Jet GHD-20pf' GHD-20pft User manual

JET DRILLING
Belt Drive Drill Press . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Variable Speed Drill Presses . . . . . . . . . . . . . . . . . . . . 83
Geared Head Drill Presses . . . . . . . . . . . . . . . . . . . . . 85
Radial Arm Drill Presses . . . . . . . . . . . . . . . . . . . . . . . 88
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

jettools.com
82
DRILLING
83
jettools.com
JET DRILLING
DRILLING 20" VARIABLE SPEED DRILL PRESSES
20" FLOOR DRILL PRESS
• Hinged metal belt and pulley cover coupled with quick
adjustment motor mount allow rapid changing of spindle
speeds
• Rotating, 45° tilting, crank-operated worktable with quick
release clamp
• On/off switch located on front of the drill press head
• A 1/2" diameter external positive depth stop with three
nut locking feature for quick adjustment
• Adjustable tension spindle return spring
• Spindle is supported by high quality ball bearings
• Built-in work lamp on all models, bulb not included.
• Drill chuck and key included
20" FLOOR DRILL PRESS
STOCK NUMBER 354170
Model Number JDP-20MF
Drills to Center of Circle (in.) 20-1/2
Drilling Capacity (in.) 1
Chuck Size (in.) 3/4
Spindle Travel (in.) 4-5/8
Spindle Distance to Base (in.) 46-3/4
Spindle Distance to Table (max/in): 29-1/8
Table Size (in.) 18-5/8 x 16-1/8
T-Slot Size (in.) 5/8
Spindle Taper MT-3
Column Diameter (in.) 3-3/8
Number of Spindle Speeds 12
Range of Spindle Speeds (RPM) 150 – 4,200
Base Size (in.) 13-5/8 x 22-3/8
Motor 1-1/2HP, 1Ph
Floor Space Required (in./L x W x H) 33 x 19 x 67
Net Weight (lbs.) 288
JET DRILLING

jettools.com
82
DRILLING
83
jettools.com
JET DRILLING
DRILLING 20" VARIABLE SPEED DRILL PRESSES
20" VARIABLE SPEED DRILL PRESSES
• UL Listed motor
• Variable spindle speeds
• Spindle speeds are easily changed by means of a front-mounted dial
• Conveniently located operating controls
• Large production table and base
• Quick-release clamp on table.
• Easy-to-read internal depth gauge
STANDARD EQUIPMENT
• T-slotted worktable
• Internal depth stop
• Tapping and reversing controls on JDP-20VS-3
OPTIONAL EQUIPMENT STOCK NUMBER
Drill chucks See Accessory Section
Drill chuck arbors See Accessory Section
Vises See Accessory Section
52pc. Clamping kit 660058
20" VARIABLE SPEED DRILL PRESSES
STOCK NUMBER 354201 354203 354204
Model Number JDP-20VS-1 JDP-20VS-3/230 JDP-20VS-3/460
Drills to Center of Circle (in.) 20 20 20
Cast Iron Drilling Capacity (in.) 1-1/2 1-1/2 1-1/2
Steel Drilling Capacity (in.) 1-1/4 1-1/4 1-1/4
Cast Iron Tapping Capacity (in.) N/A 3/4 3/4
Column Diameter (in.) 4 4 4
Distance Spindle to Column
(max./in.) 10 10 10
Spindle Distance to Base 39 39 39
Spindle Distance to Table 28-1/2 28-1/2 28-1/2
Table Size (in.) 22 x 19-1/2 22 x 19-1/2 22 x 19-1/2
Table Travel (in.) 20 20 20
T-Slots (Number & Size) 2 & 5/8 2 & 5/8 2 & 5/8
T-Slot Centers (in.) 8-7/8 8-7/8 8-7/8
Work Table Capacity (lbs.) 110 110 110
Spindle Taper MT-3 MT-3 MT-3
Range of Spindle Speeds 300–2,000 150–2,000 150–2,000
Base Size (in.) 26 x 19 26 x 19 26 x 19
Base Work Table (in.) 13 x 15-1/2 13 x 15-1/2 13 x 15-1/2
Motor 1-1/2HP, 115/230V, 1Ph,
Prewired 230 V
2HP, 230V, 3Ph,
2-speed
2HP, 460V, 3Ph,
2-speed
Floor Space Required
(in./L x W x H) 36 x 22 x 71 36 x 22 x 71 36 x 22 x 71
Net Weight (lbs.) 720 740 740

