Jackson Airmax+ Installation instructions

Airmax+®
User Instruction for Airmax+®Powered Air
Purifying Respirator
Instructions d’utilisation du système de protection
respiratoire à épuration d’air motorisé Airmax
Bedienungsanleitung für das Airmax+®
gebläsegestützte Atemschutzsystem
Manuale di istruzioni per gli utenti del sistema di
respirazione assistita Airmax+®
Manual de instrucciones para el usuario del
sistema respiratorio Airmax+®
EN 12941:1998+A1:2003+A2:2008 TH3
g
e
f
i
s

IMPORTANT NOTICE
Please read these instrucons carefully before unpacking your JACKSON SAFETY®
AIRMAX+ ® PAPR. Failure to comply with the
instrucons in this leaet may void your limited product warranty and adversely aect
your health and safety.
The selecon of this respiratory for the applicaon should be the result of the risk
assessment conducted by a professional health and safety ocer. Its use should be
strictly in accordance to the instrucons provided along with the product. If you have
any quesons regarding the suitability of this product for your assigned task, please
contact your designated health and safety ocer or use our dedicated technical help
line for further support.
The use of this system is limited to the product variants indicated in this packaging. Any
alteraon made to adapt to other protecve devices may end up aecng the health
and safety of the wearer.
CONTENT
• This JACKSON SAFETY® AIRMAX+ ® powered respirator system should include:
• Blower Unit and PRSL Filter
• Waist belt
• Welding helmet head top (welding helmet and hood/head gear) unit or grinding
(visor and hood) unit
• Hose and hose cover assembly
• Baery charger
• Lithium-ion baery
• Instrucon Manual
• Flow-Test-Unit
SYSTEM OVERVIEW
JACKSON SAFETY® AIRMAX +® has been designed and manufactured to comply with EN
12941:1998+A1:2003+A2:2008 TH3 P R SL.
This powered air purifying respirator is belt mounted and provided with a high eciency
SL replaceable lter canister that provides a ltraon eciency level above 99.8%. The
respiratory system will provide a Nominal Protecon Factor (NFP) of 500 when used in
conjuncon with an original JACKSON SAFETY® AIRMAX+® parculate lter CE marked as
EN 12941:1998+A1:2003+A2:2008 TH3 P R SL.
The blower (4 cells baery pack) weights 900gr at a minimum ow rate of 170LPM for
at least 8 hours at a comfortable noise intensity of <70 dB. Lithium-ion baeries can be
recharged mulple mes and nally replaced at the end of their lifeme, they should be
fully charged at the beginning of the working shi.
2
e

The blower unit incorporates a number of safety measures to avoid the inadvertently
change in the ow condions that include:
•The device has an audible alarm to indicate a blocked lter or low baery
•The device alarm acvates for about 1 second when the blower unit is switched on,
and deacvates once the minimum operaonal ow rate is achieved. Please consider
the power-o state an abnormal situaon while in use
•The switch for the air supply is recessed and so not possible to switch the air supply
o inadvertently
A Flow-Test-Unit is provided along with every AIRMAX+® PAPR unit to verify the right air
ow supply condions. Please follow the instrucons and recommendaons provided in
this manual.
EN REGULATORY COMPLIANCE AND CE MARKS
P R SL-Filter AIRMAX: Product code 40302
Filter colour coding: White (background)
EU Manufacturer Surewerx USA Inc
Elgin IL USA 60123
Compliance EN
2941:1998+A1:2003+A2:2008
TH3 P R SL
Module B Audit conducted by APAVE SUDEUROPE SAS
Noed Body 0082
CS60193 13322 MARSEILLE
CEDEX 16
France
Module C2 APAVE SUDEUROPE SAS
Noed Body 0082
CS60193 13322 MARSEILLE
CEDEX 16
CE marks See labels on product
components
3
12941:1998+A1:2003+A2:2008

