JCM EBA-40 Quick setup guide

© 2013, JAPAN CASH MACHINE CO., LTD.
Support: http://www.jcmglobal.com/en/contact/default.aspx website: http://www.jcmglobal.com
Issue #4103-IGE-01-00
EBA®Series
Banknote Acceptor (EBA-40)
Integration Guide
Revision A, December 4, 2013
P/N 960-000173R_Rev. A {EDP #229278}

This product document (hereinafter referred to as “Manual”) is fully covered by legal Copyrights owned by the JAPAN
CASH MACHINE CO., LTD. (hereinafter referred to as “JCM”) under Japanese laws and other Foreign Countries.
This Manual contains many copyrighted, patented or properly registered equipment items manufactured by JCM, that
are prohibited and illegal to duplicate, replicate, copy in whole, or in part, without the express authorization by JCM with
the following exceptions:
1. When an authorized JCM agency or distributor duplicates the Manual for sales promotion and/or service
maintenance of the product, or technical service personnel education as required; and
2. When an end user duplicates the Manual to maintain operation of the product or operate the product in general.
JCM retains all rights to amend, alter, change or delete any portion of this Manual in whole, or in part, or add items
thereto without notice regarding the product or its related products.
JCM is a registered trademark of JAPAN CASH MACHINE CO., LTD. All other product names mentioned herein may be
registered trademarks or trademarks of their respective companies. Furthermore, ™, ®and © are not always mentioned
in each case throughout this publication.
Copyright © 2013 By JAPAN CASH MACHINE CO., LTD.
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
• RoHS Directives
• CE Mark
• CB Scheme
NOTE: The above listed compliance confirmations are currently being examined for approval or
certification.
REVISION HISTORY
Rev №.Date Reason for Update Comment
A 12/4/13 Initial Document
or or or or
Issue #4103-IGE-01-00
International Compliance

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
i
EBA®Series
Banknote Acceptor (EBA-40)
Table of Contents Page
1 GENERAL INFORMATION......................................................................................1
Description.......................................................................................................................... 1
EBA-40 Unit ........................................................................................................................ 1
Model Descriptions ............................................................................................................. 2
Type Descriptions ...............................................................................................................2
Software Descriptions ......................................................................................................... 2
Precautions......................................................................................................................... 2
User Cautions ................................................................................................................................. 2
Installation Cautions ..................................................................................................................... 2
Mounting, Dismounting & Transportation...................................................................................... 3
Placing Foreign Objects into the Unit ...........................................................................................3
Preventive Maintenance ............................................................................................................... 3
Banknote Fitness Requirements..................................................................................................... 4
Primary Features ................................................................................................................4
Component Names ............................................................................................................. 5
2 SPECIFICATIONS....................................................................................................6
Technical Specifications...................................................................................................... 6
Environmental Specifications .............................................................................................. 7
Electrical Specifications ...................................................................................................... 7
Structural Specifications...................................................................................................... 7
3 INSTALLATION .......................................................................................................8
Installation Procedure ......................................................................................................... 8
Entire Unit Installation ..................................................................................................................... 8
Acceptor Head Installation .............................................................................................................. 8
Lock Installation .................................................................................................................. 9
DIP Switch Configurations ................................................................................................ 10
4 CONNECTOR PIN ASSIGNMENTS ......................................................................11
CONNECTOR PIN ASSIGNMENTS (Continued 1).......................................................... 12
CONNECTOR PIN ASSIGNMENTS (Continued 2).......................................................... 13
CONNECTOR PIN ASSIGNMENTS (Continued 3).......................................................... 14
CONNECTOR PIN ASSIGNMENTS (Continued 4).......................................................... 15
CONNECTOR PIN ASSIGNMENTS (Continued 5).......................................................... 16
CONNECTOR PIN ASSIGNMENTS (Continued 6).......................................................... 17
5 PREVENTIVE MAINTENANCE .............................................................................18
Retrieving Banknotes........................................................................................................ 18
Clearing a Banknote Jam.................................................................................................. 18
Cleaning Procedure .......................................................................................................... 18
Sensor and Roller Cleaning Procedure ........................................................................................ 18
Sensor and Roller Locations......................................................................................................... 19
6 STANDARD INTERFACE CIRCUIT SCHEMATICS..............................................20
STANDARD INTERFACE CIRCUIT SCHEMATICS (Continued 1)................................... 21
STANDARD INTERFACE CIRCUIT SCHEMATICS (Continued 2)................................... 22
STANDARD INTERFACE CIRCUIT SCHEMATICS (Continued 3)................................... 23
7 OPERATIONAL FLOWCHART .............................................................................24
Operational Flowchart (Continued 1)................................................................................ 25
8 TROUBLESHOOTING ...........................................................................................26
Introduction ....................................................................................................................... 26
Troubleshooting Overview ................................................................................................ 26

