ICE-CUBE MANUFACTURER
HNG MODEL

WARNING
The instructions of this manual are exclusively directed to the Technical Assistance
Service personnel.
The installation of this equipment should be done by the Technical Assistance
Service department.
ALWAYS disconnect the power supply from the machine BEFORE any cleaning or
maintenance service operation.
Any change needed on the electrical installation for the appropriate connection of
the machine, should be exclusively performed by qualified and certified
professional personnel only.
Any use of the ice maker not intended to produce ice, using drinking water, is
considered inappropriate.
It is extremely dangerous to modify or intend to modify this machine, and shall
make any type warranty void.
This machine should not be used by children or handicapped without the proper
supervision and monitoring.
Children should be monitored to assure that they do not play near the equipment.
This machine is not intended to be used outdoors nor exposed to the rain.
Connect the equipment to the drinking water network.
The machine should be connected using the power cable supplied with the
equipment. The connection is not intended for fixed cabling.
In order to assure the proper operation and efficiency of this equipment, it is of
paramount importance to follow the recommendations of the manufacturer,
IT IS MANDATORY TO GROUND THE EQUIPMENT
To avoid possible discharges on individuals or damages to the equipment, the
machine should be grounded pursuant local and/or national regulations as the
case may be.
THE MANUFACTURER SHALL BE HELD HARMLESS IN CASE OF DAMAGES
ARISING DUE TO THE LACK OF THE GROUND INSTALLATION.

SPECIALLY THOSE RELATED TO CLEANING AND MAINTENANCE
OPERATIONS, which should be performed mostly by qualified personnel only.
DESCRIPTION
The most significant characteristics are:
•18/8 Stainless steel bodywork
•Telescopic guides for maintenance
•Anti-lock injectors.
•Pump without seals.
•R134A refrigerants
•Safety pressure switch in High
•TRANSPARENT ICE CUBES mainly with water network.
OPERATION PRINCIPLE
WHEN STARTING UP THE MACHINE FOR THE FIRST TIME, IT WILL BE IN
THE WATER REMOVAL-INLET CYCLE.
In this moment, the compressor is functioning and the water and gas inlet valves
are opened. The necessary water amount is loaded for the manufacturing of the
next ice cycle and the excess goes to the drainage through the maximum level
overflow tank.
Once the specified time goes by, the hot gas and water entry valves close. The
pump starts and sends water through the injectors against the molds of the cubes,
where the ice is formed little by little. At the same time, the evaporation
temperature decreases until the cubes are completely made. When this period of
time goes by, the removal cycle starts (1.5-2 minutes). Now, the pump is stopped
and the hot gas and water entry valves are activated.
Once the removal cycle has ended, the machine starts producing ice until the
storage is full. This is when the stop order will be given.
With the purpose of not having non-terminated ice cubes, if when the stock
thermostat detects that the storage bin is full, and the cycle is already started, it will
end it.

SPECIFICATIONS
MAIN DIMENSIONS
Profundidad Hueco Opening Depth
Altura hueco Opening Height

HNG ICE CUBE MACHINE TECHNICAL DATA
MODEL
WATER
CONSUMPTIO
N
L/HOUR (1)
NET
WEIGHT
(KG)
PACKING
DIMENSIONS
X*Y*Z
NET
WEIGHT
(KG)
VOLUME
(M
3
)
HNG
2.4 40 670X685X570
46 0.27
MODEL
REFRIGE
RANT
REFRIG.
LOAD
PRESSURE IN HIGH
PRESSURE
IN LOW
TOTAL
INTENS
SECU
RITY
FUSE
TOTAL
ABSORBED
POWER
MINIMUM
MAXIMUM
MEAN
(2)
(TO INSTALL)
ABSORBED (2)
(GR)
Kg/cm
2
psi
Kg/cm
2
psi
Kg/cm
2
psi
(A)
(A)
(W)
HNG
R134A
150 8
115
18
265
0.5
7
1.8 10 250
Production environment 20°C
–
water
15°C
Production Kg/ 24 h 10
Cycle period of time
(minutes)
38
Ice cubes per cycle 12
Weight per ice cube (gr) 22
(1) Obtained data with Envt=20ºC, water intake T=15ºC and water quality=500ppm
(2) Obtained maximum consumption at Envt=43ºC, according to UNE rules for the T Class climatic
classification (TROPICALIZED).
NOTE: Controlled expansion per capillary.
RECEPTION OF THE MACHINE
Inspect the outside packing. In case of damages, MAKE THE CORRESPONDING
CLAIM TO THE CARRIER.
To confirm the existence of damages, UNPACK THE MACHINE IN THE
PRESENCE OF THE CARRIER and state any damage on the equipment on the
reception document, or on a separate instrument.

