JRC JUE-410F - User manual

For further information, contact:
Since 1915
PrintedinJapan2003.10 C2003.10 CAT.No.Y14-192（No.729-1-5）A
Main Office: Nittochi Nishi-Shinjuku bldg.
10-1, Nishi-Shinjuku 6-chome
Shinjuku-ku, Tokyo 160-0023, Japan
Telephone: [phone]
Facsimile: [phone]
Overseas Branches : Seattle, Amsterdam
Liaison Offices : Taipei, Manila, Jakarta, New York,
Piraeus
22EM
ISO9001， ISO14001 Certified
URL
IMPORTANT
Compasssafedistance
Standardcompass
Steeringcompass
WARNING警告
:3.0m
:3.0m

DONOTPAINT
RADOME
このドームに近づくな
電磁波障害の恐れあり
MICROWAVEHAZARD
DONOTAPPROACH
MICROWAVERADIATION
CANCAUSESEVEREINJURY

Dxxxxxxv.sRxxxxxxLxxxxx
Dxxxxxx
4.5m
3.0m
1.0m
10w/m
2

25w/m
2

100w/m
2
Rxxxxxx
FWD
1215
φ1380
●Above Deck Equipment(ADE)
Mass: 80kg approx.
GND 15A
ACINONOFF
HSDtoJB
to
ADE
TEL2TEL1
W-RF
DTE ISDN USBEthernet
ENT
CLR
STOP
SEL
CHR
CONT
DIM
DISTRESS
JUE-410F
SIM&PCMCIACARDSLOT
POWER VOICEDISTRESSREQUESTPROCEDURE
COMPASSSAFEDISTANCE:3.0m
1.Openhingedcover
andpushDISTRESSbuttonfor6seconds.
2.Whenthecontinuoussounds,pickuphandset.
3.Push#keytorequestthedistresscall.
pushSTOPbuttontocancelthedistressrequest.
OFF
PushOpen
警告 WARNING
このカバーをはずすな
感電の恐れあり
HIGHVOLTAGE
DONOTREMOVE
THECOVER
INMARSATFLEETF77
MOBILEEARTHSTATION
BELOWDECK
EQUIPMENT
MADEINJAPAN
MODEL
SERIALNO.
ISN
CE
MODEL
MASS
DATE
GSC-412A
5kg
JUE-410F
GW
225
230
80
325
Mass: 5kg approx.
●Below Deck Equipment(BDE)
228
150
78
Mass: 0.7kg approx.
●Telephone
Major Specifications
●Read the Instruction Manual before your use for safety in operation.
●Do not install this equipment in a place with water, wetness, vapor, dust and oily smoke. Otherwise, a fire, electric shock or failure may result.
●For the installation work for this equipment, request to JRC agents or dealers. The installation work done by any non-specialist personnel
may result in an electric shock or failure.
●The appearance and dimensions of the equipment may be subject to change without notice.
Cautions for Safety
With more than 25 years experience in developing Inmarsat
terminals, and more than ……. Inmarsat terminals delivered, we
know what it takes to meet the extreme environmental demands of the sea.
Maritime communication has changed over the years,from telex,
and telephone, to High Speed data gateways.
The New FLEET 77 from JRC, incorporates cutting edge
technology, flexible interfacing,and the familiarWindows
Operating System, ensuring reliable and user-friendly operation.
●Frequency range
Transmit : 1626.5〜1660.5MHz
Receive : 1525.0〜1559.0MHz
Channel Spacing: 1.25KHz
●E.I.R.P.: +32 +1/-2 dBW Max.
●G/T: -4dB/K or more
●Modulation
BPSK : 3Kbps O-QPSK: 4.8Kbps
16QAM : 64Kbps
●Antenna
Type : 0.89m φparabolic
Polarization : Right –hand circular
Beam : 15°at 3dB down
Enclosure : 1.38m φradome
Roll +/-30deg./s
Pitch+/-10deg./6sec
Taw +/-8deg./s, Turning 6deg./s
●Primary power
Voltage : AC100/110,200/220V ±10%
Frequency : 50/60Hz ±6%
●Environmental conditions
Temperature : -25〜+55℃(ADE)
-15〜+55℃(BDE)
Humidity : Up to 95%
(40℃Relative)
Above Deck Equipment (ADE)
Below Deck Equipment (BDE)
Telephone
ADE-BDE single coaxial cable (Cable length: 50m)


