Jet JTSS-1600 User manual



JTSS‐1600 PanelSaw

Original:
GB
OperatingInstructions

Translations:
D
Gebrauchsanleitung

F
Moded´emploi

















JPW(Tool)AG
Tämperlistrasse5
CH‐8117Fällanden
Switzerland
Phone +41448064748
Fax +41448064758

www.jettools.com


M‐10000044T2017‐06


CE‐ConformityDeclaration
CE‐Konformitätserklärung
DéclarationdeConformitéCE

Product/Produkt/Produit:
Panelsaw
Formatkreissäge
sciecirculaireàformat

JTSS‐1600

Brand/Marke/Marque:

JET

Manufacturer/Hersteller/Fabricant:
JPW(Tool)AG,Tämperlistrasse5,CH‐8117Fällanden
Schweiz/Suisse/Switzerland

Weherebydeclarethatthisproductcomplieswiththeregulations
Wirerklärenhiermit,dassdiesesProduktderfolgendenRichtlinieentspricht
Parlaprésente,nousdéclaronsqueceproduitcorrespondauxdirectivessuivantes

2006/42/EC
MachineryDirective
Maschinenrichtlinie
DirectiveMachines

2014/30/EU
ElectromagneticCompatibility
ElektromagnetischeVerträglichkeit
compatibilitéélectromagnétique

designedinconsiderationofthestandards
undentsprechendfolgenderzusätzlicherNormenentwickeltwurde
etétédéveloppédanslerespectdesnormescomplémentairessuivantes

ENISO12100:2010
EN1870‐18:2013
EN60204‐1:2006+A1:2009
EN55014‐1:2006+A1+A2/EN55014‐2:2015
EN61000‐3‐2:2014/EN61000‐3‐3:2013

ResponsiblefortheDocumentation/Dokumentations‐Verantwortung/RésponsabilitédeDocumentation:

HansjörgMeier

HeadProduct‐Mgmt./LeiterProdukt‐Mgmt./Resp.GestiondesProduits
JPW(Tool)AG







2017‐06‐16AlainSchmid,GeneralManager
JPW(Tool)AG,Tämperlistrasse5,CH‐8117Fällanden
Schweiz/Suisse/Switzerland



GB‐ENGLISH
OperatingInstructions

DearCustomer,
ManythanksfortheconfidenceyouhaveshowninuswiththepurchaseofyournewJET‐machine.Thismanualhasbeenpreparedforthe
ownerandoperatorsofaJETJTSS‐1600Panelsawtopromotesafetyduringinstallation,operationandmaintenanceprocedures.Please
readandunderstandtheinformationcontainedintheseoperatinginstructionsandtheaccompanyingdocuments.Toobtainmaximumlife
andefficiencyfromyourmachine,andtousethemachinesafely,readthismanualthoroughlyandfollowinstructionscarefully.

…TableofContents
1.Declarationofconformity
2.Warranty
3.Safety
Authorizeduse
Generalsafetynotes
Remaininghazards
4.Machinespecifications
Technicaldata
Noiseemission
Dustemission
Contentsofdelivery
Descriptionofmachine
5.Transportandstartup
Transportandinstallation
Assembly
Dustconnection
Mainsconnection
Startingoperation
6.Machineoperation
7.Setupandadjustments
Changingsawblade
Mountingtheravingknife
Mountingthesawguard
Risingandtiltingsawblade
Setupofscoringsawblade
Slidingtablesetup
Crosscuttablesetup
Crosscutfencesetup
Mitrefencesetup
Ripfencesetup
8.Maintenanceandinspection
9.Troubleshooting
10.Environmentalprotection
11.Availableaccessories

1.Declarationofconformity
Onourownresponsibilityweherebydeclarethatthisproduct
complieswiththeregulations*listedonpage2.Designedin
considerationwiththestandards**.CEtypeexamination***
performedby****.

2.Warranty
TheJPW(Tool)AGguaranteesthatthesuppliedproductisfree
frommaterialdefectsandmanufacturingfaults.
Thiswarrantydoesnotcoveranydefectswhicharecaused,either
directlyorindirectly,byincorrectuse,carelessness,accidental
damage,repair,inadequatemaintenanceorcleaningandnormal
wearandtear.
Anywarrantydetails(i.e.warrantyperiod)canbefoundinthe
GeneralTermsandConditions(GTC)thatare
integralpartofthecontract.TheseGTCcanbeviewedatthe
websiteofyourdealerorsenttoyouuponrequest.
JPW(Tool)AGreservestherighttomakechangestotheproduct
andaccessoriesatanytime.

3.Safety
3.1Authorizeduse
Thismachineisdesignedforsawingwood,woodderivedmaterials
aswellassimilartobemachinedhardplasticsonly.
Machiningofothermaterialsisnotpermittedandmaybecarried
outinspecificcasesonlyafterconsultingwiththemanufacturer.
Nometalworkpiecesmaybemachined.
Theworkpiecemustallowtosafelybeloaded,supportedand
guided.
Nocutswithoutusingtheripfence,the90°fenceorthesliding
tablemaybeperformed.
Nosubmergedcutsbyremovingtherivingknifeand/orsawguard
maybeperformed.
Theuseofapowerfeederisnotconsidered.
Theproperusealsoincludescompliancewiththeoperatingand
maintenanceinstructionsgiveninthismanual.
Themachinemustbeoperatedonlybypersonsfamiliarwithits
operation,maintenanceandrepairandwhoarefamiliarwithits
hazards.
Therequiredminimumagemustbeobserved.
Themachinemustonlybeusedinatechnicallyperfectcondition.
Whenworkingonthemachine,allsafetymechanismsandcovers
mustbemounted.
Inadditiontothesafetyrequirementscontainedinthisoperating
instructionandyourcountry’sapplicableregulations,youshould
observethegenerallyrecognizedtechnicalrulesconcerningthe
operationofwoodworkingmachines.

