Jason.L Quadro Loop Desk User manual

ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
Page 1 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation
All manuals and user guides at all-guides.com

ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
Table top x1
Legs Quadro x2
Legs Quadro Loop x2
Beam x1
Plastic bracket x4
A
B
C
D
E
Allen key x2J
M8x20MM CSK x2
M8x20MM Socket head x2
M6x20MM Socket head x4
M6x30MM Socket head x4
F
G
H
I
COMPONENTS
SCREWS
Page 2 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
D
E
F G H I
A
B
C
All manuals and user guides at all-guides.com

G
ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
Using Allen Key provided, attach 2 plastic brackets per leg (E)
(as per picture above) using M6x20MM (H) Socket head screw.
Connect Loop Legs (C) to Bottom of Quadro Legs (B) by using 4
bolts per leg.
Using Allen Key provided, attach M8x20MM Socket head (G)-
screw socket half way into leg for both legs (B)
STEP 02
Page 3 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
H
STEP 01
All manuals and user guides at all-guides.com

ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 03
Adjust extendable beam (D) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50
All manuals and user guides at all-guides.com

ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 04
TOP VIEW
Attach beam (D) to legs (B) using nut insert in legs.
See point attached
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
STEP 05
Page 5 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
F
F
All manuals and user guides at all-guides.com

ASSEMBLY INSTRUCTIONS
Quadro Loop
Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 06
Page 6 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place desktop ontop of frame - with cutout at the back of the desk.
Nut inserts in top will align with plastic joiner brackets using M6x30MM
(I) sockets attached top to frame.
I
TABLE TOP
BOTTOM VIEW
nut insertnut insert
All manuals and user guides at all-guides.com
