Jacuzzi JS-1i User manual

Jacuzzi®Full Spectrum Infrared Saunas
Please read this manual before using your Sauna for the first time.
Please keep this manual for future reference.
www.Jacuzzi.com
Owner’s Manual

Table of Contents
Installation ----------------------------------------04
01 | Jacuzzi®JS-1i and JS-2i ---------------------------05
Packaging ----------------------------------------06
Assembly Instructions --------------------------------07
02 | Jacuzzi®JS-3i ----------------------------------20
Packaging ----------------------------------------21
Assembly Instructions --------------------------------22
Enjoying Your Sauna ---------------------------------35
Using Your Sauna Control Panel--------------------------36
Tips for Use ---------------------------------------40
Safety Instructions- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 42
Important Safeguards --------------------------------44
* The information contained in this manual is subject to change without notice.

Installation
Choosing a Location
Place your sauna on a dry and level surface for best results.
Installation requirements for your sauna are as follows:
1. Your Jacuzzi®sauna is a self-contained and freestanding unit. It should not be built into any structure without prior
authorization.
2. Please maintain a minimum of 4-inch clearance on all sides of the unit to allow air to circulate while giving access
for the power cord.
Cleaning and Maintenance
1. Before using your sauna for the first time, clean the inside of the sauna with a damp cloth.
2. Place a towel on the floor and bench to absorb any perspiration. Wash these often to maintain a clean and pleasant
environment inside your sauna.
3. Perspiration may darken the wood over time. Refer to Varnish Instructions.
Please be careful when carrying and installing the glass pieces to avoid breakage. Make certain the
glass is securely fastened during installation before letting go of any individual piece that could break.
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
5
01
Packaging - - - - - - - - - - - - - - - - - - - - - - - - 06
Assembly Instructions - - - - - - - - - - - - - - - - - - 07
Jacuzzi®Saunas JS-1i and JS-2i

6
www.jacuzzi.com
Packaging
.
Box 1 of 6 Box 2 of 6 Box 3 of 6 Box 4 of 6
Roof and Floor Panels Left Side Wall Front Wall Metal Threaded Rods
Installation Manual Right Side Wall Back Wall
Box 5 of 6 Box 6 of 6
Parts and Accessories 2 x Full Spectrum
Heaters
Right Side Wall
Contents of Boxes
Accessory Box Contents
Door Handle Wood piece
(2 pieces)
Front Heater
Mounting Screws
(4 sets)
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
7
Assembly Instructions
Assembly of the sauna requires a minimum of two adults to complete. As noted, a third person is recommended when
installing the glass components. Please read the instructions thoroughly before and during assembly to ensure proper
installation of the unit. Wearing booties to cover your shoes will protect the wood from getting scuffed or stained.
When determining a location for your sauna, please keep in mind the following:
1. The main power cord on the sauna must be easily accessible.
2. The location must be dry and level.
3. Panels should be installed in the following order:
1) Floor 4) Right Side Wall 7) Roof
2) Back Wall 5) Under Bench Support 8) Front Wall Glass
1. Place the bottom floor panel on the ground
near the location you will be using the sauna.
Make sure the front of the floor is in the desired
location of the door. The metal threshold
indicates the front of the sauna.
1. Connect the back panel to the floor panel by lining up
the back panel on the groove of the floor panel.
1 - Location of Sauna and Installation Order
2 -Placing Floor Panel 3 - Connecting the Back Panel to
the Floor Panel
Jacuzzi®Saunas JS-1i and JS-2i

8
www.jacuzzi.com
Assembly Instructions Cont’d
1. Place the left side wall in the slot in
the floor positioned as in the drawing
below.
2. When the wall is in place, make sure
the metal rod is positioned in the
metal nut in the floor.
3. Screw the metal bolt from the top of
the panel into the metal nut in the
floor using your hand to twist the
metal rod.
4. Repeat this step installing the Right
Side Wall.
4 - Connecting Side Walls
Left Side Wall Installed Right Side Wall Installed
If the panels still seem too tight to come down all the way, try backing off the
bracket screws by one half turn with a Phillips head screwdriver.
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
9
1. Insert the left side wall glass into the slot in the left side wall and make sure it’s well seated on the floor.
2. Repeat this step with the Right Side glass.
5 - Installing Side Wall Glass
When installing the glass panels, a third person is recommended to support the glass during installation..
Jacuzzi®Saunas JS-1i and JS-2i
Assembly Instructions Cont’d