JET DRILLING
jettools.com
84
DRILLING
85
jettools.com
JET DRILLING
DRILLING
20" ELECTRONIC VARIABLE SPEED DRILL PRESSES
• Runs quieter and smoother than a conventional variable speed head
• 230V model can run on single phase power
• Low maintenance head has less moving parts
• Incorporates a high-low gear box to maintain low speed torque
• Chrome molybdenum gears are hardened, ground, and shaved
• Quiet running and longer life
• Speed can be adjusted in each range during operation
• LED spindle RPM readout is conveniently mounted
• Tapping mode allows instantaneous spindle reversal
• Easy to read internal depth gauge
• Extra large emergency stop button adds to safe operation
• Table can be raised from the front or side
• Large production table and T-slotted dish-in base
STANDARD EQUIPMENT
• Integrated tapping and reversing controls
• Complete coolant system
• T-slotted work table
20" ELECTRONIC VARIABLE SPEED DRILL PRESSES
OPTIONAL EQUIPMENT STOCK NUMBER
Vises See Accessory Section
52 pc. Clamping kit 660058
Drill chucks See Accessory Section
Drill chuck arbors See Accessory Section
STOCK NUMBER 354210 354212
Model Number JDP-20EVS/230 JDP-20EVS/460
Drills to Center of Circle (in.) 20 20
Cast Iron Drilling Capacity (in.) 1-1/2 1-1/2
Steel Drilling Capacity (in.) 1-3/8 1-3/8
Steel Tapping Capacity (in.) 3/4 3/4
Column Diameter (in.) 4-1/2 4-1/2
Distance Spindle to Column (max./in.) 10-7/16 10-7/16
Spindle Taper MT-3 MT-3
Spindle Travel (in.) 6 6
Number of Spindle Speeds Variable Variable
Range of Spindle Speeds (RPM) 65 – 2000 65 – 2000
Distance Spindle to Base (max./in.) 44-1/4 44-1/4
Distance Spindle to Table (max./in.) 32-3/8 32-3/8
Table Size (in.) 22 x 18-3/4 22 x18-3/4
Table Weight (max./lbs.) 230 230
T-slot (Number & Size) (in.) 2 & 5/8 2 & 5/8
T-slot Centers 8-1/2 8-1/2
Main Motor 2HP, 230V, 3Ph 2HP, 460V, 3Ph
Coolant Motor 1/8HP, 3Ph 1/8HP, 3Ph
Floor Space Required (in./L x W x H) 37 x 37 x 82-1/4 37 x 37 x 82-1/4
Net Weight (lbs.) 722 722

JET DRILLING
jettools.com
84
DRILLING
85
jettools.com
JET DRILLING
DRILLING
20" GEARED HEAD DRILL PRESSES
• Heavy duty design allows a variety of precision drilling applications
• Easy to read internal depth gauge (GHD-20)
• Three power down feeds (GHD-20PF)
• Calibrated ne down feed built-in
• Built-in spindle lock
• Head tilts left or right
• Easy accessible table raiser
• Large production table and T-slotted base
STANDARD EQUIPMENT
• T-slotted worktable
• Drill chuck arbor
• Draw bar
OPTIONAL EQUIPMENT STOCK NUMBER
Drill chucks See Accessory Section
Drill chuck arbors See Accessory Section
Rotary Phase converter See Accessory Section
Vises See Accessory Section
52 pc. Clamping Kit 660058
20" GEARED HEAD DRILL PRESSES
STOCK NUMBER 354020 354024
Model Number GHD-20 GHD-20PF
Drills to Center of Circle (in.) 20 20
Cast Iron Drilling Capacity (in.) 1-1/2 1-1/2
Steel Drilling Capacity (in.) 1-1/4 1-1/4
Column Diameter (in.) 4-1/2 4-1/2
Distance Spindle to Column (max./in.) 10 10
Spindle Taper MT-3 MT-3
Spindle Travel (in.) (GHD-20) 5
Spindle Travel (in.) (GHD-20PF) Manual 4-1/2
Spindle Travel (in.) (GHD-20PF) Auto 4-1/4
Quill Diameter (in.) 3 3
Spindle Distance to Base (in.) 44-3/8 44-3/8
Spindle Distance to Table (in.) 30-7/8 30-7/8
Table Size (in.) 21-1/4 x 18-1/2 21-1/4 x 18-1/2
T-slots, Number & Size (in.) 2 & 5/8 2 & 5/8
T-slot Centers (in.) 9 9
Number of Spindle Speeds 12 12
Range of Spindle Speeds (RPM )
Lo Speed 60, 130, 230, 450, 800, 1500 60, 130, 230, 450, 800, 1500
Range of Spindle SPeeds (RPM)
Hi Speed 120, 260, 460, 900, 1600, 3000 120, 260, 460, 900, 1600, 3000
Number of Powerfeeds (GHD-20PF) 3
Range of Powerfeeds .004, .007, .01
Motor 2HP, 230V only, 3Ph,
2 Speed
2HP, 230V only, 3Ph,
2 Speed
Floor Space Required (in./L x W x H) 32 x 24 x 71 32 x 24 x 71
Net Weight (lbs.) 660 660
354020

JET DRILLING
jettools.com
86
DRILLING
87
jettools.com
JET DRILLING
DRILLING
20" GEARED HEAD DRILLING AND TAPPING PRESSES
• Heavy-duty design allows a variety of precision drilling and tapping
applications
• Easy to read internal depth gauge
• Three power down feeds (GHD-20PFT)
• Calibrated ne down feed built-in
• Built-in spindle lock
• Head tilts left or right
• Easy accessible table raiser
• Large production table and T-slotted base
STANDARD EQUIPMENT
• Integrated tapping and reversing controls
• T-slotted worktable
• Drill chuck arbor
• Draw bar
• TEFC Motor
OPTIONAL EQUIPMENT STOCK NUMBER
Drill chucks See Accessory Section
Drill chuck arbors See Accessory Section
Vises See Accessory Section
52pc. Clamping Kit 660058
Rotary Phase converter See Accessory Section
Note: Use of static equipment will void warranty.
20" GEARED HEAD DRILLING & TAPPING PRESSES
STOCK NUMBER 354022 354026
Model Number GHD-20T GHD-20PFT
Drills to Center of Circle (in.) 20 20
Cast Iron Drilling Capacity (in.) 1-1/2 1-1/2
Cast Iron Tapping Capacity (in.) 13/16 13/16
Steel Drilling Capacity (in.) 1-1/4 1-1/4
Column Diameter (in.) 4-1/2 4-1/2
Distance Spindle to Column (max./in.) 10 10
Spindle Taper MT-3 MT-3
Spindle Travel
Manual 5 4-1/2
Auto 4-1/4
Tapping 4-7/8 4-7/8
Quill Diameter (in.) 3 3
Spindle Distance to Base (in.) 44-3/8 44-3/8
Spindle Distance to Table (in.) 30-7/8 30-7/8
Table Size (in.) 21-1/4 x 18-1/2 21-1/4 x 18-1/2
T-slots, number & size 2 & 5/8 2 & 5/8
T-slot Centers 6-1/4 6-1/4
Number of Spindle Speeds 12 12
Range of Spindle Speeds (RPM)
Lo Speed 60, 130, 230, 450, 800, 1500 60, 130, 230, 450, 800, 1500
Range of Spindle Speeds (RPM)
Hi Speed
120, 260, 460,
900, 1600, 3000
120, 260, 460,
900, 1600, 3000
Number of Powerfeeds 3
Range of Powerfeeds .004, .007, .01
Motor 2HP, 230V, 3Ph, 2-speed 2HP, 230V, 3Ph, 2-speed
Floor Space Required (in./L x W x H) 32 x 24 x 71 32 x 24 x 71
Net Weight (lbs.) 670 670
354026

