X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL
PRESENTATION
The X-Line Sources and Chargers of 40A, 60A, 70A, 120A, 150A and 200A are high-power
supplies, in super compact format "SLIM", which allow to power and charge automotive batteries.
They provide a maximum current of 40A, 60A, 70A, 120A, 150A and 200A at their output,
respectively, and operate in 3 intelligent modes that manage battery charging. In addition, the line
has the exclusive X-LIINE FUNCTION.
They are designed for heavy use, being able to provide maximum power for an extended
period of time, keeping the sound on and charging the batteries. Its super compact "SLIM" format is
ideal for use in any project.
X-Line Sources and Chargers oer performance, INTELLIGENCE, DIAGNOSTIC functions
and COMFORT items with the best design. They were designed and developed to be the most
complete product on the market until then.
MODES OF OPERATIONS AND FUNCTIONS
PERFORMANCE
X-LINE FUNCTION: Unique to X-LINE chargers, it raises battery bank voltage to up to 15.2V
for 30 seconds, allowing amplificators to deliver maximum performance.
INTELLIGENCE
AUTO SCI MODE: STORM Sources have auto sci operating mode, ideal for use when the
system is turned on and the sound takes power from the batteries and the source or when a quick
charge is required on the batteries.
In this mode, the STORM Source will maintain maximum output power (14.4V) whenever requested,
and will automatically enter the PULSED SCI system (SMART CHARGE SYSTEM) when the batteries
are charged, remaining into flutuation.
SLOW CHARGE MODE: X-Line Sources have SLOW BATTERY charging mode, charging
them in 3 phases (LIFTING, ABSORPTION, EQUALIZATION) indicated on the CONTROL PANEL by 3
LEDs. This function is ideal for recharging low-charge batteries and the sound system turned o.
When using the SLOW LOAD, the battery is charged at 100% capacity and without suering heating,
as its smart charge curve is adjusted to the capacity of the battery or the Batteries Installed. You get
a maximum eciency in upload without Wear. Right Extend a life useful of battery beyond from
enable still more load.
1

During phase 1 (LIFTING) the battery current is limited to a maximum of 20% of the current of the
previously configured battery bank; which gradually increases the voltage of the battery cells
without heating or overloading. This phase has 6 steps, which are indicated by the firing frequency
of LED 1 (ELEVATION), from 1 to 6Hz. When LED 1 (ELEVATION) lights up constantly, it means that
this phase has already been performed. After the battery voltage is raised to 14.4V, the source
automatically enters phase 2 (ABSORPTION). In phase 2 (ABSORPTION),the voltage remains
constant at 14.4V while the battery absorbs charge, until the current reaches 4% of the bank value,
previously configured, triggering LED 2 (ABSORPTION) constantly and automatically moving to
phase 3 (EQUALIZATION). In phase 3 (EQUALIZATION), the voltage is reduced to 13.8V with pulses
of 14.4V every 5 minutes. The battery is charged at its maximum capacity, because the equalization
is done pulsatively.
SOURCE MODE - Fixed Output Voltage: X-LINE Sources allow the user to digitally choose
between 6 voltage values at the source output (12.6V / 13.0V / 13.4V / 13.8V / 14.0V / 14.4V). This
mode is ideal for battery-free systems, allowing you to power the amplifier or other devices with a
stable voltage.
DIAGNOSIS
CCA METER – Cold Start Current: Função exclusiva das Fontes STORM, a medição de CCA -
Corrente de Partida a Frio (Cold Cranking Ampere) - permite realizar uma análise da bateria em
apenas 10 segundos, fornecendo o valor de CCA da bateria em amperes, que pode ser comparado
com o CCA disponível no rótulo da bateria ou com medições anteriores. A função mede também a
resistência interna (Ri) em mΩ (miliOhm) e a porcentagem comparativa da carga em relação a uma
bateria nova.
BATTERY CHECK-UP - Accumulated Charge Meter: The STORM Sources display, in
addition to working such as voltmeter and ammeter, informs the user how much cargo was
accumulated by the battery during the charging cycle, letting you know if the battery is still in good
working order.
2
PHASE 1 PHASE 2 PHASE 3
CURRENT
CONSTANT
PULSATING
CONSTANT
VOLTAGE
MAXIMUM
LOAD
ELEVATION ABSORPTION EQUALIZATION
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

