Jorvik Jet-E1 User manual

Jorvik JMT Mid Drive Electric Mountain Trike

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 2

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 3
User Manual
Thank you for purchasing a Jorvik Tricycles “JMT Range”.
We believe this is the future of transport, not only is it an eco-friendly way of transportaon of yourself or goods in the
basket but the rider will also reap the benets of a healthy body and a healthy mind. The JMT range is built with style,
quality, ease of use and ruggedness to explore those unbeaten tracks.
The possibilies are endless but mainly it should bring a smile to your face.
HAPPY TRIKING!
Please scan the above QR code and subscribe to our YouTube channel for useful hints and ps videos.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 4
Warning
Electric tricycles can be dangerous to use. The user assumes all risk of personal injury, damage or failures of the tricycle
or system and any other losses or damage to themselves or others, including property arising from the result of using
the tricycle.
As with all mechanical components, the tricycle is subject to wear and tear and high stresses. Dierent materials and
components may react to wear or stress fague in dierent ways. If the design life of material has been exceeded, it
may suddenly fail possibly causing injury to the rider. Any cracks, scratches, changes of colour in the paint in high stress
areas indicates the life of that component has been reached and should be replaced.
For replacement parts, technical informaon and warranty assistance, please contact Jorvik Tricycles on
[phone] or E-Mail: [email protected]
DDO NOT DISSASSEMBLE, MODIFY OR REPLACE ANY OF THE ELCTRICAL PART.
Your insurance policy may not provide coverage for accidents involving the use of electric tricycles. Contact your
insurance company or agent to determine if you are covered.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 5
Index
User manual 3
Warning 4
Index 5
Product 6
How to Assemble the Tricycle 7
Maintenance and upkeep 22
About Charging 26
Removing the Baery 28
Starng the Tricycle 32
Safety 33
Troubleshoong 36
Notes 47

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 6
Display
Gear
Product
Gear Selecon
Display

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 7
How To Assemble This Tricycle
Assembly Instrucons
Your trike has been pre-assembled. It requires only a few simple steps to get it ready for your rst ride.
1. Remove the outside carton aer cung the nylon bands and taking o the lid. Carefully remove your trike from the
box and gently rest it in place.
2. Remove all the inside cardboard protecon and bubble wrap.
3. Locate and set aside the kit box containing the pedals, this user’s manual, and tool kit.
4. Install the front wheel by lining up the disc brake and place the fork of the trike onto the front wheel. (You may need
to remove the spacer between the disc brake pads)
5. Insert the quick release skewer & turn the skewer adjusng nut clockwise to ghten it. Keep turning the adjusng
nut unl you see or feel the nut contact the face of the dropout.
6. Next, try closing the lever. Your goal is to ghten the adjusng nut enough so that the lever can be fully closed and
closing it requires signicant force. You want it to be hard to close, you want to see a lever mark on your hand. If the
lever is not hard to close, hold the lever and further ghten the adjusng nut, try again. If not possible to close or its
very, very hard to close, hold the lever and slightly loosen the adjusng nut, try again. Towards the end of the
adjustment process, quite small changes, like ½ turn, of the adjusng nut are necessary. Your goal is to ghten the

