JTS US-36G2 User manual

US-36G2 /
Mh-36G2 / PT-36BG2
59508-043-03
No.148, Gongye 9th Rd., Dali Dist., Taichung
City 41280, Taiwan (R.O.C.)
Tel: [phone] Fax: [phone]
Email: [email protected]
PROFESSIONAL CO., LTD
www.jts.com.tw

Instruction Manual
UHF PLL
TRue DIversity
WIRELESS SYSTEMS
Mh-36G2
PT-36BG2
US-36G2

ank you for choosing the JTS wireless system. In order to obtain the best eciency from the system,
you are recommended to take few minutes to read this instruction manual carefully.

1. Important Caution
2. Features
3. Specication
3-1 Receiver// US-36G2
3-2 Handheld Transmitter // Mh-36G2
3-3 Body-pack Transmitter // PT-36BG2
3-4 Optional Condenser Microphone
4. Part Identication & Accessories
4-1 Receiver // US-36G2
4-2 Handheld Transmitter // Mh-36G2
4-3 Body-pack Transmitter // PT-36BG2
4-4 Optional Condenser Microphone
4-5 Accessories
5. Preparing Procedures
6. Basic Operation
7. Recommendation
8. Important notice
1
1
2
2
2
3
3
6
6
7
8
9
13
14
15
28
28
INDEX

WIRELESS MICROPHONE SYSTEM
1
1. Important Caution
2. Features
• Always make all connections before plugging the unit into an AC power outlet.
• Do not leave the devices in a place neither with high temperature nor high humidity.
• Always do not handle the power cord with wet hands !
• Keep the devices away from re and heat sources.
• Due to the PLL synthesized technology, the system can oer up to 1441 selectable frequencies
for choosing simultaneously.
• 6 groups, maximum 23 channels in one group.
• e true diversity reception with 2 independent RF receivers ensure the stable transmission and
reception.
• Adjustable Pilot tone squelch control can eectively reduce the noise.
• Equipped with S.A.W. lter benets the interference-resistant.
• Tuned antennas can benet the stable RF reception.
• Built-in Noise Squelch circuity & Mute function are available to restrain the interference for
signals.
• Rugged metal housing can pass through the dicult environment.
• Equipped with balanced XLR and balanced output allow great convenience.
• Anti-interference design is available to work with every computer device.
• Transmission power selectable between “High”and “Low”

2
3. Specication
3-1 Receiver // US-36G2
3-2 Handheld Transmitter // Mh-36G2
Frequency Preparation........
Carrier Frequency Range..
S/N Ratio.....................................
T.H.D...............................................
Display.............................................
Display Contents.....................
Controls.........................................
Audio Output Level..............
AF Output Impedance........
Squelch...........................................
Operation Voltage..................
Output Connector.................
Dimension(m/m).................
PLL Synthesized Control
502~960 MHz
> 105dB
<0.6%@1KHz
LCD / LED
Group, Channel, Frequency, Antenna A/B, Mute Display,
AF Meter (LED BAR), RF Meter (LED BAR) , Baery Status
Power On/O, Group, Channel, Frequency Up/Down,
Frequency Scan, Audio Level, Lock-on, Output Pad-12dB
-12dB
600Ω
Pilot Tone & Noise Mute
12V 500mA
1 XLR Balanced Socket
1 Ø6.3mm Unbalanced phone jack
212.3mm (W)* 38.3mm (H)* 144mm (D)
Frequency Preparation.............
Carrier Frequency Range.......
RF Outputs......................................
Stability ...................................
Frequency Deviation................
LCD Display....................................
Controls..............................................
Spurious Emissions....................
Audio Frequency Response..
Baery..................................................
PLL Synthesized Control
502~960 MHz
High / Low
<±10KHz
±48KHz (Peak)
Group, Channel, Frequency, Baery Status,
Sensitivity
Power On/O, Mute On/O, Mode Seing, AF Level,
Group, Channel, Frequency Up/Down, Lock-on Mode
<-50 dBC
50Hz~18k Hz
UM3, AA Alkaline x2

