Jabra JX10 - MANUAL 2 User manual

2
Jabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
3
Jabra JX10 Bluetooth headsetJabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
English
Thankyou.................................................................................... 4
AboutyourJabraJX10........................................................................ 5
Whatyournewheadsetcando................................................................ 6
Gettingstarted ............................................................................... 6
Chargeyourheadset.......................................................................... 7
Turningyourheadsetonandoff…............................................................ 7
Pairitwithyourphone........................................................................ 7
Wearithowyoulikeit......................................................................... 7
Howto........................................................................................ 8
Whatthelightsmean......................................................................... 9
UsingJabraJX10with2mobilesphones....................................................... 9
UsingaBluetooothHub....................................................................... 9
Troubleshooting&FAQ......................................................................10
Need more help?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Takingcareofyourheadset..................................................................10
ServiceandWarrantyinformation............................................................11
Certificationandsafetyapprovals ............................................................12
Glossary.....................................................................................12

4
Jabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
5
Jabra JX10 Bluetooth headsetJabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
Thank you
Thank you for purchasing the Jabra JX10 Bluetooth® Headset. We hope you enjoy it! This
instruction manual will get you started and ready to make the most of your headset.
WARNING!
Headsets are capable of delivering sounds at loud volumes and high pitched tones. Exposure
to such sounds can result in permanent hearing loss damage. The volume level may vary based
on conditions such as the phone you are using, its reception and volume settings, and the
environment. Please read the safety guidelines below prior to using this headset.
Safety guidelines
1. Prior to using this product follow these steps:
• before putting on the headset, turn the volume control to its lowest level,
• put the headset on, and then
• slowly adjust the volume control to a comfortable level.
2. During the use of this product
• Keep the volume at the lowest level possible and avoid using the headset in noisy
environments where you may be inclined to turn up the volume;
• If increased volume is necessary, adjust the volume control slowly;
and
• If you experience discomfort or ringing in your ears, immediately discontinue using
the headset and consult a physician.
With continued use at high volume, your ears may become accustomed to the sound level,
which may result in permanent damage to your hearing without any noticeable discomfort.
Using the headset while operating a motor vehicle, motorcycle, watercraft or bicycle may be
dangerous, and is illegal in some jurisdictions.
Check your local laws. Use caution while using your headset when you are engaging in any
activity that requires your full attention. While engaging in any such activity, removing the
headset from your ear area or turning off your headset will keep you from being distracted, so
as to avoid accident or injury.
Keep out of reach of children: The plastic bags the product and its parts are wrapped in
are not toys for children. The bags themselves or the many small parts they con¬tain may
cause choking if ingested. Never try to dismantle the prod¬uct yourself. None of the internal
components can be replaced or repaired by users.
Only authorised dealers or service centres may open the product. If any parts of your product
require replacement for any reason, including normal wear and tear or breakage, contact your
dealer.
Avoid exposing the product to rain or other liquids.
Dispose of the product according to local standardsand regulations.
www.gnnetcom.com/weee
ACA TS028 – Ignition of flammable atmospheres
Do not use the Headset in environments where there is a danger of ignition of flammable gases.
About your Jabra JX10
1. LED light
• Blue indicates mode (pairing, active or standby)
• Red/green indicates battery level (low, charging, or charged)
2. Volume up (+), volume down (-)
3. Charging socket
4. Pairing button – press to put headset
into pairing mode
5. Answer/end button
• Press to turn headset on
(blue flash burst indicates success)
• Press and hold to turn headset off
(blue flash burst indicates success)
• Tap to answer or end a call

Instruction: Duration of press
Tap Press briefly
Double Tab 2 quickly repeated Taps
Press Approx: 1 second
Press and hold Approx: More than 3 seconds
6
Jabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
7
Jabra JX10 Bluetooth headsetJabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
What your headset can do
Your Jabra JX10 lets you do all this (dependent on your phone supporting the function:
•Answer calls
•End calls
•Reject calls*
•Voice dialling*
•Last number redialling*
•Call waiting*
•Put call on hold*
• Multi-point
* Phone dependent
Specifications
• Up to 6 hours talk time/standby time up to 200 hours
• Rechargeable battery with charging option from AC power supply, PC via USB cable,
desktop charger or car charger
•Less than 17 grams
• Operating range up to 10 metres (approx. 33 feet)
•Headset and hands-free Bluetooth profiles
•Bluetooth specification (see glossary) version 2.0
GETTING STARTED
The Jabra JX10 is easy to operate. The answer/end button on the headset performs different
functions depending on how long you press it.