COMFORT
SMART COOLER: X-LINE sources feature an intelligent ventilation system with dynamic
PWM control. When the source is turned on, the fan initiates a gradual acceleration, reduces the
rotation to the appropriate value, and adjusts to the source's need. There is also a decrease in noise
level, maintaining cooling and increasing the life of fans.
SLIM FORMAT: With the highest power density, X-LINE Fonts have robust, modern and
super compact design, taking up the smallest space in automotive sound design, which makes them
ideal in any project.
MAIN FEATURES
1. Control panel: Displays all source information and allows you to configure all functions;
2. Ventilation: Forced ventilation inlet from the source (do not block);
3. DC connector protection cover: Protege as conexões de saída da fonte;
4. DC output connector: Connects the battery terminals to the bus or equipment to be powered.
Always check the correct connection polarity;
5. Fixation points: Robust system, allowing to be firmemente fixados by the metal chassis;
6. AC Connection: Connection of the Source to the power grid. Use compatible connection socket
and do not use adapters and/or line machines;
7. Output from Ventilation: Output ventilation of the Source. Do not obstruct.
3
1
2
3
4
5
6
7
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

DASHBOARD FROM CONTROL
8. LED that indicates the voltage parameter VOLTAGE, CURRENT
or BATTERY CHECK-UP (2 LEDS on);
9. VOLTAGE, CURRENT and BATTERY CHECK-UP readings selector key;
10. Selector switch of SLOW LOAD, AUTO SCI e OUTPUT VOLTAGE;
11. LEDs that indicate SLOW LOAD, AUTO SCI and OUTPUT VOLTAGE;
12. BATTERY capacity selector switch (when in SLOW CHARGE mode), VOLTAGE of the output (when
in VOLTAGE OUTPUT mode) or triggering of the X-LINE function (press for 2 seconds);
13. BATTERY CHARGED LED indicator;
14. Indicator LEDs of the 3 loading phases of SLOW LOAD mode;
15. Voltage/current indicator display or hour ampere counter.
INSTALLATION AND CONNECTIONS
X-LINE sources have a robust fixation system, allowing them to be firmly fixed by the
metal chassis, giving greater resistance and safety in the installation (fig. 1).
To remove the protective cover from the DC connectors, pull it up by exposing the
connecting screws to the output cables (fig. 2).
4
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
8
9
10
11
12 13
14
Fig. 1 Fig. 2
15
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

12V
+
12V
12V
-
PARALLEL CONNECTION
Each Source 40A, 60A, 70A, 120A, 150A and 200A can power about 2,000, 3,000, 3,500,
6,000, 7,500 and 10,000 Wrms of sound playing respectively, provided that a parallel battery is
used to supply the peak consumption.
When connecting to the batteries, observe the correct polarity of the connection and use
the appropriate cable gauge, according to the MINIMUM GAUGE table OF THE CABLES FOR
CONNECTION (see page 11). In battery-powered systems, the source should always be connected to
the battery and the battery to the amplificators (the connection point should always be made in the
battery post).
You can use as many Fonts (40A, 60A, 70A, 120A, 150A and 200A) that are required to
power the sound, with reference that each one keeps about 2,000, 3,000, 3,500, 6,000, 7,500 and
10,000 Wrms of sound playing respectively.
Another important point to note is that, operating in parallel, the sources must be in the
same OPERATING MODE, example:
AUTO SCI MODE: All sources must be in SCI.
OUTPUT VOLTAGE MODE: All sources must have the same output voltage.
5
12V
+
12V
12V
-
SERIAL CONNECTION - HIGH VOLTAGE
12V
Amplifier
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

OPERATING MODES AND FUNCTIONS
MODE (REDLINE) SLOW LOAD - Smart Slow Load
To use Smart Slow Load mode, press the SELECTOR MODE until the LED indicative Of
LOAD SLOW Light. Press a key SELECTOR BATTERY e Select a capacity, in amperes, of the battery to
be charged. Upon arriving in 999, the counter returns to the first value.
If your battery does not fit the options, use the nearest smallest value, and in case there is
more than one battery in parallel in the system, add the amperage of all and select the capacity that
most closely closes to that of the seat.
The available options are:
IMPORTANT: If there are more sources in parallel in the system, use only one of the
sources in slow load mode and keep the other ones o.
SCI MODE - Smart Fast Charge
To use AUTO SCI mode, press the MODE SELECTOR switch until the Auto SCI (Smart
Charging System) LED lights up.
This mode allows the source output to operate at 14.4V when the system requests more
(sound on playing or in a battery charge situation). In fluctuation, it operates with the tension from
output in Cycles from 13.8V during 5 minutes e 14.4V during 10 Seconds.
6
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
1
2
712 17 25 40 45 50 60 70 75 80
90 100 105 115 150 200 300 400 600 800 999
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
A
/
H
1
2
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

