Issue #4119-IGE-01-00

RBA-40C™

Banknote Acceptor

Integration Guide

Revision A, January 27, 2020

This product document (hereinafter referred to as “Manual”) is fully covered by legal Copyrights owned by the JAPAN

CASH MACHINE CO., LTD. (hereinafter referred to as “JCM”) under Japanese laws and other Foreign Countries. 

This Manual contains many copyrighted, patented or properly registered equipment items manufactured by JCM, that

are prohibited and illegal to duplicate, replicate, copy in whole, or in part, without the express authorization by JCM with

the following exceptions:

1. When an authorized JCM agency or distributor duplicates the Manual for sales promotion and/or service 

maintenance of the product, or technical service personnel education as required; and

2. When an end user duplicates the Manual to maintain operation of the product or operate the product in general. 

JCM retains all rights to amend, alter, change or delete any portion of this Manual in whole, or in part, or add items 

thereto without notice regarding the product or its related products.

JCM is a registered trademark of JAPAN CASH MACHINE CO., LTD. All other product names mentioned herein may be

registered trademarks or trademarks of their respective companies. Furthermore, ™, ® and © are not always mentioned

in each case throughout this publication.

RBA-40C™ Banknote Acceptor Integration Guide

Electrical Current Symbol

Direct Current: indicates Direct Current values on product labels.

International Compliance

• RoHS Directive

• CE Mark

• CB Scheme

NOTE: All the compliance confirmations above are currently being examined for approval.

The JCM Website for patents is: http://www.jcm-hq.co.jp/english/patents/

REVISION HISTORY

Rev №.Date Reason for Update Comment

A Jan-27-2020 Initial Release

or or or

This product must not be used in residential areas.

Issue #4119-IGE-01-00

RBA-40C™

Banknote Acceptor

Table of Contents

Page

1 GENERAL INFORMATION ........................................................................................1

RBA-40C Unit......................................................................................................................1

Product Descriptions.........................................................................................................2

Model Descriptions...............................................................................................................2

Type Descriptions ................................................................................................................2

Software Descriptions ..........................................................................................................2

Precautions.........................................................................................................................2

User Cautions ......................................................................................................................2

Installation Cautions........................................................................................................................ 2

Mounting, Dismounting & Transportation........................................................................................ 3

Operation Cautions ......................................................................................................................... 3

Preventive Maintenance.......................................................................................................3

Banknote Fitness Requirements..........................................................................................3

Primary Features................................................................................................................4

Component Names ............................................................................................................5

2 SPECIFICATIONS ......................................................................................................6

Technical Specifications ..................................................................................................6

Environmental Specifications ..........................................................................................7

Electrical Specifications....................................................................................................7

Structural Specifications...................................................................................................7

3 INSTALLATION ..........................................................................................................8

DIP Switch Settings ...........................................................................................................8

SW1 (DIP Switch Block 1)....................................................................................................8

SW2 (DIP Switch Block 2)....................................................................................................8

4 CONNECTOR PIN ASSIGNMENT .............................................................................9

Power Supply Connector Pin Assignment; TTL and Encoder ............................................9

Power Supply Connector Pin Assignment; USB and Encoder .........................................10

Bezel Connector Pin Assignment ..................................................................................11

5 PREVENTIVE MAINTENANCE ................................................................................12

Clearing a Banknote Jam...................................................................................................12

Opening the Centering Mechanism....................................................................................12

Cleaning Procedures..........................................................................................................12

RBA-40C Sensors and Cleaning Locations .......................................................................13

6 STANDARD INTERFACE CIRCUIT SCHEMATICS ................................................15

RBA-40C TTL and Encoder Interface Circuit Schematic ...................................................15

RBA-40C USB and Encoder Interface Circuit Schematic ..................................................16

RBA-40C Bezel LED Light Controller Circuit Schematic....................................................17

7 OPERATIONAL FLOWCHARTS..............................................................................19

Initialization and Banknote Acceptance Flowchart.............................................................19

Validation Flowchart...........................................................................................................20

Discharging Flowchart........................................................................................................21

Table of Contents

Page

RBA-40C™ Banknote Acceptor

8 TROUBLESHOOTING ............................................................................................. 22

Introduction ......................................................................................................................22

Troubleshooting Overview..............................................................................................22

Fault Table Listings .........................................................................................................22

Error Codes ......................................................................................................................24

