95% 13.1V
90% 13.1V
85% 13.0V
80% 13.0V
75% 13.0V
70% 13.0V
65% 12.9V
60% 12.9V
55% 12.9V
50% 12.9V
45% 12.8V
40% 12.8V
35% 12.8V
30% 12.7V
25% 12.6V
20% 12.5V
15% 11.8V
10% 10.5V
0% 9.5V
8.0
9.0
10.0
11.0
12.0
13.0
14.0
15.0
0%10%20%30%40%50%60%70%80%90%100%
Battery Voltage (Volts)
State of Charge %
X Range Discharge Curve 0.1C Load

8
OPTIMISING YOUR CHARGING
Embedded within every iTechworld X Range battery lies a sophisticated battery
management system (BMS) which sets our batteries apart from conventional
lead-acid, calcium, or even other lithium batteries. This BMS enables the battery to
accept a broad range of charge proles, including sealed, ooded, AGM, and GEL,
making it versatile for various charging systems. However, it's important to note that
the battery is not compatible with calcium-based charging proles.
For optimal performance in systems with adjustable parameters, we recommend
following our guidelines below. However, if your charger offers a dedicated lithium
charge prole, it's advisable to use that prole for the best results.
BULK: 14.4v
ABS: 14.4v
FLOAT: 13.5V
RECOMMENDED CHARGING CURRENT
iTECH400X PRO: 1-150A
iTECH240X PRO: 1-100A
iTECH120X PRO: 1-60A
iTECH120X: 1-50A
iTECH100SX: 1-50A
SAFE MODE
We are committed to delivering the safest batteries in the Australian market, which
is why we've integrated multiple safety features, including over-current protection,
over-voltage protection, high and low-temperature protection, cross polarity
protection, and over-discharge protection.
In the event that any of these safety features are activated, the iTechworld lithium
battery will drop into safe mode, rendering it temporarily unusable until it is brought
out of safemode. In nearly all situations, except for when the battery's voltage falls
below 10.5 volts, the battery is designed to automatically exit safe mode.
For example, if the battery's internal temperature surpasses 80 degrees, it will enter
safe mode. However, as soon as the internal temperature drops below 80 degrees,
the battery will automatically recover and exit safe mode.

9
Please follow one of the below procedures to bring your iTechworld lithium
battery out of safe mode.
If you have a solar panel in ideal weather, please follow the below steps in
sequence to bring your iTechworld lithium battery out of safe mode.
• Disconnect all loads/inputs from the iTechworld battery.
• Connect your ‘at’ battery to an unregulated solar panel.
• Leave the battery connected to the panel for 5 minutes.
• Once that 5 minutes is up. Disconnect the battery from the panel.
• Reconnect the battery to another charging source as soon as possible.
(DCDC charger, Regulated solar panel, AC charger, etc)
If you have a portable Jump Starter, follow the below steps in sequence to bring
your iTechworld lithium battery out of safe mode.
• Disconnect all loads/inputs from the iTechworld battery.
• Connect the Jump Starter cables to the battery (Positive to Positive,
Negative to Negative)
• Connect an ACDC charger to the iTechworld battery. We recommend a three
stage 20 amp or higher charger.
• Activate the jump starter to supply power to the iTechworld battery. The
charger will now detect the battery and begin to charge.
• When the charger begins to charge the iTechworld battery, disconnect the
Jump Starter from the battery.
• The charger should continue to charge the iTechworld battery, bringing it
out of safe mode.
If you have a charged battery (E.G. car battery) and jumper cables, follow the below
steps in sequence to bring your iTechworld lithium battery out of safe mode.
• Disconnect all loads/inputs from the iTechworld battery.
• Connect your ‘at’ battery to an unregulated solar panel.
• Disconnect all loads/inputs from the iTechworld battery.
• Connect the iTechworld battery in parallel to a different battery (number 2)
• Connect an ACDC charger to the iTechworld battery at the same time as the
paralleled battery and allow it to begin charging. We recommend a three
stage 20 amp or higher charger.