Always state the machine number and model. This number is printed on two
locations:
Packing
On the outside, it contains a label with the manufacturing number (1).
Exterior of the Equipment
On the outer part of the packing, there appears a label with the same
characteristics as the previous one (1).
CAUTION: ALL PACKING ELEMENTS (plastic bags, carton boxes and wood
pallets) SHOULD BE KEPT OUTSIDE THE REACH OF CHILDREN, AS THEY
ARE A SOURCE OF POTENTIAL HAZARD.
INSTALLATION
Location zone conditions.
The HNG machines are designed to operate at room temperature between 5ºC
(41ºF) and 43ºC (109.40ºF).
There may be some difficulties in ice- cube removal under the minimum
temperatures. Above the maximum temperature, the life of the compressor is
shortened and the production is substantially less.
The machines take air for the ventilation on the front part and they expel the air
through the back part.
If the front air input is not free or the exit is totally or partially blocked, the machine
will not work correctly and the production will be affected.
The water pipe shall not go near the heat focus so as not to lose production.

60
5
60
1
00
60
560
440
5
60
HuecoSalidaDesagüe
HuecoVentilación
Housing dimensions.
To install the ice manufacturer in the correct way, it will be necessary that the hole
located for such effect in the piece of furniture has the dimensions established in
the drawing (560x440x560 mm.).
The drainage must be in the position established in the drawing. In the left part of
the housing and below the inferior level of the machine. In this way the flexible
pipes have the enough path to allow the extraction of the machine.
Hueco ventilación Ventilation opening
Hueco salida desagüe Drainage output opening

Toma agua Water connection
Toma Eléctrica Power Inlet
Salida desagüe Drainage Output
Zona libre para paso de la máquina Free space for machine clearance

IMPORTANT
It must be taken into account that an exit must be left for the air that the machines
takes through the front louver. It can be a back hole (with an outdoor exit) or a
louver on the machine.
The water connection, drainage and electrical steps of the equipment are also
necessary. (see the figure)
Anchoring of the machine
Follow the following steps:
1- Screw the guides in the hole of the piece of furniture to have them
horizontally and set back 5 mm as it is indicated on the figure.

2- Screw the fastening bridge of the machine in the position of the drawing.
3- Screw the fastening flanges of the drainage hoses
4- Place the machine on the support angles of the guides. Adjust the wide
before fastening the screws checking that it slides softly along the path.

Water and Drainage
The water quality notably affects the quality, hardness and taste of the ice.
Have in mind the following considerations:
a) WATER IMPURITIES:
The big ones are retained by the filters that accompanied each machine. Its
cleaning will be more or less periodic in function of the water purity. For the small
impurities we recommend the installation of a filter of 5 micron.
b) WATER WITH MORE THAN 1000 PPM:
The ice will be less hard and will stick a bit in the stock. There can be ice cubes
with white marks. In the machine, there will be lime deposits that can interfere with
its good operation. Water hardness is corrected with the installation of a good
decalcifier.
c) VERY CHLORATED WATER:
The ice gives a bleach (chlorine) taste. To eliminate such taste a coal filter can be
installed.
Have in mind that water can be received with the three cases simultaneously.