Anyotheruseexceedsauthorization.Intheeventofunauthorized
useofthemachine,themanufacturerrenouncesallliabilityand
theresponsibilityistransferredexclusivelytotheoperator.

3.2Generalsafetynotes
Woodworkingmachinescanbedangerousifnotusedproperly.
Thereforetheappropriategeneraltechnicalrulesaswellasthe
followingnotesmustbeobserved.
Readandunderstandtheentireinstructionmanualbefore
attemptingassemblyoroperation.

Keepthisoperatinginstructionclosebythemachine,protected
fromdirtandhumidity,andpassitovertothenewownerifyou
partwiththetool.
Nochangestothemachinemaybemade.
Dailyinspectthefunctionandexistenceofthesafetyappliances
beforeyoustartthemachine.
Donotattemptoperationinthiscase,protectthemachineby
unpluggingthemainscord.
Donotweargloveswhileoperatingthismachine.
Removealllooseclothingandconfinelonghair.

Beforeoperatingthemachine,removetie,rings,watches,other
jewellery,androllupsleevesabovetheelbows.
Wearsafetyshoes;neverwearleisureshoesorsandals.
Alwaysweartheapprovedworkingoutfit:
‐safetygoggles
‐earprotection
‐dustprotection

Forthesafehandlingofsawbladeswearworkgloves.
Observethechapter“saveoperation”inthismanual.
Checkthecorrectrotationofthesawbladebeforeoperatingthe
machine.
Donotstartcuttingoperationuntilsawbladeisatfullspeed.
Controlthestoppingtimeofthemachine,itmaynotbelonger
than10seconds.
Donotusesidepressuretostoprotatingblade.
Insurethattheworkpiecedoesnotrollwhencuttinground
pieces.
Usesuitabletableextensionsandsupportingaidsfordifficultto
handleworkpieces.
Alwaysholdandguidetheworkpiecessafelyduringmachining.
Thefencemustsecurelybelockedbeforemachineuse.
Payparticularattentiontoinstructionsonreducingtheriskof
kickback.
Thesuppliedravingknifemustalwaysbeused.Adjustthespaceto
thesawbladetobebetween2to5mm.
Donotperformanyoperationforwhichthetoolhasnotbeen
designedfor,e.g.donotusethistablesawtocutlogsorfirewood.
Donotperformanyoperationfreehand.
Neverreacharoundoroverthesawblade.
Whenrippingnarrowworkpieces(smallerthan120mm)useas
push‐stickorpush‐wood.
Pushstickorpushwoodmuststaywiththemachinewhentoolis
storedandnotinuse.
Alwaysusecrosscutfenceormitregaugeforcuttingoff.
Theuseofdado‐bladesandgroovecuttersisnotpermissible.
Makesurethatsmallcutoffworkpieceswillnotbecaughtand
thrownawaybytherisingsawbladeteeth.
Removecutandjammedworkpiecesonlywhenmotoristurned
offandthemachineisatacompletestandstill.
Installthemachinesothatthereissufficientspaceforsafe
operationandworkpiecehandling.
Keeptheinsideofthecabinetclearofsawdustandwoodchips.
Makesurethemotorfanandfancoverarekeptclearofsawdust.
Keepworkareawelllighted.
Themachineisdesignedtooperateinclosedroomsandmustbe
placedstableonfirmandlevelledground.
Makesurethatthepowercorddoesnotimpedeworkandcause
peopletotrip.
Neverusethepowercordtocarrythetool.
Donotexposethepowercordtoheat,oiloranysharpcorners.
Donotpullthecordtounplug.
Keeptheflooraroundthemachinecleanandfreeofscrap
material,oilandgrease.
Stayalert!
Giveyourworkundividedattention.Usecommonsense.
Keepanergonomicbodyposition.
Maintainabalancedstanceatalltimes.
Pullthemainsplugifthetoolisnotinuse.
Pullthemainsplugpriortoanymaintenanceorchangeof
accessory(e.g.sawblade).
Beforestartingthemachinemakesurethatoperatingand
measuringtoolsareremovedfromthemachine.
Donotoperatethemachinewhenyouaretired.
Donotoperatethemachineundertheinfluenceofdrugs,alcohol
oranymedication.Beawarethatmedicationcanchangeyour
behaviour.
Keepchildrenandvisitorsasafedistancefromtheworkarea.