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 8
adjusng nut enough so that the lever can be closed but requires signicant force to close. You want it to be hard to
close, you want to see a mark on your hand.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 9
Fing the Stem JMT 7 13
1. Remove the white safety
cover/spacer.
2. Make sure the front fork is aligned to
the wheel.
3. Mount the handlebar onto the top of
the front fork stem.
4. Tighten the stem down with a 5mm
hex key.
5. Tighten the 2 pinch bolts on the stem
with a 5mm hex key.
6. Adjust the height by slacking the
single 5mm bolt on the right side of
the stem and adjusng the angle as
required. Then ghten.
7. Adjust the bar rotaon undoing the 4
x 4mm bolts on the face plate then
ghten evenly checking that the bars
do not move under pressure.
1.
2.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 10
Fing the Stem JMT 9
1. Lightly grease the quill of the stem
2. At the boom of the stem li the
chrome safety clasp then open the quick
release lever.
3. Then mount the stem into the top of the front
fork.
4. Tighten the bolt in the stems centre using a
6mm hex key making sure the front fork is
aligned to the wheel.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 11
Adjusng the Stem JMT 9
To adjust the handlebar height, open the black quick release lever
at the top of the stem, adjust to desired height then close again.
To collapse or raise the handlebars, li the chrome safety clasp
then open the vercal quick release lever, collapse the
handlebars.
To raise and lock into posion again reverse the same procedure.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 12
Aaching the Front Fender
Attach the front fender and light using the bolt already located in the fork arch or in the hardware box. Attach the front
light using the same bolt/bracket as shown.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 13
Fing the Pedals
Apply a small amount of grease onto the
pedal threads.
NOTE: You will see either “L” or “R” on the
end of the pedal thread. The “R” is for the
righthand pedal and needs to be turned
clockwise to ghten and the “L” or lehand
pedal Counterclockwise to ghten. Incorrect
ng can damage your crank.
Use a 15mm spanner to ghten the pedals
rmly.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 14
Fing the Saddle
Apply a small amount of grease into the seat tube or boom of the seat post. Release the seat clamp lever and insert the seat post
into the tube and slide up and down to make sure it moves freely.
Clamp the seat post by moving the lever back to the closed posion. It should require rm pressure (enough to leave a small
imprint on the palm of your hand to close. Check the seat height so that when the pedals are set the furthest down your leg has a
slight bend.
If the seat moves when weight is put on it open the clamp and adjust the nut on the opposite side clockwise to add to the
clamping force. Adjust in ¼ turns unl the seat is secure.
Do not exceed minimum inseron mark.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 15
Rear Fender Assembly
The rear fenders are aached to the basket by 2x 5mm hex bolts (found in the fenders). The front of the basket has the
mounng brackets further forwards. Use the bolts and washers to x the fenders in place as shown.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 16
Front Suspension and Sag Guide
Sag is a measurement of the amount of
suspension fork travel with the rider
staonery in their normal riding posion.
The Sag depends on the posion and weight
of the rider and should be between 15%
and 30% of the fork’s max travel depending
on the intended use and preferences. The
adjustment is made in the le-hand side leg
of the fork.
The right-hand leg controls the lock out
(prevents fork movement). This is useful
when riding on smooth terrain where
suspension is not needed.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 17
Gears
Your Jorvik JMT model trike is equipped with 7 speed nexus hub gear driven system. The rst gear is for easier and uphill
pedalling, and the last gear is for maximum speed on level or downhill terrain. Change gears only while pedalling. When
the grip shi nexus gear selector shows ‘1’ you are in the rst gear, or the lowest gear. When it displays ‘7’ you are in the
highest gear. Adjustments require the ne tuning and should only be made by a qualied technician.
Avoid changing gears very rapidly from rst gear to the last gear or vice versa.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 18
Throle Control JMT 9
The throle control is operated on the le-hand side of the handlebars.
You control the throle by pushing it down using your thumb, the more you press the more power is released. The
further the throle switch is from its resng posion; the more power is delivered to the motors to accelerate the Jorvik
JMT trike. When you want to slow down, you simply release the throle and let it return to its resng posion and
simultaneously apply the brakes.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 19
Throle Control JMT 7 and 9
For 250w models the throle/walk mode is operated by tapping the (-) buon on the + - control unit (le hand side of
handlebars) unl the person walking next to a bike image is displayed, as seen in Image I. Once that mode is engaged,
keep the (-) buon held down to acvate the throle/walk mode, if you release the pressure on the (-) buon the
throle/walk mode will stop. For 500w models you control the throle/walk mode by pushing the throle lever using
your thumb, the harder you press the throle the more assist you will get, release the pressure from throle and the
trike will slow down and eventually stop.

Jorvik JMT Mid Drive Electric Mountain Trike
Page | 20
Disc Brakes
Jorvik Tricycles are equipped with disc brakes for maximum reliability whatever the condions and load. Pulling on the
brake levers will engage the brake calliper and apply pressure from the pads to the brake rotor on the wheel. This
creates fricon slowing the wheel down. The more pressure applied the more braking force is applied and so the faster
the tricycle will come to a stop.
Braking should be done in a smooth acon. Applying the front or rear brake quickly can cause the rider to be thrown o
the saddle. Best pracce is to apply braking force evenly at rst then applying slightly more front brake to reduce the
possibility of skidding.
Disc brakes can somemes make a very light scraping noise; especially cable disc brakes, this is normal.
Warning:
Disc brakes can become extremely hot under braking. DO NOT TOUCH rotor aer use. Wet weather will
require longer braking distances and increase the possibility of skidding. Brake early and progressively in
wet or muddy condions
