USB Wireless Conference System User Manual
QuickShare
USB Wireless Conference System
User Manual

USB Wireless Conference System User Manual
CONTEN
QuickShare......................................................................................................................................1
Startup Preparation........................................................................................................................4
USB Mirror.......................................................................................................................................5
Phone Mirror ...................................................................................................................................7
WIFI..........................................................................................................................................7
iPhone Mirror...........................................................................................................................8
Android Mirror .........................................................................................................................9
（1）APP Mirror ( Android 5.0+) .................................................................................9
（2）Miracast ...............................................................................................................10
Q & A..............................................................................................................................................12
USB Sender ..........................................................................................................................12
（1）Not Find the USB Display after Connect with Computer..............................12
（2）Receiver Not Found...........................................................................................13
（3）USB Sender Pairing...........................................................................................13
（4）Upgrade USB Sender........................................................................................14
（5）Display Screen Not Full Screen .......................................................................14
Phone Mirror .........................................................................................................................15
（1）Android Phone Not Find Hotspot.....................................................................15
（2）Phone Not found Quickshare ...........................................................................16
（3）Android Mirror without Audio ............................................................................16
（4）iPhone unable to mirror.....................................................................................16

USB Wireless Conference System User Manual
Change Default Screen Saver Pictures ............................................................................16
Change WIFI Hotspot Channel ..........................................................................................17
Change Wallpaper................................................................................................................17
Adjust Display Screen Resolution......................................................................................18
Upgrade App.........................................................................................................................18

USB Wireless Conference System User Manual
Startup Preparation
（1）Bill Of the Material: Quickshare x 1、Antenna x 3、Power x1、USB x 1 or 2ps;
（2）Setup 3ps Antenna on the Quickshare;
Connect the Quickshare with the display screen with the HDMI or VGA cable;
Connect the power cable and turn on the power button;
Wait for 15-20s until the red light on
（3）As following picture:
HDMI Output is: 1080P
SSID, Password, Local IP, Device Name, Password will show on the top of the screen
Setting button is on the low right corner
（4）Connect USB mouse to operate. Left click means confirm, and the right click means
back

USB Wireless Conference System User Manual
（5）Click one of for a seconds and then an App list will come out for
selecting. After select one of App on the list, the selected App will show on the right
bottom corner.
USB Mirror
Connect the USB Sender to the PC without setting;
1.For the First time, need to run the USBDisplay application by double click

USB Wireless Conference System User Manual
it:
2.If run on Windows 10 System, need to close the Windows Defender.
3.USB device will auto start with the flash light for around 12s, once finish launching the
light will not flash, and USBDisplay is ready for screen sharing as follow:
4.Press the button to start mirror screen and press it again to stop mirror;
5.Rigt click the icon which on the right bottom corner of PC, you are able to do
more Mirror setting.
6. Click the mirroring device list, you can designate which machine to mirror or not.

USB Wireless Conference System User Manual
Phone Mirror
WIFI
1.Long press the app icon on the right bottom of the screen and find the System Setting
from the App List;
Connect the Wifi for Quickshare
2.Once Quickshare have connected with Wifi or Ethnet, the mirroring phone can also have
internet access as well. This is one of our Exclusive Function compared with our
competitor (e.g. Barco)

USB Wireless Conference System User Manual
iPhone Mirror
1. Connect to the hotspot of Quickshare for the iPhone
2. Slide up from bottom of the phone, and select “Screen Mirror”
2.Select the Quickshare to Mirror screen
4.Select the “Stop mirror” on the “Screen Mirroring” page to exit mirror

USB Wireless Conference System User Manual
Android Mirror
（1）APP Mirror ( Android 5.0+)
1. Let android phone connect to internet
2. Scan the QR code on the left bottom of the screen and
download the Android client.
3. Install the USBDisplay App
4. Let the phone connect the hotspot of Quickshare
5. Open USBDisplay App on the phone and then select the target
Quickshare to mirror screen.
6. Click Share for Mirror
7.Click OK to enable Bluetooth and Pair them as well
(If Exit/Cancel clicked, then no audio when mirror)

USB Wireless Conference System User Manual
Android Mirror with the audio is our Exclusive Function compared with competitor (e.g.
Barco).
If the Bluetooth permission request is rejected or cancelled, need to turn on it and connect
with Quickshare manually. And then the Mirror will with the audio again.
In the future, once Mirror, the Bluetooth will pair automatically with below message:
If no this message come out, need to pair the Bluetooth again.
（2）Miracast
1.Long press the APP and select the Miracast Receiver from the App List:
