I. Preface
The Alphatron LT-3100 Iridium is a maritime satellite communication product. The Alphatron LT-3100
Iridium is designed for the professional market (deep sea, fishing, and workboats), but can be used
for the leisure market as well. The Alphatron LT-3100 Iridium meets all standards and certification
requirements needed for worldwide maritime satellite communication equipment.
The Alphatron LT-3100 Iridium is a high quality, easy to install Satellite Navigation System.
•Thoroughly read this instruction manual before installation and operation of the equipment.
•We recommend keeping this manual nearby the equipment to ensure ready access to it.

5 | Introduction
Revision History
Revision
No.
Date
Description
Author
1.0
28-07-2020
First release
J. Kreeft

6 | Introduction
Glossary
The glossary contains a list of abbreviations and a list of definitions.
Abbreviations
Abbreviations as used in this manual are explained in the table below.
DC
Direct Current
DHCP
Dynamic Host Configuration Protocol
I/O
Input/Output
IEC
International Electrotechnical Commission
ICC-ID
Integrated Circuit Card Identifier
ISP
Iridium Service Provider
LCD
Liquid Crystal Display
MO
Mobile Originating
MSISDN
Mobile Station Integrated Services Digital Network
PCB
Printed Circuit Board
PIN
Personal Identification Number
PUK
Personal Unblocking Key
RX
Receiver
SIM
Subscriber Identity Module
TFT
Thin Film Transistor
TX
Transmitter
UI
User Interface
VSAT
Very Small Aperture Terminal
W
Watt
Definitions
The meaning of standard definitions as used in this manual are explained in the table below.
DHCP
A network management protocol used on Internet Protocol networks
whereby a DHCP server dynamically assigns an IP address and other
network configuration parameters to each device on a network so
they can communicate with other IP networks.
IEC
A non-profit, non-governmental international standards organization
that prepares and publishes International Standards for all electrical,
electronic, and related technologies.
MSISDN
A number uniquely identifying a subscription in a mobile network. It is
the mapping of the telephone number to the subscriber identity
module in a device.
PIN
A numeric or alpha-numeric password used in the process of
authenticating a user accessing a device.
SIM
An integrated circuit that is intended to securely store the
international mobile subscriber identity number and its related key,
which are used to identify and authenticate subscribers on devices.

7 | Introduction
II. Safety Information
The signal words DANGER, WARNING and CAUTION used in this manual indicate the degree of
hazard that may be encountered by the user. These words are defined as follows:
DANGER
Indicates a hazardous situation which, if not avoided, will result in death
or serious injury. This signal word is limited to the most extreme
situations.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury.
The signal word NOTICE used in this manual indicates information considered important but not
related to injury. It is typically used to prevent damage to equipment or property.
To safely install, service, repair and operate this system, the following DANGERS, WARNINGS, and
CAUTIONS must be adhered to. Failure to comply with the precautions or with specific dangers,
warnings, and cautions elsewhere in this manual violates safety standards of design, manufacture,
and intended use of the equipment. ALPHATRON MARINE assumes no liability for the customer's
failure to comply with these requirements.
WARNING
Keep away from live circuits. Otherwise, it may cause a fire, or you may
suffer an electrical shock.
WARNING
Under certain conditions, dangerous voltages may exist even with the
cable removed. To avoid injuries, always disconnect power and discharge
circuits before touching them. Otherwise, it may cause a fire, or you may
suffer an electrical shock.
WARNING
Do not disassemble or modify the equipment. Otherwise, it may cause a
fire, or you may suffer an electrical shock.
WARNING
Do not insert or remove the power cord or operate switches with a wet
hand. Otherwise, you may suffer an electrical shock.

8 | Introduction
WARNING
Operate the equipment only at the power supply voltage of 24 Vdc.
Otherwise, it may cause a fire, or you may suffer an electrical shock.
WARNING
Do not scratch, damage, modify, heat, pull, excessively bend, or heavily
load the power supply cables. Otherwise, it may cause a fire, or you may
suffer an electrical shock.
WARNING
Immediately turn off the power and disconnect the power supply cable if
the equipment is generating any smoke or odour, or is overheated.
Immediately inform your local service agent of the symptom to have it
repaired. Prolonged equipment operation under such a condition can
cause a fire or electric shock.
WARNING
Do not place a vessel containing liquid on the equipment. Otherwise, it
may cause a fire, or you may suffer an electrical shock if knocked over.
WARNING
When unplugging the instrument, be sure to remove the cord terminal
correctly. If the cord is pulled, the cord may get damaged resulting in a fire
or an electrical shock.

