JBL SUB 100P User manual

INCLUDED ITEMS
Your new JBL®powered subwoofer incorporates a high-performance
transducerand built-in amplifier that deliver the powerful, dynamic
and accurate low-frequency performance that makes your film
soundtracksand music come alive. And with adjustable crossover,
phase controlsand automatic turn on/off, it isalso simple to connect
and set up.
We’re confident that this JBL subwoofer will provideevery note
of enjoyment that you expect – and that when you thinkabout
purchasingadditional audio equipment for your home, car or
office, you will once again choose JBL products.
This quick-start guide contains all the information you need to
set up, connect and adjust your new subwoofer. For more
in-depth information,goto our web site: www.jbl.com.
Powered Subwoofer
THANK YOU FOR CHOOSING THIS JBL®PRODUCT
SUB 100P
OWNER'S MANUAL
4X

2
SUBWOOFER REAR-PANEL CONTROLS AND CONNECTION
1) Power Mode:
When switched to 'Auto' position, the subwoofer will then be in Standby
mode. It will automatically turn on when an audio signal is detected and
will return to the Standby mode when no audio signal is detected after
approximately 10 minutes. Setting this switch to ‘On’ keeps the
subwoofer powered until Power Switch is turned 'Off.'
2) On/Standby LED:
When the Power Switch is in the ‘On’ position, this LED indicates
whether the subwoofer is in the On or Standby state.
• When the LED glows blue, the subwoofer is turned On.
• When the LED glows red, the subwoofer is in the Standby mode.
3) Phase Switch:
This switch determines whether the subwoofer transducer's piston-like
action moves in and out in phase with the main speakers. If the
subwoofer were to play out of phase with the main speakers,
the sound waves from the main speakers could partially cancel out the
sound waves from the subwoofer, reducing bass performance and sonic
impact. This phenomenon depends in part on the placement of all the
speakers relative to the listening position and to each other in the room.
4) Crossover Control:
This control determines the highest frequency at which the subwoofer
reproduces sounds. The higher you set the Crossover control, the higher
in frequency the subwoofer will operate and the more its bass will
“overlap” that of the speakers. This adjustment helps achieve a smooth
transition of bass frequencies between the subwoofer and the speakers
for a variety of different rooms and subwoofer locations.
5) Volume:
Use this control to adjust the subwoofer’s volume. Turn the knob
clockwise to increase the volume; turn the knob counterclock-wise
to decrease the volume.
6) Subwoofer (LFE Input):
Connect the subwoofer to the dedicated subwoofer / LFE
output of a receiver/processor.
7) Power Switch:
Set this switch in the ‘On’ position to turn the subwoofer on. If you
will be away from home, or will not be using the subwoofer for an
extended period, set this switch in the ‘Off’ position to conserve energy.
8) Power Input:
After you have made and verified the subwoofer’s input connection,
plug the power cord into an active, unswitched electrical outlet for
proper operation of the subwoofer.
DO NOT plug the power cord into the accessory outlets found on
some audio components.
ON
OF F
PO W POWER
INPUT
ER
PW R
BLUE:ON
RE D :STA NDBY
RE V ERS E
NO R MAL
PHASE
MO D E
AU TO
ON
CROSSOVER VOLUME
MI N M A X
50Hz 150Hz
SUBWOOFER
IN P U T
PO W E R
SUB 100P

ON
OFF
POW POWER
INPUT
ER
PWR
BLUE:ON
RED:STANDBY
REVERSE
NORM AL
PHASE
MODE
AUTO
ON
CROS SOV ER VO LUME
MIN MA X
50Hz 1 50H z
SUBW OOF ER
IN PUT
POWE R
SUB 100P
ON
OFF
POW POWER
INPUT
ER
PWR
BLUE:ON
RED:STANDBY
REVERSE
NORM AL
PHASE
MODE
AUTO
ON
CROS SOV ER VO LUME
MIN MA X
50Hz 1 50H z
SUBW OOF ER
IN PUT
POWE R
SUB 100P
3
www.jbl.com
English
PLACING THE SUBWOOFER
CONNECTING THE SUBWOOFER
The performance of a subwoofer is directly related to its placement in the listening room
and its physical position relative to the other speakers in the system.
While it is true that in general our ears do not hear directional sounds at the low
frequencies where subwoofers operate, when installing a subwoofer within the limited
confines of a room, the reflections, standing waves and absorptions generated within
the room will strongly influence the performance of any subwoofer system. As a result,
the specific location of the subwoofer in the room does become important to the
amount and quality of bass that is produced.
For example, placing the subwoofer next to a wall generally will increase the amount of
bass in the room; placing it in a corner (1) generally will maximize amount of bass in the
room. However, corner placement can also increase the destructive effect of standing
waves on bass performance. This effect can vary depending on the listening position
– some listening positions may yield very good results while others may have far too
much (or too little) bass at certain frequencies.
We strongly recommend that you experiment with placement before choosing a final
location for your subwoofer. One way you can determine the best location for the sub-
woofer is by temporarily placing it in the listening position and playing music with strong
bass content. Move around to various locations in the room while the system is playing
(putting your ears where the subwoofer would be placed), and listen until you find the
location where the bass performance is best. Place the subwoofer in that location.
Front Left
Speaker
TV
Center
Speaker Front Right
Speaker
Surround Left
Speaker Surround Right
Speaker
1.
2.
3.
TO A RECEIVER OR PREAMP/PROCESSOR WITH A LOW-PASS FILTERED DEDICATED SUBWOOFER OUTPUT (LFE)
TO A RECEIVER OR PREAMP/PROCESSOR WITH PREAMP OUTPUTS
SUBWOOFER
LFE OUT
PREAMP
OUTPUT
Receiver/Processor
Receiver/Processor
In many rooms, placing the subwoofer along the same plane as the left and right
speakers (2) can produce the best integration between the sound of the subwoofer
and that of the left and right speakers. In some rooms, the best performance could
even result from placing the subwoofer behind the listening position (3).
SUBWOOFER
IN PU T
SUBWOOFER
IN PU T
NOTE: This subwoofer / LFE cable is not included,
but can be purchased from an electronics retailer.
• Be sure to turn the Crossover on the subwoofer
fully clockwise when using this type of connection.
This type of setting bypasses the subwoofer’s
internal crossover and uses your receiver or
processor’s crossover.
• Check your receiver or processor menu settings and
set the subwoofer selection to ‘On’ or ‘Yes.’
Please be sure to review the owner’s manual for your
receiver or processor for more information on speaker
setup and configuration.
• We recommend setting the subwoofer’s Crossover
setting to 80Hz for mid-sized speakers, higher for
smaller (satellite) speakers, and lower for larger
floorstanding speakers.
NOTE: This special subwoofer / LFE cable is not
included, but can be purchased from an electronics
retailer. An RCA Y-Adapter cable can also be used to
make this type of connection.

