Jason.L Quadro Loop User manual

ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
Page 1 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
Table top x4
Leg Quadro x2
Leg Quadro Loop x2
Connector frame x1
Beam x4
Plastic bracket x16
A
B
C
D
E
F
Allen key x2K
M8x20MM CSK x8
M8x20MM Socket head x8
M6x20MM Socket head x16
M6x30MM Socket head x16
G
H
I
J
COMPONENTS
SCREWS
Page 2 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
E
F
G H I J
A
BD
C

ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
Using Allen Key provided, attach 4 plastic brackets per leg (E)
(as per picture above) using M6x20MM (I) Socket head screw.
Do the same with Connector frame (D). Connect Loop Legs (C)
to Bottom of Quadro Legs (B) by using 4 bolts per leg
Using Allen Key provided, attach M8x20MM Socket head (H)-
screw socket half way into leg for both legs (B) and into
Connector frame (D).Page 3 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
H
STEP 02
I
STEP 01

ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
STEP 03
Adjust extendable beam (E) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
Attach beam (E) to legs (B) and Connector frame (D)
using nut insert in legs. See point attached
Frame looks like this. Using Allen Key, attach beam (E) with Socket (G)
STEP 05
Page 5 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
G
G
G
G
G
G
G
G
STEP 04
TOP VIEW

ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
STEP 06
Page 6 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place desktops ontop of frame - with cutout at the back of the
desk. Nut inserts in top will align with plastic joiner brackets
using M6x30MM (J) sockets attached tops to frame.
J
TABLE TOP
BOTTOM VIEW

ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
Page 7 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
TABLE TOPS
BOTTOM VIEW
The following nut inserts should be used for this specific desk / workstation
nut insertnut insert nut insertnut insert
nut insertnut insert nut insertnut insert