JET DRILLING
jettools.com
86
DRILLING
87
jettools.com
JET DRILLING
DRILLING
20" GEARED HEAD DRILL PRESSES SERIES E
• Heavy-duty design allows a variety of precision drilling applications
• Helical gears for smooth, quiet operation
• Easy-to-read depth gauge
• Eight Spindle speeds
• T-slotted table with coolant trough
• Easy accessible table raiser
• Two position, high/low switch
• Emergency stop button
OPTIONAL EQUIPMENT STOCK NUMBER
Drill chucks See Accessory Section
Drill chuck arbors See Accessory Section
52 pc Clamping Kit 660058
Vises See Accessory Section
Rotary Phase converter See Accessory Section
20" GEARED HEAD DRILL PRESSES - SERIES E
STOCK NUMBER 354121 354125
Model Number GHD20E-4 GHD20E-4PF
Drills to Center of Circle (in) 20 20
Steel Drilling Capacity (in.) 1 1
Column Diameter (in.) 3-7/8 3-7/8
Distance Nose to Table (max./in) 30 30
Number of Spindle Speeds 8 8
Range of Spindle Speeds (RPM) 130, 260, 420, 535, 840, 1070, 1745,
3490
130, 260, 420, 535, 840, 1070,
1745, 3490
Spindle Taper MT-3 MT-3
Spindle Travel (in.) 5 5
Quill Diameter (in.) 2-3/8 2-3/8
Quill Feed Manual Feed Power Feed
Quill Feed Rates ( number & range) 4 (.004, .006, .009, .014)
Spindle Distance to Base (in.) 44 44
Spindle Distance to Table (in.) 30 30
Table Size (in.) 15 x 15 15 x 15
Motor (Two Speed) 1.5HP / 1HP, 440V, 3Ph 1.5HP / 1HP, 440V, 3Ph
Floor Space Required (in./L x W x H) 24 x 15-3/4 x 70 24 x 15-3/4 x 70
Net Weight (lbs) 450 690
354121
354125

JET DRILLING
jettools.com
88
DRILLING
89
jettools.com
JET DRILLING
DRILLING
RADIAL ARM DRILL PRESS
RADIAL ARM DRILL PRESS
• Spindle head has hardened and ground gears mounted on a
spline shaft
• Column designed for rigidity and minimal deection
• The arm is ribbed to withstand stress and minimize deection
• Arm is mounted with a ground sliding way which elevates easily
with the touch of a switch
• High carbon steel spindle is spline driven and supported by large
tapered roller bearings
• Base plate has T-slots and drain channels
• Coolant tank is incorporated into the casting
• Motor has an independent overload protection system
• Downfeed scale has satin chrome nish
• Spindle reversing switch is conveniently located
• Limit switches at lower and upper limits prevent over-travel of arm
STANDARD EQUIPMENT
• Complete coolant system
• Worktable
• Amp meter
• Reversing controls
• Anchor bolt set
• Fluorescent worklight
• Tool box with tools
STOCK NUMBER 320032
Model Number JRD-1000
Steel Drilling Capacity (power feed/in.) 1-3/8
Cast Iron Drilling Capacity (in.) 2
Steel Tapping Capacity (in.) 3/4
Cast Iron Tapping Capacity (in.) 1
Steel Boring Capacity (in.) 3
Cast Iron Boring Capacity (in.) 4
Column Diameter (in.) 9
Distance Spindle to Column (min./in.) 16-1/2
Distance Spindle to Column (max./in.) 42-1/4
Head Travel on Arm (in.) 25-1/2
Distance Spindle to Bed (min./in.) 21-5/8
Distance Spindle to Bed (max./in.) 43-3/4
Vertical Movement of Arm (in.) 21-5/8
Size of Worktable (L xW x D/in.) 27 x 16-1/2 x 15
T-Slot (number & size/in.) 3 & 3/4
Spindle Taper MT-4
Spindle Travel (in.) 9
Number of Spindle Speeds 12
Range of Spindle Speeds (RPM) 44 – 1,500
Number of Feeds 3
Feed per Revolution (in./rev.) 002, .0035, .006
Spindle Motor 2HP, 230V, 3Ph
Arm Elevation Motor 1HP
Coolant Pump Motor 1/8HP
Floor Space Required (in.) 62 x 27 x 80
Net Weight (lbs.) 3520