9 | Introduction
III. Warranty
To not to adversely affect the warranty, the following notices must be adhered to.
NOTICE
Operating personnel must not remove equipment covers. Only personnel trained
and certified by ALPHATRON MARINE must make component replacement and
internal adjustment.
NOTICE
Non-compliance with the installation, operation and maintenance requirements
may void the warranty.
NOTICE
Do not disassemble or modify the equipment. Failure to observe this instruction
may cause equipment failure, and it will void the warranty.
NOTICE
The system components are sensitive to humidity, temperature fluctuations and
aggressive substances. Store them appropriately.
If the instruments are not stored as described, it will void the warranty.
NOTICE
Any modification to this equipment without prior written permission from
ALPHATRON MARINE will void the warranty.
NOTICE
Installation of this product shall only be done by a certified installation company
approved by either ALPHATRON MARINE or by an official ALPHATRON MARINE
distributor. Acting otherwise will void the warranty.
NOTICE
To This product must be installed in accordance with the installation methods
described in this manual. Acting otherwise will void the warranty.
NOTICE
Operate the equipment only at the power supply voltage of 24 Vdc. Failure to
observe this instruction may cause equipment failure, and it will void the warranty.
NOTICE
This product contains no operator serviceable parts. Service and repair shall only be
carried out by personnel trained and certified by ALPHATRON MARINE.
NOTICE
Do not place a vessel containing liquid on the equipment. The equipment can be
damaged if knocked over.

10 | Introduction
NOTICE
Do not allow the instrument to fall or immerse into water. The equipment can be
damaged.
NOTICE
When cleaning the surface, do not use any organic solvent such as thinner or
benzine. Otherwise, the paint and markings on the surface may get damaged. For
cleaning the surface, remove the dust and debris and wipe with a clean dry cloth.
Contact the Alphatron dealer regarding the terms of the warranty.

11 | Introduction
IV. About the manual
Intended readers
This is an Installation and Operation Manual for the Alphatron LT-3100 Iridium. The manual is
primarily intended for installers and service personnel.
Personnel installing or servicing the system should be professionals with technical expertise, properly
trained, and likewise authorized.
All safety instructions and guidelines in this manual must be observed. The safety instructions are
listed in the beginning of the manual. The guidelines are to be found in the separate chapters, where
it is needed.
Manual overview
This manual has the following chapters:
•Introduction contains an introduction of the system.
•Unpacking (in-the-box) lists the part numbers and describes initial inspection the individual
components.
•Accessories lists accessory parts that are not part of the basic system and must be ordered
separately, if needed.
•System overview contains a description of system.
•Installation and Mounting explains how to mount the system components, and how to
connect the components in the system.
•Interfaces describes the external interfaces to Control Unit, including the coaxial cable
interface to the Antenna Unit.
•User Interface (UI) describes the user interface for operating and configuring the system.
•Web server describes the webpages provided (i.e. Dashboard, Software update, and
Diagnostic report)
•Service & Repair describes what the end-user must do in case of required service or repair.
Software version
This manual is applicable to software version 1.01.

12 | Introduction
1Introduction
The Alphatron LT-3100 Iridium is a maritime satellite communication product. The Alphatron LT-3100
Iridium is designed for the professional market (deep sea, fishing, and workboats), but can be used
for the leisure market as well. The Alphatron LT-3100 Iridium meets all standards and certification
requirements needed for worldwide maritime satellite communication equipment.
The Alphatron LT-3100 Iridium has voice and data capabilities with 100% global coverage provided by
the Iridium® Communications Network. The Alphatron LT-3100 Iridium consists of a control unit,
antenna unit, handset, and cradle. A single coaxial cable connects the control unit with the antenna
unit. Using a standard coaxial cable, up to 500 meters of separation between the units can be
obtained, giving freedom to mount the antenna unit in the best possible location, with free line of
sight to the satellites.
The Alphatron LT-3100 Iridium can be used as the primary satellite communication product on
vessels, covering the basic communication needs in terms of connectivity between the ship and
shore.

