Jabra GO 6470 Installation and user guide

How to connect my Jabra PRO / GO with Alcatel IP Touch
4028, 4038, 4068
Jabra GO 6470
Requirements:
Jabra LINK 14201-36
To connect your headset please follow these steps:
1. On the 2-sided end, plug the RJ45 connector (red band) in the red socket
marked AUX on the Jabra device base.
2. Plug the RJ10 connector (blue band) into the blue socket marked with
the phone symbol on the Jabra device base.
3. For the 2-fold Y coupling end, plug the 3.5 mm phone connector into
the headset interface.
4. Plug the RJ12 connector into the socket marked by a bell on the phone.
(The additional socket on the Y-coupling remains free to connect to an IP
device.
5. Then follow the instructions on the Jabra device touch-screen:
a. Select Phone settings.
b. Select Connect desk phone.
c. Select Manual.
06/04/2021 16:25
https://www.jabra.ca/supportpages/jabra-go-6470/6470-15-207-505/faq/63cea1ea-94dc-
4d4e-88b3-86766af1b3f4
Page 1 of 4

d. Select adapter type MSH.
6. For the base settings on the phone:
a. Set the phone set-up switch to position A.
06/04/2021 16:25
https://www.jabra.ca/supportpages/jabra-go-6470/6470-15-207-505/faq/63cea1ea-94dc-
4d4e-88b3-86766af1b3f4
Page 2 of 4

b.We recommend the microphone volume to be set to 7 out of 13
Guided setup:
As a part of the installation, you can dial into your local Jabra Setup server
which will configure the audio path. Please follow the instructions shown
on the display. If your Jabra Setup server is unavailable, please contact
your local Jabra Support team.
Phone settings with device software version 9.xx and higher:
Phone settings are no longer required. Once the phone connector has
been inserted correctly, a headset symbol should appear in the “phone”
display. If the headset symbol does not appear, please check the following
settings:
Menu>Settings>Phone>Phone connector>Activate/select headset
Phone settings with device software version lower than 9.xx:
Please note that the “Force Headset” function must not be activated on
the device as this will prevent you from accepting external calls.
Menu>Settings>Phone>Phone connector>Force headset OFF
Menu>Settings>Phone>Socket>Activate headset
Ringtone signal / phone settings:
Please note that the ring tone signal ont eh headset will only be
06/04/2021 16:25
https://www.jabra.ca/supportpages/jabra-go-6470/6470-15-207-505/faq/63cea1ea-94dc-
4d4e-88b3-86766af1b3f4
Page 3 of 4

transferred if one of the following ringtones has been selected:
Standard / Classic / Cold River / Dooing-Dooing
(Select ringtone from Menu>Settings>Ringtone>Internal/External)
If you have set the correct ringtone and you still do not have a ringtone
signal, check the following settings:
Menu>Settings>Phone>Internal/External>additional optionsThe following
options need to be set to “OFF”: No tone, Progressive, Beeps.
Calls using the headset can be connected/transferred as follows:
1. Dial the phone number
2. “Transfer” will now appear on the phone display
3. Press the associated function button next to the phone display
4. End the conversation using the button marked, “Headset”
