Jøtul Cube 200 GG WS Manual

Monterings- og bruksanvisningen må oppbevares under hele produktets levetid. These instructions must
be kept for future references. Ce manuel doit être conservé pour de futures interventions. Wir empfehlen
Ihnen, die Montage- und Bedienungsanleitung für spätere Zwecke sorgfältig aufzubewahren.
Jøtul Cube 200 / 400 / 500 / 530
Manual Version P02
Jøtul Cube 200 / 400 / 500 / 530
GB - Installation and Operating Instructions 3
FR - Manuel d’installation et d’utilisation 15
ES - Manual de instrucciones 27
IT - Installazione e Istruzioni per l’uso 39
NL - Installatie- en montagehandleiding 51
Jøtul Cube 200 GG
Jøtul Cube 400 GG
Jøtul Cube 500 GG
Jøtul Cube 530 GG
Jøtul Cube 200 GL
Jøtul Cube 400 GL
Jøtul Cube 500 GL
Jøtul Cube 530 GL
Jøtul Cube 200 AG
Jøtul Cube 400 AG
Jøtul Cube 500 AG
Jøtul Cube 530 AG
Jøtul Cube 200 AL
Jøtul Cube 400 AL
Jøtul Cube 500 AL
Jøtul Cube 530 AL

2

3
ENGLISH
1.0 Relationship with the
authorities
Jøtul Cube is a freestanding product with Jøtul I 400 FL,Jøtul I 500
FL or Jøtul I 530 FL as the burn chamber, which can be positioned
against walls at the distances described in Fig. 1a and Fig. 1b.
Installation of the fireplace must be according to local codes and
regulations in each country.All local regulations,including those
that refer to national and European standards,shall be complied
with when installing the product.
Installation instructions for the surround are included.
Installation and user instructions for the insert are enclosed
with the product.
For day-to-day use, maintenance, servicing, etc., please see this
document. The installation may only be used once it has been
inspected and a certificate of completion has been issued.
Prior to using the product the installation must be approved by
a qualified person.
4 name plates of heat-resistant material are enclosed with the
product. The name plate for the chosen combination shall be
placed between the cage and the decor panel (see figure). This
contains information about identification and documentation
for the product.
m.a.b
2.0 Technical Data
Weight, Jøtul Cube 400 GG : Approx. 228 kg
Weight, Jøtul Cube 400 GL : Approx. 256 kg
Weight, Jøtul Cube 400 AG : Approx. 219 kg
Weight, Jøtul Cube 400 AL : Approx. 247 kg
Weight, Jøtul Cube 500 GG : Approx. 250 kg
Weight, Jøtul Cube 500 GL : Approx. 278 kg
Weight, Jøtul Cube 500 AG : Approx. 241 kg
Weight, Jøtul Cube 500 AL : Approx. 269 kg
Weight, Jøtul Cube 530 GG : Approx. 243 kg
Weight, Jøtul Cube 530 GL : Approx. 271 kg
Weight, Jøtul Cube 530 AG : Approx. 234 kg
Weight, Jøtul Cube 530 AL : Approx. 262 kg
Height, w/glass decor : 1178 mm
Height, w/aluminium decor : 1182 mm
Depth, w/glass decor : 485 mm
Depth, m/aluminium decor : 481 mm
Width : 780 mm
Table of contents
1.0 Relationship with the authorities...............3
2.0 Technical data...............................................3
3.0 Safety........................................................... 6
4.0 Mounting......................................................8
5.0 Installation completed............................... 14
6.0 Maintenance .............................................. 14
7.0 Optional equipment .................................. 14
8.0 Warranty..................................................... 14
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number
when contacting your retailer or
Jøtul.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoffen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certificate/
The appliance can be used in a shared flue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Serial no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Efficiency
Klasse II
Classification
Standard
Flue gas temperature
Room heater fired by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC SP
EN
Serial no.