JET DRILLING
jettools.com
88
DRILLING
89
jettools.com
JET DRILLING
DRILLING
CENTER SLIDE BAR TYPE DRILL PRESS VISES
• The axial sleeve and movable jaw are cast in one single piece
• Allowable tolerance between the axial sleeve and center bar is 0.002"
• The manner in which the center slide bar is connected to the axial
sleeve assures an even 360° contact
• Much more accurate and stable than the traditional screw and cross
plate means of attaching the movable jaw to the vise bed
STOCK NUMBER 365523 365524 365525 365526
Model Number DPV-3BT DPV-4BT DPV-5BT DPV-6BT
Jaw (in./W x D) 3 x 1 4 x 1-1/8 5 x 1-1/4 6 x 1-3/8
Jaw Opening (in.) 2-13/16 3-1/2 4-5/16 5-1/2
Base Width (in.) 5-1/2 6-9/16 7-1/2 9
Base Length (in.) 6-1/47 7 8 -1/4 9-13/16
Overall Ht. (in.) 2-3/16 2-3/8 2-5/8 3
DRILL PRESS ANGLE VISES
• Adjusts quickly to a full 90° vertical or horizontal position
• High tensile iron casting is strong and heavy
• Two bolt slots on base provide easy positioning on drill press table
STOCK NUMBER 365533 365534 365535
Model Number DPAV-3 DPAV-4 DPAV-5
Jaw (in./W x D) 2-1/2 x 1-1/2 3-1/2 x 1-1/2 4-1/2 x 1-1/2
Jaw Opening (in.) 2-5/8 3-3/16 4
Base Width (in.) 3-5/16 4-1/2 5-1/2
Base Length (in.) 8-1/4 9-5/32 11-1/4
Overall Height (in.) 3-1/8 3-1/2 3-5/8
DRILL PRESS ANGLE VISES WITH SWIVEL BASE
• Use with or without swivel base
• Swivels 360°
• Quickly adjusts to 90° vertical or horizontal position
• Constructed of high tensile cast iron
STOCK NUMBER 365543 365544
Model Number DPAV-3SB DPAV-4SB
Jaw (in./W x D) 2-1/2 x 1-1/2 3-1/2 x 1-1/2
Jaw Opening (in.) 2-5/8 3-3/16
Base Width (in.) 4-1/2 5-5/8
Base Length (in.) 8-1/4 9-3/8
Overall Height (in.) 4-3/8 4-5/8
DRILL PRESS VISES AND ACCESSORIES
MODEL NUMBER STOCK NUMBER SIZE
DCA-22 561763 MT-2 x JT-2
DCA-233 561764 MT-2 x JT-33
DCA-26 561765 MT-2 x JT-6
DCA-23 561766 MT-2 x JT-3
DCA-32 561770 MT-3 x JT-2
DCA-333 561771 MT-3 x JT-33
DCA-36 561772 MT-3 x JT-6
DCA-33 561773 MT-3 x JT-3
DCA-34 561774 MT-3 x JT-4
MORSE TAPER MOUNT DRILL
• Precision hardened and ground high grade alloy steel
• All sizes with drift tang

JET DRILLING
jettools.com
90
DRILLING
91
RAPID ACTION DRILL PRESS VISESES
• Instant setting by moving sliding steel bar and handle attached to
movable jaw
• Locking the workpiece in the vise jaws is achieved by means of a cam
action on the lead bar caused by a single strike of the locking lever
STOCK NUMBER 365566 365567
Model Number PJQ-3 PJQ-4
Fits Jaw Size (in.) 3 4
STOCK NUMBER 365564 365565
Model Number QGV-3A QGV-4A
Jaw (in./W x D) 3-1/8 x 1 4-1/8 x 1
Jaw Opening (in.) 3 4-3/4
Base Length (in.) 9-1/2 12
Base Width (in.) 3-5/16 4-5/16
STOCK NUMBER 365560 365561 365562
Model Number QGV-3 QGV-4 QGV-6
Jaw (in./W x D) 3-1/4 x 1 4-5/16 x 1 6 x 1-1/4
Jaw Opening (in.) 2-3/4 4-1/4 6
Base Length (in.) 8-5/16 11 14-1/2
Width (in.) 4-1/2 6 9
PRISMATIC
• Instant setting by moving sliding steel bar and handle attached to
movable jaw
• Locking the workpiece in the vise jaws is achieved by means of a cam
action on the lead bar caused by a single strike of the locking lever
• Instant setting by moving sliding steel bar and handle attached to
movable jaw
• Locking the workpiece in the vise jaws is achieved by means of a cam
action on the lead bar caused by a single strike of the locking lever
HORIZONTAL/VERTICAL RAPID ACTION DRILL PRESS VISES
PRISMATIC JAWS FOR JET RAPID ACTION DRILL PRESS VISES
DRILL PRESS VISESAND ACCESSORIES
STOCK
NUMBER TDC-375 TDC-500 TDC-501 TDC-625 TDC-750
Model Number 561702 561704 561706 561708 561709
Capacity (in.) 0 - 3/8 0 - 1/2 0 - 1/2 1/8 - 5/8 1/8 - 3/4
Taper Mount JT-2 JT-3 JT-33 JT-3 JT-4
Body Diameter (in.) 1-15/32 1-5/8 1-25/32 2-3/16 2-7/8
Overall Length (in.) 2-3/8 2-31/32 3-1/8 3-11/16 5
TAPER MOUNT DRILL CHUCKS
• All components are heat-treated high grade alloy steel
• Chuck jaws are precision tted to withstand 115 PSI of torque
without distortion
• All models meet JIS Specication: B4634E Grade
STOCK NUMBER 660038 660012 660058
Model Number CK-38 CK-12 CK-58
Stud Size 3/8” - 16 T.P.I. 1/2” - 13 T.P.I. 5/8” - 11 T.P.I.
T-slot Sizes (in.) 7/16 and 1/2 9/16 and 5/8 11/16 and 3/4
CLAMPING KITS
• Metal storage tray can be mounted on machine or wall
• Three complete sets to choose from
52-piece kit includes:
Six T-slot nuts, Six Flange nuts, Four Coupling nuts, Six Step blocks, Six
Step clamps, Twenty four Studs, four each (3", 4", 5", 6", 7" & 8" lengths)