THE AUTO SCI allows the battery to absorb a greater amount of charge and prevent
excessive elevation of the potential of the plates, a chemical phenomenon caused by load stress
(electrolysis), increasing the life and eciency of the batteries.
OUTPUT VOLTAGE MODE (Fixed Source Mode)
To use in FIXED OUTPUT VOLTAGE mode, press the SELECTOR switch MODE until the LED
VOLTAGE OUTPUT turns on.
Immediately after, press the VOLTAGE SELECTOR switch and select the desired output voltage.
The options healthy:
X-LINE FUNCTION
To select the X-LINE function, simply hold down the BATTERY /VOLTAGE/X-LINE
SELECTOR switch for 2 seconds. When triggered, the display will show the SPL inscription flashing
for 30 seconds. After this time, the display displays the OFF subscription and the font returns to its
previous operating condition.
To disable the function, before time runs out, simply press the key again
BATTERY/VOLTAGE/STORM SELECTOR while the function is running. The display displays the
inscription OFF e a source Returns à its condition from operation previous.
7
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
12
3
12,6 13,0 13,4 13,8
VDC
14,0 14,4
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
1
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

CCA METER FUNCTION (Cold Start Current Meter)
To perform CCA measurement, simultaneously press the SELECTOR READING and
SELECTOR MODE keys.
When the CCA METER function is activated, the STORM Source disconnects from the AC
power grid, disconnects the fan, and starts the battery test. When the display displays the CCA-
BATXXX information, press the BATTERY SELECTOR switch to select the battery capacity to be
tested. During this process, the display displays the word CCA flashing. After 10 seconds, the display
displays the CCAXXX information, which can range between 20A and 999A, with the CCA value
obtained in the reading and RiXXXX (internal battery resistance) in mΩ the percentage of battery
charge is displayed in comparison to a new battery (selected at the beginning of the test).
This function can be used to test a battery bank that is within the maximum source
specifications (for parallel connection, add CCA of each battery) however, it is more indicated that
the test is done on individual batteries.
For proper operation, use 50mm2 x 30cm cables for 200A and 150A sources; 35mm2 x
30cm for 120A sources; and 16mm2 x 30cm for 70A, 60A and 40A sources; and make sure that the
supply terminals are correct ly so in the terminals to the battery terminals.
BATTERY CHECK-UP FUNCTION (Cumulative Charge Meter)
To perform a BATTERY CHECK-UP, proceed:
The battery must be discharged to approximately 11V voltage.
Turn on the source, press the key SELECTOR READING until the mode BATTERY CHECK-UP
is active (VOLTAGE and CURRENT LEDS ON). To reset the counter, hold down the key SELECTOR
READING by 5 Seconds.
8
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
1
1
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
1
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

Connect the battery to the charger and wait the indication light BATTERY LOADED
(charging time may vary depending on battery capacity and the source used). Read in display a
quantity from Amps than a battery Accumulated during o process from load.
Verify the value obtained is close to the amount of amperes specified by the battery
manufacturer (e.g. If the battery charged is 60A, the obtained value should be close to 60A). The
lower, in relation to the value indicated by the manufacturer, the worse the battery status. If a
battery bank is used in parallel, add the currents of the seat batteries.
(Note: When the meter reaches 9 9 9 it must be reset to continue reading the
accumulated charge on the battery).
VOLTAGE READING
The X-LINE Source display allows you to view the output voltage (in Volts) that is being
applied at that time to the system. To access this voltage value, press the SELECTOR READING
switch until the VOLTAGE INDICATOR LED lights up.
CURRENT READING
The X-LINE Source display allows you to view the output current (in amperes) that is being
applied at that time to the system. To access this current value, press the SELECTOR READING
switch until the CURRENT INDICATOR LED lights up.
9
CONTROL PANEL
VOLTAGEBATTERYAUTO
ICS
SLOW
CHARGE OUTPUT
VOLTAGE CHARGED BATTERY
2.ABSORPTION
3.EQUALIZATION
MODE
SELECTOR
READING
SELECTOR
VOLTAGE AMPERAGE
1.ELEVATION
SLOW CHARGE
PHASES
BATTERY CHECK-UP
SELECTOR
super-x
METER
CCA - Ri m
1
PAINEL DE CONTROLE
TENSÃO BATERIAAUTO
SCI
CARGA
LENTA TENSÃO
SAÍDA BATERIA
CARREGADA
2. ABSORÇÃO
3. EQUALIZAÇÃO
SELETOR
MODO
SELETOR
LEITURA
TENSÃO CORRENTE
1. ELEVAÇÃO
CARGA LENTA
CHECK-UP DA BATERIA
SELETOR
MEDIDOR
CCA - Ri m
1
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