WARNINGS AND LIMITATIONS OF USE
•This PAPR is not suitable for work in poorly venlated areas (i.e. conned spaces)
where oxygen level is suspected to be below 17%.
•Determinaon of the use of this PAPR system should be addressed by a trained
health and safety ocer that determines the suitability of the protecon oered by
this device for the parcular task and the hazards involved.
•Do not use this respiratory device when the concentraon of hazardous substances
has not been determined and their impact on human health and safety by a trained
health and safety ocer.
•The wearer of this respiratory system must have read this manual and fully
understood the funcons and sengs on the AIRMAX+® PAPR system. Its use,
cleaning, maintenance, disinfecon and storage condions should follow the
instrucons provided in this manual. Products returned for warranty replacement
will only be considered for replacement only if all recommendaons provided in this
manual were fully followed.
•Do not use the AIRMAX+® PAPR system in areas were explosions might occur. Avoid
direct exposure to ames and/or sparks. Do not use the AIRMAX+® PAPR system in
the presence of strong winds.
•Use only original lters cered for EN 12941:1998+A1:2003+A2:2008 TH3 P R SL
the parcular respiratory system.
•If the blower unit acousc alarm sounds please leave immediately the working area
and enter a non-contaminated environment.
•Do not store nor use this respiratory system under temperature condions that
exceed recommendaons of this manual (below -5°C and above +55°C).
•Parcle lters are not suitable to provide protecon against gases and vapours
above occupaonal exposure limits. Please use TH3 P R SL lters packed in original
packaging only, unsealed or second-hand products must not be used.
•Carefully review the sealing gasket and search for any visible damage. Do not use
if its serviceability is suspected to be aected. Only use parcle lters produced by
Surewerx USA Inc properly labelled and packed.
•Do not aempt to touch or modify the components of this PAPR.
•At very high work rates the pressure in the device may become negave at peak
inhalaon ow.
•JACKSON SAFETY® AIRMAX+® PAPR systems are for use only by competent, trained
personnel.
•Make sure that the air hose doesn`t make a loop and does not get caught up on
something in the work environment.
•Filters shall not be ed directly to the helmet / hood.
•Do not allow water or other liquids to enter the blower unit.
•When the blower unit is switched o lile or no respiratory protecon is to be
expected. When the blower unit is switched o a rapid build up of carbon dioxide
and depleon of oxygen within the head unit may occur.
4

• Evacuate the contaminated area in any of the alarms is detected, any part of the
product becomes damaged or a considerable change in the air ow or smell is
detected. You should also leave the area if you feel dizziness, discomfort or diculty
in breathing.
APPLICATION GUIDELINES
AIRMAX +® PAPR can be eecvely used, but is not limited, to protect the wearer in
mulple tasks in the following areas of use
General industrial
applicaons
GRP manufacture Ship construcon and
maintenance
Agriculture Mining Metal transformaon
industry
Construcon and
demolion
Metal foundries Waste disposal
Chemical plants Paint spraying
(water based)
General welding
General
maintenance
Pharmaceucal DIY
Food processing Pest control Tunnelling and
quarrying
Mining Water and sewage
treatment
Texles manufacture
SYSTEM ASSEMBLY
①②③④
⑥
⑤
⑬
⑨
⑩
⑫
⑦
⑧
⑪
5

AIRMAX +®PAPRwithPAPRWeldingHeadTopUnit
Item Descripon Part code
1TL355 Shell with Face Seal & Airduct 40100
1TL455 Shell with Face Seal & Airduct 40101
1TL455HH Shell & Hard Hat with Face Seal & Airduct 40102
1TL555 Shell with Face Seal & Airduct 40103
2TL355 PAPR Face Seal 40200
2TL455 PAPR Face Seal 40201
2TL455HH PAPR Face Seal 40202
2TL555 PAPR Face Seal 40203
3 Headgear 20692
4Sweat band 32187
5 Cover Sleeve for PAPR Hose 40330
6 Airmax Systems PAPR Hose w Cover Sleeve, 1050mm 40341
7 Airmax+ PAPR IP54 Blower Unit 40381
8 Airmax+ Welding HEPA PAPR Filter (EU) 40302
9Airmax+ Replacement Pre-Filters - pack of 10 40311
10 Airmax+ Replacement Carbon Filters - pack of 10 40312
11 Airmax+ PAPR Baery Charger 40363
12 Airmax+ PAPR 4 Cell Baery 40353
12 Airmax+ PAPR 6 Cell Baery 40351
13 Airmax+ PAPR Waist Belt 40371
13 Washable/Disposable Belt 40372
INITIAL ADJUSTMENT
• Put the belt around the waist and faster the two ends together
• If the belt is too loose, slide the male adjuster down the belt, towards the female half.
If the belt is too ght, slide the male adjuster away from the female half.
• Repeat the above processes unl a comfortable and secure t is achieved.
Loosen Tighten
6
••