Neverreachintothemachinewhileitisoperatingorrunning
down.
Neverleavearunningmachineunattended.Beforeyouleavethe
workplaceswitchoffthemachine.
Donotoperatetheelectrictoolnearinflammableliquidsorgases.
Observethefirefightingandfirealertoptions,forexamplethefire
extinguisheroperationandplace.
Donotusethemachineinadumpenvironmentanddonot
exposeittorain.
Wooddustisexplosiveandcanalsorepresentarisktohealth.
Dustformsometropicalwoodsinparticular,andfromhardwoods
likebeachandoak,isclassifiedasacarcinogenicsubstance.
Alwaysuseasuitabledustextractiondevice
Beforemachining,removeanynailsandotherforeignbodiesfrom
theworkpiece.
Specificationsregardingthemaximumorminimumsizeofthe
workpiecemustbeobserved.
Cutthinorthin‐walledwork‐pieceonlywithfine‐toothedsaw
blades.
Nevercutseveralwork‐piecesatthesametime–andalsono
bundlescontainingseveralindividualpieces.Riskofpersonal
injuryifindividualpiecesarecaughtbythesawblade.
Whencuttingroundstock,useasuitablejigtopreventthework‐
piecefromturning.
Nevercutwork‐piecescontainingthefollowingmaterials:
‐Ropes,strings,cords,cablesandwires.
Donotforcethepowertool.Itwilldoabetterandsaferjoband
giveyoumuchbetterserviceifitisusedattherateforwhichit
wasdesigned.
Donotremovechipsandworkpiecepartsuntilthemachineisata
completestandstill.
Neveroperatewiththeguardsnotinplace–seriousriskofinjury!
Donotstandonthemachine.
Connectionandrepairworkontheelectricalinstallationmaybe
carriedoutbyaqualifiedelectricianonly.
Alwaysunwindanyextensioncordsfully.
Haveadamagedorworncordreplacedimmediately.
DonotusethemachinewhentheON‐OFFswitchdoesnot
operatecorrectly.
Theuseofaccessoriesotherthanthoserecommendedinthis
manualcancreateasafetyhazard.
Makeallmachineadjustmentsormaintenancewiththemachine
unpluggedfromthepowersource.

Wheninstallinganewsawblademakesurethatitmatchesthe
ravingknife.
Theravingknifethicknessmustbeinbetweensawbladebody
thicknessandwidthofcut.
Makesurethatthesawbladeissuitablefortheworkpiece
materialtobecut.
UseonlysawbladesaccordingtoEN847‐1
NeverusesawbladesmadefromHighSpeedSteel(HSS).
Removedefectivesawbladesimmediately.
Aworntableinsertmustbereplaced.

3.3Remaininghazards
Whenusingthemachineaccordingtoregulationssomeremaining
hazardsmaystillexist
Themovingsawbladeintheworkareacancauseinjury.
Brokensawbladescancauseinjuries.
Thrownworkpiecescanleadtoinjury.
Tippingoftheworkpieceduetoinsufficientsupportcanleadto
injury.
Woodchipsandsawdustcanbehealthhazards.Besuretowear
personalprotectiongearsuchassafetygogglesear‐anddust
protection.
Useasuitabledustexhaustsystem.
Theuseofincorrectmainssupplyoradamagedpowercordcan
leadtoinjuriescausedbyelectricity.
Thetypeandconditionofthesawbladeisimportantinkeeping
thenoiselevelaslowaspossible.
Thisdoesnotnegatethefactthatextrasafetyequipmentsuchas
earprotectionmustbeused.


4.Machinespecifications
4.1Technicaldata
MachineTable...................................................800x385mm
Rearextensiontable...........................................310x500mm
Rightextensiontable.........................................800x400mm
Slidingtablesize...............................................1600x270mm
Max.travelofslidingtable......................................1600mm
Max.lengthofcut....................................................1350mm
Crosscuttable...................................................680x580mm
CrossCutFence............................................1200(2200)mm
Sawbladediameter........................................Ø250‐315mm
Bladeborediameter.................................................Ø30mm
Bladespeedno.......................................................4700rpm
Scoringbladediameter..............................................Ø90mm
Scoringbladeborediameter.....................................Ø20mm
Scoringbladespeedno...........................................8700rpm
Cuttingheightat90°/45°...................................100/80mm
Tiltingrangeofblade.................................................90°‐45°
MaxDistance‐bladetoripfence..............................1220mm

Dustportdiameter....................................................100mm
Weight.........................................................................250kg
Mains.......................................................400V~3/PE/50Hz
Motoroutputpower........................................P2=3.0kWS1
Referencecurrent..........................................................6.6A
Extensioncord(H07RN‐F)......................................4x1,5mm²
Installationfuseprotection..............................................16A


4.2Noiseemission
DeterminedaccordingtoEN1870‐18
(Inspectiontolerance4dB)
Workpieceplywood16mm:
Acousticpowerlevel(accordingtoENISO3746):
Idling...........................................................LwA98,3dB(A)
Operating....................................................LwA104dB(A)
Acousticpressurelevel(accordingtoENISO11202):
Idling..........................................................LpA84,4dB(A)
Operating...................................................LpA90,2dB(A)
Thespecifiedvaluesareemissionlevelsandarenotnecessarilyto
beseenassafeoperatinglevels.
Althoughthereisacorrelationbetweenemissionandexposure
levels,thiscannotbeusedreliablytodeterminewhetherornot
furtherprecautionsarerequired.
Factorsthatinfluencetheactuallevelofexposureofthe
workforceincludethecharacteristicsoftheworkroom,other
sourcesofnoise,thenumberofmachinesorotheradjacent
processes.
Thepermissibleexposurelevelcanvaryfromcountrytocountry.
Thisinformationisintendedtoallowtheusertomakeabetter
estimationofthehazardsandrisksinvolved.