4
ENGLISH
Fig. 1a Jøtul Cube 200 / 400 / 500 / 530
Product: Jøtul Cube 200 / Jøtul Cube 400 / Jøtul Cube 500 / Jøtul Cube 530
Min. measure floorplate X / Y = Acc. to national regulatives and regulations.
Hole in floor for external air - Ø100
Access for external air
* Semi insulated chimney / covered flue pipe down towards the product.
Min. distance to combustible wall.
900112-P00
1253
1178
780
485
400
X
Y
Insert A B Jøtul I 200 FL 247 450 Jøtul I 400 FL 223 433 Jøtul I 500 FL 247 450 Jøtul I 530 FL 245 449
150
150
*50
*50
400
250
*50
A
B
B
Combustible wall

5
ENGLISH
Fig. 1b Jøtul Cube 200 / 400 / 500 / 530
900112-P00
Combustible wall
Firewall
Min. distance to combustible wall protected by approved firewall. External firewall Min. distance to combustible wall protected by approved firewall. Integrated firewall
920
30
30
30 30
30
30 30
30
1120
300
300
1150
1150
1150
1150
1050 1050
1050
1250

6
Technical data for Jøtul I 400 FL according to EN 13229
Nominal heat output: 6,0 kW
Flue gas mass flow: 7,3 g/s
Recommended chimney draught: 12 Pa
Efficiency: 74 %@6,0 kW
CO emission (13% O2): 0,19%
Flue gas temperature: 259 oC
Operational type: Intermittent
Technical data for Jøtul I 500 FL according to EN 13229
Nominal heat output: 9,0 kW
Flue gas mass flow: 8,1 g/s
Recommended chimney draught: 12 Pa
Efficiency: 80%@ 9,9 kW
CO emission (13% O2 ): 0,06 %
Flue gas temperature: 314
o
C
Operational type: Intermittent
Technical data for Jøtul I 530 FL according to EN 13229
Nominal heat output: 9,0 kW
Flue gas mass flow: 8,4 g/s
Recommended chimney draught: 12 Pa
Efficiency: 71%@ 9,0 kW
CO emission (13% O2 ): 0,25 %
Flue gas temperature: 350
o
C
Operational type: Intermittent
3.0 Safety
NB! To guarantee optimal performance and safety, Jøtul stoves
must be fitted by a qualified installer.
Any modifications to the product by the distributor, installer
or consumer may result in the product and safety features not
functioning as intended.The same applies to the installation of
accessories or optional extras not supplied by Jøtul. This may
also be the case if parts that are essential to the functioning
and safety of the fireplace have been disassembled or removed.
In all these cases, the manufacturer is not responsible or liable
for the product and the right to make a complaint becomes null
and void.
3.1 Fire Prevention Measures
There is a certain element of danger every time you use your
fireplace.The following instructions must therefore be followed:
• The minimum safety distances when installing and using the
fireplace are given in fig. 1.
• Ensure that furniture and other flammable materials are not
too close to the fireplace.Flammable materials should not be
placed within 1 metre of the fireplace.
• Allow the fire to burn out. Never extinguish the flames with
water.
• The fireplace becomes hot when lit and may cause burns if
touched.
• Only remove ash when the fireplace is cold. Ash can contain
hot embers and should therefore be placed in a non-
flammable container.
• Ash should be placed outdoors or be emptied in a place where
it will not present a potential fire hazard.
In case of chimney fire:
• Close all hatches and vents.
• Keep the firebox door closed.
• Check the loft and cellar for smoke.
• Call the fire service.
• Before use after a fire an expert must check the fireplace
and the chimney in order to ensure that it is fully functional.
3.2 Foundations
You need to make sure the foundation is suitable for a stove.See
“2.0 Technical data”for specified weight.
Remember: If a steel chimney resting on the burn chamber is
being used, the weight of the steel chimney should be taken
into account.
NB: It is extremely important that the product be stable; the
surface it is installed on must be completely inflexible.
It is recommended that flooring that is not attached to the
foundation – «floating floors» – be removed beneath the product.
3.3 Floor covering
Jøtul Cube has an airtight bottom plate and no extra floor
covering is required beneath the product.
Any floor covering of inflammable material, such as linoleum,
carpets, etc. must be removed from under the product.
3.4 Floor plate
A plate made of steel or some other suitable non-inflammable
metal (optional extra) is placed in front of the hearth.
The floor plate must comply with national laws and regulations.
Contact your local building authorities regarding restrictions and
installation requirements..
3.5 Air supply
There must be a flow of air between the burn chamber and the
surround.This is to ensure that there is not too great a build-up
of heat inside the surround.
NB: It is extremely important that air openings not are covered
up. See Fig. 1a and Fig. 1b for distances.
ENGLISH