Posion the blower unit around the waist at the centre of the back to minimize the risk
of the blower or hose becoming caught up in use.
ATTACHING THE HOSE TO THE AIRMAX + PAPR BLOWER UNIT
Align the pins of the hose bayonet connector with the boom of the arrow on the air
outlet of the blower. Push the bayonet connector into the blower unl it reaches the
boom of the hole and then twist in a clockwise direcon on blower side unl the
locang pins clip into place. Repeat the process by turning counter clockwise to lock the
other end of the hose to the head top.
FITTING THE WELDING HELMET
• First set the welding head top rake and adjust the welding lter to suit. Li the
helmet to its upper posion
• Place over the head and adjust the headgear ratchet wheel by rotang it unl a
sasfactory ghtness is achieved
• Pull the elascized chin guard downwards and at the same me pull the helmet
down
• The welding head top is then ready for use.
7

OPERATING THE
PAPR
Acvate the Power-Switch at the side of the unit. Once
turned on, the ow alarm acvates for about 1 second
unl the minimum ow rate is achieved and respiratory
protecon is provided given that all components are in
place for the wearer to start the task.
The airow can be adjusted by two arrow-buons from
170 l/min up to 240 l/min. The number of lit Green LED
diodes shows the actual airow level.
The blower should then provide an inial air ow of
+170 LPM for at least 8 hours at a comfortable noise
intensity of <70dB.
CHECKING THE AIR FLOW
With the blower unit running place the Flow-Test-Unit onto the hose so that the sealing
gasket is securely gripping the air outlet. Check that the indicator ball rises above the pass
fail marker. This easy tesng device is supplied with every AIRMAX® PAPR unit. Jackson
Safety recommends carrying out this operaon at least at the beginning of every shi and
aer changing the lter or any other cleaning or maintenance acvity.
8

Face seal replacement
The face seal is fastened in using hook and loop to remove/replace
• Release the press stud strap that goes over the headgear both sides.
• Separate the hook and loop from chin and work up the sides unl the face seal is free
To re-t
• Start in the chin ensuring the D ring is in the chin and facing outwards.
• Line up the hook and loop all the way around ensuring that he face seal is evenly
spread and that there are no gaps.
• Once lined up press the hook and loop together once the face is aached re
fasten the headgear strap
PROBLEM SOLVING
Inspect and dismantle this unit only in a clean environment where no presence of
respiratory hazards is suspected. Always leave the contaminated area to assess any
encountered problem. If the alarm acvates during the execuon of a task, leave the
contaminated area and remove the TH3P R SL lter with the blower with the power on.
If the alarm deacvates, replace the lter; if not, recharge the unit. Check the air ow
with the Flow-Test-Unit. If the problem connues aer the system is recharged, ask for
technical support.
Make sure that the baery unit if fully loaded at the beginning of the shi. The AIRMAX
+® PAPR blower unit is set to sound for 1 second once powered; if the alarm sll sounds
aer check if the hose or lter are clogged; otherwise the baery needs re-placing or re-
charging. If the problem persists, contact Surewerx USA Inc for support.
9