Reject Codes ....................................................................................................................25

LED Flash Reject Error Code Conditions; Banknotes........................................................26

LED Reject Error Code Conditions; Barcode Tickets.........................................................27

9 UNIT DIMENSIONS.................................................................................................. 29

RBA-40C without Bezel Outside Dimensions ....................................................................29

10 TECHNICAL CONTACT INFORMATION ................................................................ 31

Americas ............................................................................................................................31

JCM American ...............................................................................................................................31

Europe, Middle East, Africa & Russia ................................................................................31

JCM Europe GmbH .......................................................................................................................31

UK & Ireland.......................................................................................................................31

JCM Europe (UK Office) ................................................................................................................31

Asia and Oceania...............................................................................................................31

JCM Gold (HK) Ltd. .......................................................................................................................31

JAPAN CASH MACHINE CO., LTD. (HQ).....................................................................................31

11 INDEX.......................................................................................................................33

iii

RBA-40C™

Banknote Acceptor

List of Figures Page

Figure 1 RBA-40C Unit..............................................................................................1

Figure 2 Precautionary Symbols ...............................................................................2

Figure 3 Unacceptable Banknotes ............................................................................3

Figure 4 Automatic Centering Mechanism ................................................................4

Figure 5 RBA-40C Component Names .....................................................................5

Figure 6 Clearing a Banknote Jam..........................................................................12

Figure 7 Opening the Centering Mechanism...........................................................12

Figure 8 General Cleaning Image ...........................................................................12

Figure 9 RBA-40C Sensors and Cleaning Locations ..............................................13

Figure 10 RBA-40C TTL and Encoder Interface Circuit Schematic ..........................15

Figure 11 RBA-40C USB and Encoder Interface Circuit Schematic .........................16

Figure 12 RBA-40C Bezel LED Light Controller Circuit Schematic...........................17

Figure 13 RBA-40C Initialization and Banknote Acceptance Flowchart....................19

Figure 14 RBA-40C Validation Flowchart..................................................................20

Figure 15 RBA-40C Discharging Flowchart ..............................................................21

Figure 16 RBA-40C without Bezel Outside Dimension .............................................29

THIS PAGE INTENTIONALLY LEFT BLANK

RBA-40C™

Banknote Acceptor

List of Tables Page

Table 1 RBA-40C Model Number Specifications .....................................................2

Table 2 RBA-40C Type Number Specifications .......................................................2

Table 3 RBA-40C Software Number Specifications.................................................2

Table 4 RBA-40C Technical Specifications .............................................................6

Table 5 RBA-40C Environmental Specifications......................................................7

Table 6 RBA-40C Electrical Specification ................................................................7

Table 7 RBA-40C Series Structural Specification ....................................................7

Table 8 SW1 (DIP Switch Block 1) Settings.............................................................8

Table 9 SW2 (DIP Switch Block 2) Settings.............................................................8

Table 10 Power Supply Connector Pin Assignments (TTL and Encoder) .................9

Table 11 Power Supply Connector Pin Assignments (USB and Encoder) ..............10

Table 12 RBA-40C Bezel Connector Pin Assignments............................................11

Table 13 RBA-40C Sensor Type Cleaning Methods................................................13

Table 14 General Fault Conditions ..........................................................................22

Table 15 Calibration Fault Conditions ......................................................................23

Table 17 RBA-40C Unit LED Flash Error Codes .....................................................24

Table 16 Communication Fault Conditions ..............................................................24

Table 18 LED Flash Reject Error Codes For Banknotes .........................................26

Table 19 LED Flash Reject Error Codes For Barcode Tickets.................................27

THIS PAGE INTENTIONALLY LEFT BLANK

RBA-40C™

Banknote Acceptor

Integration Guide

Revision A

This section provides a general overview of the

RBA-40C™ Banknote Acceptor (RBA-40C), pic-

tured in Figure 1. This section is designed to help

the user navigate through this guide with ease. It

includes the following information:

• RBA-40C Unit

• Product Descriptions

• Precautions

• Primary Features

• Component Names

In order to make operating this device and 

navigating within this manual easier, the following

illustrations are used:

• Safety Instructions need to be observed in order to

protect the operators and the equipment; these are

identified with Bold text and the following

pictographs:

• Special Notes affect the use of the RBA-40C Unit;

these are identified with italic text and the following

pictograph:

• Steps require the operator to perform specific

actions; these are identified with sequential

numbers (1, 2, 3, etc.).