Table of Contents
Continued
P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
ii
Page
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
Fault Table Listings ............................................................................................................26
LED Indication Conditions .................................................................................................28
LED Flash Error Code Conditions .................................................................................................28
LED Flash Reject Code Conditions; Banknotes............................................................................30
LED Reject Error Code Conditions; Barcode Coupons.................................................................31
9 UNIT DIMENSIONS ............................................................................................... 33
Entire Unit Outside Dimensions.....................................................................................................33
Head Assembly Outside Dimensions ............................................................................................33
10 TECHNICAL CONTACT INFORMATION ............................................................. 34
Americas .......................................................................................................................................34
JCM American.............................................................................................................................34
Europe, Africa, Russia & Middle East ...........................................................................................34
JCM Europe GmbH.....................................................................................................................34
UK & Ireland ..................................................................................................................................34
JCM Europe (UK Office)..............................................................................................................34
Asia and Oceania ..........................................................................................................................34
JCM Gold (HK) Ltd. .....................................................................................................................34
JAPAN CASH MACHINE CO., LTD. (HQ)...................................................................................34
11 INDEX .................................................................................................................... 35

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
iii
EBA®Series
Banknote Acceptor (EBA-40)
List of Figures Page
Figure 1 EBA-40 Unit ...............................................................................................1
Figure 2 Precautionary Symbols ..............................................................................2
Figure 3 Unacceptable Banknotes ...........................................................................4
Figure 4 Automatic Centering Mechanism (with the SD3 Stacker) ..........................4
Figure 5 Automatic Centering Mechanism (without the SD3 Stacker) .....................4
Figure 6 EBA-40 Component Names ......................................................................5
Figure 7 M3 Screw Locations (Bottom) ....................................................................8
Figure 8 Key Hole Slot Locations (Rear) .................................................................8
Figure 9 M4 Screw Locations (Rear & Bottom) .......................................................8
Figure 10 M3 Screw Locations (Rear & Bottom) .......................................................9
Figure 11 Key Hole Location ......................................................................................9
Figure 12 Lock Dimension & Cylinder Length ............................................................9
Figure 13 Key Unlock Rotation Requirement ...........................................................10
Figure 14 Retrieving Banknotes ...............................................................................18
Figure 15 Clearing an Entrance Banknote Jam .......................................................18
Figure 16 Clearing a Stacker Box Banknote Jam ....................................................18
Figure 17 Sensor Cleaning ......................................................................................19
Figure 18 EBA-40 Sensor and Roller Cleaning Locations .......................................19
Figure 19 EBA-40 TTL Interface Schematic Diagram ..............................................20
Figure 20 EBA-40 MDB Interface Schematic Diagram ............................................20
Figure 21 EBA-40 ccTalk Interface Schematic Diagram ..........................................21
Figure 22 EBA-40 Photo-Coupler Interface Schematic Diagram .............................21
Figure 23 EBA-40 RS232C Interface Schematic Diagram ......................................22
Figure 24 EBA-40 USB Interface Schematic Diagram .............................................22
Figure 25 EBA-40 Bezel LED Interface Schematic Diagram ...................................23
Figure 26 EBA-40 Operational Flowchart (Initializing) .............................................24
Figure 27 EBA-40 Operational Flowchart (Validation) .............................................25
Figure 28 EBA-40 Operational Flowchart (Stacking) ...............................................25
Figure 29 EBA-40 Banknote Acceptor’s Outside Dimensions .................................33
Figure 30 EBA-40 Banknote Acceptor’s Outside Dimensions .................................33

