Features
PORTABLE
■
•Combination benchtop jointer & planer provides a 2 in 1 machine to maximize workspace
■
•Compact benchtop design ts conveniently in smallshop environments
■
•Integrated cord wrap makes transporting easy and ensures workshop safety
POWERFUL
■
•Heavy-Duty 13 Amp motor for various cutting applications
■
•Two high speed steel knives for precise, smooth cuts
■
•Oversized, ergonomic knobs provide ease of use andmaximum control
PRECISE
■
•Large aluminum extruded fence makes joining stable and precise
■
•Sheet metal outfeed table with height adjustment supports long workpieces and helps
reduce snipe
■
•Planing and joining tables lock to ensure precision cutting
■
•Precision machined table top ensures a smooth, straight cut
Large aluminum extruded fencea.
Sheet metal outfeed table with b.
height adjustment
Planing and joining tables lockc.
Precision ground table topd.
Oversized, ergonomic knobse.
Integrated cord wrapf.
C FB
SPECIFICATIONS
Stock Number 707400
Model Number JJP-8BT
Motor 120V, 60Hz, 13Amp
Knife Size (in.) 8.25 x .65 x .06
Number of Knives (RPM) 2
Cutting Speed 9,000
Cuts Per Minute CPM 18,000
Feed Speed FPM 19.5
Max. Cutting Width (in.) 8
Jointer Max. Cut Depth (in.) 1/8
Planer Max. Cut Depth (in.) .08
Cutting Thickness (in.) .20 - 4.92
Jointer Table Size (LxW/in.) 29 x 8-1/4
Planer Table Size (LxW/in.) 10-5/8 x 8-1/2
Planer Table with Out feed (LxW/in.) 17-3/4 x 8-1/2
Fence Size (LxW/in.) 4-1/8 x 21
Fence Tilt (deg.) 0-45
Gross Wt. / Net Wt. (lbs.) 68.3 / 58.4
jettools.com/b3nch
B3NCH™
AIR FILTRATION SYSTEM
The new JET AFS-400 Air Filtration unit can either be hung from the
ceiling by four hooks to save shop space or be used as benchtop.
This little powerhouse cleans and circulates air in a 20' x 20' x 8'
shop, 7 cycles per hour to provide you with a cleaner, healthier
shop environment. Three speeds 260, 362, and 409 CFM allow you
to choose the most efcient air ltration for your shop. The remote
control with built-in timer settings for 2, 4 and 8 hours will shut off
automatically at the end of the designated time, cleaning the air in
your shop even while you are away.
THE WOODWORKERS
•
CHOICE FOR
PRECISION
TOOLS
Features
•
• Remote control has built-in timer with 1, 2 and 4 hour settings;
automatically shuts system off at the end of the time setting
•
• Select from three speeds 260, 362, 409 CFM for the most efcient air
ltration
•
• Disposable electrostatic outer lter attracts more dust particles than
standard lters
•
• Inner pocket lter is removable for easy cleaning out with ease
•
• Inner lter is washable and reusable
•
• Rubber feet prevent marring of surface when placed on workbench
•
• Four hooks let you hang unit from shop ceiling
•
• Easy grip handle for portability
Electrostatic Outer Filtera.
Remote Controlb.
Easy Carying Handlec.
Control Paneld.
SPECIFICATIONS
Stock Number 710612
Model Number AFS-400
Net Weight 31 Lbs
Gross Weight 34 Lbs
Speeds (CFM) 260, 362, 409
Cycles per Hour (20' x 20' x 8') 7
Timer Settings (hours): 1, 2 and 4
Outer Filter (microns): 5
Inner Filter (microns): 1
Motor HP 1/8HP
Amps .9
Motor Phase 1 Ph
Motor Voltage 115V
Prewired 115V
C
D
A
B
Front View