Checking the air ow alarm
Proper funconing of the air ow can be checked by using the setup from previous
paragraph and by pung blower unit into bag. First keep the bag loose around blower,
so that air ow is not obstructed and ow indicator is in green sector. Then ghten bad
around the blower, so that air ow is reduced and ow indicator goes to red sector.
In few seconds ow alarm sound should be heard, (if not, Flow alarm is not working
properly). Release the bag to free air ow and indicator moves to green sector. Aer a
few seconds alarm should stop. If the alarm doesn’t stop, do not use the unit and contact
Jacksonsafety.eu for support.
FILTER REPLACEMENT CRITERIA
Filter should be replaced in all cases when its integrity is suspected to have been aected
as a result of contaminaon or physical damage. Filter must also be replaced at the end of
its service lifeme, which can be determined when the fully charged operaonal JACKSON
SAFETY® AIRMAX+® PAPR unit can’t supply airow above 170LPM tested with the use
of the Flow-Test-Unit provided with the product. This is clear indicaon that the lter is
clogged and should be replaced. If the alarm deacvates aer replacing the lter, the unit
is fully operaonal again; if not, recharge the unit before using it in a contaminated area.
You should always double check the air ow again with the Flow-Test-Unit to make sure the
unit is fully operaonal.
Removing the Filter:
Opening the lter cover: Grip the blower and pull up the cover from the right side of the
blower.
ATTENTION! It is strictly forbidden to use any tools to open the lter cover.
To remove the lter, pull it out of the unit. Clean the unit from dust ensuring no dust
enters the air inlet.
FITTING THE FILTERS
Inspect the lter sealing gasket lter panels and conrm that is free of damage. Make
sure that the new lters are used within their expiry date. Make use of the opportunity
to inspect that the lter holder is clean; nally assemble the new lter into the blower.
Inserng a new lter: Put the lter back into posion and gently push unl it ts well on
the body of the unit.
10

Closing the lter Cover; simply snap the cover into place. Pay special aenon to snap the
cover properly into the blower. Do not aempt to use the blower unit without the cover
ed correctly.
WARNING!
It is essenal that the user must not confuse the markings on the lter relang to any other
standard other than EN12941:1998 + A1:2003 + A2:2008 with the classicaon of the device
when used with this lter. The lters must be regularly checked (see Air Flow Test) and
replaced. Filters are intended to be replaced and not cleaned / re-used.
MAINTENANCE OF THE AIRMAX+® PAPR SYSTEM
• The blower unit, lter housing and head units must all be regularly cleaned to keep
them in good working order
• For single users, the units can be cleaned with a cloth moistened with warm water
and soap or an anmicrobial wipe.
• For mulple users, the units should be disinfected when passed from one user to
another.
• Liquids must not be allowed to enter the workings of the blower unit or get on to
the element of the lter. Parts should be allowed to air dry. Under no circumstances
should any solvents or abrasive cleaning agents be used. The unit must not be dried
using heat.
• The unit should connue to provide protecon to the designed specicaon for at
least 3 years when maintained in accordance with these instrucons. The duraon
of use depends on various factors such as type of use, cleaning, storage and
maintenance.
Shelf Life from date of manufacture when stored in original packaging under the
recommended storage condions
1. Motor Unit/Blower 5 years
2. Baery pack (Standard + HD ) 1 year
3. P R SL lter 5 years
4. Head top 5 years
5. ADF (Auto Darkening Filter 5 years
• Prior to each use the user should check that all components of this system
are free from defects, such as burnt areas, holes, splits or broken lters and
hoses, cracked visors, ADF’s and helmets.
If addional cleaning is required, leave in the lter/cartridge and breathing tube. To
minimize material falling onto the motor/blower. The Airmax+ can now be showered
under running water but not immerse, or put in a respirator. Water temperature should
not exceed 122°F (50°C). Blowers which have been dropped or damaged should not be
11

Showered due to potenal water ingress. Once the unit has been showered and dried the
lter is to be disposed of and not reused.
CHARGING THE BATTERY
Once the unit has reached the Minimum Design
Flow (MDF), it is beer to leave it to run down
completely before recharging. The baery can
either be charged whist installed in the blower
unit or removed and charged separately. Plug
the charger into the main socket, t the plug on
the end of the lead into the socket at the back of
the baery. The charger unit is a smart charger meaning that once the baery is fully
charged the charger unit stops providing power to the baery this allows the baery to
be charged overnight. It is not recommended to charge baeries for extreme lengths of
me as this can reduce the baeries capacity.
REMOVING AND REPLACING THE BATTERY
Hold the motor unit with the hose outlet down
(in a clean area away for contaminants) carefully
pull the baery tab towards the middle. Li the
baery up at the catch end and the baery will
now come free. To replace the baery, place it
into the cavity sliding the non-catch end in rst
into the locaon groove. Then push the baery
down ensuring to get a rm click.
STORAGE AND TRANSPORTATION
When not in use or during transportaon the blower and head units should be stored
in the container in which they were supplied, in a place away from direct sunlight and
contact with solvents or other surfaces or objects that may impact and damage them. Do
not store in areas with extreme temperature (outside -5°C to +55°C range) or humidity
(above 75%RH) condions.
USER INSTRUCTION MANUAL FOR THE AIRMAX+® PAPR BATTERY CHARGER
Component code – 40363
This charger complies with the European regulaons. Please read and keep these
instrucons carefully, they contain important operaon and safety descripons. If the
charger is not used in accordance with this manual you may risk causing a re, personal
injury or equipment damage. Check label on the rear of the charger for further details.
12