4
3
2
When the LED is green, it is fully charged.
Charge from your desktop holder
Connect your USB cable/AC power adaptor to the desktop holder. Place your JX10 in the cradle
as shown in fig. 3
Please note: The lifetime of the battery will be significantly reduced if your device is left
uncharged for a long period. We therefore recommend that you recharge your device at least
once a month.”
Turning your headset on and off
• Press the answer/end button to turn on your headset.
• Press and hold the answer/end button to turn off your headset.
Pair it with your phone
Before you use your Jabra JX10, you need to pair it with your mobile phone.
1. Put the headset in pairing mode
• Make sure the headset is on.
• Press the pairing button marked .
2. Set your Bluetooth phone to ‘discover’ the Jabra JX10
Follow your phone’s instruction guide. This usually involves going to a ‘setup,’ ‘connect’ or
‘Bluetooth’ menu on your phone and selecting the option to ‘discover’ or ‘add’ a Bluetooth
device. * (See example from a typical mobile phone in fig. 6).
3. Your phone will find the Jabra JX10
Your phone then asks if you want to pair with it. Accept by pressing ‘Yes’ or ‘OK’ on the phone
and confirm with the passkey or PIN = 0000 (4 zeros). Your phone will confirm when pairing is
complete. In case of unsuccessful pairing, repeat steps 1 to 3.
Wear it how you like it
The Jabra JX10 is ready to wear on your right ear. If you prefer the left, gently remove the
earhook and rotate to fit left ear. (See fig. 4)
Make sure that your Jabra JX10 headset is fully charged before you start using it. Use the AC
adaptor to charge from a power socket, or charge directly from your PC with the USB cable
provided. Connect your headset as shown in fig. 2. When the LED is solid red, your headset is
charging.
1
Charge your headset

8
Jabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
9
Jabra JX10 Bluetooth headsetJabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
5
How to…
Answer a call
• Tap the answer/end button on your headset to answer a call.
End a call
• Tap the answer/end button to end an active call.
Make a call
• When you make a call from your mobile phone, the call will (subject to phone settings)
automatically transfer to your headset. If your phone does not allow this feature, tap on
the Jabra JX10’s answer/end button to transfer the call to the headset.
Reject a call*
• Press the answer/end button when the phone rings to reject an incoming call.
Depending on your phone settings, the person who called you will either be forwarded
to your voice mail or hear a busy signal.
Activate voice dialling*
• Press the answer/end button. For best results, record the voice-dialling tag through your
headset.
Please consult your phone’s user manual for more information about using this feature.
Redial last number*
• Double Tap the answer/end button when the headset is on and not used.
Adjust sound and volume
• Press the volume up or down (+ or -) to adjust the volume. (Show fig 1).
Call waiting and placing a call on hold*
This lets you put a call on hold during a conversation and answer a waiting call.
• Press the answer/end button once to put the active call on hold and answer the waiting
call.
• Press the answer/end button to switch between the two calls.
• Tap the answer/end button to end the active conversation.
* Functions marked with * are dependent on your phone supporting these
features.
Check your phone’s user manual for further information.