4.3Dustemission
Thecircularsawhasbeendustemissioninspected.
Atanairvelocityof20m/seconthedustportdia100mm:
Vacuumpressure......................................................800Pa
Volumeflow........................................................565m³/h
TheTRK‐valueof2mg/m3isnotexceeded.

4.4Contentofdelivery
Maincrate
Mainsawunit
Castironextensiontable
Steelplateextensiontablew/supportleg
Rearextensiontablew/support
Swingarmassembly(insidemainsawunit)
Crosscuttable
Roller,crosscut
Bladeguard
50mmdusthose
Dustport
Mitregauge
Handwheels(2)
Hardware&Tools:
‐13‐15mmopenheadwrench
‐Arborwrench
‐Arborpin
‐3,4,5,6mm"L"wrench
‐Pushstick
‐Edgeshoe
(Somepartsareinsidethemainsawunit)

Railcrate
Ripfence
Ripfencerail
Rearsupportrail
Slidingtable
Slidingtablecarrier
Supportlegsforslidingtable(2)
Crosscutfence
Holddownw/fence
Flipstop


4.5Descriptionofmachine


Fig1
A…..Crosscuttable
B…..Flipstop
C…..Crosscutfence
D…..Rearextensiontable
E…..Slidingtable
F…..Bladeguard
G….Roller
H…..ON/OFFSwitch
I…..Telescopicswing‐arm
J…...Bladeelevationhand‐wheel
K……Bladetilthand‐wheel
L……Mitregauge
M….Ripfence
N……Fenceprofilelocklever
O……E‐stopbutton
P……Fenceassemblylockdownlever
Q……Ripfencerail
R……Supportleg
S……Hand‐wheellockknob
T……HolddownwithmitreGauge


Fig2
U……Rivingknife
V……Mainblade
W……Scoringblade
1…...Scoringbladealignmentscrew
2……Scoringbladelockscrew
3……Scoringbladeelevationscrew
5.Transportandstartup
5.1Transportandinstallation
Themachinewillbedeliveredonacrate.
Attention:
Donotremovethemotortransportlockbeforethemachinehas
beensetinplace.
Donotoperatethehandwheels.
Useaforkliftorliftingstrapstoliftthemachineoffthepallet(Fig
3).



Fig3

Warning:
Themachineweightisheavy.
Assurethesufficientloadcapacityandproperconditionofyour
liftingdevices.
Neverstepunderneathsuspendedloads.
Fortransporttothedesiredlocationuseaforkliftorhandtrolley.
Makesurethemachinedoesnottiporfalloffduringtransport.
Themachineisdesignedtooperateinclosedroomsandmustbe
placedstableonfirmandlevelledground.
Toavoidmachinetippingandforstaticstability,thetablesupport
legsmustalwaysbeinstalledandadjustedtothefloor.
Themachinemustbelevelledinbothdirectionstoassuregood
slidingmotionoftheslidingtable.
Ifpossible,themachinemustbeplacedonrubberplateswhichact
asshockabsorbersandreducethenoiselevel.
Theremustbesufficientspacetooperatethemachine


Fig4
Forpackingreasonsthemachineisnotcompletelyassembled.

5.2Assembly
Ifyounoticeanytransportdamagewhileunpacking,notifyyour
supplierimmediately.Donotoperatethemachine!
Disposeofthepackinginanenvironmentallyfriendlymanner.
Cleanallrustprotectedsurfaceswithamildsolvent.
Somemachinecomponentsareheavy.Gethelpfromasecond
person.

MountingRearExtensionTable:
Attachrearextensiontable(tothemachinetableandputsurfaces
inlevelwithhelpofscrews(U,Fig5).

Fig5

Attachthediagonalsupportbeam(Fig6).

Fig6
MountingRightExtensionTable.
Attachrightextensiontabletothemachinetableandputsurfaces
inlevel(Fig7).

Fig7
Therighttableextensionhasanadjustablesupportleg(R).
Info:
Tablealignmentcanbeachievedquickly,bytappingitwithablock
ofwood(Fig8‐1).

Fig8‐1
Checkthattablesurfacesandedgesarealigned,thenfirmly
tightenthescrews.
Installthehosesupport(A,Fig8‐2)andthetablesupport(B).


Fig8‐2
Mountingripfencerail:
InsertfourM10x80hexheadboltsintoripfencebaserail(Q,Fig
9).
LooselyattachtwoM10hexnutswithwasherinbetweenforeach
bolt.
Mount the rip fence base rail to the front of the saw table and
righttableextensionwithM10hexnuts.
First tighten nuts on two external bolts, aligning the rail parallel
withthetable,andthentightentheothernuts.
Insertthescalecarrier(I)andattachwithnutsandwashers.


Fig9

Mountingripfence:
Mounttheripfencetotheripfencebaserail(Fig10).

Fig10

Mountingthemainbladeelevation&anglehandwheel:
Fittingtheelevationhandwheel(1,Fig11)andanglehandwheel(2)
ontotheelevationandangleshaft.
Installthehandwheellockknobs(3&4).