THIS PAGE INTENTIONALLY LEFT BLANK
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
iv

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
v
EBA®Series
Banknote Acceptor (EBA-40)
List of Tables Page
Table 1 EBA-40 Model Number Specifications ........................................................2
Table 2 EBA-40 Type Number Specifications .........................................................2
Table 3 EBA-40 Software Number Specifications ...................................................2
Table 4 EBA-40 Technical Specifications ................................................................6
Table 5 EBA-40 Environmental Specifications ........................................................7
Table 6 EBA-40 Electrical Specifications .................................................................7
Table 7 EBA-40 Structural Specifications ................................................................7
Table 8 DIP Switch Block 1 Settings .....................................................................10
Table 9 DIP Switch Block 2 Settings .....................................................................10
Table 10 EBA-40 TTL Interface Pin Assignments ...................................................11
Table 11 EBA-40 MDB Interface Pin Assignments ..................................................12
Table 12 EBA-40 ccTalk Interface Pin Assignments ...............................................13
Table 13 EBA-40 Photo-Coupler Interface Pin Assignments ..................................14
Table 14 EBA-40 RS232C Interface Pin Assignments ............................................15
Table 15 EBA-40 CN13 RS232C Connector Pin Assignments ...............................15
Table 16 EBA-40 USB Interface Pin Assignments ..................................................16
Table 17 EBA-40 CN3 mini-B Connector Pin Assignments .....................................17
Table 18 EBA-40 CN2 Bezel Connector Pin Assignments ......................................17
Table 19 EBA-40 Sensor Type Cleaning Methods ..................................................19
Table 20 General Fault Conditions ..........................................................................26
Table 21 Adjustment Fault Conditions .....................................................................27
Table 22 Communication Fault Conditions ..............................................................28
Table 23 LED Flash Error Codes .............................................................................28
Table 24 LED Flash Reject Codes For Banknotes ..................................................30
Table 25 LED Flash Reject Error Codes For Barcode Coupons .............................31

THIS PAGE INTENTIONALLY LEFT BLANK
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
vi

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
1
EBA®Series
Banknote Acceptor (EBA-40)
Integration Guide
Revision A
Description
This section provides a general overview of the
EBA®Series Banknote Acceptor Unit (EBA-40),
pictured in Figure 1. This section is designed to
help the user navigate through this guide with ease.
It includes the following information:
• EBA-40 Unit
• Model Descriptions
• Type Descriptions
• Software Descriptions
• Precautions
• Primary Features
• Component Names
• Specifications
• Installation
• Connector Pin Assignments
• Preventive Maintenance
• Standard Interface Circuit Schematics
• Operational Flowchart
• Troubleshooting
• Unit Dimensions
• International Compliance
• Technical Contact Information
In order to make operating this device and navigat-
ing within this manual easier, the following illustra-
tions are used:
• Safety Instructions need to be observed in
order to protect the operators and the
equipment; these are identified with bold text
and the following pictographs:
• Special Notes affect the use of the Banknote
Acceptor; these are identified with italic text
and the following pictograph:
• Steps require the operator to perform specific
actions; these are identified with sequential
numbers (1, 2, 3, etc.).
1 GENERAL INFORMATION
EBA-40 Unit
Figure 1 EBA-40 Unit