Voice (4.8K Voice/64K Speech)
Data (64K/56K UDI, MPDS)
Facsimile (64K Audio:G3, 64K UDI:G4)
JRC Supplied :
Remote telephone
G3 facsimile
Buzzer box
Voice distress button
Card reader
Card reader interface
Wide band FR interface
Customer Supplied :
Personal Computer (WindowsXP/2000)
G4 facsimile
Router
Video Phone etc.
Standard Components
Standard Functions
Dimensions & Weight
Options

The Quality Leader in Maritime
Communication
High Performance
and Quality
FleetF77
Maritime Satellite Communication Terminal
Inmarsat Certification No. 66JR01

The Fleet F77 JUE-410F maritime satellite communication terminal station is designed according to JRC’s proven
high quality standards.
It is user-friendly, easy to install, and the antenna is the most rugged in the Inmarsat market. JUE-410F provides
voice (normal and high quality), G3 & G4 FAX, up to 64Kbps MPDS (Mobile Packet Data Service) communication,
and up to 64Kbps HSD (High-Speed Data) communication, as standard.
Advanced Features; 
◆“All-in-one” design, including a comprehensive line of interfaces for high flexibility in operation.
◆Modern user-friendly windows based operation.
◆JRC’s unique design of antenna (ADE), recognized for very high reliability.
◆The BDE (below deck equipment) comes with Ac power supply as standard.
◆Dedicated mechanical / electrical interfaces for upgrading from Inmarsat-A/B to Fleet F77.
◆Voice Distress Communication (Distress button protected from unintended transmission with cover).
The JUE-410FÕs all-in-one design provides
superior quality, easy installation, user-friendly operation and heavy-duty construction
Interface&Operation
Networking support with a variety of interfaces
JRC's JUE-410F is the world's first Inmarsat Fleet Mobile Terminal with built-in Ethernet
interface. The new Fleet 77 incorporates a wide range of standard interfaces, such as Ethernet,
RS-232 serial, ISDN and USB. These interfaces allow flexible on-board networking. Built-in Web
Server function enables easy operation by PC.
◆Easy to connect PC with standard interfaces like Ethernet and RS-232.
◆Easy access to Internet with built-in terminal adapter.
◆Easy web access operation with built-in web server function.
High-SpeedDataServices
Two types of high-speed data service
JRC's JUE-410F supports two types of 64kbps data service.
Mobile Packet Data Service (MPDS) and High Speed Data
Service (HSD). By selecting the appropriate service it enables
you to use the most cost effective solution for any kind of
communication
◆MPDS : Web browsing, Emailing, Chat communication, etc.
◆HSD :
Digital image transmission, Videophone, Chart Collection, etc.
HighReliability
JRC's Unique Antenna Design
JRC's JUE-410F Antenna is designed using the latest structural design methodology,
incorporating analysis from ship’s motion and vibration data, collected from a wide range of
vessels.
JRC’s long established experience in Inmarsat antenna design – dating back to the late 70’s -
has resulted in:
◆High reliability antenna for merchant vessels to middle-small size fishing boats.
◆Easy installation by connecting the ADE and BDE with one coaxial cable. (Up to 100m)
World-wideSupport
The JUE-410F is equipped with a self-diagnostics function making troubleshooting and repair
simple. JRC’s service network can analyze the failure by using a self-diagnostics data,
providing fast, reliable response. JRC’s worldwide support network with 60 countries and 165
ports guarantees strong support.
With reliable JRC customer support
Standard
Option
Standard
Option
User supply
（STEP/SYNC/NMEA）
ADE-BDE single coaxial cable
Standard：CFQ-3922A（up to 50m）
Option：CFQ-3923A（up to 100m）
Main Unit
Below Deck
Network
Telephone
G3facsimile
（up to 16units） 

G4facsimileVideo Telephone
TEL

PC1

PC2
Router

Distress signal
send button Remote Telephone facsimile
（ up to 5units ）

Card Reader
Interface
External Buzzer Card Reader
Distress signal send button/External Buzzer/Card Reader Interface
（total：up to10units）
ISDN（BRI）：up to 8 units
Advanced functions for networking
are integrated in compact design
 
Gyro signal
Junction Box
Telephone
Serial
ISDN
Ethernet
Above Deck
Below Deck
Option Port
Terminal
Adapter
PC
PC