10
• When the charger begins to charge the iTechworld battery, disconnect
battery number 2.
• The charger should continue to charge the iTechworld battery, bringing it
out of safe mode.
• Allow the charger to fully charge the battery.
STORAGE
When your iTechworld X range battery is not in use, it is recommended to
completely isolate the battery, charge it up to 13.5V and check the voltage every 3
months, then charging the battery as needed. To ensure your battery is completely
isolated, it's essential to disconnect it from any connected devices or systems.
You can also keep our maintenance chargers connected permanently, but if the
battery is going to be completely out of use, keeping it connected is not necessary.
INSTALLATION
Your iTechworld X Range battery boasts an impressive IP67 rating, making it suitable
for installation in a wide range of environments. Here's what you need to know:
The X Range battery can be installed in any orientation, except for upside down
(with terminals facing down). For those looking to mount your X Range battery
under the bonnet of a vehicle, we recommend using a heat shield to protect the
battery from under-the-bonnet temperatures. With the robust IP67 rating and
these installation guidelines, your iTechworld X Range battery is ready to deliver
reliable power wherever you need it.

11
CERTIFICATIONS
Our iTechworld X Range batteries are in compliance with the following
standards and certi cations:
UL1642
IEC62133
IEC62619
CE
ROHS
WARRANTY
Your iTechworld X Range battery is covered by a warranty for a total duration of 5
years. This warranty is divided into two phases:
3 Years Full Replacement:
During the  rst 3 years from the date of purchase, if your battery experiences any
manufacturing defects or failures, we will provide a full replacement at no cost to
you. This period ensures that your battery is protected from any initial defects or
unforeseen issues.
2 Years Pro-rata Warranty:
Following the initial 3-year full replacement period, you have an additional 2 years
of warranty coverage through our pro-rata warranty. During this time, if your
battery experiences any issues, the replacement cost will be pro-rated based on
the remaining warranty period. This means that you will only be responsible for a
portion of the replacement cost, and the exact amount will depend on the remaining
duration of the warranty.
Australian
Certied
IEC: 62619
IEC: 62133

12
WARRANTY CONDITIONS
This warranty covers manufacturing defects and failures due to normal usage.
Damage caused by misuse, abuse, or improper installation is not covered.
The warranty is valid from the date of purchase and requires proof of purchase
for any claims.
To make a warranty claim, please contact our customer service team for
assistance ([e-mail]).
The warranty is applicable to the original purchaser and is not transferable.
We are committed to providing you with a reliable and long-lasting battery. If you
have any questions or need assistance regarding your warranty, please do not
hesitate to reach out to us. We are committed to providing you with a reliable
and long-lasting battery. If you have any questions or need assistance regarding
your warranty, please do not hesitate to reach out to us.
WARNING:
Do not use any type of oil, organic solvent, alcohol, detergent, strong acids,
strong alkalis, petroleumbased solvent or ammonia solution to clean the battery
covers and end plates. These materials may cause permanent damage to the
battery covers and end plates and will void the warranty.
DANGER:
People with physical disabilities, visual, sensory, or mental impairments
(including children) should not use this device. Children should be supervised to
ensure they do not play with the battery.
WARNING:
Avoid using the battery near re.
WARNING:
Please use the wires recommended in this user guide; otherwise, it may result in
damage to the battery, a risk of electrical shock, re, death, or serious injury.
WARNING:
Do not drop the battery.

13
WARNING:
Do not use the battery to connect equipment if there is a defect.
WARNING:
Do not disassemble or modify the battery; doing so will result in your warranty
being void, it may result in a risk of electrical shock, re, death, or serious injury.
WARNING:
Never smoke or allow a spark or ame in the vicinity of the battery. This may
cause the battery to explode.
LIMITATIONS OF USE:
Do not use in connection with life support systems or other medical equipment
or devices.

When it comes to energy storage and creation at iTechworld, we take pride in
being one of the biggest names in the industry. Based in Australia, we are a
family-owned and operated business. With many more innovative products on
the horizon we are committed to constantly raising the bar to provide bigger
and better bene ts to all our customers Australia-wide.
Whether you’re an avid camper, 4WD enthusiast , freedom seeker or camper,
we’ve got your power needs covered. Escape the grid without compromise,
minimise your downtime and travel with comfort with our large range of leading
products at great prices.
iTechworld. The Power Expert.
1300 483 249
[e-mail]
www.itechworld.com.au
CONTACT US
LOVE YOUR XRANGE BATTERY? LEAVE A REVIEW
