Jason.L Quadro Square Boardroom table User manual

ASSEMBLY INSTRUCTIONS
Quadro Square
Boardroom table
Size: 1100mm x 1100mm
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro Square
Boardroom table
Size: 1100mm x 1100mm
Table top x1
Leg Quadro Square x2
Beam x1
Plastic bracket x4
A
B
C
D
Allen key x2I
M8x20MM CSK x2
M8x20MM Socket head x2
M6x20MM Socket head x4
M6x30mm Socket head x 4
or M6x30 Wood screws x 4 and washers
E
F
G
H
COMPONENTS
SCREWS
Page 2 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
C
D
E F G H
A
B
Colour of the beam is always black, regardless desk frame colour.
*
*

STEP 03
Secure 1000mm beam (C)
using screws provided
ASSEMBLY INSTRUCTIONS
Quadro Square
Boardroom table
Size: 1100mm x 1100mm
Page 3 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
F
G
STEP 01
Using Allen Key provided, attach 2 plastic brackets per leg (D)
(as per picture above) using M6x20MM (G) Socket head screw
Using Allen Key provided, attach M8x20MM Socket head (F)-
screw socket half way into leg for both legs (B)
STEP 02

ASSEMBLY INSTRUCTIONS
Quadro Square
Boardroom table
Size: 1100mm x 1100mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
STEP 04
TOP VIEW
Attach beam (C) to legs (B) using nut insert in legs.
See point attached
Frame looks like this. Using Allen Key, attach beam (C) with Socket (E)
STEP 05
Page 4 of 5
E
E

ASSEMBLY INSTRUCTIONS
Quadro Square
Boardroom table
Size: 1100mm x 1100mm
Page 5 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
STEP 06
Place desktop on top of the frame. Please place the top equally
centred at the same distance from left and right of the leg frame
and make sure that front and back of the top will have the same
distance from the legs frame as well.
STEP 07
Please drill wood screws (H) through the plastic brackets
into the underneath of the Tops.
H