JET DRILLING
jettools.com
90
DRILLING
WILTON DRILLING
Belt Drive Drill Presses . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Variable Speed Drill Presses . . . . . . . . . . . . . . . . . . . . . . 94
Geared Head Drill Presses . . . . . . . . . . . . . . . . . . . . . . . . 97
Direct Drive Drill Presses . . . . . . . . . . . . . . . . . . . . . . . . 101
Radial Arm Drill Presses . . . . . . . . . . . . . . . . . . . . . . . . 103
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

92
WILTON DRILLING
DRILLING
93
WILTON DRILLING
DRILLING
15" AND 20" DRILL PRESSES
• Cast iron head
• Large quill allows greater accuracy
• Head casting features a permanently lubricated ball bearing spindle assembly, using
four heavy duty ball bearings mounted in an enclosed quill for extended life
• Massive T-slotted production work table (Model 2550 only)
• Table tilts 45°
• Large ground steel column diameter for maximum head and table support
• 3-3/8" stroke for deep hole applications
• Accurate depth stop for precise hole depths
STANDARD EQUIPMENT
• 5/8" Drill chuck and arbor
15" AND 20" DRILL PRESSES
STOCK NUMBER 2530 2500 2550
Type 15" Bench 15" Floor 20"Floor
Drills to Center of Circle (in.) 15 15 20
Cast Iron Drilling Capacity (max./in.) 5/8 5/8 3/4
Steel Drilling Capacity (max./in.) 1/2 1/2 5/8
Quill Diameter (in.) 1-7/8 1-7/8 2-1/4
Quill Travel (in.) 3-3/8 3-3/8 4-3/4
Spindle Taper 2 MT 2 MT 3 MT
Number & Range of Spindle Speeds (RPM) 12 (250, 340, 390, 510, 600, 650, 990,
1550, 1620, 1900, 2620, 3100)
12 (250, 340, 390, 510, 600, 650, 990,
1550, 1620, 1900, 2620, 3100)
12 (150, 260, 300, 440, 490, 540, 1150,
1550, 1840, 2220, 2950, 4200)
Overall Table Size (in.) 10 x 10 10 x 10 18-1/2 x 16-1/2
Table Working Surface (in.) 10 x 10 10 x 10 14 x 16
T-slot Number & Size (in) N/A N/A 3 & 1/2
Column Diameter (in.) 2-7/8 2-7/8 3-5/8
Base Size (in.) 11 x 18-1/2 11 x 19-1/2 22-3/4 x 17-3/4
Spindle to Base (in.) 24-1/2 48-3/4 43-1/2
Motor 3/4HP, 115V, 1Ph, 1725 RPM 3/4HP, 115V, 1Ph, 1725 RPM 1-1/2HP, 115V, 1Ph, 1725 RPM
Floor Space Required (in./L x W x H) 26 x 13-3/8 x 39 26 x 13-3/8 x 63-1/2 34 x 21 x 67
Net Weight (lbs.) 157 185 321
*Capacities for continuous production use will vary based on application
2530 2500 2550

92
WILTON DRILLING
DRILLING
93
WILTON DRILLING
DRILLING
15" 6-SPEED DRILL PRESSES
• Constructed to provide a solid base for drilling
• Offers a greater range in spindle speeds than others in this class
• Larger quill provides greater accuracy
• Large production work table give the operator the room to work
and support for the job
• 3" Column for head support, while the quill is also supported to
lessen deection
STANDARD EQUIPMENT
• 1/2" Drill Chuck and arbor
15" 6- SPEED DRILL PRESSES
STOCK NUMBER A3816 A3836
Type 15" Floor 15" Bench
Drills to Center of Circle (in.) 15 15
Cast Iron Drilling Capacity (in.) 5/8 5/8
Steel Drilling Capacity (in.) 1/2 1/2
Quill Diameter (in.) 2-1/4 2-1/4
Spindle Travel (in.) 6 6
Number of Spindle Speeds 6 6
Spindle Speeds (RPM) 375, 625, 1125,
1950, 3400, 5000
375, 625, 1125,
1950, 3400, 5000
Table Overall/Table
Working Surface (in.)
15-1/4 x 17-3/4/
12-1/2 x 14-1/2
14-1/4 x 12-3/8 /
10-5/8 x 12-3/8
T-slot Number & Size (in.) 2 & 1/2 2 & 1/2
Spindle to Table (in.) 41
Spindle to Base (in.) 47-1/2 11
Overall Height (in.) 67-1/2 36-1/2
Spindle Taper 2 MT 2MT
Column Diameter (in.) 3 3
Table Capacity (max./lbs.) 100 100
Motor 1HP, 115/230V, 1Ph
Prewired 115V
1HP, 115/230V, 1Ph
Prewired 115V
Floor Space Required (in./L x W x H) 30 x 20 x 71
Net Weight (lbs.) 394 375
A3816

