ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 1200 mm
Page 1 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 1200 mm
Table top x1
Leg Quadro x2
Leg Quadro Loop x2
Beam x2
Plastic bracket x8
A
B
C
D
E
Allen key x2J
M8x20MM CSK x4
M8x20MM Socket head x4
M6x20MM Socket head x8
M6x30MM Socket head x8
F
G
H
I
COMPONENTS
SCREWS
Page 2 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
D
E
F G H I
B
A
C

G
ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 1200 mm
Using Allen Key provided, attach 4 plastic brackets per leg (E) (as per
picture above) using M6x20MM (H) Socket head screw. Connect Loop
Legs (C) to Bottom of Quadro Legs (B) by using 4 bolts per leg.
Using Allen Key provided, attach M8x20MM Socket head (G)-
screw socket half way into leg for both legs (B).
STEP 02
Page 3 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
H
STEP 01

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 1200 mm
STEP 03
Adjust extendable beam (D) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 1200 mm
STEP 04
TOP VIEW
Attach beam (D) to legs (B) using
nut insert in legs. See point attached
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
STEP 05
Page 5 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
F
F
F
F

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 1200 mm
STEP 06
Page 6 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place desktop ontop of frame. Nut inserts in top will align with plastic
joiner brackets using M6x30MM (I) sockets attached tops to frame.
TABLE TOP
BOTTOM VIEW
I