Features
The AIRMAX+® PAPR charger is suitable for Lithium-ion baery packs only and has been
provided with a short circuit protecon device. Each charger has quick-change socket
power adapter for various mains (see picture below). It is designed to quick charge 4-6
cells Lithium–Ion baery packs with a capacity of 5200mAh to 7800mAh.
• Operational
range:
100Vac
– 240Vac
• Frequency:
50-60Hz at 150mA
• Operating temperature
range:
0°C to 40°C
• Operatingrelative
humidity:
8% to 85%
• Initial charge before rst use of batteries:
8 hours
AIRMAX® charger-40363
Technical Specications
Only use this charger with baeries that meet the specicaons on the chart below:
Connect its DC output plug to the baery and then connect its AC input plug to 100-
240VAC mains power before switching on the mains power point; ensure the charging
lights are illuminated.
It is normal that the charger and the baery might warm up (below 50°C) during charging;
otherwise please stop using it. Please disconnect the charger AC input plug rst and then
disconnect the DC output plug when charging is nished. The red LED shows that the
baeries are sll charging. The green LED indicates that the baery is fully charged and
ready for use. Do not leave the baery charger in the power supply when not in use
.
Safety
Do not charge any other baeries than the specied in this manual. Don’t use the charger if
it shows visible damage. Do not aempt to repair the charger, this will end the warranty and
will increase the accident and/or damage. Never expose the charger to water, rain or snow.
Contact your supplier if charger replacement is needed.
Environmental disposal
Baeries are chemical waste, dispose them in a special container or hand them in at an
authorized recycling centre
.
PACKAGING / LABELING
Lot Code Descripon: WLyjjj-xxxx (e.g. WL0013-0005)
WL= Manufacturer idener
y = Last digit of year of producon (e.g. 0 for 2020)
jjj = Julian (sequenal) day of producon (e.g. 013 for January 13)
xxxx = Last four digits of purchase order number (e.g. 0005
)
13
• Operaonal range: 100Vac – 240Vac
• Frequency: 50-60Hz at 150mA
• Operang temperature range: 0°C to 40°C
• Operang relave humidity: 8% to 85%
• Operang temperature range: 0°C to 40°C
• Inial charge before rst use of baeries: 8 hours

TECHNICAL DATA
This powered respirator is light-weight and easy to handle. It is equipped with a replaceable
parculate lter. The system aords reliable protecon against parculates and aerosols.
Air ow: 170 to 240 lpm. Minimum ow rate 170 lpm
Weight with lter: 1085 g (Fied with 6 cell baery)
Operang temperature: between -5°c and +55°c
Type of lter: P R SL
Type of Baery: Replaceable and rechargeable Li-Ion (4 cell )7.4V/5200mAh (6 cell)
7.4V/7800mAh Charging Cycles >350. Charge me: 4-6 hours (depending on residual
charge). Visual alarm for low baery voltage.
Visual, audible alarms and Vibraon alarms: (NPF) 500
Noise level: 70dBA
Operang me: greater than 8 hours on minimum ow rate with a new lter and fully
charged baery in a clean environment at room temperature.
Note! Operang me can be shortened in case of clogged lter or under charged baery
WARRANTY
Surewerx warrants that its products (1) comply with Surewerx standard specifications as of the delivery date
to Surewerx authorized distributors/direct purchasers and are warrantied for the following periods from end
user’s date of purchase (verified by valid sales receipt) 2 year warranty is offered on the Airmax+ PAPR 1 year
on the battery; (2) comply with all Surewerx labelling representations; and (3) are manufactured in compliance
with all applicable federal, state, and local laws in effect at the time and place of manufacture of the products.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Surewerx is not liable
for any kind of special, incidental, or consequential damages. Surewerx liability for breach of contract, tort or
other cause of action shall not exceed the product purchase price. Purchasers and users are deemed to have
accepted the above warranty and limitation of liability, and cannot change the terms by verbal agreement or by
any writing not signed by Surewerx. To the extent required by applicable law, Surewerx does not limit its liability
for death/ injury resulting from Surewerx negligence.
EU DECLARATION OF CONFORMITY:
hps://www.jacksonsafety.com/europe-products-documentaon
14