Fig11

Mountingtheslidingtable:

Fig12‐1
LifttheslidingtableontothemachineandattachwithT‐boltsand
nuts.


Slidingtableadjustment:
Theslidingtableisadjustedexworks.
Theslidingtablemustbealignedtorunparalleltothesawblade.
Thetablesurfacemustbeapproximately0,1‐0,4mmhigherthan
themachinetable(Fig12‐2).
Loosenthebolts(A)andadjustwithscrews(B).

Fig12‐2

Mountingtheslidingtablesupportlegs(2x):

Fig13

Mountingthetelescopicswingarm:

Fig14
MountingCrosscutTable:
Placethecrosscuttable(A,Fig16)ontotelescopicarmsupportrod
(B).

Fig15
SlidetwoM8x70carriageboltswithT‐blocksintotheT‐slotofthe
slidingtable,attachwith2wingnuts.
AdjustM12hexnuts(C)tobringthecrosscuttableintosame
planewithslidingtableandmachinetable.
Movetheslidingtableandcheckplaneagain.
Note:
Incasethecrosscuttablechangedinheight,thismustbe
eliminatedontheswingarmrotateaxis(Fig16).

Fig16
MountingCrosscutFence
Dropthecrosscutfence(C,Fig17)intotheforwardorrearguide
pinhole.
Tightentheknurlednut.
AttachwithT‐boltandlockinghandle(G).
Turnthe"Z"lockplate(F)toquickaligningthefencetosquare.
Turnthestartypescrewandclampthefenceinposition.
Slidetheflipstop(D)intothefence.


Fig17
PlaceaT‐nutintothetopslotoffence,threadthestudofhold‐
downonfence.
Ifneeded,puttheholddownarmontothestud(E).
Referencetochapter7.8

MountingMitreFence
Seechapter7.9

MountingSawblade
Seechapter7.1

Mountingsawguard
TherivingknifehasslotsfordifferentbladesizesFig18
MinbladesizeØ250mm,maxbladesizeØ315mm
Referencetochapter7.3

Fig18

5.3Dustconnection
Installthe50mmdusthoseontothebladeguardwithhoseclamp.
Fig19.
Putthe50mmdusthoseontodusthosesupport,tokeepfreewith
theworkingtable.
Anotherendof50mmdusthoseclampstothemaindustporton
thebottomofrearpanel.
Install100mmdusthosetomaindustportwithhoseclamp.

Fig19
Beforeinitialoperation,themachinemustbeconnectedtoadust
extractor.
Thesuctionshouldswitchonautomaticallywhenthesawis
switchedon.
Ahose,aY‐pieceandahosesupportaresuppliedwiththe
machine.
Theflowrateonthesuctionportdia100mmmustbe20m/sec.
Flexiblehosesmustbeofnon‐flammablequality,andmustbe
connectedtothemachinegroundsystem.

5.4Mainsconnection
Mainsconnectionandanyextensioncordsandplugsusedmust
complywiththeinformationonthemachinelicenceplate.
Themainsconnectionmusthavea16Asurge‐prooffuse.
OnlyuseconnectioncablesmarkedH07RN‐F,withwires1,5mm2
ormore.
Powercordsandplugsmustbefreefromdefects.
Connectionsandrepairstotheelectricalequipmentmayonlybe
carriedoutbyqualifiedelectricians.
Themachineisequippedwitha16AmpCCEEuroplug,mountedat
thebacksideoftheframe.


Attention:
‐Checkfirstifthesawspindlerunsfreelyandifallsafetydevices
arefittedbeforestartingthemachine.
‐Ifthedirectionofrotationisnotcorrect,thephaseconverter
insidetheCCEEuroplugmustbepushedinandturned180°.

(Clockwisedirectionofthemainspindleiscorrect).
Forsafetyreasonsthismustonlybedonewithoutthesawblade
installed!

5.5Startingoperation
YoucanstartthemachinewiththegreenON‐button.
TheredOFF‐buttonstopsthemachine(H,Fig20‐1).
Thescoringsawbladeisstartedandstoppedsimultaneouslywith
themainsawblade.

Fig20‐1
Note:
‐Whenthelowersawbladecoverisopen,itisimpossibletostart
upthemachine.
‐Incaseofmachineoverloadthemotoroverloadcut‐offwillreact.
Afterappr.10minofcoolingthemachinecanbestartedagain.

Emergencystop:
PressE‐stopbutton(O,Fig20‐2)toshutdownallmachine
operations.

Fig20‐2
Note:
TheE‐stopremainsengageduntilitisrotatedclockwiseforrelease
6.Machineoperation
Correctworkingposition:
Infrontofthemachinestandingoutofthelineofcutting(danger
zone)Fig21.

Fig21
Workpiecehandling:
Handsplacedflatontheworkpieceoutsidethecuttingarea.
Feedtheworkpiecetowardsthesawbladeinthedirectionofthe
sawline.Pushtheworkpiecesteadilyforward;completethecut
asasinglemovement.
Supportlongandwideworkpieceswithhelpingrollerstands.
Theuseofapowerfeederisnotconsidered.
Crosscutwithcrosscutfence(Fig22‐1).