What does this mean about your headset
Flashing every second: active on a call
Flashing every three seconds: in standby mode
Running low on battery
Charging
Fully charged
In pairing mode – see section 3
What you see
Flashing blue light
Flashing blue light
Flashing red light
Solid red light
Solid green light
Solid blue light
6
What the light means
Jabra JX10 is capable of having two mobile phones connected to the headset at the same time.
This will give you the freedom of having only one headset to operate both your mobile phones
and the operation of the functions in the headset functions as described in section 5.
Only it must observed that Last Number Redial will dial the number from the last outgoing call,
independent of the mobile phones, and the Voice Dialling function only will work on the last
paired mobile phone.
The Jabra JX10 can used along with the Jabra Bluetooth Hub (sold separately). This will enable
you to use the headset with both your mobile phone and your office phone.
To pair the Jabra JX10 with the Jabra Bluetooth Hub
The pairing process is a little different:
• Put your Jabra JX10 in pairing mode
• Put the Jabra JX10 in pairing mode.
• Place them close together. You do not need a dedicated pin code to pair
the two Jabra products. Consult the Jabra Bluetooth Hub user manual for
more information on how to connect the Bluetooth hub to your office phone.
The use of the Jabra JX10 with the Jabra Bluetooth Hub is very similar to using the headset with
a mobile phone only. The only difference lies in the transfer of a call to the headset from the
office phone.
Transfer the call to the headset
• Tap the answer/end button to transfer the call from the office phone to the
headset via the Jabra Bluetooth Hub
The answering of a call from the office phone requires a hook lifter in order to have the Jabra
JX10 answer the call automatically.
7
Using Jabra JX10 with 2 mobile phones
8
Using a Jabra Bluetooth Hub

10
Jabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
11
Jabra JX10 Bluetooth headsetJabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
I hear crackling noises
For the best audio quality, always wear your headset on the same side of the body as your
mobile phone.
I cannot hear anything in my headset
• Increase the volume on the headset.
• Ensure that the headset is paired with the phone.
• Make sure that the phone is connected to the headset – if it does not connect either
from the phone’s Bluetooth menu or by tapping the answer/end button, follow the
pairing procedure (see section 3).
I have pairing problems even though my phone indicates otherwise
You may have deleted your headset pairing connection in your mobile phone.
Follow the pairing instructions in section 3.
Will the Jabra JX10 work with other Bluetooth equipment?
The Jabra JX10 is designed to work with Bluetooth mobile phones. It can also work with
other Bluetooth devices that are compliant with Bluetooth version 1.1 or 1.2 and support a
headset and/or hands-free profile..
See the inside cover for your country’s support details.
9
Troubleshooting & FAQ
10
Need more help?
• Always store the Jabra JX10 with the power off and safely protected.
• Avoid storage at extreme temperatures (above 45°C/113°F – including direct sunlight
– or below -10°C/14°F). This can shorten battery life and may affect operation. High
temperatures may also degrade performance.
• Do not expose the Jabra JX10 to rain or other liquids.
11
Taking care of your headset
Limited one-Year Warranty
GN Netcom AS (“GN”), warrants this product to be free from defects in materials and
workmanship (subject to the terms set forth below) for a period of one (1) year from the date
of purchase (“Warrenty Period”). During the Warranty Period, GN will repair or replace (at GN’s
discretion) this product or any defective parts (“Warrenty Service”). If repair or replacement is
not commercially practicable or cannot be timely made, GN may choose to refund to you the
purchase price paid for the affected product. Repair or replacement under the terms of this
warranty does not give right to any extension or a new be-ginning of the period of warranty.
Claims under the Warranty
To obtain Warranty Service, please contact the GN dealer from which you purchased this
product or visit www.gnnetcom.com or www.jabra.com for further information about
customer support.
You will need to return this Product to the dealer or ship it to the dealer or to GN (if so
indicated on www.gnnetcom.com or www.jabra.com) in either its original packaging or
packaging affording an equal degree of protection.