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
2
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
Model Descriptions
Table 1 lists the product model number
descriptions.
Type Descriptions
Table 2 lists the product type number descrip-
tions.
Software Descriptions
Table 3 lists the software number descriptions.
Precautions
Symbols in Figure 2 are defined as follows:
1. (Type 1) Do not insert a torn, folded, or wet
Banknote; it may cause a jam inside the unit.
2. (Type 2) Do not expose the unit to water. The unit
contains several precision electronic devices that
can be damaged if water or any liquid is sprayed
or spilled into the unit.
3. (Type 3) Do not install the unit in a dusty
environment. Dust may affect/degrade the sen-
sor’s performance.
U SER C AUTIONS
Careful measures were taken in the design of this
product to ensure its quality; however, the follow-
ing cautions pertain to all users and should be fol-
lowed for safe operation.
Installation Cautions
The Installation Cautions are defined as follows:
1. Be sure the Host Machine contains enough
protection to avoid wet or dusty conditions when
installing the unit in an indoor or open-air space.
The unit is not designed for outdoor installations.
2. Be sure the Host Machine is designed with
careful consideration for retrieving a Banknote
and/or clearing a Banknote jam.
3. Be careful not to use excessive outside pressure
on the Mounting Plate when removing the Cash
Box from the Unit.
4. Avoid exposing the Banknote Insertion Slot to
direct Sunlight and/or Incandescent Lamp
illumination having a Gradient Angle of 15
Degrees or more, and an illumination index of
3000 Lux or less. Insure that the Host Machine is
also designed to avoid exposing the Banknote
Table 1 EBA-40 Model Number Specifications
NoModel: EBA- * * - SD3
No(1)(2)
(1) Model Number
4 = Standard
(2) Model Series Number
0 = Standard
1-9 = Reserved
Table 2 EBA-40 Type Number Specifications
NoModel: ***(*) - * * * * * - **
No(1) (2)(3)(4)(5)(6) (7)
(1) Denomination (Country Code)*
*. The Country Code is indicated following the ISO 3166.
(2) Cash Box Capacity†
0 = None (Without Stacker)
4 = 400 notes (Standard)
†. The numbers of stacked Notes depends on the Banknote’s condition.
(3) Bezel (Option)
0 = Without Bezel (Standard)
1 = Bezel Type A
(4) Interface Conversion Board
0 = Without I/F Conversion Board (Standard)
(5) Key Switch
0 = Without Key Switch (Standard)
1 = With Key Switch
2 = OEM Key Switch
(6) Bar Sensor
0 = Without Bar Sensor (Standard)
1 = With Bar Sensor (Up type)
2 = With Bar Sensor (Down type)
(7) Interface
03 = ID-003 (JCM Serial)
D3 = ID-0D3 (MDB)
E3 = ID-0E3 (ccTalk)‡
** = Other (Last 2 digits of interface ID)
‡. Serial communication protocol developed by MoneyControl is
employed for ccTalk.
Table 3 EBA-40 Software Number Specifications
No
Software: EBA-40 * * * - 0 * * - V * .**
No(A) (B) (C) (D)
(A) Software Model Name
(B) Denomination (Country Code)*
*. The Country Code is indicated following the ISO 3166.
(C) Interface Protocol Name
(D) Software Version
Type 1 Type 2 Type 3
Figure 2 Precautionary Symbols