wiltontool.com
WILTON DRILLING
94
DRILLING
95
WILTON DRILLING
DRILLING
15" VARIABLE SPEED DRILL PRESSES
• Speeds from 400 to 5,000 RPM
• Handwheel adjustment sets the speeds
• Large 2-1/4" quill allows greater accuracy
• 3" column diameter for maximum head support
• Full bearing support on quill for maximum spindle stiffness
• 6" stroke for deep hole applications
• Accurate depth stop for precise hole depths
• 1/2" Drill chuck and arbor
• Safety collar
15" VARIABLE SPEED DRILL PRESSES
STOCK NUMBER A5816/A5818 A5836/A5838
Type 15" Floor 15" Bench
Drills to Center of Circle (in.) 15 15
Cast Iron Drilling Capacity (max./in.) 5/8 5/8
Steel Drilling Capacity (max./in.) 1/2 1/2
Column Diameter (in.) 3 3
Quill Diameter (in.) 2-1/4 2-1/4
Spindle Taper 2 MT 2 MT
Spindle Travel (in.) 6 6
Spindle Speeds (RPM) 400 to 5000 400 to 5000
Overall Table Size (in.) 15-1/4 x 17-3/4 14-1/4 x 21
Table Working Surface (in.) 12-1/2 x 14-1/2 10-5/8 x 12-3/8
T-slot Number & Size (in.) 2 & 1/2 2 & 1/2
Spindle to Table (in.) 41
Spindle to Base (in.) 47-1/2 11
Overall Height (in.) 67-1/2 36-1/2
Motor A5816/A5836 1 HP, 115/230V, 1Ph,
Prewired 115V
1 HP, 115/230V, 1Ph, Prewired
115V
Motor A5818/A5838 1HP, 230/460V, 3Ph,
Prewired 230V
1HP, 230/460V, 3Ph, Prewired
230V
Floor Space Required (in./L x W x H) 30 x 20 x 71
Net Weight (lbs.) 426 336
*Capacities for continuous production use will vary based on application
A5816
A5836

wiltontool.com
WILTON DRILLING
94
DRILLING
95
WILTON DRILLING
DRILLING
20" VARIABLE SPEED DRILL PRESSES
• Variable spindle speeds from 300 to 2000 RPM
• External #3 Morse Taper
• Front mounted positive control depth stop
• 6" quill travel
• Massive 3" quill diameter
• Heavy duty cast iron design
• Large precision ground T-slot production table for easy set ups
• Front or side rack and worm gear table raiser
• Table rotates 360° around the column
• Machined T-slotted base
• Head is massively constructed for more accuracy and rigidity
OPTIONAL EQUIPMENT STOCK NUMBER
Coolant system, 1/8HP pump, 115/220V, 1Ph 5512104
Coolant system, 1/8HP pump, 220/440V, 3Ph 5508071
Jacob's chuck, 3/16"–3/4", keyed with #3 arbor 5108010
20" VARIABLE SPEED DRILL PRESSES
STOCK NUMBER 2221VS 2223VS
Drills to Center of Circle (in.) 20 20
Cast Iron Drilling Capacity (in.) 1-1/4 1-1/4
Steel Drilling Capacity (in.) 1 1
Column Diameter (in.) 4-1/2 4-1/2
Range of Spindle Speeds (RPM) 300 to 2000 300 to 2000
Distance Spindle to Column (max./in.) 10-7/16 10-7/16
Distance Spindle to Table (in.) 32-3/8 32-3/8
Spindle Travel (in.) 6 6
Spindle Taper 3 MT 3 MT
Quill Diameter (in.) 3 3
Table Size (in.) 18-1/8 x 14-3/4 18-1/8 x 14-3/4
T-slot Number & Size (in.) 2 & 5/8 2 & 5/8
Table Travel (in.) 32-3/8 32-3/8
Base Working Surface (in.) 15-1/4 x 12-1/16 15-1/4 x 12-1/16
Base Slots Number & Size (in.) 2 & 5/8 2 & 5/8
Motor for 2221VS 2HP, 115/230V, 1Ph,
Prewired 115V
2HP, 230/460V, 3Ph,
Prewired 230V
Floor Space Required (in./L x W x H) 34-1/4 x 27 x 77-1/4 34-1/4 x 27 x 77-1/4
Net Weight (lbs.) 715 715
* Capacities for continuous production use will vary based on application

