jbc JN2020 User manual

INSTRUCTION MANUAL
For JTT Heater
JT Nozzles

2
The following items are included:
Packing List
This manual corresponds to the following references:
Nozzle for JTT Heater .................................................................... 1 unit
(according to purchased reference)
Manual ............................................................................................... 1 unit
Ref. 0029001
Bent:
JN2015
JN2012
JN6633
Straight:
JN2020
JN8417
Flat:
JN7637
JN7638
JN7639

3
1. Push the nozzle tab inwards
slightly with a screw driver or
flat-nosed pliers.
2. Assemble the nozzle onto
JTTagain.
Maintenance
In case of a loosely fitting nozzle:
Nozzle Models
Ref. Shape Size Ref. Sha-
pe
Size
JN2020 Straight Ø 8mm JN6633 Bent Ø 8mm 18º
JN8417 Straight Ø 10mm JN7637 Flat 10 x 2mm
JN2015 Bent Ø 4mm 18º JN7638 Flat 20 x 2mm
JN2012 Bent Ø 6mm 18º JN7639 Flat 30 x 2mm
Straight Bent Flat
Ø mm Ø mm A x B mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic
equipment at the end of its life must be collected and returned to an
authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against all manufacturing defects,
including the replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must be returned, postage paid, to
the dealer where it was purchased.
Specifications
JT Nozzles
For JTT Heater
Net Weight: Package Weight:
Ref.: JN2020 7.2 g / 0.016 lb 14.2 / 0.031 lb
Ref.: JN8417 6 g / 0.013 lb 14 g / 0.031 lb
Ref.: JN2015 6 g / 0.013 lb 14 g / 0.031 lb
Ref.: JN2012 6.9 g / 0.015 lb 14 g / 0.031 lb
Ref.: JN7639 10 g / 0.022 lb 17 g / 0.037 lb
Ref.: JN7637 6 g / 0.013 lb 14 g / 0.031 lb
Ref.: JN7638 8 g / 0.018 lb 14 g / 0.031 lb
Ref.: JN7639 10 g / 0.022 lb 17 g / 0.037 lb
- Package Dimensions: 60 x 35 x 27 mm
(L x W x H) 2.36 x 1.38 x 1.06 in
0029001-130522