7
3.6 Steel chimney
When using semi-insulated chimney: It is extremely important
that the shield is all the way down towards the top ring. (see
figure 2)
Fig. 2
m.a.b
3.7 Ceiling
Make sure the room where the Jøtul Cube is to be placed has a
ceiling height of at least 2300 mm.
3.8 Chimney and flue pipe
• The stove must be connected to a chimney and flue pipe
approved for solid fuel fireplaces with flue gas temperatures
as specified in «2.0 Technical data» in the insert manual.
• The cross-section of the chimney must be at least that of the
flue pipe. To calculate the correct chimney cross section, see
«2.0 Technical data» in the insert manual.
• Several solid fuel products can be connected to the same
chimney system if the chimney cross-section is adequate.
Contact your local building authorities regarding restrictions
and installation requirements.
• Connection to the chimney must be performed in accordance
with the installation instructions of the chimney supplier.
• Make sure that the fluepipe risesall thewayup to thechimney.
• Please note that it is extremely important for connections to
have a degree of flexibility.
For recommended chimney draught, see «2.0 Technical data» in
the insert manual.
3.9 Preparation
NB: Check that there is no visible damage to the product when
you unpack it, and make sure that the control handles move
freely.
The burn chamber is heavy, – make sure it does not topple over
while you are installing it!
Ensure you have help when positioning and installing it.
ENGLISH
The product is supplied together with 3 manuals:
1. General user and maintenance manual
2. Jøtul Cube 200 / 400 / 500 / 530 (surround).
3. Jøtul I 400 FL, Jøtul I 500 FL or Jøtul I 530 FL (burn chamber).
Prior to installation, decide on the following:
1. Where the smoke outlet should be.
2. Position of external air connection if being used.
3. Ash collection system if being used.
Refer to manuals for parts installation instructions.
Reducing the weight of burn chamber and protecting parts
during installation:
Fig. 3
B
E
A
C
D
1. Unpack the insert. Take out the box with contents and,
if necessary, burn plates to make the product lighter.
2. Remove the heat shield (Fig. 3 E).
3. Remove the side burn plates (Fig. 3 A) by lifting them
slightly and pulling out. If they are difficult to remove, use
a screwdriver to draw them up.
4. Then lift the back burn plate out (Fig. 3 B).
Special instructions for the Jøtul I 500 FL:
5. Pull the air chamber (Fig. 3 C) forward while lifting it at the
front edge. Ease it down and take it out through the door
opening. Be careful – it is heavy!
6. Lift the exhaust deflector (Fig.3 D) up at the back edge,push
it slightly backwards.Then lift it down at the front edge,out
through the door opening.

8
4.0 Mounting
Important!
Bear in mind that the parts may be damaged if they are handled
roughly.Installation should be carried out by a qualified person.
Be especially careful in the treatment of the glass panels. Injuries
in the tempered glass will impair its characteristics,and the panel
may explode at the high temperatures it is exposed to.
Fig. 4
Overview of nuts and bolts used during mounting of the product:
M6
M5 x 6
DIN 7982
M5 x 16
M6 x 16
M8 x 10
4.1 Mounting of the cage and the insert
Fig. 5a
m.a.b
Fig. 5b
1
2
m.a.b
1. The 3 legs (Fig. 5b.1) are mounted to the bottom plate with
screws (Fig. 5b.2).
Fig. 6
1
2
m.a.b
1. Mount the adjustable feets (Fig. 6.1).
2. If external air through floor: Remove one of the knockouts
(Fig. 6.2).
ENGLISH

9
Fig. 7
1
m.a.b
1. Place the bottom plate in the correct distanse from the
wall. Min. distanse (Fig. 7.1):
Against combustible wall:61 mm.
Against firewall: 41 mm.
Fig. 8
m.a.b
1
2
!
1. Ensure that the bottom plate (Fig. 8.1) is level by adjusting
the screws (Fig. 8.2).
Fig. 9
1
m.a.b
1. Assemble the air intake cover (Optional: cat.no. 50043352)
with 4 screws (Fig. 9.1).
Fig. 10
1
2
m.a.b
1. Assemble the first level sides and back (Fig. 10.1)
2. Mount the air intake cover (Optional: cat.no. 50043352) on
the back (Fig. 10.2) if this is selected.
Fig. 11
m.a.b
1. Lift the first level on to the bottom plate. Grab the sides
when lifting.
ENGLISH

10
Fig. 12
1
2
H
m.a.b
1. Prepare the insert and adjust its height to 815 mm (Fig.12.H).
Refer the insert manual for instructions.
2. Lift the insert (Fig. 12.1) on to the 3 legs (Fig. 12.2).
Fig. 13
2
1
m.a.b
1. Mount the first level front (Fig. 13.1).
2. Assemble the second level sides and back
(Fig. 13.2) and place it on the first level.
Fig. 14
1
m.a.b
1. Mount second level front (Fig. 14.1).
ENGLISH