10
www.jacuzzi.com
Assembly Instructions Cont’d
1. Located the two (2) front columns and the
corresponding metal rods.
3. Align one of the threaded columns with the left side
glass and position the metal rod over the metal nut in
the floor.
4 Hand screw the metal rod into the nut until it is tight.
5. Repeat this step for the Right Side Column.
2. Thread the rods through the columns.
6 - Install Front Columns
Note: Some of the rod will be exposed
at the top of the column.
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
11
Assembly Instructions Cont’d
Slide down the bench heater panel by lining up its sides with the vertical guides on the left and right side wall
panel.
1. Be careful not to scratch the side panels when positioning the heater panel.
2. Push the bench heater panel all the way down until it is touching the floor panel and securely in place.
7 - Installing Under Bench Support
Vertical bench heater
panel guides are found
on the side panels.
Heater must be
facing outward
Jacuzzi®Saunas JS-1i and JS-2i

12
www.jacuzzi.com
Assembly Instructions Cont’d
8 - Connect Heater Connection Under Bench
1. Locate the power supply on the left side wall.
2. The outlets in the power supply are numbered. Match the six (6) numbered black IEC plugs with the numbered
outlets and plug them in. Make sure they are well seated.
3. Plug the cable with the Blue/Red/Green wires and molex connector into the receptacle in the power supply.
4. Locate the wood power supply guard.
5. Place it over the power supply and screw it in place.
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
13
Assembly Instructions Cont’d
Install the bench panel by sliding it over the horizontal bench guides on the side panels. Be careful not to scratch
the adjacent panels when sliding in the bench.
Push the bench all the way in until it touches the back panel and is securely in place.
Be sure that the bench is pushed all the way back until it slides under the heater guard to secure the bench in place.
LEFT
TOP
BOTTOM
FRONT
BLACK
9 - Installing the Bench
After the bench is installed, slide in the
included wood pieces to prevent the bench
from sliding left to right. One piece can be
placed on each side next to the bench.
Jacuzzi®Saunas JS-1i and JS-2i

14
www.jacuzzi.com
Assembly Instructions Cont’d
1. Locate the roof.
2. Lift the roof over the exposed metal rods and align the
holes in the roof over the metal rods.
3. Lower the roof down onto the walls and front columns.
10 - Installing the Roof
11 - A J® B W S
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
15
Assembly Instructions Cont’d
1. Locate the Left Front Glass.
2. Lift up the roof an inch and position the left front glass in place
sliding it into the left front column.
3. Seat the roof on the glass making sure the glass is in the slot
in the roof.
4. Repeat this step for the Right Front Glass.
11 - Installing Left and Right Side Glass Window
Jacuzzi®Saunas JS-1i and JS-2i

16
www.jacuzzi.com
Assembly Instructions Cont’d
13 - Installing Front Heaters
1. Locate the two (2) front heaters.
2. Align the left front heaters and plug the connector that comes out of the bottom of the heaters into the plug
coming out of the in the floor.
3. Align the the hole in the back of the heater with the hole in the front wall glass. Using the included screws and
washers, secure the heater to the glass through the pre-drilled hole. One washer will be placed on the inside
and one on the outside glass. The heater will be secured with these screws in two locations.
4. Be sure to tuck the cable into the bottom of the heater so it is hidden and will not be damaged.
1. Locate the door handle.
2. Attach the door handle using the enclosed screws.
12 - Installing Door Handle
Note: If you are using a tablet or smartphone to control your sauna, the door handle will act as both the
door handle and tablet/smartphone holder when the door is closed.
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
17
Assembly Instructions Cont’d
Front Heater Installed
Warning Notice
The infrared heaters in your sauna are a potential BURN HAZARD. DO NOT TOUCH the
infrared heaters when they are in operation and allow to cool before servicing.
4. Repeat this step for the right front heaters.
14 - Installing Front Heaters
Jacuzzi®Saunas JS-1i and JS-2i

18
www.jacuzzi.com
Assembly Instructions Cont’d
15 - Locating and plugging in power cord
The power cord comes out of the back wall of the sauna at the left facing back corner about 6” from the floor. The
power cord must be plugged into the appropriate grounded outlet.
Note: We do not recommend using
an extension cord for your sauna.
Please plug the sauna directly into
the wall receptacle.
Jacuzzi®Saunas JS-1i and JS-2i

www.jacuzzi.com
19
Assembly Instructions Cont’d
Installation of your sauna is now complete. Using a damp cloth, wipe out the sauna to remove any excess
saw dust that may have settled on the wall & floor panels and the heater panels during manufacturing and shipping.
Please refer to usage instructions located later on in this manual.
16 - Installation is Complete
Jacuzzi®Saunas JS-1i and JS-2i

20
www.jacuzzi.com
02
Packaging - - - - - - - - - - - - - - - - - - - - - - - - 21
Assembly Instructions - - - - - - - - - - - - - - - - - - 22
Jacuzzi®Saunas JS-3i