d) WATER OF HIGH PURITY:
Production can decrease up to a 10%.
Connections to the Water Network
Use a flexible pipe with the two filter joints supplied with the machine. Pressure
should be established between 1 and 5 Kg/cm
2
If pressures overpass such values, install the necessary corrective devices.
Leave free the needed length to extract the machine up to the end of the guides.
The rest can be flanged and gathered at a side to avoid that when storing the
machine it can touch the water pump and stop it or make noise.
Connection to drainage
The drainage must be in the position established in the drawing. In the left part of
the housing and below the inferior level of the machine. In this way the flexible
pipes have the enough path to allow the extraction of the machine.
it is convenient that the drainage pipe has an entry with an interior diameter of 50
mm to introduce the two drainage hoses of the machine.
Fix the pipes with the flanges that were provided. Thus, we ensure that when
taking out and storing the machine, the pipes do not come out.
Electrical connection:
The machine is provided with a 1.5 m (4.92 feet) cable with a schucko jack. In case
the supply cable is damaged, it should be replaced by a cable or a special
assembly to be furnished by the manufacturer or post-sale service.
Safeguard the base of the jack.
It is convenient to install a switch that allows the total disconnection of the machine
without taking it out.
IT IS MANDATORY TO GROUND THE EQUIPMENT
To avoid possible discharges on individuals or damages to the equipment, the
machine should be grounded pursuant local and/or national regulations as the
case may be.

Voltage and tension are indicated on the nameplate and on the technical
specifications of this manual. Variation on voltage above the 10% stated on the
nameplate could result on damages or prevent the machine start-up.
The line up to the base of the socket shall have a minimum section of 1.5 mm
2
.
Check that the voltage of the net and the indicated one is the same.
START-UP
Previous Checkup
a) Is the machine leveled?
b) Are voltage and frequency the same as those on the nameplate?
c) Are the discharges connected and operating?
d) Are the air circulation and site temperature appropriate?
ROOM CONSUMPTION
MAXIMUM 43ºC (109.40ºF) 35ºC (95ºF)
MINIMUM 5ºC (41ºF) 5ºC (41ºF)
e) ** Is water pressure appropriate?
MINIMUM 1 kg./cm2
MAXIMUM 5 kg./cm2
NOTE: If the inlet pressure of the water is superior to 5 kg/cm2, install a pressure
reducer.
START-UP
Once the installation instructions are followed (ventilation, site conditions,
temperatures, water quality, etc.), proceed as follows:
1) Connect the machine to the drinking water network.
2) Open the water inlet. Verify the existence of leakages.
3) Connect the machine to the electrical network.
4) Set the time of the machine (see the user menu electronic operation, adjust
time)

5) Trigger the starting up switch. The display will light with the message
Started during 30 seconds, then it will start working with the removal,
message in the display dispensing.
6) Verify that there are no vibrations or frictions on the elements.
7) Verify that the shield moves freely.
8) Verify that the injectors send water to the evaporator on the right direction,
during the manufacturing process (even spread).
9) After 10 minutes, verify that the water container has no leakages through the
maximum level retainer.
10)Verify that after the final cycle, the frost on the aspiration pipe is at 50 mm (0.78
in) of the compressor.
11)Check that during the fall of the ices, there is no water lose.
12)Introduce the machine in the piece of furniture. Fix with the screwed anchoring
and put the front louver. See drawing.

THE EXTRACTION OF THE MACHINE FOR ITS HOUSING MUST ONLY BE
MADE BY THE TECHNICAL SERVICE.
MAINTENANCE AND CLEANING INSTRUCTIONS
If a good maintenance is performed, the machine will continue producing a good
quality ice and will be free of damages.
Maintenance and cleaning intervals will depend on the conditions of the location
and water quality.
CAUTION:
INSTRUCT THE USER ABOUT MAINTENANCE PROCEDURES, INDICATING
THAT THIS ONE AS WELL AS DAMAGES DUE TO LACK THEREOF, ARE NOT
COVERED BY THE WARRANTY.
CAUTION:
At least, one revision and cleaning should be performed every six months.
On dusty environments, it might be necessary to clean the condenser on a
monthly basis.

MAINTENANCE TABLE:
OPERATION
MONTHLY
QUARTERLY
HALF-
YEARLY
ANNUAL
BIENNIAL
T UNIT
Air condenser cleaning
Air inlet filter
0000 0000 **** **** **** 30 minutes
Injector cleaning
#### #### **** **** 30 minutes
Water circuit cleaning
Manufacturing
#### #### **** **** 45 minutes
Sanitary cleaning
#### #### **** **** 30 minutes
Water filter
clearing/exchange
#### #### **** **** **** 30 minutes
Cleaning of the container
&&& &&& &&& &&& &&& --
Exterior Cleaning
&&& &&& &&& &&& &&& --
0000 Depending on the local conditions.
#### Depending on the water conditions and quality.
&&& TO BE DONE BY THE USER
**** ESSENTIAL
MAINTENANCE AND CLEANING OPERATION AS WELL AS DAMAGES DUE
TO THE LACK OF SUCH OPERATIONS: ARE NOT INCLUDED ON THE
WARRANTY.
The technical installer shall invoice traveling costs, hours and materials used on
such operations.
MAINTENANCE AND CLEANING PROCEDURES
**
CAUTION:
For all cleaning and maintenance operations: Disconnect the
machine from the power supply.**

