joke DIPROFIL FMR/E5 User manual

DIPROFIL®
FMR/E5 /E10 /E15
Mini hand-filing machine
Instruction Manual

1
List of contents
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
2
1 List of contents .................................................................................... Page 02
2 Tips on using the manual................................................................... Page 03
3 Safety instructions ............................................................................... Page 04
4 Warranty/Identification ..................................................................... Page 06
5 Operation/ Maintenance/Care....................................................... Page 07
6 Telefax form ......................................................................................... Page 09

2
Tips on using the manual
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
3
This manual has been written for the device user to ensure a prob-
lem-free operation, care and maintenance.
Important instructions and information concerning safety and op-
erational reliability have been highlighted.
The symbols used in the manual have the following meanings:
Working and operating processes which must be observed to the
letter to exclude any risk to persons.
CAUTION!
IMPORTANT! Working and operating processes which must be observed to the
letter to avoid any damage to the device.
INFORMATION! Technical information to which the device operator must give spe-
cial attention.
The illustrations and diagrams are numbered in sequence within
each chapter. Some of these illustrations have keys. References to il-
lustrations within the text e. g. (5.1/2) have the following meaning:
5.1 = Figure 5.1
2 = Position 2 in the key to the figure.
Please feel free to call our customer service department at any time
should you encounter technical problems which are not dealt with
in this manual:
Telephone [phone] / 8 39 - 0
Telefax +49 (0) 22 04 / 8 39 - 60
INFORMATION! www.joke.de
Spare parts lists and operating manuals for our products are to be found at
www.joke.de.

3
Safety instructions
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
4
This device has been built according to the latest technical standards and
generally accepted safety regulations. Nevertheless, it can constitute dan-
ger to life and limb for operator or third parties and a hazard to the de-
vice itself or other equipment during use.
IMPORTANT (1) Only use the device if in perfect working order and for its intended pur-
pose. You must always pay attention to the instruction manual and sa-
fety instructions therein and be aware of the risks! Repair any faults
which could affect the device’s safety immediately by yourself or
have these repaired.
The unit is designed exclusively for grinding, milling and polishing work
with the tools listed and approved in the joke catalogue „Surface
Finishing“. Any other use will be deemed to be contrary to its intended
purpose. The manufacturer cannot be held liable for any resulting
damages. The risk is borne solely by the user.
Correct use also includes compliance with the instruction manual and
an observation of the care and maintenance conditions.
(2) Keep the instruction manual handy at the device’s place of use.
(3) Pay attention to and observe generally applicable statutory and oth-
erwise binding regulations relating to accident prevention and envi-
ronmental protection in addition to the information provided in the in-
struction manual!
CAUTION!
(4) All personnel commissioned to work on or with the device must have
read this instruction manual, and particularly the safety instructions
chapter, before starting work. This applies especially for personnel who
only work with the device occasionally.
(5) Stop the device immediately should you notice changes to the device
or its operating behaviour that are relevant to its safety. Have these
remedied before restarting work.
(6) Do not carry out any modifications, additions or conversions to the de-
vice! This also applies to the installation and adjustment of safety e-
quipment.
IMPORTANT! (7) Spare parts must meet the technical requirements specified by the
manufacturer. This can only be guaranteed with original joke spare
parts.

3
Safety instructions
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
5
(8) Any work on/with the device may only be carried out by quali-
fied, appropriately trained and authorised personnel. Pay atten-
tion to minimum statutory age limits!
CAUTION! (9) Wear safety goggles when working with the handpiece.
(10) Personnel undergoing training or in a general apprenticeship should
only be allowed to work with the machine under the constant supervi-
sion of an experienced operator!
(11) Restrain from any type of work that could jeopardise your safety.
(12) The device may only be used if all protective and safety equipment is
in place and in proper working order.
(13) Do not leave the device unattended when switched on!!
(14) Stop and secure the device immediately in the event of malfunctions!
Faults must remedied at once.