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
3
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
Insertion Slot to direct Sunlight or incandescent
light.
5. Do not allow the Acceptor to endure a range of
temperature and humidity beyond the environ-
mental limits specified (See “Environmental
Specifications” on page 7 of this Section).
6. Do not use the Acceptor in environments that
may be subject to server temperature changes.
7. Do not use the Acceptor where it may be exposed
to airborne evaporated or sporadic chemicals.
8. Clean and maintain the Acceptor regularly when
located in an excessively smoke filled environ-
ment.
Mounting, Dismounting & Transportation
Methods for mounting, dismounting and transport-
ing the unit:
1. Be sure to turn the Power OFF before mounting
or removing the Unit from its permanent location.
Plugging or unplugging Connector Plugs from
their receptacles while the Power is ON may
cause damage to the Unit.
2. When reassembling a disassembled Unit Part,
ensure that the each part is properly replaced in its
correct original location and the Acceptor is not
removed by pulling it forward.
3. Be sure to carry the Unit by both hands when
transporting it. Holding the Unit by one hand may
cause personal injury if the Unit accidentally
becomes disassembled and drops away.
4. Be careful not to use excessive outside pressure
on the Unit, or subject it to excessive vibration
during transportation.
Placing Foreign Objects into the Unit
Observe the following precautions when placing
foreign objects into the Unit:
1. Do not insert anything except Banknotes into the
Insertion Slot. Inserting Receipts, Stapled Tickets,
Rubber Bands, or Credit Cards into the Unit may
damage the Banknote Transport path.
2. Do not inject liquids into the Banknote Insertion
Slot. Injecting water, oil or cleaning agents may
damage the Sensors within the Banknote Trans-
port path.
Preventive Maintenance
The preventive maintenance requirements are
defined as follows:
1. When closing the Upper Tray of the Acceptor,
ensure that it clicks firmly into place.
2. Do not redesign or disassemble the EBA-40
Acceptor. Unauthorized use by inadequately
trained personnel, or use outside the original man-
ufacturer’s intent for operation voids the war-
ranty.
3. Perform routine cleaning and maintenance at least
once a month to keep the EBA-40 Unit’s perfor-
mance stable.
4. Use a soft, lint-free cloth, cotton swab or com-
pressed air spray to clean dust and debris from the
Rollers.
5. If the Unit is exposed to water or liquids, use a
clean, dry micro-fiber cloth to wipe off and
absorb excess liquids immediately. Any remain-
ing liquids or fluids may affect and degrade the
Sensors and Validation component performance.
Caution: Turn the EBA-40 Unit’s Power
OFF when opening the Upper Tray;
otherwise, the Rollers may begin
operating and personal injury to fingers
may occur by getting them pulled into
the Unit.
Caution: Be careful to avoid personal
injury to your fingers when closing the
Upper Guide Section.
WARNING: Do not inject water or liquid
agents of any kind into the Acceptor, as
this may cause extreme damage to the
Unit.
WARNING: To minimize risk of damage
to internal printed circuit boards, never
allow excess fluid (e.g., from a wet
cleaning cloth) to drip or leak into the
device. Internal printed circuit boards
may be damaged. Do not use any
alcohol, citrus based cleaners, solvents
or scouring agents that can damage the
plastic surfaces of the device.
Caution: Make sure Interface Harness
connections to the Host Machine are
shorter than 9.84 Feet (3 Meters) in
length. Cut off all unused portions of
the Interface Harness wiring to avoid
static electrical effects or short circuit
possibilities that could cause damage
to the Unit.
WARNING: This Unit is designed for
use with a Current limiting Power
Source! Design the Host Cabinet space
to meet all local related safety
standards.

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
4
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
B ANKNOTE F ITNESS R EQUIREMENTS
The following Banknote types may not validate
correctly, or worse, can cause a jam and/or damage
to the unit’s Transport Path.
Banknotes exhibiting the following conditions
illustrated in Figure 3 should be avoided:
• torn
• excessive folds or wrinkles
• dirty
• wet
• containing foreign objects and/or oil
Primary Features
The EBA-40 Banknote Acceptor Unit contains the
following primary features:
• Proven Anti-Pullback Technology – This JCM
patented Anti-Pullback Mechanism provides
powerful protection against Banknote
stringing.
• Automatic Centering – The Centering
Mechanism (See Figure 4 & Figure 5) allows
the unit to read Banknote without using special
Banknote Guides. It helps to improve the
overall acceptance rate:
– With the SD3 Stacker: 62mm to 85mm in width
– Without the SD3 Stacker: 60mm to 85mm in
width.
Damaged Banknotes
Wrinkled Banknotes
Curled Banknotes
Folded or Partial Banknotes
Figure 3 Unacceptable Banknotes
62mm-85mm
Figure 4 Automatic Centering Mechanism
(with the SD3 Stacker)
Figure 5 Automatic Centering Mechanism
(without the SD3 Stacker)
60mm-85mm

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
5
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
Component Names
Figure 6 illustrates the EBA-40 component names and locations.
Figure 6 EBA-40 Component Names
a) Acceptor Unit
b) DIP Switch Block 2
c) DIP Switch Block 1
d) Coin Lock
e) Interface Connector
f) External Display Connector
g) SD3 Stacker Box
b
c
d
e
f
g
a

