Jabra BT2090 User manual

User manual
www.jabra.com
Jabra BT2090
j
a
br
a

1
ENGLISH
JABRA BT2080
CONTENTS
THANKYOU....................................................2
ABOUTYOURJABRABT2090...................................2
WHATYOURHEADSETCANDO................................3
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHARGEYOURHEADSET.......................................4
TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . 4
PAIRINGITWITHYOURPHONE.................................4
CONNECTING WITH YOUR PHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
WEARITHOWYOULIKEIT.....................................6
HOWTO .......................................................6
HOW THE STATUSDISPLAY™ WORKS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
TROUBLESHOOTING&FAQ ....................................8
NEEDMOREHELP?.............................................9
TAKING CARE OF YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
WARNING!....................................................10
SAFETYINFORMATION!.......................................11
BUILT BATTERYCARE:......................................11
CHARGERCARE: ..............................................12
WARRANTY...................................................13
CERTIFICATION ...............................................15
GLOSSARY....................................................16

2
ENGLISH
JABRA BT2090
THANK YOU
Thank you for purchasing the Jabra BT2090 Bluetooth® headset.
We hope you enjoy it! This instruction manual will get you started
and ready to make the most of your headset.
ABOUT YOUR JABRA BT2090
A. Answer/end button
B.
C. StatusDisplayTM
With battery indicator and Bluetooth connection indicator
D. Charging socket
E. Volume up/down
F. Ear hook
F
E
C
B
A
D
j
a
b
ra

3
ENGLISH
JABRA BT2090
WHAT YOUR HEADSET CAN DO
Your Jabra BT2090 lets you do all this:
- Answer calls
- End calls
- See battery status
- See Bluetooth connection status
- Reject calls*
- Voice dialling*
- Last number redial*
- Mute
- Transfer calls
- Adjust volume
- Talk time 6 hours
- Standby time 8 days
- B .1 with EDR and eSCO
- Weight 8 gram
- Operating range up to 10 meters (approximately 33 feet)
- Supported B
- Internal rechargeable battery charged by wall charger
- Always see your battery and connection status on the
Jabra StatusDisplay™
GETTING STARTED
You should follow three steps before using your headset
1 Charge your headset
2 Activate Bluetooth on your mobile phone (refer to the
manual for your mobile phone)
3 Pair your headset to your mobile phone
The Jabra BT2090 is easy to operate. The answer/end button on
you press it.

4
ENGLISH
JABRA BT2090
Instruction Duration of press
Tap
Press Approx: 1 second
Press and hold Approx: 5 seconds
CHARGE YOUR HEADSET
Make sure that your headset is fully charged for two hours before
you start using it. Use the AC power supply to charge from a
power socket. When the battery indicator has a solid red light,
your headset is charging. When the headset is fully charged the
.
Use only the charger provided in the box - do not use chargers
from any other devices as this may damage your headset.
Please note: T
if your device is left uncharged for a long period. We therefore
recommend that you recharge your device at least once a month.
TURNING YOUR HEADSET ON AND OFF
Slide the switch to the 'I' position to power on, and to the 'O' position
to power o.
PAIRING IT WITH YOUR PHONE
Headsets are connected to phones using a procedure called
‘pairing’. By following a few simple steps, a phone can be paired
with a headset in a matter of minutes.
1 Put the headset in pairing mode
- When you turn on your Jabra BT
headset will automatically start up on pairing mode – i.e. it is
discoverable for your phone. When the headset is in pairing
mode the Bluetooth status indication on the StatusDisplay™ is
.
9

5
ENGLISH
JABRA BT2090
2 Set your Bluetooth phone to‘discover’ the Jabra BT2090
- Follow your phone’s instruction guide. First make sure that
Bluetooth is activated on your mobile phone. Then set your
phone to discover new devices. This usually involves going
to a‘setup,’‘connect’ or‘Bluetooth’ menu on your phone and
selecting the option to ‘discover’or ‘add’ a Bluetooth device.*
3
- BT2090”.
Your phone then asks if you want to pair with the headset.
Accept by pressing‘Yes’or ‘OK’ on the phone. You may be asked
. Then use 0000 (4 zeros). Your
Bluetooth
light to steady light.
CONNECTIVITY
SELECT
MobilSurf
BLUETOOTH
Infrared port
Wap options
Synchronization
Networks
DEVICES FOUND
Jabra BT2090
Jabra BT2090
OK
Passkey:
****
HANDSFREE
SELECT
Jabra BT2090
added.
The handsfree is
now ready for use
SELECT
Manual pairing mode
pairing process was interrupted, you can manually set the headset
to pairing mode.
Make sure the headset is on. Press and hold the answer/end
button for approximately 5 seconds until the Bluetooth icon turns
. Then repeat steps 2 and 3 in
the above pairing guide.
CONNECTING WITH YOUR PHONE
used together. When the headset and phone have been paired
once, they will automatically connect when the headset is on and
Bluetooth is activated on the phone. The headset can be used
when it is“connected” to the phone. If the devices are paired, but
do not immediately connect, tap the answer/end button. When
your headset is connected the Bluetooth connection icon in the
StatusDisplay™ will be constant on for 3 seconds.
9

