Jet AFS-400 Owner's manual

The JET AFS-400 was designed
specifically to be effective in small to mid-
sized woodworking shops!
JET AFS-400 Air Filtration Unit
The new JET AFS-400 Air Filtration unit has been
designed with the small to mid-sized shop in mind.
Its 260, 362, and 409 CFM rates will clean and
circulate the air in a 20’ x 20’ x 8’ shop at a rate of 7
cycles per hour!
To be most compatible with common space
restrictions, the JET AFS-400 Air Filtration Unit has
rubber feet on its bottom panel so it can be operated
while sitting on a bench or table. The 20-1/4” X 17 X
10-1/8”, 31-lb unit can also be hung from a ceiling
and we include the necessary hardware for the most
common installations.
Task Compatible
Not all woodworking tasks generate the same amount of dust so we made the JET AFS-
400 Air Filtration Unit versatile. The 1/8HP, 115V motor is electronically controlled to
produce airflow rates of 260, 362 and 409 CFM (cubic feet per minute). That range of
speeds allows you to set the airflow rate most appropriate to handle the current situation
effectively while conserving power and saving money.
This versatility is
further enhanced by the
portability of the JET
AFS-400 Air Filtration
Unit. Moving the
intake closer to the task
can often allow using
one of the lower flow
rates without
sacrificing
effectiveness.
The JET AFS-400 comes with a handy remote control (left) that accesses all of the
control panel features from across the shop! The control panel (right) has LED light
that indicate the current settings, including the timer so you know when the AFS-
400 will shut off.
Control
The JET AFS-400 Air Filtration Unit has a pushbutton control panel at the rear of the
unit. In addition to selecting speeds, the JET AFS-400 Air Filtration Unit control panel
features a timer that allows programming it to run 1, 2, or 4 hours before shutting off
automatically. We also include a remote control that provides full access to all of those
control functions from across the shop!

Filtering Efficiency
The JET AFS-400 Air
Filtration Unit has two
filtering stages. The outer
electrostatic filter is more
effective than plain
elements. Its fine weave
filtering element catches
particles down to 5
micron in size. The inner
pocket type filter then
traps particles down to 1
micron before the air is
discharged back into the shop!
The dual filter elements (left) allow the AFS-400 to capture particles down to 1
micron in size! Both filter elements are easy to remove by simply flipping open
the spring-loaded clips (right) and slipping them out of the cavity.
Both filter elements are easily removed without tools for cleaning or replacement.
Simply flip the retaining clips open to remove the filters! In most cases, you can clean the
filter elements several times before having to replace them. The inner filter can be
washed in warm water (no soap) and air dried to restore its efficiency! The amount of
dust normally generated in your shop and the effectiveness of your dust collection play a
big part in the amount of airborne dust the JET AFS-400 Air Filtration Unit encounters.
The versatility and power of the JET AFS-400 Air Filtration Unit make it effective in the
ever-changing home woodworking shop environment. The user-friendly design and
features make it
possible for you to
work in a cleaner
environment. We
are so sure you
will like the JET
AFS-400 Air
Filtration Unit, we
cover it with our 5-
year warranty!
The AFS-400 has rubber feet so it can be used while sitting (left) on a bench. We also
supply the hardware (right) for hanging the AFS-400 from commonly configured
ceilings.