wiltontool.com
WILTON DRILLING
96
DRILLING
97
WILTON DRILLING
DRILLING
STOCK NUMBER 2232AC 2234AC
Drills to Center of Circle (in.) 20 20
Cast Iron Drilling Capacity (in.) 1-1/2 1-1/2
Steel Drilling Capacity (in.) 1-3/8 1-3/8
Quill Diameter (in.) 3 3
Distance Spindle to Column (in.) 10-7/16 10-7/16
Distance Spindle to Table (max./in.) 32-3/8 32-3/8
Spindle Speeds (RPM) 65 to 2000 65 to 2000
Spindle Travel (in.) 6 6
Spindle Taper 3 MT 3 MT
Quill Travel (in.) 6 6
Column Diameter (in.) 4-1/2 4-1/2
Table Working Surface (in.) 18-1/8 x 14-3/4 18-1/8 x 14-3/4
T-slot Number & Size (in.) 2 & 5/8 2 & 5/8
Table Travel (in.) 32-3/8 32-3/8
Table Overall Size (in.) 22 x 18-3/4 22 x 18-3/4
Base Working Surface (in.) 15-1/4 x 12-1/16 15-1/4 x 12-1/16
Base Slots Number & Size (in.) 2 & 5/8 2 & 5/8
Overall Base Size (in.) 27-2/4 x 20 27-2/4 x 20
Motor 2HP, 230V, 3Ph 2HP, 460V, 3Ph
Floor Space Required (in./L x W x H) 37 x 27 x 82-1/4 37 x 27 x 82-1/4
Net Weight (lbs.) 792 792
OPTIONAL EQUIPMENT STOCK NUMBER
Coolant system, 1/8HP pump,
220V/440V, 3Ph 5508071
Coolant system, 1/8HP pump,
115V/220V, 1Ph 5512104
Jacob's chuck, 3/16"–3/4",
keyed with #3 arbor 5108010
ELECTRONIC VARIABLE SPEED DRILL PRESSES
• Variable spindle speeds from 65 to 2000 RPM
• #3 Morse taper spindle
• Latest AC inverter variable speed technology
• High torque at all speeds both forward and reverse
• Continuous speed adjustment while in operation
• Front mounted LED spindle RPM readout
• Forward and reverse for tapping
• Emergency stop
• Front mounted positive control depth stop
• Large precision ground T-slot production table for easy set ups
• Head is massively constructed for more accuracy and rigidity
ELECTRONIC VARIABLE SPEED DRILL PRESSES

wiltontool.com
WILTON DRILLING
96
DRILLING
97
WILTON DRILLING
DRILLING
OPTIONAL EQUIPMENT STOCK NUMBER
Keyless drill chuck and arbor KDC130-MT3
Jacobs drill chuck, key and arbor 5108010
Foot operated start/stop switch 5245631A
Flanged Quill 2G08459
5-speed forward/reverse switch* 1820061
Foot reversing switch* 5245631
* 3 phase machines only
20" WILTON/ARBOGA GEAR HEAD DRILL PRESSES
• Helical gears for smooth, quiet operation
• Quick release drill ejector
• Safety latch to prevent head dropping when unclamped
• Eight spindle speeds
• T-Slotted table with coolant trough
• Head and table rotate 360° around column
• 2 position, High/Low switch
• 3-15/16" Column diameter
• English/Metric depth gauge
20" WILTON/ARBOGA GEAR HEAD DRILL PRESSES
STOCK NUMBER A2608-1/ A2608-2/
A2608-4
A2608M-PF2/
A2608M-PF4
Drills to Center of Circle (in.) 20 20
Drilling Capacity Mild Steel (in.) 1-1/4 1-1/4
Tapping Capacity Mild Steel (in.) 1/2 1/2
Column Diameter (in.) 3-15/16 3-15/16
Distance Spindle to Table (max./in.) 35-5/8 35-5/8
Spindle Taper 3 MT 3MT
Spindle Speeds (RPM) 8 (130, 260, 420, 840, 535,
1070, 1745, 3480)
8 (130, 260, 420, 840, 535,
1070, 1745, 3480)
Quill Feed Manual Power Feed
Quill Feed Rates (IPR) N/A (.004, .006, .009, .012)
Quill Travel (in.) 5-1/8 5-1/8
Quill Diameter (in.) 2-3/8 2-3/8
Vertical Movement of Drill Head 8-5/8 8-5/8
Table Size (in.) 15-3/4 x 19-3/4 15-3/4 x 19-3/4
T-slot Number & Size (in) 2 & 9/16 2 & 9/16
Table Weight Capacity (lbs.) 350 350
Vertical Movement of Table (in.) 24-1/2 24-1/2
Motor for A2608-1 (2 speed) 3/4 to 1HP, 115V, 1Ph
Motor for A2608-2 (2 speed) 1 to 1-1/2HP, 220V, 3Ph 1 to 1-1/2HP, 220V, 3Ph
Motor for A2608-4 (2 speed) 1 to 1-1/2HP, 440/460V, 3Ph 1 to 1-1/2HP, 440/460V, 3Ph
Floor Space Required (in./L x W x H) 24 x 22 x 72 24 x 22 x 72
Net Weight (lbs.) 475 600
A2608M-PF2

wiltontool.com
WILTON DRILLING
98
DRILLING
99
WILTON DRILLING
DRILLING
STOCK NUMBER A3808M-PF2 A3808M-PF4
Drills to Center of Circle (in.) 25 25
Drilling Capacity Mild Steel (in.) 1-3/8 1-3/8
Tapping Capacity Mild Steel (in.) 3/4 3/4
Column Diameter (in.) 4-15/16 4-15/16
Range of Spindle Speeds (RPM) 8(90, 190, 320, 640,
530, 1060, 1790, 3610)
8(90, 190, 320, 640,
530, 1060, 1790, 3610)
Spindle Taper 4MT 4MT
Quill Feed Power Feed Power Feed
Distance Spindle to Table (max./in.) 32 32
Quill Feed Rates (IPR) 4 (.004, .006, .009, .012) 4 (.004, .006, .009, .012)
Quill Travel (in.) 5-1/8 5-1/8
Quill Diameter (in.) 2-3/8 2-3/8
Vertical Movement of Drill Head (in.) 9 9
Table Size (in.) 15-3/4 x 19-1/2 15-3/4 x 19-1/2
T-slot Number & Size (in) 2 & 9/16 2 & 9/16
Table Weight Capacity (lbs.) 350 350
Vertical Movement of Table (in.) 24-1/2 24-1/2
Motor 2-1/4 to 3HP, 220V,
3Ph, 2-Speed 2-1/4 to 3HP, 460V, 3Ph
Floor Space Required (in./L x W x H) 26 x 23 x 71 26 x 23 x 71
Net Weight (lbs.) 640 640
25" WILTON/ARBOGA GEAR HEAD DRILL PRESSES
• Helical gears for smooth, quiet operation
• Quick release drill ejector
• English/Metric depth gauge
• T-Slotted table and base with coolant trough
• Automatic feed control buttons located on feed levers
• Electro-magnetic clutch power feed
• Head and table rotate 360° around column
• No-volt release prevents spindle start when power returns
after shut down
OPTIONAL EQUIPMENT STOCK NUMBER
Automatic spindle reverse 1T05030
Foot reversing switch 5245631
Foot operated start/stop switch 5245631A
25" WILTON/ARBOGA GEAR HEAD DRILL PRESSES