HARMAN International Industries, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA
TURNING THE SUBWOOFER ON AND OFF
Set the subwoofer’s Power Switch to the ‘On’ position. Now set the
subwoofer’s Power Mode to the ‘Auto’ position. The subwoofer will
automatically turn itself on when it receives an audio signal, and it will
go into Standby mode after it has received no audio signal for
approximately 10 minutes. The subwoofer’s LED will glow blue when
the subwoofer is on and will glow red when the subwoofer is in Standby.
If you will not be using the subwoofer for an extended period – for
instance, if you’re going on vacation – set the Power Switch to the
‘Off’ position.
SUBWOOFER ADJUSTMENTS: CROSSOVER
The Crossover control adjusts the subwoofer’s built-in low-pass filter
crossover between 50Hz and 150Hz. The higher you set the Crossover
control, the higher in frequency the subwoofer will operate and the
more its bass will ‘overlap’ that of the speakers. This adjustment
helps achieve a smooth transition of bass frequencies between the
subwoofer and the speakers for a variety of different rooms and
subwoofer locations.
To set the Crossover control, listen for the smoothness of the bass.
If the bass seems too strong at certain frequencies, try a lower
Crossover control setting. If the bass seems too weak at certain
frequencies, try a higher Crossover control setting.
SUBWOOFER ADJUSTMENTS: VOLUME
Use the volume control to set the subwoofer’s volume. Turn the knob
clockwise to increase the subwoofer’s volume; turn the knob
counterclock-wise to decrease the volume. Once you have balanced
the subwoofer’s volume with that of the other speakers in your system,
you shouldn’t have to change the volume control setting.
Notes on Setting Subwoofer Volume:
• Sometimes the ideal subwoofer volume setting for music is too loud
for films, while the ideal setting for films is too quiet for music. When
setting the subwoofer volume, listen to both music and films with
strong bass content and find a ‘middle ground’ volume level that
works for both.
• If your subwoofer always seems too loud or too quiet, you may want
to place it in a different location. Placing the subwoofer in a corner will
tend to increase its bass output, while placing it away from any walls
or corners will tend to lessen its bass output.
SUBWOOFER ADJUSTMENTS: PHASE
The Phase switch determines whether the subwoofer driver’s piston-like
action moves in and out in phase with the speakers. If the subwoofer
were to play out of phase with the speakers, the sound waves from the
speakers could partially cancel out the waves from the subwoofer,
reducing bass performance and sonic impact. This phenomenon
depends in part on the placement of all the speakers relative to each
other and the listener(s) in the room.
Although in most cases you should leave the Phase switch in the
‘Normal’ position, there is no absolutely correct setting for the Phase
switch. When the subwoofer is properly in phase with the speakers, the
sound will be clearer and have maximum impact, and percussive sounds
like drums, piano and plucked strings will sound more life-like. The best
way to set the Phase switch is to listen to music that you know well and
to set the switch in the position that gives drums and other percussive
sounds maximum impact.
USING THE SUPPLIED CARPET SPIKES
Four metal spikes are supplied for use when you place the subwoofer on
a carpeted surface. Do not use these spikes when placing subwoofer on
non-carpeted surfaces.
To insert the spikes:
1. Gently lay the subwoofer on its side (not its front or back) on a soft,
nonabrasive surface.
2. Screw each spike into the threaded insert in each foot. Make sure all
four spikes are screwed in completely for stability.
Note: NEVER drag the subwoofer to move it. Always carefully lift the
subwoofer and carry it to its new location.
© 2014 HARMAN International Industries, Inc. All rights reserved.
JBL is a trademark ofHARMAN International Industries, Incorporated, registered in the United States and/or other countries.
Features, specifications and appearance are subject to change without notice.
www.jbl.com XXX-XXXX_A
OPERATING THE SUBWOOFER
