JBL Studio 570 User manual

Release Date 2011 Discontinued Date XXXX
Technical Manual
STUDIO 570
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep test: 6.0V input 45Hz to 20kHz
• LF Aural Sweep test: 5.0V input 45Hz to 1.5kHz
• HF Aural Sweep test: 1.0V input 1.5kHz to 20kHz
PHYSICAL SPECIFICATIONS:
• Dimensions (W x H x D): 34-1/16" x 8-7/16" x 11-3/16"
(896mm x 214mm x 284mm)
• Weight: 34.4 lb (15.6kg)
WARRANTY:
• Refer to the warranty statement packed with the product.
* The maximum recommended amplifier power rating will
ensure proper system headroom to allow for occasional
peaks. We do not recommend sustained operation at these
maximum power levels.
STUDIO 570
12/11
ACOUSTIC & ELECTRICAL SPECIFICATIONS :
• Nominal impedance: 6 ohms
• Recommended amplifier
power*: 150 watts
• Frequency response: 45Hz – 40kHz (–6dB)
• Sensitivity (2.83V/m): 88dB
• Crossover frequency: 1.5kHz
SYSTEM COMPONENTS:
• Cabinet: Studio 570 cabinet (not for sale)
• Grille: 244-050-05448-0BAE
• Low-frequency transducer: Two 5-1/4" (130mm) PolyPlas™ cones
with Symmetrical Field Geometry™
magnet structures, cast frames and
rubber surrounds, magnetically
shielded (553J)
DC resistance: 10.0 ohms
• High-frequency transducer: 1" (25mm) compression driver with
neodymium magnet and one-piece
Teonex® diaphragm, magnetically
shielded (0500166001Z)
DC resistance: 3.8 ohms
• Crossover network: 013-7600-05936-E
STUDIO 570 WIRING DIAGRAM
Legend on Page 2
STUDIO 570 SCHEMATIC
PACKAGING

1 237-025-05120-0BAE Bi-Radial® horn, glass-filled ABS 1
2 237-025-05127-0BAE Horn rear, glass-filled ABS 1
3 0500166001Z 1" (25mm) compression driver, 1
neodymium magnet
4 350-AM05025D141-E Screw 4
5 244-050-05448-0BAE Studio 570 grille 1
6 350-HM04020D148-E Screw 8
7 553J 5-1/4" (130mm) Symmetrical Field Geometry™
woofer, PolyPlas™ cone 2
8 327-010-05055-0BAE Grille cup 6
9 350-AM04020D079-E Screw 8
10 301-ABS-05146-0BAE Bezel 1
11 Not for sale Studio 570 cabinet (black, cherry) 1
12 Not for sale Studio 570 port tube 1
13 317-ABS-05059-0BAE Terminal cup 1
14 350-EM03520D082-E Screw 4
15 013-7600-05936-E Network (LF board and HF board) 1
16 321-ABS-05150-0BAE ABS plastic foot 4
17 320-SR-05272-0BAE Rubber foot 4
18 350-AM04020D079-E Screw 8
19 431-000-07444-E Top packing 1
20 430-002-05487-E EPE bag 1
21 Not for sale Plastic bag for owner’s manual 1
22 376-000-01292-E Accessory bag 1
23 Visit www.jbl.com Owner’s manual 1
24 431-000-07458-E Middle packing 1
25 431-000-07445-E Bottom packing 1
26 Not for sale Desiccant pack 1
27 400-000-10277-E Studio 570 carton (black) 1
400-000-10361-E Studio 570 carton (cherry) 1
Technical Manual
STUDIO 570
STUDIO 570
EXPLODED VIEW
HARMAN Consumer, Inc.
8500 Balboa Blvd., Northridge, CA 91329 USA
© 2012 HARMAN International Industries, Incorporated. All rights reserved. JBL and Bi-Radial are trademarks of HARMAN International Industries, Incorporated, registered
in the United States and/or other countries. PolyPlas and Symmetrical Field Geometry are trademarks of HARMAN International Industries, Incorporated. Teonex is a
registered trademark of DuPont Tenjin Films.
Features, specifications and appearances are subject to change without notice.
Part No. 950-XXXX-001 Rev. A
12/11
www.jbl.com
ITEM
NO. PART NO. DESCRIPTION QTY.
ITEM
NO. PART NO. DESCRIPTION QTY.
