optrel P.AIR User manual

User Instructions
IMPORTANT : Keep these User Instructions for reference
i

IMPORTANT
This respirator reduces the exposures to airborne particles.
All wearer must read and understand this User Instruction
provided as a part of the product packaging. Follow all local
regulations. A written respiratory protection program must
be implemented in accordance of the requirements of OSHA
1910.134, including training, fit testing and medical evaluation.
Keep this User Instruction for future reference. Please note: This
mask is for single use and cannot be reused.
Use For
• Particles such as those from grinding, sanding, sweeping,
sawing, bagging, or processing minerals, coal, iron ore,
flour, metal, wood, pollen and other solid particles.
• Liquid or non-oil based droplets from sprays that do not
also emit oil aerosols or vapors.
•
Solid particulates and liquid mists in concentracions
not exceeding 10x PEL/OEL. Follow all applicable local
regulations.
For additional and latest information visit the webpage www.
optrel.com. Always follow User Instruction and use in indicated
manner.
Do Not Use For
DO NOT use for gases, vapors, oil aerosols, absestos, arsenic,
cadmium, lead, 4,4-methylene dianiline (MDA) or abrasive
blasting. DO NOT use for particulate concentrations exceeding
10x the occupational exposure limit or applicable government
regulastions, whichever is lower. DO NOT use in any manner
not indicated in the User Instruction. This respirator does not
supply oxygen.
Biological Particles
The respirator reduces inhalation exposures to airborne
biological particles (e.g. mold, Bacillus anthracis, Mycobacterium
tuberculosis, etc.) but cannot offer absolute protection from
infections, illness or disease. OSHA and other government
agencies have not established safe exposure limits for these
contaminants.
Use Instructions
1. The mask is intended for single use and cannot be reused.
2. Store the respirator away from contaminated areas.
3. Inspect respirator before use to ensure that it is in good
operationg condition. Examine all the respirator parts for signs
of damage including the two headbands, attachment points
and nose clip. The respirator must be disposed immediately
if parts are damaged or missing.The filtering facepiece must
be inspected prior use: Make sure the breathing zone is free
from any damage. Immediately replace respirator if damaged.
4. Failure to follow all instructions and limitations on the
use of this respirator and/or failure to wear this respirator
during all times of exposure can reduce respirator
effectiveness and may result in sickness or death.
5. In the U.S., before occupational use of this respirator, a written
respiratory protection program must be implemented meeting all
the requirements of OSHA 29 CFR 1910.134, such as training,
fit testing, medical evaulation, and applicable OSHA substances
specific standars. Follow all applicable local regulations.
6. Leave a contaminated area immediately and contact
supervisor if dizziness, irritation, or other distress occurs.
7. Conduct a seal check before each use as specified in the
Fitting Instructions section. If you cannot achieve a proper
seal or the mask does no longer tightly close, do not use
the respirator.
8. Change the mask when it is saturated with humidity,
particulates or breathing becomes difficult; or every 4 hours
after continuous use, only change in a save environment.
9. Dispose the used product in accordance with all applicable
regulations.
Use Limitations
1. This respirator does not supply oxygen. Do not use it in
atmospheres containing less than 19.5% oxygen.
2. Do not use respirator when concentrations of contaminants
are immediately dangerous to life and health, are unknown or
when concentrations exceed 10x the permissible exposure
limit (PEL) or according to specific OSHA standards or
applicable government regulations, whichever is lower.
3. Do not alter, wash, abuse or misuse the respirator.
4. The mask is intended for single use and cannot be reused.
5. Do not use with beards or other facial hair or other
conditions that prevent a good seal between the face and
the sealing surface of the respirator.
6. Respirators can help protect your lungs against certain
airborne contaminants. They will not prevent entry through
other routes such as the skin, which will require additional
personal protective equipment (PPE).
7. This respirator is designed for occupational/professional
use by properly trained adults. This respirator is not designed
to be used by children.
English

1
2
3
4
5
First of all clean hands before taking mask out of its packaging.
1. Prestretch top and bottom straps before placing respirator on the face.
2. Cup the respirator in your hand, with the nosepiece at your fingertips,
allowing the headbands to hang freely below your hand.
Do not touch the respirator on the inside.
3. Position the respirator under your chin with the nosepiece up. Pull the
strap over your head resting it high at the top back of your head.
Pull the bottom strap over your head and position it around the neck
below the ears.
! Pinching the nosepiece using one hand may result in improper fit and less
effective respirator performance. Use two hands.
4. Place your fingertips from both hands at the top of the metal nosepiece.
Using two hands, mold the nose area to the shape of your nose by pushing
inward while moving your fingertips down both sides of the nosepiece.
5. Perform a User Seal Check prior to each wearing. To check the respirator-
to-face seal, place both hands completely over the respirator and exhale
sharply. Be careful not to disturb the position of the respirator. If air leaks
around nose, readjust the nosepiece as described in step 4.
If you CANNOT achieve a proper seal, DO NOT enter the contaminated
area. Report to your supervisor.
Fitting - and Removal Instructions
Removal Instructions:
Hold the respirator in one hand to maintain the position on face. Pull bottom strap over head.
Still holding the respirator in position, pull to strap over head and remove respirator. Clean your
hands after removing the respirator. Dispose of used product in accordance with applicable
regulations. Single use only! Do not reuse!
Storage Conditions and Shelf Life (Details see last page)
Before use, store respirators in the original packaging away
from contaminated areas, dust, sunlight, extreme temperatures,
excessive moisture and damaging chemicals.
When stored in accordance with temperature and humidity
conditions specified below, the product may be used until the
"use by" date specified on packaging (5 years after production
date). Always inspect product and conduct a user seal check
befor use as specified in the User Instructions. If you cannot
achieve a proper seal or the mask holds no longer close
tightly, do not use the respirator.
Time Use Limitation
If respirator becomes damaged, soiled or breathing becomes
difficult (e.g. saturated with breathing air humidity), leave the
contaminated area immediately and replace the respirator.
The respirator is intended for single use and cannot be
reused.
Acceptable Fit Test Protocols
Fit Test Protocol*
Quantitive Protocols Saccharin Acceptable with this product!
Bitrex TM Acceptable with this product!
Quantitative Protocols* Acceptable with this product!
*Refer to OSHA 1910.134.

9610.157UI Rev A9610.157UI Rev A
declaration of conformity
https://www.optrel.com/service/downloads/
optrel tec ag
industriestrasse 2
ch-9630 wattwil
phone: [phone]
fax: [phone]
[email protected]
www.optrel.com
Specifications
(We reserve the right to make technical changes)
Material Composition Straps - Elastic Spandex /
Polyester
Nose Clip - Metal / Polymer
Filter - Propylene
Weight Approximate 0.32 oz.
Country of Origin Made in Switzerland
Standards NIOSH (approval pending)
End of Shelf Life
Use respirators before the "used by" date specified on the
packaging
(date format MM/YYYY)
Storage temperature Range
-4°F (-20°C) to +86°F (+30°C)
Storage Maximum Relative Humidity
<80% RH (not exceeding 80%) <80% HR
+30°C
+86°F
-20°C
-4°F
optrel inc.
5 Division St #35
US-East Greenwich, RI 02818
phone: [phone]
fax: [phone]
[email protected]
www.optrel.com
Current approval matrixCurrent approval matrix