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
6
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
2 SPECIFICATIONS
Technical Specifications
Table 4 EBA-40 Technical Specifications
Acceptance Rate*:
*. Refer to the specific Country’s “Software Information Sheet” for each Country’s particular Banknote acceptance rate.
98% or greater
Note: The following banknote types are excluded:
•Banknotes with excess or poor magnetism or unclear graphics
•Double (dual) Notes
•Worn, dirty, wet, stained, torn or excessively wrinkled Banknotes
•Banknotes having folded corners or edges
•Banknotes having the wrong cut dimensions or printing displacement
•Returned Banknotes because of incorrect or failed insertion.
Banknote Types Accepted:
With the SD3 Stacker
•Long side: 120-160mm (4.72-6.29 in.)
•Short side: 62-85mm (2.44-3.34 in.)
Without the SD3 Stacker
•Long side: 110-181mm (4.33-7.12 in.)
•Short side: 60-85mm (2.36-3.34 in.)
Barcode Coupon†:
†. Refer to the specific Country’s “Bar Code Coupon Specification” for more details.
Standard Specification
•Read code interleaved: 2 of 5
•Narrow Bar: 0.5-0.6mm (0.019-0.023 in.)
•Wide Bar to Narrow Bar ratio = 3:1
•Characters: 18 Characters
•Print Position: Middle (Divides a Coupon equally from the left, right, top and
bottom of the Coupon’s center)
•Print Width: Wider than 10mm (0.39 in.)
Insertion Direction: Refer to the Specific Country’s “Software Information Sheet”
Processing Speed‡:
‡. Excluding Host Communication time lag (Power Supply: +12V DC, Temperature: 25º C ±5º C, Humidity: 30%-60%).
Approximately 1.8 seconds
(from Banknote insertion to sending Vend Signal)
Approximately 3.5 seconds
(from Banknote insertion to stacking completion)
Validation Method: Validation Sensor and Magnetic Sensor
Diagnostic Indicators: LED (Green/Red), External Display Output
Escrow: 1 Note
Anti-stringing Mechanism: Pull-Back (PB) Unit (Anti-pullback System - JCM Patented)
Cash Box Capacity**:
**.The number of Notes stacked depends on the Banknote’s condition.
Approximately 400 notes (new Banknotes)
Cash Box Access: Front Access
Interface††:
††.The Interface Harness connecting to the Host should be less than 3m(9.84 ft).
TTL Serial Interface
MDB Interface
ccTalk
RS232C
USB (USB Specification Rev. 2.0 Compliance) (Full Speed/12Mbps)

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
7
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
Environmental Specifications
Electrical Specifications
Structural Specifications
Table 5 EBA-40 Environmental Specifications
Operating Temperature: 5ºC to +50ºC (41ºF to 122ºF)*
*. Depends on hydrothermal conditions.
Storage Temperature: -20ºC to +60ºC (-4ºF to 140ºF)*
Relative Operating Humidity: 30% to 85% RH (non-condensed)
Relative Storage Humidity: 30% to 85% RH (non-condensed)
Visible Light Sensitivity: Avoid contact with direct sunlight (Interior lighting must be incandescent with a
Radiant Angle of 15 Degrees or more having an Illumination index of 3000 Lux or less)
Installation: Indoors Only
Table 6 EBA-40 Electrical Specifications
Supply Voltage: 12V DC ±5% (Greater than 3A)
24V DC ±5% (Greater than 1.6A)*
*. Use a Current Source Limiting Power Supply
Current Consumption:
12V DC
•Standby = 180mA
•Operation = 1.0A
•Peak = 3.0A
24V DC
•Standby = 110mA
•Operation = 0.6A
•Peak = 1.6A
Table 7 EBA-40 Structural Specifications
Weight: With the SD3 Stacker: Approximately 2.5kg (5.51lbs.)
Without the SD3 Stacker: Approximately 1kg (2.2lbs.)
Mounting: Horizontal
Outside Dimensions: See “Entire Unit Outside Dimensions” on page 33 of this Manual
Hydrothermal Condition Table
Humidity [%RH]
Temperature [ºC]
Allowable
and Humidity Range
Operating
Temperature 50ºC/40RH%
35ºC/80RH%