13 | Unpacking (in-the-box)
2Unpacking (in-the-box)
Unpack the Alphatron LT-3100 Iridium Basic set (P/N: G-007784) and check that the following items
are present in the box:
•LT-3110 Control Unit (P/N: G-004717)
•LT-3120 Handset (P/N: G-007781)
•LT-3121 Handset cradle (P/N: G-007782)
•LT-3130 Antenna Unit (P/N: G-007783)
•Bracket Mount, Control Unit
•Power Cable, 3m (P/N: G-007773)
•4 x Stainless steel A4 screws (for Bracket Mount, Control Unit)
•2 x Stainless steel A4 screws (for Handset cradle)
•4 x Unit Test Sheets
•Alphatron LT-3100 Iridium Installation and Operation Manual
NOTICE
Antenna unit mounts (bracket and pole mount) are not included in the Alphatron
LT-3100 Iridium and must be ordered separately. The antenna unit must only be
mounted, using the bracket or pole mounted. The antenna unit mounts are listed
with part numbers (P/N) in Accessories on page 14.
Inspection
Inspect the shipping cartons and/or wooden box immediately upon receipt for evidence of damage
during transport. If the shipping material is severely damaged or water stained, request that the
carrier's agent be present when opening the cartons and/or wooden box. Save all box packing
material for future use.
After unpacking the system and opening the cartons, inspect it thoroughly for hidden damage and
loose components or fittings. If the contents are incomplete, if there is mechanical damage or defect,
or if the system does not work properly, notify your dealer.
WARNING
To avoid electric shock, do not apply power to the Alphatron LT-3100
Iridium system components if there is any sign of shipping damage to any
part of a unit or the outer cover. Read the Safety Information at the front
of this manual before installing or operating the unit.

14 | Accessories
3Accessories
Mounts
The following accessory parts are not part of the basic system and must be ordered separately:
•G-007771 Bracket Mount (1.5" to 2.5" tube), Antenna Unit
•G-007772 Pole Mount (1.5" tube), Antenna Unit
Cable and connectors
The following cable and connector parts are not part of the basic system and must be ordered
separately:
•G-007774 Aux Cable, 3m
•G-007775 Coaxial cable Ø4.9mm, 10m
•G-007776 Coaxial cable Ø4.9mm, 25m
•G-007777 Coaxial Cable Ø10.3mm 10m
•G-007778 Coaxial Cable Ø10.3mm 25m
•G-007779 Coaxial Cable Ø10.3mm 50m
•N Conn. (male) for Coaxial Cable Ø4.9mm
•N Conn. (male) for Coaxial Cable Ø10.3mm
•Crimping Tool for Coaxial cable Ø4.9mm
•Crimping Tool for Coaxial cable Ø10.3mm
Coaxial cables are delivered with one fixed N connector (outdoor mounting), another loose N
connector and crimp parts come with the cable. It is required to use an appropriate crimping tool for
attaching the loose N connector.
NOTE
For further details on the cable and connectors, please contact Alphatron Marine. A
coaxial cable up to a length of 500 meters can be used for connecting the LT-3110
Control Unit and the LT-3130 Antenna Unit. Details about the coaxial cable,
specification and cable lengths, are described in section Antenna on page 29.

15 | System overview
4System overview
The Alphatron LT-3100 Iridium is a standalone communication product, which is using the Iridium®
satellite constellation. The Alphatron LT-3100 Iridium is working on the Iridium® legacy satellites as
well as the new Iridium® NEXT satellites, which are taking over the Iridium services throughout 2018.
An overview of the Alphatron LT-3100 Iridium is illustrated in Figure 1.
Figure 1: Alphatron LT-3100 Iridium - Basic components and interfaces
The LT Alphatron LT-3100 Iridium consists of the following units, provided by Alphatron Marine:
•LT-3110 Control Unit
•LT-3120 Handset
•LT-3121 Cradle
•LT-3130 Antenna Unit
NOTE
The Alphatron LT-3100 Iridium was released to customers with the initial software
version 1.01. Software version 1.01 includes basic voice functionality, together with
basic functionality for operating the system. During 2018, software releases will be
available, supporting the Iridium® legacy services. Please contact Alphatron Marine
for details about future software releases and features.

16 | Installation and Mounting
5Installation and Mounting
5.1 LT-3110 Control Unit
The LT-3110 Control Unit is the master unit in the system, supporting all external interfaces and the
operational user interface. The LT-3110 Control Unit is designed for indoor mounting. Check the
specifications in Appendix A: Specifications on page 45.
Figure 2: LT-3110 Control Unit (front view)
The LT-3110 Control Unit has the following interfaces:
•2-pin power connector (male), marked ‘PWR’
•Chassis ground connector, marked ‘GNDC’
•N connector (female) for coaxial cable to the LT-3130 Antenna Unit, marked ‘ANT’
•Ethernet (RJ-45) connector, marked ‘LAN’
•10-pin auxiliary connector (male), marked ‘AUX’
•SIM card, marked ‘SIM’
•5-pin connector (female) for LT-3120 Handset (front of the control unit)
The LT-3110 Control Unit interfaces are described in Interfaces on page 27. The LT-3110 Control Unit,
front view and backside view, are illustrated in Figure 2 and Figure 3.