wiltontool.com
WILTON DRILLING
98
DRILLING
99
WILTON DRILLING
DRILLING
26" WILTON/ARBOGA GEAR HEAD DRILL PRESSES
• Helical gears for smooth, quiet operation
• Quick release drill ejector
• English/Metric depth gauge
• Machined, T-Slotted base plate
• Head and table rotate 360° around column
• No-volt release prevents spindle start when power returns after
shut down
• Fully enclosed spindle
OPTIONAL EQUIPMENT STOCK NUMBER
Flanged Quill 1T08019
Automatick spindle reverse 1T05030
Foot reversing switch 5245631
Foot operated start/stop switch 5245631A
26" WILTON/ARBOGA GEAR HEAD DRILL PRESSES
MODEL NUMBER A3008-2/ A3008-4 A3008M-PF2/
A3008M-PF4
Drills to Center of Circle (in.) 26 26
Drilling Capacity Mild Steel (in.) 1-1/4 1-1/4
Tapping Capacity Mild Steel (in.) 5/8 5/8
Distance Spindle to Table (max./in.) 35 35
Spindle Taper 3MT 3MT
Range of Spindle Speeds (RPM) 8(90, 190, 320, 530 ,640, 1060,
1790, 3610)
8 (90, 190, 320, 530,640, 1060,
1790, 3610)
Column Diameter (in.) 4-1/2 4-1/2
Quill Feed Manual Power Feed
Quill Feed Rates (IPR) 4 (.004, .006, .009, .012)
Quill Travel (in.) 6 6
Quill Diameter (in.) 2-7/16 2-7/16
Vertical Movement of Drill Head (in.) 9 9
Table Size (in.) 15-3/4 x 19-3/4 15-3/4 x 19-3/4
T-slot Number & Size (in) 2 & 9/16 2 & 9/16
Table Weight Capacity (lbs.) 450 450
Vertical Movement of Table 30 30
Motor for A3008-2/ A3008M-FP2 (2 speed) 1-1/2 to 2HP, 220V, 3Ph 1-1/2 to 2HP, 220V, 3Ph
Motor for A3008-4/ A3008M-FP4 (2 speed) 1-1/2 to 2HP, 440/460V, 3Ph 1-1/2 to 2HP, 440/460V, 3Ph
Floor Space Required (in./L x W x H) 28 x 24 x 72 28 x 24 x 72
Net Weight (lbs.) 565 600
A3008M-PF2

wiltontool.com
WILTON DRILLING
100
DRILLING
101
WILTON DRILLING
26" WILTON/ARBOGA GEAR HEAD DRILL PRESSES
• Helical gears for smooth, quiet operation
• Quick release drill ejector
• English/Metric depth gauge
• Machined, T-Slotted base plate
• Head and table rotate 360° around column
• No-volt release prevents spindle start when power returns after
shut down
• Fully enclosed spindle
• Large T-Slotted Table
STOCK NUMBER A4008-2 / A4008-4 A4008M-PF2/
A4008M-PF4
Drills to Center of Circle (in.) 26 26
Drilling Capacity Mild Steel (in.) 1-7/8 1-7/8
Tapping Capacity Mild Steel (in.) 1 1
Column Diameter (in.) 5-1/2 5-1/2
Range of Spindle Speeds (RPM) 8 (108, 162, 240, 360,
528, 805, 1175, 1800)
8 (105, 162, 240, 360,
528, 805, 1175, 1800)
Spindle Taper 4 MT 4 MT
Quill Feed Manual Power Feed
Quill Feed Rates (IPR) 4 (.004, .006, .009, .013 )
Quill Travel (in.) 8 8
Quill Diameter (in.) 2-3/4 2-3/4
Distance Spindle to Table (max./in.) 32 32
Table Size (in.) 20 x 24 20 x 24
Table Weight Capacity (lbs.) 550 550
Vertical Movement of Table (in.) 25 25
Motor for A4008-2/
A4008M-PF2 3HP, 220V, 3Ph 3HP, 220V, 3Ph
Motor for A4008-4/
A4008M-PF4 3HP, 440/460V, 3Ph 3HP, 440/460V, 3Ph
Floor Space Required
(in./L x W x H) 23 x 28 x 81 23 x 28 x 81
Net Weight (lbs.) 700 750
OPTIONAL EQUIPMENT STOCK NUMBER
Foot operated start/stop switch 5245631A
Automatic spindle reverse 1T05030
Foot reversing switch 5245631
Flanged Quill 2GO8599
26" WILTON/ARBOGA GEAR HEAD DRILL PRESSES
A4008-2