AVIS IMPORTANT
Veuillez lire aenvement les instrucons contenues dans le présent manuel avant
de déballer votre respirateur Jackson Safety® AIRMAX+® PAPR. Le non-respect des
instrucons fournies dans ce document peut annuler la garane limitée du produit et
nuire à votre santé et sécurité.
Le choix de ce respirateur pour votre applicaon doit résulter d’une étude d’évaluaon
du risque menée par un professionnel en maère de santé et sécurité. Son ulisaon
doit strictement se conformer aux instrucons qui l’accompagnent. Pour toute queson
concernant l’adéquaon de ce produit aux tâches qui vous sont assignées, veuillez
contacter le professionnel désigné en maère de santé et de sécurité ou faire appel à
notre service d’assistance technique pour une aide supplémentaire.
L’ulisaon de ce respirateur est limitée aux modèles indiqués dans le présent manuel.
Toute modicaon apportée au produit an de l’adapter à d’autres disposifs de
protecon peut nuire à la santé et à la sécurité de l’ulisateur.
CONTENU
• Ce respirateur JACKSON SAFETY® AIRMAX+® doit être livré avec les éléments
suivants :
• Venlateur avec baerie et ltre intégrés
• Sangle ventrale
• Casque de soudeur (masque de soudeur et harnais crânien) ou protecon en
toile abrasive (visière et protecon)
• Tuyau et protecon du tuyau
• Chargeur de baerie
• Baeries au lithium-ion
• Noce explicave
• Test du débit d’air
PRÉSENTATION DU SYSTÈME
Le respirateur JACKSON SAFETY® AIRMAX+® a été conçu et fabriqué conformément à la
norme EN 12941:1998+A1:2003+A2:2008 relave aux disposifs de protecon P R SL de
classe TH3.
Ce disposif de protecon assistée avec ltrage des parcules est xé sur une sangle
ventrale et livré avec une cartouche de ltre SL haute ecacité remplaçable qui garant
une ecacité de ltraon supérieure à 99,8 %. Le respirateur ore un facteur de
protecon nominal (FPN) de 500 lorsqu’il est ulisé conjointement à un ltre à parcules
JACKSON SAFETY® AIRMAX+®portant le marquage CE, conformément à la norme EN
12941:1998+A1:2003+A2:2008 TH3 P R SL.
Le venlateur (baeries incluses) pèse 900 g à un débit minimum de 170 LPM pendant
au moins 8 heures, pour un niveau d’intensité de bruit confortable inférieur à 70 dB. Les
baeries aux lithium-ion peuvent être rechargées plusieurs fois et remplacées à la n de leur
vie ule. Celles-ci doivent être complètement chargées au début de chaque prise de poste.
f
15

Le venlateur intègre plusieurs disposifs de sécurité desnés à protéger l’ulisateur
contre toute variaon inaendue du débit d’air, notamment :
• L’appareil intègre une alarme sonore qui se déclenche en cas d’obstrucon du
ltre ou de baisse du niveau de charge de la baerie.
• Cee alarme retent pendant 1 second à la mise sous tension du venlateur et
s’arrête lorsque le débit d’air minimum admissible est aeint. La mise hors tension
du venlateur pendant son ulisaon constue une situaon de fonconnement
anormale.
• L’interrupteur d’admission d’air étant en retrait, toute coupure accidentelle du
débit d’air est impossible.
• Un kit de test du débit d’ait est fourni avec chaque respirateur AIRMAX+ an de
s’assurer des bonnes condions d’alimentaon en air. Veuillez suivre et respecter
les instrucons et recommandaons fournies dans ce manuel.
CONFORMITÉ RÉGLEMENTAIRE ET MARQUAGES CE
Filtre P R SL AIRMAX : Référence produit 40302
Code couleur du ltre : Blanc (fond)
Fabriquant agréé CE Surewerx USA Inc
Elgin IL USA 60123
Conformité EN 12941:1998+A1:2003+A2:2008 TH3
P R SL
Module B sous la surveillance de
l’organisme noé
APAVE SUDEUROPE SAS
Noed Body 0082
CS60193 13322 MARSEILLE
CEDEX 16
France
Module C2 APAVE SUDEUROPE SAS
Organisme noé 0082
CS60193 13322 MARSEILLE
CEDEX 16
France
Marquages CE Voir les équees sur les composants
du produit
16