Fig22‐1
Trimmingwithbackstop(Fig22‐2).

Fig22‐2

Crosscutwithripfence(Fig22‐3).

Fig22‐3

Rippingofnarrowstock(Fig22‐4).

Fig22‐4
Useofpushwoodwithhandle(Fig22‐5).

Fig22‐5
Operatinghints:
Workonlywithasharpandflawlesssawblade.
Takecarethattheselectionofthesawbladedependsonthe
materialtobecut.
Useasuitablewedgetopreventroundtimberfromturningunder
thepressureofthecut.
Usesuitabletableextensionsandsupportingaidsfordifficultto
handleworkpieces.
Alwaysholdandguidetheworkpiecessafelyduringmachining.
Thefencemustsecurelybelockedbeforemachineuse.
Donotperformanyoperationfreehand.
Guideandpushtheworkpieceagainstthefence.
Takecarewhenslotting.
Whenrippingnarrowworkpieces(<120mm)useaspush‐stickor
pushwood.
Pushsticksandpushwoodsshallbemadefromplastic,woodor
plywood.


Pushsticksmusthaveaminimumlengthof400mmandaV‐mouth.


Tocutwedges,aspecialpushwoodmustbeused.

Makesurethatsmallcutoffworkpieceswillnotbecaughtand
thrownawaybytherisingsawbladeteeth.
Removecutandjammedworkpiecesonlywhenmotoristurned
offandthemachineisatacompletestandstill.
Payparticularattentiononreducingtheriskofkickback.
Thesuppliedravingknifemustalwaysbeused.

7.Setupandadjustments
Generalnote:
Setupandadjustmentworkmayonlybecarriedoutafterthe
machineisprotectedagainstaccidentalstartingbypullingthe
mainsplug.


7.1Changingsawblade
Thesawbladehastomeetthetechnicalspecification.
UseonlysawbladesaccordingtoEN847‐1
Theminimumdiameterofthesawbladesusedonthemachineis
250mm.
Themaximumdiameterofthesawbladesusedonthemachineis
315mm.
Checksawbladeforflaws(cracks,brokenteeth,bending)before
installation.Donotusefaultysawblades.
WARNING:
TheuseofHSSsawbladesisprohibited;useonlycarbidetipped
sawblades.
Thesawbladeteethmustpointincuttingdirection(down)
Alwayswearsuitablegloveswhenhandlingsawblades.
Wheninstallingorchangingsawblade,alwaysdisconnectsaw
frompowersource,unplug!
Pushtheslidingtabletothefrontandopenthelowersawblade
cover.
Raisethemainsawbladetoitshighestposition.
Removethesawguard.

Changingmainsawblade:
Loosenthearbornut(J,Fig23)whilestoppingthearboragainst
rotationwiththelockingpin(K).

Fig23
Attention:lefthandthread.
Removethearbornut(J)andflange(I).
Placesawbladeonarborshaftmakingsureteethpointdownat
thefrontofthesaw.
Reinstallflangeandarbornutandsecurelytighten.
Removethelockingpin(K).
Checkthecorrectpositionoftheravingknifeinregardstothesaw
blade(seeChapter7.2).
Reinstallthesawguard.

Thescoringsawbladeischangedasfollows:
Puttheenclosedspannerontothesawarbornut(M,Fig24)


Fig24
Putthelockingpin(N)intheopeningofthesawtableandturnthe
arborwiththespanneruntilthelockingpinengagesintheholein
thesawarborpulley.
Nowunlockthenut.
Changethescoringblade.
Afterchangingthebladetightenthebolt.

7.2Mountingtheravingknife
Thesuppliedravingknifemustalwaysbeused.
Themachineisequippedwitharavingknifefortheuseof
sawbladesdiameter250to315mm.
Theravingknifehastobeadjustedinsuchawaythatoverits
entirelengththegapbetweensawbladeandravingknifedoesnot
exceedmin.3mmandmax.8mm(Fig25).


Fig25
Theravingknife(P,Fig26)canbeadjustedinbothverticaland
horizontaldirection.
Theheightsettinghastobeadjustedinsuchawaythatthe
sawguardbottomneverexceedsmorethan3mmabovethe
highestplacedsawbladetooth.
Afterheightadjustmentalwayslocksthecentralbolt(Q).
Theravingknifeissideadjustedexworks.
The4littleadjustmentscrewsareusedfortheexactsettingofthe
ravingknifeinlinewiththesawblade.

Forslottingorgroovingaspecialravingknifeisneeded.
Theravingknifehastobeadjustedinsuchawaythattheupper
partoftheravingknifeisneversetlowerthanthehighestsaw
toothinuse.
Neverremovethisravingknife.
Kickbacksaresevereandverydangerous.
Nosubmergedcutsbyremovingtheravingknifeand/orsawguard
maybeperformed.

7.3Mountingthesawguard
Thesawguard(G,Fig26)mustalwaysbeused.
Attachthesawguardtotheravingknife(P),intheslot(S)
matchingthesawbladediameter.
Thesawguardmustbeloweredtotheworkpiecetominimisethe
amountofexposedteeth.


Fig26
Adjustmentshallneverbeperformedwhenthemachineis
running.
Thesawguardhastobeconnectedtothedustextractorsystem.