1 GENERAL INFORMATION

RBA-40C Unit

Figure 1 RBA-40C Unit

Section 1 RBA-40C™ Banknote Acceptor General Information

Product Descriptions

Model Descriptions

Table 1 lists the product model number

descriptions.

Type Descriptions

Table 2 lists the product type number descrip-

tions.

Software Descriptions

Table 3 lists the software number descriptions.

Precautions

The Figure 2 symbols are defined as follows:

1. (Type 1) Do not insert a damaged or exhibited

unfit condition Banknote; it may cause a jam

inside the unit.

2. (Type 2) Do not expose the unit to water. The unit

contains several precision electronic devices that

can be damaged if water or any liquid is sprayed

or spilled into the unit.

3. (Type 3) Do not install the unit in a dusty 

environment. Dust may damage the unit or

degrade its performance.

User Cautions

Careful measures were taken in the design of this

product to ensure its quality; however, the follow-

ing cautions pertain to all users and should be fol-

lowed for safe operation.

Installation Cautions

The Installation Cautions are defined as follows:

1. Do not allow the Unit to endure or operate at a

high temperature, in high humidity and/or in a

dusty environment.

2. Do not install the Unit into an area where exces-

sive vibration or shock is present or strong exter-

nal pressure is applied.

3. The Unit is not designed for outdoor installation.

Be sure that the Host Machine contains enough

protection to avoid wet or dusty conditions,

including the internal unit assemblies, when

installing in either an indoor or open-air space.

4. Avoid exposing the Unit to direct Sunlight and/or

incandescent Lamp Illumination. (Refer to

“Environmental Specifications” on page 7).

5. Ensure that the Host Machine is designed for

daily operational access for maintenance and/or

clearing a Banknote Jam. (Refer to “Unit Dimen-

sions” on page 29).

6. Do not use the Unit where it may be exposed to

airborne evaporated or sporadic chemicals and/or

oil.

Table 1 RBA-40C Model Number Specifications

(1) Model Number

4 = Standard

(2) Model Series Number

0 = Standard

1-9 = Reserved

Table 2 RBA-40C Type Number Specifications

(1) Denomination (Country Code)*

*. The Country Code is indicated per the ISO 3166 standard.

(2) Bezel

0 = Without Bezel (Standard)

1-9 = Reserved

(3) Reserved

(4) Magnetic Sensor

0 = Without Magnetic Sensor (Standard)

1 = With Magnetic Sensor

(5) Interface Protocol ID

64 = ID-064GD†

** = Last 2 digits of interface ID

†. Serial communication protocol developed by ADP.

Table 3 RBA-40C Software Number Specifications

(A) Denomination (Country Code)*

*. The Country Code is indicated per the ISO 3166 standard.

(B) Interface Protocol Name

Model: RBA - 4 0C

(1) (2)

Type: * * * (*) - * * * - * *

(1) (4) (5)(2)(3)

(A)

Software: RBA-40C (* * *) ID 0 * * V * * *

(B) (C)

Caution: User cautions should be

included in any user guides or manuals.

Caution: Careful measures were taken in

the design of this product to ensure its

quality; however, ensure that a fail-safe

design is used for the Host Machine to

assure safety.

Figure 2 Precautionary Symbols

Type1 Type2 Type3

NOTE: Refer to “Banknote Fitness

Requirements” on page 3.

General Information RBA-40C™ Banknote Acceptor Section 1

7. Ensure that the Host Machine is designed consid-

ering the risk of electronic components that can

cause induced noise. The noise generated by the

components on the Host Machine may affect and

degrade the Validation performance.

Mounting, Dismounting & Transportation

Methods for mounting, dismounting & 

transporting the RBA-40C Unit:

1. Be sure to turn the Unit’s Power OFF before

mounting or removing the Unit from its perma-

nent location. Plugging or unplugging Connec-

tors from their Receptacles while the Power is

ON may cause damage to the Unit.

2. When reassembling a disassembled Unit Section,

ensure that each part is properly replaced into its 

correct location.

3. Be careful not to use excessive outside pressure

on the Unit, or subject it to excessive vibration

during transportation.

4. Do not throw or apply external pressure on the

Unit. Improper handling may cause personal

injury and/or damage to the equipment.

