Joab EcoDrive User manual

JOAB Försäljnings AB
Östergärde Industriområde
417 29 Göteborg
Telephone
031-705 06 00
Telefax:
031-705 06 09
E-post:
[e-mail]
Operation and Maintenance
Manual for Hook-Lifts
www.joab.se
13300 Edition 1 | 2019-01-31 | KM

EcoDrive manual: 13300 Edition 1 | 2019-01-31

iii
Table of Contents
Introduction vii
About the Hook-Lift 1
Correct Usage 2
Hook-lift Components 3
LA-Model Hook-Lifts 4
Optional Locking Mechanisms 4
Manufacture Plate 4
Design 5
Body Standard 7
Safety 9
Operation 11
CBW controller 11
User Interface 12
Icon Definitions 12
Page Set-Ups 14
Hook Positioning 15
Function Buttons 15
Background Light 16
Warnings 16
Control Stick Function 16
Snow Plough Functions 18
Diagnostics and Statistics 19
Continuous-Hydraulic-Supply 19
Emergency Stop 20
Emergency Operation 21
EcoDrive Standard Functions 21
Intelligent Pump Control - IPC 22
EcoDrive Pressure Control - EPC 22
Fast Drive System - FDS 22
Smartlock System - SLS 22
EcoDrive Load Holding - ELH 22
Electronic Cylinder Damping - ECD 22
Electronic Speed Control- ESC 23
EcoDrive Tipper Mode ETM 23
Fast Lowering System - FLS 23
Friction Free Drive - FFD 23
EcoDrive manual: 13300 Edition 1 | 2019-01-31

Tipper Safety System - TSS 24
Trailer Safety Tipper - TST 24
Trailer Fast Lowering System - TFS 24
Decentralized Hydraulic System - DHS 24
EcoDrive Optional Functions 24
Position Memory System - PMS 24
Fast Lowering System Plus - FLS+ 25
Fast Tipper System - FTS 25
Fast Drive System Plus - FDS+ 25
Service Online System - SOS 26
Auto-Cycle 26
Snow Plough Functions 26
Radio Controllers 27
Before Operation 27
Operation 27
Display 28
LEDs 28
Emergency Stop 28
Function Mode 28
Start the Radio Controller 29
Fast Operation 30
Axle Weight Reading 30
Charging 30
Distributing a Load on a Body 31
Loading a Body 33
Tipping a Body 39
Unloading a Body 41
Shunting a Body 45
Risk of Damage 48
Service and Maintenance 51
Daily Maintenance 51
Washing the Hook-Lift 52
Lubrication Points 53
Service of the Hook-Lift 54
Service-Reminder Sticker 54
Service Packets and Warranty 54
Torquing of Fasteners 55
iv
Table of Contents
EcoDrive manual: 13300 Edition 1 | 2019-01-31

Table of Contents
Working on the Hook-Lift 56
Safety Warnings 59
Technical Data 61
Fault Tracing the Hook-Lift 63
Contact Information 65
Service and Warranty Claims 65
vEcoDrive manual: 13300 Edition 1 | 2019-01-31

Table of Contents
vi EcoDrive manual: 13300 Edition 1 | 2019-01-31

vii
Introduction
This manual explains how to operate and maintain your EcoDrive Hook-Lift. It contains import-
ant information for your own safety and the surrounding environment.
JOAB’s products are characterised by a high level of safety, reliability, and long service-life. To
get the best out of your EcoDrive Hook-Lift, we recommend reading this manual carefully.
This manual also contains information regarding fault tracing, lubrication, and servicing of your
EcoDrive Hook-Lift. This manual is based on the original mounted equipment only. Refer to the
relevant supplier’s manuals for all other optional or auxiliary equipment.
JOAB takes no responsibility for consequences that occur due to work carried out by non-pro-
fessionals.
After receiving the EcoDrive Hook-Lift, ensure that it is in proper working order. If it is not, con-
tact JOAB, your dealer, or other supplier.
The specifications, constructions, and illustrations found in this manual are not binding.
JOABAB retains the right to make changes without prior notice.
For all EcoDrive Hook-Lifts sold in Sweden, the general delivery regulations apply.
A training CD is included with certain deliveries. This comprehensively describes how to use
JOAB’s products, such as EcoDrive Hook-Lifts, lift dumpers, and the Hookmaster.
Always bare in mind that it is the operator that is responsible for handling the EcoDrive Hook-
Lift.
© JOABAB
EcoDrive manual: 13300 Edition 1 | 2019-01-31

viii
Introduction |
EcoDrive manual: 13300 Edition 1 | 2019-01-31

1
About the Hook-Lift
JOAB's hook-lifts are multi-purpose. They can
be used with all vehicle manufacturers.
However, it is important that the vehicle has
been built specifically for the purpose of bear-
ing a hook-lift.
It is important to verify that the vehicle has the
correct axle distance and wheelbase.
JOAB’s hook-lifts are designed to transport dif-
ferent types of bodies that have been man-
ufactured according to the Swedish
standardSS-3021.
These typically include: dump bodies, flat beds,
and containers, as shown.
Mounting the hook-lift onto a vehicle that has
not been specifically designed for the purpose
of carrying a hook-lift will increase the risk of an
abnormal load on the vehicle. This in turn can
lead to serious injury or damage.
EcoDrive manual: 13300 Edition 1 | 2019-01-31