7.4Risingandtiltingsawblade
Setupadjustmentsofthesawbladeshallneverbeperformed
whenthemachineisrunning.
Usethefronthandwheeltoraisethesawblade(1,Fig27).
Oneturnofthehandwheelequalsapproximately7.5mmofheight
setting.
Loosenthelockknob(3)toadjust.




Fig27
Usethelefthandwheeltotiltthesawblade(2).
Loosenthelockknob(4)toadjust.
Both45°and90°positivestopsarefactoryset.
Incase,theyareadjustable,loosenthegrubscrewandreposition
thestopcollar(Fig28).

Fig28
Afteranyadjustment,startthemachinewithcare.

7.5Setupofscoringsawblade
Theheightsettingofthescorersawbladeisdonebyturningthe
screw(T,Fig29).

Fig29
Themaximumcuttingdepthusingascorersawbladediameterof
90mmis4mm.
Eachtimethemainsawbladeisreplacedbyanewone,orevena
newlysharpenedsawblade,thescorerhastobeadjustedto
matchthemainsawbladeteethwidth.
Itisveryimportantthatthisisdoneinthecorrectwaytoensurea
cleancut,freeofsplintering.
Thesuppliedscoringsawbladehastaperedteeth.Cuttingdepth
alsoadjustscuttingwidth.
Beforeanylateraladjustmentcanbedonethelaterallock(R)has
tobeloosened.
Thelateralmovementofthescorersawbladeisachievedby
turningtheexcenter(S),lockagainafteradjustment(R).

7.6Slidingtablesetup
Whenloadingpanelsandwhencuttingusingtheparallelfencethe
slidingtableshouldbelocked.
Tolockthetableengagetheindexpinonthefrontendofthe
slidingtable.
Ifoveralongperiodoftimemanyshortmovementsofthesliding
tablearemadebye.g.crosscuttingsolidwood,thenitispossible
thattheballcarrierbetweentheupperandlowerpartofthe
slidingtablewillmove.
Thismeansitwillnolongerbecorrectlypositionedtoallowthe
slidingtabletoslidethroughitsfullcourse.
Theoperatorwillfeelresistanceintheslidingtablemotionand
thefullstrokewillnotbeachieved.
Thiseffectcanbecorrectedsimplybypushingthetablewithafew
short,lightpushesagainstthebufferstopattheend,untilthe
positionoftheballcarrierisadjustedandthetablecanbemoved
againalongitsfullstroke.
Itisrecommendedtocleantheslidingtableonceaweek,andto
removeallsawdustandchipswhichgraduallyslowdownthe
slidingtable.
Afteralldusthasbeenblownoff,thinoil,suchasWD‐40,should
besprayedontothesteelguiderodsonboththeupperandlower
partoftheslidingtable.
Neveruseathickoilorgrease!

7.7Crosscuttablesetup
Crosscuttablesetupshallneverbeperformedwhenthemachine
isrunning.
Liftthecrosscuttableontotelescopicarmsupportandslideonto
slidingtableT‐grooveandlockinplace(Fig30).


Fig30
Crosscuttableandtelescopicarmarealignedexworks(Thetable
surfacemustbeinlevelwiththeslidingtable).
Thecrosscuttablecanbepositionedalongtheslidingtable.
Startthemachinewithcare.

7.8Crosscutfencesetup
Crosscutfencesetupshallneverbeperformedwhenthemachine
isrunning.
Thecross‐cuttablehas2precisionholes,allowingthecrosscut
fencetobeputin2positions:
Atthebackandatthefrontofthecross‐cuttable.
Simplyputthefenceontothecrosscuttableandlockitinposition
usingthetwoknobs(Fig31).

Fig31

The90°adjustablestopsarefactoryset.
Calibrationofthescaleonthecrosscutfence:
Thescaleonthefenceisfactorysetandneedsnofurther
adjustments.
Tocheckthesettings,putthestopatacertainmeasureandcutoff
asample.
Measuretheexactlengthofthesample,unlockthescrewwhich
holdsthefencepivotingT‐nutandmovethefenceuntilthe
measurementcorrespondstothelengthofthepreviouslycut
length.
Whenusingthetelescopicextension,thematerialstophastobe
settotheveryendtomakethedifferentscalescorrespondwith
oneanother.
Thebestwaytocheckthatallscalescorrespond,istomake
severaltestcutsonthedifferentscales.

7.9Mitrefencesetup
Mitrefencesetupshallneverbeperformedwhenthemachineis
running.
Forgoodworkpiecesupport,thefenceprofilemustbesetcloseto
thesawblade(Fig32).


Fig32
7.10Ripfencesetup
Ripfencesetupshallneverbeperformedwhenthemachineis
running.
Tomovethefence,liftthehandle(1,Fig33)halveway.


Fig33
Whencuttingsmallworkpiecesorwiththesawunitinclinedat45°,
thefenceprofilemustbeusedinthelowposition(Fig34).

Fig34
Theripfencehasamicroadjustfeature.Liftthehandle(1)fully
androtatethemicroadjustknob(4)
Whencrosscuttingusingtheparallelfence,toavoidthewood
gettingstuckbetweenthefenceandtherivingknife(resultingina
highlydangerouskickback)itisnecessarytopositionthefenceso
thatitsendcorrespondswiththefrontofthesawblade(Fig35).