5. Be sure to carry the Unit by both hands when

transporting it for your safety.

Operation Cautions

The Operation Cautions are defined as follows:

1. When closing the Unit, ensure all Service Door

including the Upper Guide locks securely.

2. Ensure that the RBA-40C Unit is properly placed

into its correct location.

Preventive Maintenance

The preventive maintenance requirements are

defined as follows:

1. Be sure to turn the Unit’s Power OFF before

beginning a cleaning or maintenance procedure. 

Cleaning or performing maintenance while the

Power is turned on may cause personal injury if

the Unit mechanisms accidentally move.

2. To keep the RBA-40C Unit’s performance and

Banknote acceptance at optimal rates, clean and

maintain the Unit regularly. (Refer to “Cleaning

Procedures” on page 12 for the cleaning proce-

dures and schedule).

3. Perform cleaning and maintenance regularly

when using the equipment in an smoky environ-

ment such as where excessive Automobile

exhaust emission or Cigarette Smoke may exist.

4. Do not redesign or disassemble the Unit. 

Unauthorized use by inadequately trained 

personnel, or use outside the original manufac-

turer’s intent voids the warranty.

5. If the Unit is exposed to water or other liquids,

use a clean Micro-fiber Cloth to wipe off and

absorb excess liquids immediately. Any 

remaining liquids may affect and degrade the

Sensors and Validation performance.

Banknote Fitness Requirements

The following Banknote types may not validate

correctly, or worse, can cause a Banknote jam and/

or damage to the Unit’s Transport Path. Banknotes

exhibiting the following conditions illustrated in

Figure 3 should be avoided:

• Torn

• Worn

• Taped

• Excessive folds or wrinkles

• Dirty

• Wet and/or Oiled

• Adhering foreign objects

• Excessive miscuts, misaligns and/or misprints

WARNING: This Unit is designed for

use with a Limited Power Source!

Design the Host Cabinet space to meet

all local related safety standards.

WARNING: Make sure Interface Harness

connections to the Host Machine are

shorter than 9.84 Feet (3 Meters) in

length. Cut off all unused portions of

the Interface Harness wiring to avoid

static electrical effects or short circuit

possibilities that could cause damage

to the Unit. (Refer to “Connector Pin

Assignment” on page 9 for the

recommended wires).

WARNING: Do not inject water or liquid

agents of any kind into the Unit, as this

may cause extreme damage to the Unit.

Caution: Do not use Alcohol, thinner or

Citrus based products for cleaning any

Banknote Transport Sensors or surfaces.

The lenses can become clouded by

chemical evaporation residue that may

cause acceptance errors.

Caution: Be careful to avoid personal

injury to your fingers when closing the

Upper Guide Section.

Figure 3 Unacceptable Banknotes

Damaged or Taped Banknotes

Wrinkled or Folded Banknotes

Curled, Folded or Partial Banknotes

Dirty Banknotes Wet or Oiled Banknotes

Section 1 RBA-40C™ Banknote Acceptor General Information

Primary Features

The RBA-40C Banknote Acceptor Unit contains

the following primary features:

• Proven Anti-Pullback Technology – The JCM

patented Anti-Pullback Mechanism provides

powerful protection against Banknote

stringing.

• Automatic Centering – The Centering

Mechanism allows the unit to read Banknotes

ranging from 60mm to 85mm in width without

using special Banknote Guides. It helps to

improve the overall acceptance rate

Figure 4 Automatic Centering Mechanism

60mm-85mm

General Information RBA-40C™ Banknote Acceptor Section 1

Component Names

Figure 5 illustrates the RBA-40C component names and locations.

Figure 5 RBA-40C Component Names

a) RBA-40C Unit (Acceptor Head Unit)

b) Upper Guide Open/Close Button

c) Acceptor Unit Release Latch

d) Centering Guide Open Shaft

e) Red Status LED

f) Green Status LED

g) USB Type-C Connector (Maintenance)

h) SW 1 (DIP Switch Block 1)

i) SW 2 (DIP Switch Block 2)

j) Bezel Connector

k) Power Supply /Interface Connector

Bottom View

Section 2 RBA-40C™ Banknote Acceptor Specifications

2 SPECIFICATIONS

This section provides specifications of the RBA-40C™ Series Banknote Acceptor (RBA-40C).