Correct Usage
Incorrect use of JOAB's products can lead to material fatigue and cause excessive wear to the
hydraulics and its components. The service life of the product can be reduced and in the worst-
case lead to breakdown.
Do not drive the vehicle with the hook lift
extended. It must be fully retracted.
Do not use the vehicle for any other
purpose than its intended use.
Make sure to reverse straight towards the
body. Do not reverse at an angle.
Do not lift loads that exceed the hook-
lift's specifications.
If the body becomes stuck, observe caution.
The hook-lift can easily be damaged.
2
About the Hook-Lift | Correct Usage
EcoDrive manual: 13300 Edition 1 | 2019-01-31

Hook-lift Components
The hook-lift consists of the following main components: a frame, cylinders, auxiliary-lifting-
arms, and a post with a lifting hook (made of high tensile steel).
A. Sub frame
B. Auxiliary lifting arm
C. Inner rear section
D. Intermediate section
E. Extending section
F. Hook
G. Hook post
H. Hydraulic lock
I. Folding hook post (LA models only)
J. Safety hook (LA models only)
K. Centre lock
L. Spreader flap deployer (accessory)
M. Rollers
3
About the Hook-Lift | Hook-lift Components
EcoDrive manual: 13300 Edition 1 | 2019-01-31

LA-Model Hook-Lifts
LA-models are equipped with both a folding-hook-post (I) and a safety-hook (J), as shown
above.
The folding-hook-post is used to allow for low lifting angles. The hook-post can be moved
upwards and downwards as required to assist the loading/unloading of a body. It is operated
using the cab controller for the hook-lift.
The safety-hook is used to lock the hook onto the lifting bracket of a body and is operated from
the cab.
Optional Locking Mechanisms
JOAB's hook-lifts can be purchased with
optional body locking devices. These options
are in addition to the governing standards rel-
evant to each country.
For information regarding the relevant body
standard, refer to "Body Standard", on page 7.
An internal-mechanical lock or hydraulic lock
can be purchased as an option, as shown
opposite.
If a hook-lift with external hydraulic locking is
purchased, the body must have cut-outs in its frame, as shown. If the body does not have cut-
outs, it will not be secured during transport!
If a hook-lift with internal-mechanical locking is purchased, make sure that the locks engage the
body correctly. If they do not engage correctly, the body will be transported unsecured!
Manufacture Plate
All hook-lifts have a manufacture-plate located
on the front left-hand side of the subframe. The
information on the manufacture-plate must be
provided in the event of making a claim or when
ordering spare parts from JOAB.
4
About the Hook-Lift | Optional Locking Mechanisms
EcoDrive manual: 13300 Edition 1 | 2019-01-31

In addition to the manufacture plate, the man-
ufacture number is a also stamped onto the cyl-
inder cross member, as shown.
Design
JOAB's products are subjected to demanding
tasks and must be of the highest quality. All of
JOAB's components and constructions are thor-
oughly tested. Simulations for calculating: load
capacity, durability, and service life are per-
formed on all components
All development and manufacture is per-
formed by JOAB. We are ISO 9001 and ISO
14001 certified.
A large proportion of our production is auto-
mated. This guarantees high quality in the man-
ufacturing process.
5
About the Hook-Lift | Design
EcoDrive manual: 13300 Edition 1 | 2019-01-31

JOAB's painting facilities meet all applicable
environmental requirements.
6
About the Hook-Lift | Design
EcoDrive manual: 13300 Edition 1 | 2019-01-31

7
Body Standard
The use of bodies that are not designed in accordance with the standard SS 3021
can lead to personal injury or environmental damage. JOAB accepts no responsibility
for the use of bodies that do not conform to the standard: SS 3021.
JOAB's hook-lifts are designed to handle bodies that are manufactured in accordance with the
Swedish standard SS 3021. Shown below are some of the more important requirements of the
standard: SS 3021.
Internal mechanical lock that locks the body
onto the hook-lift. This is optional equipment.
Holes in the body's rear beam. These are used
to secure the body onto a trailer.
Cut-outs in the body's frame. These are used
to hydraulically lock the body onto the hook-lift.
Modification in the body that allows the hook-lift
to lock the body onto the hook-lift with the use
of locking arms (optional).
EcoDrive manual: 13300 Edition 1 | 2019-01-31