Fig35
Startthemachinewithprecaution.
Theripfencemustbeparalleltothesawbladeandisadjustedat
thefactory.
8.Maintenanceandinspection
Generalnotes:
Maintenance,cleaningandrepairworkmayonlybecarriedout
afterthemachineisprotectedagainstaccidentalstartingby
pullingthemainsplug.

Repairandmaintenanceworkontheelectricalsystemmayonly
becarriedoutbyaqualifiedelectrician.
Cleanthemachineregularly.
Inspecttheproperfunctionofthedustextractiondaily.
Keeptheinsideofthecabinetclearofsawdustandwoodchips.
Makesurethemotorfanandfancoverarealsokeptclearof
sawdust.
Afteradaysusepushtheslidingtableallofthewayforwardand
backward.
Removerustfromthetablee.g.withWD‐40andaScotch‐Brite™
HandPad.
Neversmokewhilecleaningthemachine,andespeciallywhen
usingpetrol,keroseneorotherinflammableproducts.
Thiscouldleadtoanexplosionandseriousburnsfortheoperator.
Allprotectiveandsafetydevicesmustbere‐attachedimmediately
aftercompletedcleaning,repairandmaintenancework.
Defectivesafetydevicesmustbereplacedimmediately.
Checksawbladesregularlyforfaults.
Replaceadefectivesawbladesimmediately.
Aworntableinsertmustbereplaced.
Aworncrosscutfenceendcapmustbereplaced.

Maindrivebelttensioning:
Checkregularlytheconditionofthebeltsand,ifnecessary,tighten
orreplace.
Removetherearmachineaccessdoor.
Tensionthebeltbypushingthemotordownwiththetensioning
screw(B,Fig36).

Fig36

Makesurethebeltisnotovertensioned,becausethiscouldlead
todamageofthesawarborandbearings.
Maindrivebeltchanging:
Movethebladetiltto0˚(Blade90˚totable)onthecontrolpanel
andraisethebladeasfarasitwillgo.
Movetheslidingpanelallthewaytotheleftandremovetwo
M6x12panheadscrewstoexposetheinternalbladeguardthat
coversthebladesandrivingknife.
Removethebladeguardfromtherivingknifetoexposethe
mountingassembly.
Removethemainblade.
RemoveM8Allenscrewsandremovetheinnerchiphouse(Fig37).

Fig37
Note:forbetteraccess,tiltthesawblade.
Loosenthebelttensionandremovethebelt(Fig38).

Fig38
ReplacenewV‐belt,tensionbelt,closetheleftpanel,andre‐
mountinnerchiphouse,sawbladeandbladeguard.
Reattachtherearmachineaccessdoor.

Scoringunitbelttensioning:
Thescoringunitbeltisself‐tensioningbyspringload(Fig39).

Fig39
Scoringunitbeltchanging:
Movethebladetiltto0˚(Blade90˚totable)onthecontrolpanel
andlowerthebladeasfarasitwillgo.
Removethe4Allenscrewsonthetopandbottomofrightpanel,
andremovetheleftpanel.
Pushthetensionpulleyagainstthespringload.
Removetheoldbeltandreplacenewbelt.
Re‐mounttherightpanel.
MotorBreak:
Themotorbreakworkselectro‐mechanically(breakmotor).
Ifbreakingtimeshouldexceed10seconds,themotorbreak
assemblyneedstobereplaced.ContactyourJetservicestation
immediately.


9.Troubleshooting
Motordoesn’tstart
*Noelectricity
‐checkmainsandfuses.
*Defectiveswitch,motororcord
‐consultanelectrician.
*Overloadhasreacted
‐Waitandstartagain.
*Lowersawbladecoverstillopen
‐Closecovercorrectly.

Machinevibratesexcessively
*Standonunevenfloor
‐adjustlevellingscrewsforevensupport.
*dustonsawflanges
‐cleansawarborandflanges.
*defectivesawblade
‐replacesawbladeimmediately
*BadV‐belts
‐replaceV‐belts
Cutisnotaccuratelysquare
*Stopsnotadjustedcorrectly
‐checkwithsquareandadjuststops.


Materialbindsbladewhenripping
*Fencenotalignedwithsawblade
‐checkandadjustripfence.
*Wrappedwood
‐selectanotherpieceofwood.
Materialkickedbackfromblade
*Fencenotalignedwithsawblade
‐checkandadjustripfence.
*Ravingknifenotinplace
‐highdanger,mountimmediatelywithsawguard.
Cuttingsurfacesisbad
*Wrongsawbladeused
*Blademountedbackwards
*Resincollectiononsawblade
*Sawbladeisdull
*Workpieceinhomogeneous
*Feedpressuretoohigh
‐donotforcetheworkpiece.

Bladedoesnotraiseortilt
*Sawdustinmechanisms
‐clean‐andre‐grease.
Slidingtabledoesnotmove
*Sawdustinbearingguides
‐wipeoutanysawdust.


10.Environmentalprotection
Protecttheenvironment.
Yourappliancecontainsvaluablematerialswhichcanbe
recoveredorrecycled.
Pleaseleaveitataspecializedinstitution.


11.Availableaccessories
RefertotheJET‐Pricelistforvariousaccessories.