17 | Installation and Mounting
Figure 3: LT-3110 Control Unit (backside view)
The LT-3110 Control Unit user interface, display and buttons, are described in User Interface (UI) on
page 32.
NOTE
The LT-3110 Control Unit must be mounted as Console Mount or Bulkhead.
Mounting and installation considerations:
For optimum system performance, some guidelines on where to install or mount the LT-3110 Control
Unit must be followed. It is recommended to mount the unit in a location, which fulfils these
requirements:
•Mount the unit indoor (not exposed to direct water)
•Mount the unit using the supplied material
•Mount the unit on a rigid structure with a minimum of exposure to vibration and shock
•Mount the unit in an area with an ambient temperature between -15°C to +55°C (+5°F to
+131°F)

18 | Installation and Mounting
5.2 LT-3120 Handset
The LT-3120 Handset is the primary voice interface for the Alphatron LT-3100 Iridium. The LT-3120
Handset must be connected on the front of the LT-3110 Control Unit. The connector is illustrated in
Figure 2 on page 16.
Figure 4: LT-3120 Handset (front view)
The LT-3120 Handset is connected to the LT-3110 Control Unit via a 5-pin proprietary angle
connector. The spiral cord, fixed to the LT-3120 Handset is ~0.4 m from handset to connector, when
coiled. The spiral cord can be stretched to a maximum of 2 m. The LT-3120 Handset is designed for
indoor mounting. Check the specifications in Appendix A: Specifications on page 45.
Figure 5: LT-3121 Handset (backside view)
The LT-3120 Handset has the following characteristics:
•High-performance audio speaker and microphone
•Separate ringer (buzzer)
•Speaker volume control (double-button, marked with ‘+’ and ‘-‘, for volume up and down)
•Built-in off-hook detection circuit
NOTE
The LT-3110 Control Unit will inform the user if the LT-3120 handset is not properly
connected to the LT-3110 Control Unit. The following user information will be
showed in the display: ‘Handset not connected’.
NOTE
The LT-3120 Handset must be operated together with the LT-3121 Cradle, for the
off-hook detection circuit to work. The LT-3121 Cradle is described in section LT-
3121 Cradle on page 19.

19 | Installation and Mounting
5.3 LT-3121 Cradle
The LT-3121 Cradle is used together with the LT-3120 Handset. The LT-3121 Cradle should be
mounted next to the LT-3110 Control Unit, supporting the LT-3120 Handset. The LT-3121 Cradle
specifications are available in Appendix A: Specifications on page 45.
Figure 6: LT-3121 Cradle (front view)
Figure 7: LT-3121 Cradle (backside view)
NOTICE
The LT-3121 Cradle contains a magnet, to hold on to the LT-3120 Handset. Make
sure that other electronic equipment is installed in a distance respecting the
compass safe distance of 0.4 m (1.3 ft).
An outline drawing for the LT-3121 Cradle is available in Appendix G: Outline Drawing: LT-3121
Cradle on page 51.

20 | Installation and Mounting
5.4 LT-3130 Antenna Unit
The LT-3130 Antenna Unit is designed for outdoor mounting and connected to the LT-3110 Control
Unit via a coaxial cable. The LT-3130 Antenna Unit specifications are available in Appendix A:
Specifications on page 45. The LT-3130 Antenna Unit has an N connector (female) mounted, centred
at the bottom of the antenna.
Figure 8: LT-3130 Antenna Unit
Mounting and installation considerations:
•Mount the unit vertically (with the N connector pointing down)
•Mount the unit with free line of sight to the Iridium® and GNSS satellites. Make sure that the
unit can receive signals from the Iridium® and GNSS satellites (satellite reception information
is available in the LT-3110 Control Unit user interface display, see Figure 21 on page 34)
•Mount the unit on a rigid structure with a minimum of exposure to vibration and shock
•Mount the unit using either the Bracket Mount or Pole Mount provided by Alphatron Marine
•Mount the unit outdoor with an ambient temperature between -25°C to +55°C (-13°F to
+131°F)
•Mount the unit with a minimum angle of 20 degrees towards a radar antenna (above or
below) and keep a minimum distance of 2.5 m (8 ft)
•Mount the unit at least 1 m (3 ft) away from radio transmitting antennas (VHF, UHF, MF-HF)
•Mount the unit away from Inmarsat and transmitting VSAT antennas
WARNING
The safety distance from the LT-3130 Antenna Unit, is 0.1 m (0.3 ft), in
order to comply with the regional regulations.