6
ENGLISH
JABRA BT2090
WEAR IT HOW YOU LIKE IT
The Jabra BT2090 can be worn on either ear with or without
earhook. Simply remove the earhook if you prefer this wearing
your preference.
HOW TO
Answer a call
- Tap (less than 1 sec) the answer/end button on your headset to
answer a call.
End a call
- Tap the answer/end button to end an active call.
Reject a call*
- Press (approx 1 sec) the answer/end button when the phone
rings to reject an incoming call. Depending on your phone
settings, the person who called you will either be forwarded to
your voice mail or will hear a busy signal.
Make a call
- When you make a call from your mobile phone, the call will
(subject to phone settings) automatically transfer to your
headset. If your phone does not allow this feature, tap on the
Jabra BT2090’s answer/end button to transfer the call to the
headset. Press answer/end button and volume up button at the
same time, you can transfer the call back to phone.
Activate voice dialling*
- Press the answer/end button. For best results, record the voice
dialling tag through your headset. Please consult your phone’s
user manual for more information about using this feature.
Redial last number*
- Double tap the answer/end button when the headset is
connected to your phone.
Adjust sound and volume*
- Tap the volume up or down to adjust the volume.

7
ENGLISH
JABRA BT2090
Mute/un-mute
- To mute, press both volume up and down at the same time.
A low beep alert plays during a muted call.
- To un-mute, tap either of the volume buttons.
Call waiting and placing a call on hold*
- This lets you put a call on hold during a conversation and
answer a waiting call.
- Press the answer/end button once to put the active call on hold
and answer the waiting call.
- Press the answer/end button to switch between the two calls.
- Tap the answer/end button to end the active conversation.
HOW THE STATUSDISPLAY™ WORKS
Bluetooth
Indicator
Indicates if your headset is connected to your
phone
- Solid light means headset is connected to your
phone
- Flashing light means headset is in ‘pairing
mode’and ready to be connected to a new
phone
Battery
Indicator
Indicates battery level and if headset is
turned ON
- Green light indicates that the headset has more
than 10 minutes of talk time remaining
- Red light indicates that the headset has less
than 10 minutes of talk time remaining
T.
Get an instant status from the Jabra StatusDisplay™ by a tap on
any button on the headset when you are not on a call.

8
ENGLISH
JABRA BT2090
TROUBLESHOOTING & FAQ
I hear crackling noises
- Bluetooth is a radio technology, which means it is sensitive to
objects between the headset and the connected device. It is
designed for the headset and the connected device to be used
within 33 feet (10 meters) of each other, with no major objects
in the way (walls, etc.).
I cannot hear anything in my headset
- Increase the volume in the headset.
- Ensure that the headset is paired to the device that you wish to use.
- Make sure your phone is connected to the headset by tapping
the Answer/End button. See the Jabra StatusDisplay™.
I am having pairing problems
- You may have deleted your headset pairing connection in your
mobile phone.
Follow the pairing instructions.
I want to reset the headset
It is possible to reset and test the headset by ’Press and hold’the
volume down and answer/end buttons at the same time. In the
StatusDisplayTM the battery icon and B
simultaneously. In this mode, the pairing list is reset, and you can
test if the headset works as you will be able to hear audio in the
speaker from the microphone.
T. 10 seconds.
The next time you power on, the headset will go into pairing
BT2090 on.
Will the Jabra BT2090 work with other Bluetooth equipment?
- The Jabra BT2090 is designed to work with Bluetooth mobile
phones. It can also work with other Bluetooth devices that are
compliant with Bluetooth version 1.1 or higher and support a
.
I cannot use Reject call, call on hold, Redial or voice dialling
These features are dependent on the ability of your phone to
.
implemented reject call, call hold and voice dialling are optional
features which are not supported by all devices. Please consult
your device manual for details.

9
ENGLISH
JABRA BT2090
NEED MORE HELP?
1. Web: www.jabra.com
(for the latest support info and online User Manuals)
2. E-mail:
Deutsch suppor[email protected]om
English suppor[email protected]om
Español suppor[email protected]om
Français [email protected]
Italiano suppor[email protected]
Nederlands suppor[email protected]om
Polska suppor[email protected]
Scandinavian [e-mail]
Россия [email protected]
Information: [e-mail]
3. Phone:
Belgique/Belgie 00800 722 52272
Danmark 702 52272
Deutschland 0800 1826756
Die Schweiz 00800 722 52272
España 900 984572
France 0800 900325
Italia 800 786532
Luxembourg 00800 722 52272
Nederland 0800 0223039
Norge 800 61272
Österreich 00800 722 52272
Polska 0801 800 550
Portugal 00800 722 52272
Suomi 00800 722 52272
Sverige 020792522
United Kingdom 0800 0327026
Россия [phone]
International 00800 722 52272