Technical Specifications

Table 4 RBA-40C Technical Specifications

Acceptance Rate*:

*. The Banknotes accepted on the second attempt are included. The Acceptance Rate Test was conducted on more than 100 Banknotes. The Acceptance Rate may not be true

for the security-hardened Unit (against the counterfeit notes). Refer to the specific Country’s “Software Information Sheet” for each Country’s particular Banknote acceptance

rate.

99% or greater

The following banknote types are excluded:

•Banknotes with excess or poor magnetism or unclear graphics

•Double (dual) Notes

•Worn, dirty, wet, stained, torn or excessively wrinkled Banknotes

•Banknotes having folded corners or edges

•Banknotes having the wrong cut dimensions or printing displacement

•Returned Banknotes because of incorrect or failed insertion.

Banknote Types Accepted†:

†. Refer to the “Software Information Sheet” for more details.

•Long side: 110-181mm (4.33-7.12 in.)

•Short side: 60-85mm (2.36-3.34 in.)

Insertion Direction†:Banknote: Four-way

Barcode Ticket: Four-way

Barcode Ticket‡:

‡. Refer to the “Barcode Ticket Specification” for more details.

1D Barcode

•Read code interleaved: 2 of 5

•Narrow Bar: 0.5-0.6mm (0.019-0.023 in.)

•Wide Bar to Narrow Bar ratio = 3:1

•Characters: 18 Characters

•Print Position: Middle (Divides a Ticket equally from the left, right, top and bot-

tom of the Ticket’s center

•Print Width: Wider than 10mm (0.39 in.)

2D Barcode

•Format: QR Code

•Variant: Model 2

•Version: 1 - 3

•Error Correction: Level H (Highest)

•Encoding: Numeric, alphanumeric

•Module Size: Minimum 1mm

Processing Speed**:

**. Excluding Host Communication time lag.

Approximately 1.8 seconds

(from Banknote insertion to sending Vend Signal)

Escrow: 1 Note

Validation Method: CIS

Magnetic Sensor (Optional)

Anti-stringing Mechanism: Pull-Back (PB) Unit (Anti-Pullback System - JCM Patented)

Diagnostic Indicators: Green Status LED

Red Status LED

Interface: TTL Serial Interface

USB (USB Specification Rev. 2.0 Compliance) (Full Speed/12Mbps)

Specifications RBA-40C™ Banknote Acceptor Section 2

Environmental Specifications

Electrical Specifications

Structural Specifications

Table 5 RBA-40C Environmental Specifications

Operating Temperature: +5ºC to +50ºC (41ºF to 122ºF)*

*. Depends on hydrothermal conditions.

Storage Temperature: -20ºC to +60ºC (-4ºF to 140ºF)*

Relative Operating Humidity: 30%RH to 85%RH (non-condensed)

Relative Storage Humidity: 30%RH to 85%RH (non-condensed)

Visible Light Sensitivity:

Avoid contact with direct sunlight.

Interior lighting must be incandescent with a Radiant Angle of 15º degree

or more having an illumination index of 3000 lux or less

Installation:

Indoors Only, No cabinet vibration

Table 6 RBA-40C Electrical Specification*

*. Measured on a brand new and factory default RBA-40C Unit.

Supply Voltage:†

†. Use a Limited Power Source.

24V DC (±5%)

Current Consumption:

•Standby = 0.2A

•Operation = 0.5A

•Peak = 1.4A

Table 7 RBA-40C Series Structural Specification

Weight: Approximately 1.2kg (2.64lbs)

Mounting: Horizontal, 0 degrees, ±0 degrees angle (parallel to the Banknote insertion direction)

Outside Dimensions: Refer to “Unit Dimensions” on page 29.

100

050 10 15 20 25 30 35 40 45 50 55 60

Hydrothermal Condition Table

Relative Humidity [%RH]

Allowable

and Relative Humidity Range

35ºC/85%RH

50ºC/40%RH

Operating Temperature

Temperature [°C]

NOTE: Refer to “Installation Cautions” on page 2 for the details.

Section 3 RBA-40C™ Banknote Acceptor Installation

3 INSTALLATION

This section provides the installation and operating

instructions for the RBA-40C™ Series Banknote

Acceptor (RBA-40C). It includes the following

information:

• DIP Switch Settings

DIP Switch Settings

SW1 (DIP Switch Block 1)

The acceptable denominations can be configured

by SW1.

