jcb 215T User manual

215T
QUICK REFERENCE GUIDE
This Quick Reference Guide DOES NOT replace the Operators
Manual. You MUST read ALL the disclaimers and safety and other
instructions in the Operators Manual before initially operating this
product. Accordingly, no legal claims can be entertained based on
the data, illustrations or descriptions in this Quick Reference Guide.
Access additional information
www.servicepro.jcb.com
Driving Controls –ISO Pattern
Start Up Sequence
Static Dimensions
Tie Down Points
Cab and Switch Panel
Driving Controls –H Pattern
A. Left armrest (contains 12V socket)
B. Right interlock bar
C. Left joystick control lever
D. Right joystick control lever
E. Left switch panel
F. Radio
G. Front panel
H. Cab HVAC (optional)
J. Instruments
K. Hand throttle
L. Ignition Switch
P. Foot throttle control (optional)
Q. Interior rear view mirror
A. Front tie down point
B. Rear tie down points
C. Blocks
D. Machine height
E. Tie down point label
A. Left Joystick Control Level
B. Forward Drive
C. Backward Drive
D. Forward Left Drive
E. Forward Right Drive
F. Backward Left Drive
G. Backward Right Drive
H. Spin turn left
J. Spin turn right
Left Joystick Control Lever
Right Joystick Control Lever
Forward drive
Forward Right drive
Forward left drive
A.
B.
CD.
C.
D.
Spin turn left
Spin turn right
Backwards left drive
Backwards right drive
Backwards drive
DE.
CF.
F.
E.
EF.
Revision 1.0
12/2/2020
**Tie Down Points are same on Wheel & Track models**

Lift Arm Controls
Access Covers
Instrument Panel
Service Points
1. Two speed (option) / creep speed drive control
(option)
2. Horn
3. Turn signal (option)/ creep setting (option)
Controls –Right Joystick
1. Auxiliary proportional control switch
2. Auxiliary proportional control hold switch
3. Float switch (option)
A. Engine coolant temperature high
B. Fuel level
C. Hydraulic oil temperature
D. Seat belt/restraint/pod warning
E. Alternator not charging
F. Cold start active
G. Hydraulic oil pressure
H. Engine oil pressure
J. Park brake on
K. Creep
L. Direction Indicators
M. Malfunction
N. High speed
O. Shovel float
P. Air filter blocked
Q. Info and hour meter display
Controls –Left Joystick
Left Hand Switch Panel
A. Powered Quickhitch unlock (option)
B. SRS
C. High flow auxiliary (option)
D. ISO control pattern
E. H control pattern (option)
F. Powered Quickhitch lock (option)
G. Reversing fan (option)
H. Sidelights (option)
J. Hazard warning lights (option)
Left Hand Switch Panel
A. Info button
B. Front/rear work/road lights
(option)
C. Lift arm isolate
D. Electro-hydraulic attachment
positioning system (option)
E. Auxiliary hydraulics isolate switch
F. Up
G. Down
H. Park brake/drive and lift
arm/auxiliary hydraulics isolate
J. Hand throttle control knob
K. Ignition switch
L. LCD screen
ISO Pattern
1. Lift arm raise
2. Lift arm lower
3. Float switch
4. Shovel dump
5. Shovel crowd
1. Lift arm raise
2. Lift arm lower
3. Float switch
4. Shovel dump
5. Shovel crowd
H-Pattern (option)
Parallel Lift (option)
A. Parallel lift switch
Auxiliary Circuit Controls
A. Auxiliary coupler
B. Auxiliary coupler
C. Auxiliary drain coupler
A. Coolant expansion bottle
B. Fuel sedimenter
C. Air intake
D. Engine oil filler cap
E. Engine oil dipstick
F. Hydraulic oil level indicator, Hydraulic oil filler cap
G. Battery isolator
H. Battery
J. Radiator
K. Radiator cap
L. Window washer fluid bottle
M. Track tensioner
N. Sprocket
A. Handle
B. Locking pin
D. Locking position
B. Locking pin
C. Stowage position