AVERTISSEMENTS ET LIMITES D’UTILISATION
• Ce respirateur n’est pas conçu pour être ulisé dans des zones insusamment
venlées (c’est-à-dire, des locaux connés) où le niveau d’oxygène est esmé être
inférieur à 17 %.
• La nécessité d’uliser ce respirateur doit être étudiée par un professionnel
expérimenté en maère de santé et de sécurité qui doit déterminer l’adéquaon
de la protecon qu’ore cet appareil pour la tâche concernée et les risques
impliqués.
• N’ulisez pas ce respirateur tant que la concentraon des substances dangereuses
n’a pas été déterminée et que leur eet sur la santé et la sécurité des personnes
n’a pas été évalué par un professionnel expérimenté en maère de santé et de
sécurité.
• L’ulisateur de ce respirateur doit avoir lu et compris le descripf des foncons
et réglages du respirateur AIRMAX+®. L’ulisaon de celui-ci, son neoyage, sa
maintenance et sa désinfecon, ainsi que ses condions de stockage doivent
respecter les instrucons fournies dans ce manuel. Les produits retournés pour
remplacement dans le cadre de la garane ne pourront être échangés qu’à
condion d’avoir respecté toutes les recommandaons indiquées dans ce manuel.
• N’ulisez pas le respirateur AIRMAX+® dans les zones où des explosions sont
suscepbles de se produire. Évitez toute exposion directe du respirateur à une
source de ammes et/ou d’éncelles. N’ulisez pas le respirateur AIRMAX+® en
présence de vents violents.
• En cas de déclenchement de l’alarme sonore du venlateur, quiez immédiatement
la zone de travail et rendez-vous dans un environnement non contaminé.
• Vous ne devez pas stocker ni uliser ce respirateur à des températures non
conformes à celles spéciées dans ce manuel en dessous de -5 °C et au-dessus
de +55 °C).
• Ne pas uliser pour le soudage en hauteur en cas de risque de retombées de
métaux en fusion. Ce système de casque/ltre de soudage n’assure pas de
protecon contre les métaux en fusion et les projecons pendant le soudage en
hauteur.
• Les ltres à parcules n’orent pas une protecon adaptée contre les gaz
et les fumées dont la concentraon est supérieure aux limites d’exposion
professionnelle. Ulisez exclusivement des ltres de type P R SL condionnés
dans leur emballage d’origine. Les produits dont la fermeture herméque est
rompue ou qui ont déjà servi ne doivent pas être ulisés.
• Examinez aenvement le joint d’étanchéité de l’emballage et recherchez tout
signe éventuel de dommage visible. N’ulisez pas ce produit si son intégrité vous
semble compromise. Ulisez exclusivement des ltres à parcules fabriqués par
Surewerx USA, correctement équetés et emballés.
• Ne tentez pas de manipuler ou de modier les composants de ce respirateur.
17