SW2 (DIP Switch Block 2)

The interface and functions can be configured by

SW2.

Table 8 SW1 (DIP Switch Block 1) Settings

Switch No. ON/OFF Description

ON VEND 1 INHIBIT

OFF VEND 1 ACCEPT

ON VEND 2 INHIBIT

OFF VEND 2 ACCEPT

ON VEND 3 INHIBIT

OFF VEND 3 ACCEPT

ON VEND 4 INHIBIT

OFF VEND 4 ACCEPT

ON VEND 5 INHIBIT

OFF VEND 5 ACCEPT

ON VEND 6 INHIBIT

OFF VEND 6 ACCEPT

ON VEND 7 INHIBIT

OFF VEND 7 ACCEPT

8OFF*

*. Never Switched to ON.

OFF (Fixed)

12345678

SW1

Table 9 SW2 (DIP Switch Block 2) Settings

Switch

No. ON/OFF Description

ON Anti-Pullback System: Enable

OFF Anti-Pullback System: Disable

2OFF Reserved

ON Return a detected note upon power up*

*. Limited to ID-064GD.

OFF Notify a Host of the note detection upon

power up*

4OFF Reserved

ON Barcode Ticket Acceptance: Enable

OFF Barcode Ticket Acceptance: Disable

ON Check Mode-bit: Disable

OFF Check Mode-bit: Enable

7OFF Reserved

ON Pause Dispensing: Enable*

OFF Pause Dispensing: Disable*

12345678

SW2

Connector Pin Assignment RBA-40C™ Banknote Acceptor Section 4

4 CONNECTOR PIN ASSIGNMENT

This section provides the pin assignments of the RBA-40C™ Series Banknote Acceptor (RBA-40C).

Power Supply Connector Pin Assignment; TTL and Encoder

Table 10 Power Supply Connector Pin Assignments (TTL and Encoder)

Socket (RBA-40C Side): DRA-20PC-FO (JAE)

Contact (RBA-40C Side): D02-22-26P-10000 (JAE)

Socket (MD-100 Side): DRA-20SC-FO (JAE)

Contact (MD-100 Side): D02-22-26S-10000 (JAE)

Recommended Wire: Ul1571 AWG#26

Pin No. Signal Name I/O*

*. I/O (input/output) is the terminal as viewed from the Banknote Acceptor.

Function

1NC -No Connection

2NC -No Connection

3NC -No Connection

4GND -Ground

5+5V -5V DC Power Supply

6NC -No Connection

7NC -No Connection

8NC -No Connection

9NC -No Connection

10 NC -No Connection

11 NC -No Connection

12 NC -No Connection

13 NC -No Connection

14 NC -No Connection

15 NC -No Connection

16 NC -No Connection

17 NC -No Connection

18 NC -No Connection

19 MD-100_ENC1 OUT MD-100 Encoder Signal 1 (Photointerrupter Emitter Signal)

20 MD-100_ENC2 OUT MD-100 Encoder Signal 2 (Transistor Collector Signal)

21 MD-100_5V IN 5V DC Power Supply

22 NC -No Connection

23 +24V -24V DC Power Supply

24 TTL-RXD IN TTL Input Signal Line

25 TTL-TXD OUT TTL Output Signal Line

26 GND -Ground

CAUTION: Pin #5 is designed to supply +5V DC power to Pin #21 via the ADP’s PCB. 

Do Not use Pin #5 for other purposes to avoid the risk of damage to the Unit.

Front View

Section 4 RBA-40C™ Banknote Acceptor Connector Pin Assignment

Power Supply Connector Pin Assignment; USB and Encoder

Table 11 Power Supply Connector Pin Assignments (USB and Encoder)

Socket (RBA-40C Side): DRA-20PC-FO (JAE)

Contact (RBA-40C Side): D02-22-26P-10000 (JAE)

Socket (MD-100 Side): DRA-20SC-FO (JAE)

Contact (MD-100 Side): D02-22-26S-10000 (JAE)

Recommended Wire: Ul1571 AWG#26

Pin No. Signal Name I/O*

*. I/O (input/output) is the terminal as viewed from the Banknote Acceptor.