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
8
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
3 INSTALLATION
This section provides installation and operating
instructions for the EBA-40 Banknote Acceptor
unit. The information within this section contains
the following features:
• Installation Procedure
• Lock Installation
• DIP Switch Configuration
Installation Procedure
The EBA-40 Frame Unit provides installation holes
for each surface.
E NTIRE U NIT I NSTALLATION
Perform the following steps to install the EBA-40
Unit:
1. Place the EBA-40 Unit Frame in its intended
mounting location.
2. Bolt the bottom side of the EBA-40 Frame into its
intended location using four (4) M3 Screws
(See Figure 7 a1through a4) from the outside of
the Frame when this mounting configuration is
preferred.
3. Hang the EBA-40 Frame onto shafts which fit in
place for the proper width and length of the Key
Hole Slots on the rear side of the Frame when this
mounting configuration is preferred (See Figure
8).
A CCEPTOR H EAD I NSTALLATION
Perform the following steps to install the EBA-40
Acceptor Head Assembly using the Mounting
Bracket:
1. Place the EBA-40 Acceptor Head in its intended
mounting location.
2. Install the Mounting Bracket into its intended
location using four (4) M4x6 Screws (See Figure
9 a1through a4) provided with the Mounting
Bracket.
3. Slide and install the EBA-40 Acceptor Head
Assembly (See Figure 9 b) onto the Mounting
Bracket while simultaneously sliding the “Ped-
estal Rail” (See Figure 9 c1& c2) in place when
this mounting configuration is preferred.
84mm
60mm
50mm
a1
a2
a3
a4
84mm
60mm
50mm
a1
a2
a3
a4
60mm
50mm
a1
a2
a3
a4
Figure 7 M3 Screw Locations (Bottom)
WARNING: The maximum length of the
M3 Screws should be selected
considering the Cabinet or Mounting
Bracket thickness. The Mounting
Screws’ length should not extend more
than 8mm upward from the bottom of
the SD3 Stacker Box Frame.
Key
84mm
Ø6
Ø10
74mm
Rear View
9.5mm
Hole Slots
Figure 8 Key Hole Slot Locations (Rear)
105mm
91.7mm
a1
a2
a3
a4
c1
c2
b
Figure 9 M4 Screw Locations (Rear & Bottom)

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
9
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
Perform the following steps to install the EBA-40
Acceptor Head Assembly without the Mounting
Bracket:
1. Confirm the six (6) installation holes (See Figure
10 a1through a6) on the Lower Cover (See Figure
10 b) located on the bottom side of the EBA-40
Acceptor Head Assembly.
2. Place the EBA-40 Acceptor Head Assembly in its
intended mounting location.
3. Bolt the Lower Cover of the EBA-40 Acceptor
Head Assembly into its intended location using
six (6) M3 Screws (See Figure 10 c1through c6)
from the bottom side of the Frame when this
mounting configuration is preferred.
Lock Installation
One security lock can be installed onto the EBA-40
SD3 Stacker. When installing a security lock, the
following attachment accessories may be required:
• Tang
Choose a Lock that fits a standard 17.4 mm cylin-
der length format. This is the only format that is
supported. (See Figure 12).
Bottom View
37mm
25mm
c1-c6
12mm
40mm
42mm
Attention
Do not use screws
longer than 5mm
JCM GLOBAL
b
a1-a6
Figure 10 M3 Screw Locations (Rear & Bottom)
WARNING: The maximum length of the
M3 Screws should be selected
considering the Cabinet or Mounting
Bracket thickness. The Mounting
Screws’ length should not extend more
than 4mm upward from the bottom of
the SD3 Stacker Box Frame and the
Lower Cover.
Figure 11 Key Hole Location
Key Hole
17.4mm
15.8 mm
Ø19.5
Tang
(Front)
Figure 12 Lock Dimension & Cylinder Length
NOTE: Make sure the Tang is correctly installed,
as illustrated in Figure 12.