Air Condenser-filter
1) Disconnect the machine.
2) Take out the front louver. (pull out the lower clips)
3) Vacuum clean, wash or substitute the filter.
4) Dismantle the lateral lid that covers the condenser
5) If it is necessary clean the louvered area with the help of an aspirator with a
brush, non-metallic brush or low-pressure air.
Evaporator / water container
1) Prepare a solution at the 50% of phosphoric acid and distilled water. Do not use
hydrochloric acid. Pour this solution slowly in the top of the evaporator, until it
overflows in the water container. The mixture is more effective with the water
between 35ºC and 40ºC.
2) Leave the solution acting during 10 minutes.
3) Take out the overflow, wait until the water container is empty. Place the
overflow.
4) Close the water inlet.
5) Refill the system until the maximum level of the water container with the same
solution. Connect the machine (the water must be closed) and wait 20 minutes.
6) Open the water, connect the machine.
CAUTION: ** Eliminate the ice manufactured in this first cycle.
NOW THE SANITARY CLEANING STARTS.
6) Connect the machine and once there is no more water entering, remove the
evaporator lid and pour the bleach (one glass) in the same. Wait 20 minutes.
7) Disconnect the machine and connect it again, once the ice has fallen, THROW
it and leave the machine performing the complete cycle.
CAUTION: ** Eliminate the ice manufactured with this procedure.
8) Clean and mount all the components, and check that the louver is clean and
that the ice cubes slide well. Check that in the shield no slat gets blocked.
Review and/or change the water input filters.

9) CHECK THAT THE INJECTORS ARE PROPERLY LOCATED, THAT THE
WATER SPREAD FORMED BY THE INJECTORS ARE UNIFORM AND THAT
ALL OF THEM ARE EQUAL. If possible, disassemble, clean and place in the
correct position.
Ice storage bin cleaning.
1) Disconnect the machine, close the water and empty the ice-cube storage bin.
2) Use a dish cloth with detergent.
3) In case the white lime spots remain, rub them with a soft antilime, wait a few
minutes and use again a dish cloth. Clear with water, dry and start the machine
again.
Exterior Cleaning
Use the same procedure as the one indicated for the ice storage bin.
Collectors and Injectors
1) Remove the shield. (Take the time to clean it with phosphoric acid, clean with
bleach and clear under water).
2) Remove the louver of ice drop. (Clean as done with the shield).
3) PULL THE COLLECTOR UPWARDS. IT IS PRESSURE MOUNTED.
4) Disassemble the injectors and lids, and clean them.
5) Disassemble and clean the main head filter. (IT IS PRESSURE MOUNTED).
6) Assemble the filter, injectors and collector.
CAUTION
IT IS REALLY IMPORTANT THAT WHEN PLACING AGAIN THE COLLECTOR
THE INJECTORS ARE COMPLETELY PERPENDICULAR TO THE SAME, IF IT
IS LEFT BLENDED THE ICE CUBES OF THE EDGES CAN BE LEFT WITHOUT
WATER.

7) Mount the ice cube removal louver. (CAUTION: It must be locked in the back
scaffolds.
8) Mount the shield. Ensure that ALL the slats move freely.
9) Start the machine and THROW THE FIRST BATCH OF ICE.
Cleaning of the Inlet Filters
They are easily obstructed during the first days of operation, MAINLY WITH NEW
PIPING INSTALLATIONS.
Loose the hose and clean it under water.
Water Leak Control
When working on the machine, always check the water connections, status of the
clamps and hoses with the purpose of avoiding leakages and prevent damages or
floods.
Electronic operation
This machine operates by means of the digital electronic controller adapted for ice-
cubes in ITV GALA-DELTA manufactures.
In the front part of the machine we can see the display and the button panel, by
means of which we will access to the different menus, in which we can move to
consult and set up the working values.