You will bear the cost of shipping the product to GN. If the Product is covered by the warranty,
GN will bear the cost of shipping product back to you after the completion of service under this
warranty. Return shipping will be charged to you for products not covered by the warranty or
requiring no warranty repair.
The Following information must be presented to obtain Warranty Service: (a) the product,
and (b) proof of purchase, which clearly indicates the name and address of the seller, the date
of purchase and the product type, which is evidence that this product is within the Warranty
Period. Please further include (c) your return address. (d) daytime telephone number, and (e)
reason for return.
As part of GN/Jabra’s efforts to reduce environmental waste you understand that the product
may consist of reconditioned equipment that contains used components, some of which have
been reworked. The used components all live up to GN/Jabra’s high quality standards and
comply with the GN product performance and reliability specifications. You understand that
replaced parts or components will become the property of GN.
Limitation of Warranty
This warranty is only valid for the original purchaser and will automatically terminate prior
to expiration if this product is sold or otherwise transferred to another party. The warranty
provided by GN in this statement applies only to products purchased for use, and not for resale.
It does not apply to open box purchases, which are sold “as is” and without any warranty.
Specifically exempt from warranty are limited-life consumable components subject to normal
wear and tear, such as microphone windscreens, ear cushions, modular plugs, ear tips,
decorative finishes, batteries, and other accessories.
This warranty is invalid if the factory-applied serial number, date code label, or product label
has been altered or removed from this product.
12
Service and Warranty Information

12
Jabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
13
Jabra JX10 Bluetooth headsetJabra JX10 Bluetooth headset
UK
CN
CN
JP
KR
MA
TH
This Warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence,
Acts of Nature, accident, disassembling or modification of, or to any part of, the product. This
Warranty does not cover damage due to improper operation, maintenance or installation,
or attempted repair by anyone other than GN or a GN dealer which is authorized to do GN
warranty work. Any unauthorized repairs will void this warranty.
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WARRANTY ARE THE EXCLUSIVE
REMEDY OF THE CONSUMER. GN SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE AND IN
LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING BUT NOT
LIMITED TO THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL PURPOSE.
NOTE! This warranty gives you specific legal rights. You may have other rights which vary from
location to location. Some jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages or implied warranties, so the above exclusions may not apply to you.
This warranty does not affect your legal (statutory) rights under your applicable national or
local laws.
CE
This product is CE marked according to the provisions of the R & TTE Directive (99/5/EC).
Hereby, GN Netcom, declares that this product is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC. For further information please consult
http://www.jabra.com. Within the EU this device is intended to be used in Austria, Belgium,
Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland,
Italy, Latvia, Lithuania, Luxembourg, Malta, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden,
The Netherlands, United Kingdom, and within EFTA in Iceland, Norway and
Switzerland
Bluetooth
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such
marks by GN Netcom is under license. Other trademarks and trade names are those of their
respective owners.
1 Bluetooth is a radio technology that connects devices, such as mobile phones and
headsets, without wires or cords over a short distance (approx. 30 feet). Get more
information at www.bluetooth.com.
2 Bluetooth profiles are the different ways that Bluetooth devices communicate with other
devices.
Bluetooth phones support either the headset profile, the hands-free profile or both.
In order to support a certain profile, a phone manufacturer must implement certain
mandatory features within the phone’s software.
14
Glossary
13
Certification and safety approvals
3 Pairing creates a unique and encrypted link between two Bluetooth devices and lets them
communicate with each other. Bluetooth devices will not work if the devices have not
been paired.
4 Passkey or PIN is a code that you enter on your mobile phone to pair it with your
Jabra JX10. This makes your phone and the Jabra JX10 recognize each other and
automatically work together.
5 Standby mode is when the Jabra JX10 is passively waiting for a call. When you ‘end’ a call
on your mobile phone, the headset goes into standby mode.
Dispose of the product according
to local standards and regulations.
www.jabra.com/weee