• À des cadences très élevées, la pression du respirateur peut devenir négave en
cas de très fort ux d’inhalaon. Les respirateurs JACKSON SAFETY® AIRMAX+®
sont desnés à être ulisés uniquement par du personnel compétent et dûment
formé à son ulisaon.
• Ne laissez pas de l’eau ou tout autre liquide pénétrer à l’intérieur du venlateur.
• Lors de la mise hors tension du venlateur, la protecon oerte par le respirateur
est minime, voire inexistante. Lors de la mise hors tension du venlateur,
l’accumulaon rapide de dioxyde de carbone, ainsi qu’une diminuon d’oxygène
peuvent se produire au niveau du casque.
• Si l’une des alarmes de l’appareil se déclenche, si l’un des composants du
produit est défectueux ou en cas de variaon importante du débit d’air ou de
détecon de fumée, vous devez évacuer la zone contaminée. De même, en cas
d’étourdissement, de gêne ou de diculté à respirer, quiez la zone.
APPLICATIONS
L’usage du respirateur AIRMAX+® s’avère très ecace pour la protecon, entre
autres, de l’ulisateur dans les applicaons suivantes :
Applicaons industrielles
générales
Fabricaon de plasques
renforcés à la bre de
verre
Construcon et mainte-
nance navales
Agriculture Exploitaon minière Industrie de transforma-
on des métaux
Construcon et démoli-
on
Fonderies de métaux Évacuation des déchets
Usines chimiques Peinture au pistolet (à
base d’eau)
Soudage général
Maintenance générale Pharmacie Bricolage
Transformaon des ali-
ments
Lue an-parasitaire Exploitaons à anc de
coteau et de carrière
Exploitaon minière Traitement de l’eau et des
eaux usées
Fabricaon de texles
18

ASSEMBLAGE DU RESPIRATEUR
AIRMAX +® PAPR avec ensemble cagoule de soudage PAPR
①②③④
⑥
⑤
⑬
⑨
⑩
⑫
⑦
⑧
⑪
Arcle Descripon Code pièce
1TL355 Coque avec joint facial et conduit d’air 40100
1TL455 Coque avec joint facial et conduit d’air 40101
1
TL455HH Coque et casque de protecon avec joint facial et
conduit d’air 40102
1TL555 Coque avec joint facial et conduit d’air 40103
2TL355 PAPR Joint facial 40200
2TL455 PAPR Joint facial 40201
2TL455HH PAPR Joint facial 40202
2TL555 PAPR Joint facial 40203
3 harnais de casque 20692
4bandeau 32187
5 Housse de protecon pour tuyau PAPR 40330
7Systèmes Airmax Tuyau PAPR avec housse de protecon, 1050 mm 40341
8 Souerie Airmax+ PAPR IP54 40381
9Filtre HEPA PAPR Airmax+ pour le soudage (UE) 40302
10 Préltres de remplacement Airmax+ - lot de 10 40311
11 Filtres carbones de remplacement Airmax+ - lot de 10 40312
12 Chargeur de baerie Airmax+ PAPR 40363
13 Baerie Airmax+ PAPR 4 cellules 40353
13 Baerie Airmax+ PAPR 6 cellules 40351
14 Ceinture Airmax+ PAPR 40371
14 Ceinture lavable/jetable 40372
19

RÉGLAGE INITIAL
• Fixez la sangle ventrale autour de votre taille et aachez les deux extrémités.
• Si la sangle n’est pas assez serrée, faites glisser le disposif de réglage mâle sur la
ceinture, dans la direcon du disposif femelle. Si la sangle est trop serrée, faites
glisser le disposif de réglage mâle sur la ceinture, en l’éloignant du disposif femelle.
• Répétez la procédure ci-dessus jusqu’à ce que le réglage vous semble confortable
et totalement sécurisé.
desserrer serrer
Posionnez le venlateur autour de votre taille, au niveau du milieu de votre dos,
pour éviter que celui-ci ou le tuyau ne s’accroche
pendant son ulisaon.
FIXATION DU TUYAU AU VENTILATEUR AIRMAX+®
Alignez les ches du connecteur à baïonnee sur le bas de la èche qui se trouve sur
la sore d’air du venlateur. Branchez le connecteur à baïonnee au venlateur dans
l’orice, puis faites-le tourner dans le sens horaire jusqu’à ce que ses ches d’alignement
s’enclenchent. Répétez cee opéraon pour xer l’autre extrémité du tuyau au casque.
MISE EN PLACE DES CASQUES DE SOUDEUR
• Commencez par régler l’inclinaison du casque de soudeur, puis ajustez le ltre en
foncon des besoins. Relevez complètement le masque.
• Enlez le casque par-dessus et réglez la roue à cliquet en appuyant sur celle-ci et
en la faisant tourner de façon à obtenir le niveau de serrage souhaité.
• Tirez le protège-menton élasque vers le bas tout en rabaissant le masque.
• Le casque de soudeur est prêt à l’emploi.
20
