J&M Corporation HSBL-145X7-XXR User manual

© 2017 J&M Corporation. All rights reserved. 9/17
Saddlebag-Lid Kit
w/ROKKER®XXR 5X7”
Speakers & Plug-n-play Wiring
Harness Included for
2014-2018 Harley®Baggers
#
HSBL-145X7-XXR
Installation
Instructions

This complete custom saddlebag-lid kit with ROKKER XXR
5X7” speakers & plug-n-play wiring harness included, has
been designed specifically for the 2014-2018 Harley®
Bagger saddlebags.
J&M’s NEW ROKKER XXR series 5X7” speakers have
been upgraded extensively from the original release.
Spec’d at 2 ohms impedance and an impressive 300
watts maximum input (175w RMS - 91db sensitivity),
these speakers provide the ultimate in raw audio power
and include the bridge-mounted high-output tweeter.
Features of this new ROKKER XXR series speaker kit from
J&M are:
• Lightweight waterproof one-piece woven-fiber driver cone with
super-rigid metal basket design.
• High-density lite-weight Neodymium magnet structure,
specially coated to maintain flux-strength integrity even at
extreme operating temperatures.
• High efficiency VENTED voice-coil for improved cooling when
operating at high volume levels for extended periods.
• Custom bridge-mounted high-output tweeter.
These are THE most powerful 5X7” speakers you can buy for
your Harley and they will perform extremely well when used with
a medium to high-powered accessory amplifier.
Product Overview

Installation Instructions
1. If you are going to initially install these
saddlebag lids without painting them, clean
the underside of the lid seat area with alcohol,
and apply the molded rubber seal all the way
around the underside lip of each saddlebag lid.
(then skip to step #3)
2. If you going to have them painted prior to
installation, remove first the speakers and grills
from each lid and have them painted to the
color of your choice. Then install the molded
rubber seal prior to continuing on to step #3.
3. Remove both left and right saddlebag lids,
tether fasteners and latch/hinge assemblies
from the stock saddlebag lids.
4. Remove both saddlebags, side covers, seat
and fuel tank.
5. Carefully drill a 21mm or 13/16 diameter hole
on the backside of the left saddlebag in the
location shown. Diagram A
6. Install the provided rubber grommet into the
hole, with pointed end facing towards wheel/
tire. Then from the inside of the saddlebag,
route the left side speaker harness (blue-
orange/ blue grey). As per Diagram B
7. Connect the wire terminal plug to the
connector socket of the J&M 5X7” ROKKER
XXR speaker and route the speaker harness
underneath the saddlebag lid tether strap and
along the inside of the saddlebag as shown.
Diagram B
8. Connect the forward section of the saddlebag
lid speaker harness to the in-line wire plug and
route the harness under the side cover along
the frame, under the fuel tank, and into the
fairing. Secure the harness using the provided
tie-straps. Diagram C
9. Reinstall left saddlebag lid, tether fasteners
and latch/hinge assembly, SUBSTITUTING the
shorter bolt included in the hardware kit with
the longer one from the stock lid assembly.
10. Repeat the entire process for the right-side
saddlebag.
11. Reinstall the fuel tank, seat, and side covers.
12. Then reattach both left and right side
saddlebags.
7 1/4”
3 3/4”
21mm Hole or 13/16”
Fig. A
Route wires as shown
Fig. B
Route wires as shown, wire tie with supplied
ties to fender strut support bracket
Fig. C