10
CONSUMPTION - MINIMUM CABLE GAUGE - POWER
TECHNICAL SPECIFICATIONS
40A
60A
70A
120A
150A
200A
600W
900W
1050W
1800W
2250W
3000W
5A
7A
8A
15A
18A
24A
3A
4A
5A
8A
10A
14A
2,5mm2
4mm2
4mm2
4mm2
6mm2
6mm2
6mm2
10mm2
16mm2
25mm2
35mm2
50mm2
Model
X-LINE
AC input cable
(up to 10 meters)
DC output cable
(up to 1 meter)
Max power.
Output
40A
60A
70A
120A
150A
200A
Network
220Vac
Network
127Vac
Max.
Consumption
entry
AC input
Consumption with maximum load
Maximum output current
Selectable output voltage
SCI - Intelligent charging system
3-phase slow load system - Customizable
Smart cooler - Smart ventilation system
Precision voltmeter / ammeter
Protections
Dimensions L x A x P (mm)
Weight Kg
X-LINE 40A
90 to 140Vac / 170 to 240Vac (Automatic Bi-volt)
600W
40 Amperes
12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V
13,8 / 14,4 cyclic
Elevation /Absorption/ Equalization
Dynamic control by PWM
99% / 96%
Excesso de carga / Curto na saída / Temperatura
259 x 151 x 58
1,420
AC input
Consumption with maximum load
Maximum output current
Selectable output voltage
SCI - Intelligent charging system
3-phase slow load system - Customizable
Smart cooler - Smart ventilation system
Precision voltmeter / ammeter
Protections
Dimensions L x A x P (mm)
Weight Kg
X-LINE 60A
90 to 140Vac / 170 to 240Vac (Automatic Bi-volt)
900W
60 Amperes
12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V
13,8 / 14,4 cyclic
Elevation /Absorption/ Equalization
Dynamic control by PWM
99% / 96%
Overload / Short at output / Temperature
259 x 151 x 58
1,440
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

11
AC input
Consumption with maximum load
Maximum output current
Selectable output voltage
SCI - Intelligent charging system
3-phase slow load system - Customizable
Smart cooler - Smart ventilation system
Precision voltmeter / ammeter
Protections
Dimensions L x A x P (mm)
Weight Kg
X-LINE 120A
90 a 140Vac / 170 a 240Vac (Automatic Bi-volt)
1800W
120 Amperes
12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V
13,8 / 14,4 cyclic
Elevation /Absorption/ Equalization
Dynamic control by PWM
99% / 96%
Overload / Short at output / Temperature
279 x 163 x 86
2,050
AC input
Consumption with maximum load
Maximum output current
Selectable output voltage
SCI - Intelligent charging system
3-phase slow load system - Customizable
Smart cooler - Smart ventilation system
Precision voltmeter / ammeter
Protections
Dimensions L x A x P (mm)
Weight Kg
X-LINE 70A
90 a 140Vac / 170 a 240Vac (Automatic Bi-volt)
1050W
70 Amperes
12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V
13,8 / 14,4 cyclic
Elevation /Absorption/ Equalization
Dynamic control by PWM
99% / 96%
Overload / Short at output / Temperature
259 x 151 x 58
1,440
AC input
Consumption with maximum load
Maximum output current
Selectable output voltage
SCI - Intelligent charging system
3-phase slow load system - Customizable
Smart cooler - Smart ventilation system
Precision voltmeter / ammeter
Protections
Dimensions L x A x P (mm)
Weight Kg
X-LINE 150A
90 a 140Vac / 170 a 240Vac (Automatic Bi-volt)
2250W
150 Amperes
12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V
13,8 / 14,4 cyclic
Elevation /Absorption/ Equalization
Dynamic control by PWM
99% / 96%
Overload / Short at output / Temperature
289 x 172 x 95
2,250
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL

12
AC input
Consumption with maximum load
Maximum output current
Selectable output voltage
SCI - Intelligent charging system
3-phase slow load system - Customizable
Smart cooler - Smart ventilation system
Precision voltmeter / ammeter
Protections
Dimensions L x A x P (mm)
Weight Kg
X-LINE 200A MONO
170 a 240Vac (mono-volt)
3000W
200 Amperes
12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V
13,8 / 14,4 cyclic
Elevation /Absorption/ Equalization
Dynamic control by PWM
99% / 96%
Overload / Short at output / Temperature
317 x 172 x 95
2,640
AC input
Consumption with maximum load
Maximum output current
Selectable output voltage
SCI - Intelligent charging system
3-phase slow load system - Customizable
Smart cooler - Smart ventilation system
Precision voltmeter / ammeter
Protections
Dimensions L x A x P (mm)
Weight Kg
X-LINE 200A
90 a 140Vac / 170 a 240Vac (Automatic Bi-volt)
3000W
200 Amperes
12,6V / 13,0V / 13,4V / 13,8V / 14,0V / 14,4V
13,8 / 14,4 cyclic
Elevation /Absorption/ Equalization
Dynamic control by PWM
99% / 96%
Overload / Short at output / Temperature
317 x 172 x 95
2,650
X-LINE SOURCES AND CHARGERS - INSTRUCTION MANUAL