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
10
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
DIP Switch Configurations
This section provides the denomination DIP Switch
Block 1 (DS1) and 2 (DS2) Settings for the
EBA-40 Unit.
NOTE: There are many lock designs. Locks vary
greatly in price, security, keying policies, etc..
The customer is responsible for selecting a lock
that is appropriate for the intended purpose.
JCM does not test or endorse any commercially
available brand of lock for its security
characteristics.
Figure 13 Key Unlock Rotation Requirement
Unlock
Table 8 DIP Switch Block 1 Settings
Switch
No. Switch ON Switch OFF
1VEND 1 INHIBIT VEND 1 ACCEPT
2VEND 2 INHIBIT VEND 2 ACCEPT
3VEND 3 INHIBIT VEND 3 ACCEPT
4VEND 4 INHIBIT VEND 4 ACCEPT
5VEND 5 INHIBIT VEND 5 ACCEPT
6VEND 6 INHIBIT VEND 6 ACCEPT
7VEND 7 INHIBIT VEND 7 ACCEPT
8TEST MODE FUNCTION
Table 9 DIP Switch Block 2 Settings
Switch
No. Switch ON Switch OFF
1With SD3 Stacker Without SD3 Stacker
2Key Switch Enabled Key Switch Disabled
3ccTalk (Encrypted) ccTalk (Non-Encrypted )
4RS232C Interface Other Interface
5With Barcode Sensor
Board
Without Barcode Sensor
Board
6Reserved Reserved
7Reserved Reserved
8Reserved Reserved
DS1
DS2

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
11
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
4 CONNECTOR PIN ASSIGNMENTS
Table 10 through Table 18 list the EBA-40 Unit’s pin assignments.
Table 10 lists the EBA-40 TTL Interface Pin Assignments.
Table 10 EBA-40 TTL Interface Pin Assignments
Header: XG4C-1634 (OMRON)
Housing: XG5M-1635-N Slit Wire (OMRON)
Recommended Wire: UL1007 AWG#26-28
OR
Housing: XG4M-1630-T Flat Cable (OMRON)
Recommended Wire: UL2651 AWG#28
Pin No. Signal Name I/O*
*. I/O (input/output) is the terminal as viewed from the Banknote Acceptor’s backside.
Function
1+12V/+24V -Power Supply
2GND -GND
3+12V/+24V -Power Supply
4GND -GND
5TTL - TXD OUT TTL Communication Output Signal Line
6SG -Signal GND
7TTL - RXD IN TTL Communication Input Signal Line
8ccTalk TXD/RXD IN/OUT No Connection
9MDB - TXD OUT No Connection
10 MDB - RXD IN No Connection
11 MDB COM -No Connection
12 I/F 12V No Connection
13 PC - TXD OUT No Connection
14 I/F GND -No Connection
15 SW - IN IN No Connection
16 PC - RXD IN No Connection

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
12
EBA®Series Banknote Acceptor (EBA-40) Integration Guide
CONNECTOR PIN ASSIGNMENTS (Continued 1)
Table 11 lists the EBA-40 MDB Interface Pin Assignments.
Table 11 EBA-40 MDB Interface Pin Assignments
Header: XG4C-1634 (OMRON)
Housing: XG5M-1635-N Slit Wire (OMRON)
Recommended Wire: UL1007 AWG#26-28
OR
Housing: XG4M-1630-T Flat Cable (OMRON)
Recommended Wire: UL2651 AWG#28
Pin No. Signal Name I/O*
*. I/O (input/output) is the terminal as viewed from the Banknote Acceptor’s backside.
Function
1+12V/+24V -Power Supply
2GND -GND
3+12V/+24V -Power Supply
4GND -GND
5TTL - TXD OUT No Connection
6SG -No Connection
7TTL - RXD IN No Connection
8ccTalk TXD/RXD IN/OUT No Connection
9MDB - TXD OUT MDB Communication Output Signal Line
10 MDB - RXD IN MDB Communication Input Signal Line
11 MDB COM -MDB Common Signal Line
12 I/F 12V No Connection
13 PC - TXD OUT No Connection
14 I/F GND -No Connection
15 SW - IN IN No Connection
16 PC - RXD IN No Connection