4
Warranty/identification
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
6
joke Technology warrant the correct manufacture of every joke Technology
product which is delivered in accordance with the terms of
contract and delivery.
This warranty does not cover damages caused by normal wear and tear,
incorrect handling, negligent use, the fitting of non-original spare parts, ina-
dequate care and/or a failure to comply with this technical manual.
The device may only be used by appropriately trained personnel. If
it is not, all warranty claims will be forfeited according to the terms of
delivery.
IMPORTANT!
Device identification
The manufacturer’s code and type code, CE label and series number can
be found on the rear of the control units or in the case of the handpieces
on the handle sleeve.

5
Operation/maintenance/care
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
7
Technical information for connection to the micromotor J-BM 40
for the DIPROFIL®mini hand-filing machine FMR/E 5 and FMR/E 15
Order no.
DIPROFIL® mini hand-filing machine FMR/E 5
For connection to micromotor J-BM 40
for stroke length 0.5 mm, complete in case
0 001 207
DIPROFIL® mini hand-filing machine FMR/E 10
For connection to micromotor J-BM 40
for stroke length 1.0 mm, complete in case
0 001 215
DIPROFIL® mini hand-filing machine FMR/E 15
For connection to micromotor J-BM 40
for stroke length 1.5 mm, complete in case
0 001 209

5
Operation/maintenance/care
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
8
Starting the DIPROFIL mini hand-filing machine
FMR/E5, FMR/E10 and FMR/E15
The usable tools are clamped to the tool carrier using the hexagon
socket screw.
1 - Locking screw
2 - Tool carrier
3 - Guide
The maximum number of strokes should not exceed
10 000 strokes/min.
IMPORTANT!
In order to cushion against the vibration stress and heating during
more prolonged operation, use the rubber protection.
The DIPROFIL®mini hand-filing machine must only be connected to
the micromotor with the motor switched off!
IMPORTANT!
Lubrication
The bearings in the DIPROFIL®mini hand-filing machines are encap-
sulated and lubricated for the entire service life.

5
Operation/maintenance/care
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
9
The tool carrier guide should be lubricated with a few drops of oil af-
ter each 5-hour period of use.

6
Telefax form
joke Instruction manual
DIPROFIL®FMR/E5 /E10 /E15 mini hand-filing machine
10
To the
MRNH service department
+49 (0) 22 04 / 8 39 - 60
Sender:
Company
Name
Street
Postcode/town or city
Please send us the spares drawing and parts
list for the following equipment:
0as a printout (see above for address)
0 by fax, ____________________________
0as a pdf file to my email address _____________________________
ENESKA 4 control unit Ord.-no. 0 009 801 0
Rapid-chuck handpiece J-G 30 Ord.-no. 0 009 810 0
Handpiece J EHG 400 Ord.-no. 0 009 811 0
Angle handpiece J ERA 270 Ord.-no. 0 009 812 0
Angle handpiece EKC 300 Ord.-no. 0 009 813 0
Mini hand-filing machine N44 Ord.-no. 0 001 402 0
Mini hand-filing machine N48 Ord.-no. 0 001 403 0
DIPROFILmini hand-filing machine FMR/E
5
Ord.-no. 0 001 207 0
DIPROFILmini hand-filing machine FMR/E
10
Ord.-no. 0 001 215 0
DIPROFILmini hand-filing machine FMR/E
15
Ord.-no. 0 001 209 0
Hand filing machine FMM 4 Ord.-no. 0 005 300 0
Transverse handpiece QH 4 Ord.-no. 0 031 801 0
Date Signature

MRNH7HFKQRORJ\*PE+
Asselborner Weg 14 - 16
D-51429 Bergisch Gladbach
Telephone: [phone] / 8 39-0
Telefax: +49 (0) 22 04 / 8 39-60
Technical
modifications
reserved
Internet: www.joke.de
Email: [email protected] © joke 12/14