Function

1NC -No Connection

2NC -No Connection

3NC -No Connection

4GND -Ground

5+5V -5V DC Power Supply

6NC -No Connection

7NC -No Connection

8NC -No Connection

9NC -No Connection

10 USB Vbus -USB Communication Vbus Signal Line

11 USB D+ IN/OUT USB Communication D+ Signal Line

12 USB D- IN/OUT USB Communication D- Signal Line

13 USB GND -USB Communication Ground

14 NC -No Connection

15 NC -No Connection

16 NC -No Connection

17 NC -No Connection

18 NC -No Connection

19 MD-100_ENC1 OUT MD-100 Encoder Signal 1 (Photointerrupter Emitter Signal)

20 MD-100_ENC2 OUT MD-100 Encoder Signal 2 (Transistor Collector Signal)

21 MD-100_5V IN 5V DC Power Supply

22 NC -No Connection

23 +24V -24V DC Power Supply

24 NC -No Connection

25 NC -No Connection

26 GND -Ground

CAUTION: Pin #5 is designed to supply +5V DC power to Pin #21 via the ADP’s PCB. 

Do Not use Pin #5 for other purposes to avoid the risk of damage to the Unit.

Front View

Connector Pin Assignment RBA-40C™ Banknote Acceptor Section 4

Bezel Connector Pin Assignment

Table 12 RBA-40C Bezel Connector Pin Assignments

Header: S7B-ZR-3.4 (JST)

Housing: ZHR-7 (JST)

Contact: SZH-002T-P0.5 (MOLEX)

Recommended Wire: UL1061 AWG#26-28

Pin No. Signal Name I/O Function

1+12V -+12V DC Power Supply

2GND -GND

3BZLED_1 -LED Drive Line (Cathode)

4BZLED_2 -LED Drive Line (Cathode)

5BZLED_3 -LED Drive Line (Cathode)

6BZLED_4 -LED Drive Line (Cathode)

7NC -No Connection

Front View

Section 5 RBA-40C™ Banknote Acceptor Preventive Maintenance

This section provides the preventive maintenance

for the RBA-40C™ Banknote Acceptor (RBA-

40C). It includes the following information:

• Clearing a Banknote Jam

• Opening the Centering Mechanism

• Cleaning Procedures

Clearing a Banknote Jam

To retrieve a jammed Banknote located inside the

Banknote Acceptor, proceed as follows:

1. Press on to the Upper Guide Open/Close Button

(Figure 6 a) located on both sides of the RBA-

40C Unit to open the Upper Guide (Figure 6 b).

2. Remove the jammed Banknote (Figure 6 c).

Opening the Centering Mechanism

If a Banknote jam occurs in the Banknote Acceptor

when the Centering Mechanism is closed, the

Upper Guide will not open. To release (open) the

Upper Guide, power cycle the Unit and allow it to

reset.

Cleaning Procedures

To clean the RBA-40C Unit, gently rub the Sen-

sors, Rollers or Belts using a dry, soft, 

lint-free, Micro-fiber Cloth ONLY.

1. Remove electrical power.

2. Press on to the Upper Guide Open/Close Button

to open the Upper Guide.

3. Clean the appropriate path and Lens of each Sen-

sor, Roller and Belt. (Refer to “RBA-40C Sen-

sors and Cleaning Locations” on page 13 for each

Sensor and Roller that requires cleaning).

5 PREVENTIVE MAINTENANCE

Figure 6 Clearing a Banknote Jam

NOTE: If power cycling fails to clear the

Banknote jam, use a 5.5mm nut driver to

rotate the Centering Guide Open Shaft, then

open the Upper Guide and remove the

Banknote from the RBA-40C unit (Figure 7).

Figure 7 Opening the Centering Mechanism

5.5mm Nut Driver

Centering Guide Open Shaft

To keep the RBA-40C Unit’s

performance optimal, perform routine

cleaning and maintenance;

• At least once a month; and/or

• Whenever Sensors, Rollers, Belts or

Banknote Path are dirty due to dust, foreign

objects or similar debris adhering to them.

Caution: Do not use alcohol, thinner or

citrus based products for cleaning any

Sensors or surfaces. The lenses can

become clouded by chemical

evaporation residue that may cause

acceptance errors.

Caution: Do not inject water or liquid

agents of any kind into the Acceptor, as

this may cause extreme damage to the

Unit.

Caution: Be sure to use non-flammable

compressed air only.

Figure 8 General Cleaning Image

Lens Roller

Dry Lint-free Cloth/Cotton Swab/

Before

Cleaning

After

Cleaning

Belt

Non-flammable Air Jet