The body must have a stop member that pre-
vents the body from moving forwards and into
the cab of the vehicle.
Internal holes located in the body's frame mem-
bers are used to lock the body onto a trailer.
8
Body Standard |
EcoDrive manual: 13300 Edition 1 | 2019-01-31

9
Safety
Observe all safety warnings. Failure to do so can lead to serious injury or damage to equipment.
For further information regarding warning labels placed on the vehicle, refer to "Safety Warn-
ings", on page 59.
All personnel operating the hook-lift must read and follow all warnings provided in this manual
and on the hook-lift.
Every day, before operation of the hook-lift,
inspect and verify that no objects have fallen in
between the hook-lift’s tipping components.
Always make sure that the vehicle is on a level
and firm surface before operating the hook-lift.
Failure to do so can cause the vehicle to
become unevenly loaded and lead to it tipping
over.
If the vehicle leans two or more degrees there
is a risk that it will tip over.
Before collecting a body, make sure that its
body-bracket is undamaged.
Make sure that the hook on the hook-lift
engages the body's bracket properly, as shown
opposite.
If the hook-lift has a safety hook (LA models
only), make sure that it is locked.
Do not tip, load, or unload bodies when the
vehicle’s axles are raised.
Make sure the axles, where applicable, are
lowered before operating the hook-lift.
Do not make any modifications to the hook-lift
as this can effect its structural properties. If a
modification is required, contact JOAB for
advice before making a modification to the
hook-lift.
EcoDrive manual: 13300 Edition 1 | 2019-01-31

10
Safety |
EcoDrive manual: 13300 Edition 1 | 2019-01-31

11
Operation
Thischapter explains the operation and control of the EcoDrive Hook-Lift using the CBW con-
troller, that is located inside the cab.
The hook-lift can also be controlled with the use of JOAB's radio controller. Radio controllers are
an extra option. For further information see "Radio Controllers", on page 27.
CBW controller
The CBW controller has both a display and control
stick, as shown, and is used to control all functions of
the hook-lift.
Certain functions, such as the operation of the
hydraulic pump, can be installed on the cab instru-
ment panel, either in addition or separate from the
CBW controller, as required.
The CBW controller has the fallowing main parts:
1. Emergency Stop
2. User Interface
3. Control stick
4. Mounting bracket
5. Screen lock screw
The emergencystop button isused in case of an emergency. Once pressed, all functions of the
hook-lift that could cause injury are disabled. To restore operation the system must be restar-
ted.
The user interface of the CBW controller has a 2.8 inch colour display. It is configurable. It is pos-
sible to display one of five different page set-ups. Each page set-up can have six user defined
functions, such as turning lights on. For further information see "Page Set-Ups", on page 14.
The control stick is used to control the basic functions of the hook-lift, such as tipping. For
detailed information regarding its function, refer to "Control Stick Function", on page 16.
The mounting bracket is used to mount the unit inside the cab. Normally it is mounted onto the
driver's A-post. However, it is also possible to mount it onto the driver's right arm rest. This is
ideal for snow ploughs.
EcoDrive manual: 13300 Edition 1 | 2019-01-31

User Interface
Shown opposite is an overview of the user inter-
face.
The areas marked with a white rectangle on the
screen are programmable. The user can set
which functions are placed there. These func-
tions are activated by pressing the cor-
responding buttons: F1–F4 and the UP/DOWN
arrows. For further information on how to set
these functions, refer to "Function Buttons", on
page 15 below.
The function icons (F1–F4 and the UP/DOWN
arrow buttons) that are displayed in the user
interface is dependent upon which page set-up
is selected. There are five different page set-
ups. To switch between these press either the left or right arrow button located below the
screen. For more information see "Page Set-Ups", on page 14.
All other icons that are displayed on the screen (not the user defined functions) simply provide
feedback to the user regarding the status of the hook-lift, which page set-up is active, and active
functions, such as lights on etc.
See "Icon Definitions", below for a list of the icons and their function.
Icon Definitions
Provided below is a list of the functions available in the user interface and their meaning. Note,
not all functions listed below are activated for all installations. Some of the functions are optional
extras, these are marked with an asterisk (*).
Functions that can be selected for the programmable areas (F1–F4 and the UP and DOWN but-
tons) are coloured white. All other buttons (orange and green) simply provide feedback to the
user as to whether or not they are active.
Icon Function Icon Function
Night mode Deactivate FFD2. Read NOTE 2
below.
Load light -ON Tip trailer - UP*
Table 1: User interface – icon description
12
Operation | CBW controller
EcoDrive manual: 13300 Edition 1 | 2019-01-31