WIRELESS MICROPHONE SYSTEM
3
3-3 Body-pack Transmitter // PT-36BG2
3-4 Optional Condenser Microphone
Model No...............................
Connector..............................
Option Connector...........
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-501
4P Mini XLR
100~15,000 Hz
Cardioid
-60±3 dB
2.2kΩ
130dB
Ø10.1mm(W)
* 26.4mm(H)
21.5g
CM-201i
201C4 (4P Mini XLR)
201C3 (3P Mini XLR)
201CS (3.5 stereo plug)
201CR
60~15,000 Hz
Omni-directional
-60±3 dB
2.2kΩ
130dB
Ø5mm(W)* 9mm(H)
20.7g
CM-125i
201C4 (4P Mini XLR)
201C3 (3P Mini XLR)
201CS (3.5 stereo plug)
201CR
50~18,000 Hz
Omni-directional
-53±3 dB
4.4kΩ
130dB
Ø4mm(W)* 11mm(H)
7g (cable excluded)
Lavaliere Microphone
Frequency Preparation..............
Carrier Frequency Range........
RF Outputs.......................................
Stability................................................
Frequency Deviation..................
LCD Display.....................................
Controls...............................................
Output connector.........................
Spurious Emissions.....................
Audio Frequency Response...
Baery...................................................
PLL Synthesized Control
502~960 MHz
High / Low
<±10KHz
±48KHz (Peak)
Group, Channel, Frequency, Baery Status,
Sensitivity
Power On/O, Mute On/O, AF Level, Group,
Channel, Frequency Up/Down, Lock-on Mode
4P mini XLR
<-50 dBC
50Hz~18k Hz
UM3, AA Alkaline x2

4
Headset Microphone
Model No...............................
Connector..............................
Option Connector...........
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-235i
801C4 (4P Mini XLR )
801C3 (3P Mini XLR)
801CS (3.5 stereo plug)
801CR
50~18,000 Hz
Omni-directional
-53±3 dB
1.8kΩ
130dB
155mm(W)
* 134mm(H)
* 157mm(D)
17g (cable excluded)
CX-504
4P Mini XLR
801C3 (3P Mini XLR)
801CS (3.5 stereo plug)
801CR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
285mm(W)
* 55mm(H)
* 111.3mm(D)
56.3g
Model No...............................
Connector...............................
Option Connector...........
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-214i
801C4
(4P Mini XLR)
801C3 (3P Mini XLR)
801CS (3.5 stereo plug)
801CR
60~15,000 Hz
Omni-directional
-60±3 dB
1.8kΩ
130dB
125mm(W)
* 134mm(H)
* 157mm(D)
32.9g
CM-214Ui
4P Mini XLR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
205mm(W)
* 134mm(H)
* 157mm(D)
38.4g
CM-214ULi
801C3 (3P Mini XLR)
801C4 (4P Mini XLR)
801CS (3.5 stereo plug)
801CR
100 ~ 18,000Hz
Cardioid
-65±3 dB
1.8kΩ
120dB
125mm(W)
* 134mm(H)
* 157mm(D)
18g (cable excluded)

WIRELESS MICROPHONE SYSTEM
5
Ear-hook Microphone
Model No...............................
Connector..............................
Option Connector...........
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
CM-801/CM-804i
801C4 (4P Mini XLR)
801C3 (3P Mini XLR)
801CS (3.5 stereo plug)
801CR
60~15,000 Hz
Omni-directional
-64±3 dB
1.8kΩ
130dB
CM-8015/CM-825i
801C4 (4P Mini XLR)
801C3 (3P Mini XLR)
801CS (3.5 stereo plug)
801CR
50~18,000 Hz
Omni-directional
-53±3 dB
1.8kΩ
130dB
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Good For.................................
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Good For.................................
CX-500
4P Mini XLR
20~20,000 Hz
Omni-directional
-58±3dB
1.5kΩ
130 dB
Violin
CX-508W
4P Mini XLR
50~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
Winds
CX-500F
4P Mini XLR
20~20,000 Hz
Omni-directional
-58±3dB
1.5kΩ
130 dB
Flutes
CX-520
4P Mini XLR
50~16,500 Hz
Supercardioid
-78±3dB
600Ω
148 dB
Harmonica
CX-516W
4P Mini XLR
30~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
Accordion
Compatible Instrument Microphone

6
4. Parts Identication & Accessories
4-1 Receiver // US-36G2
Power On/O switch
Up buon
Down buon
Set buon
LCD Display
Volume control
AF signal level
RF signal level
Antenna
DC socket for connection of main unit
AF output, jack socket (AF UNBAL)
Balanced XLR socket
Antenna input socket
1
4
7
10
11
12
13
2
5
8
3
6
9
13 4
9
28
56 7
VOL.
MIN. MAX.
DIVERSITY RECEIVER US-36G2
ID:
SQ.
LOCK ATT.ON
CH
MHz
131210 1311
500
1856

WIRELESS MICROPHONE SYSTEM
7
G2
Mh-36
G2
Mh-36
G2
Mh-36
G2
Mh-36
MHz
MHz
Interchangeable capsule
LCD display
Set buon
Down buon
UP buon
Power On/O switch, Mute On/O switch
Baery tray buon
Baery tray
4-2 Handheld Transmitter // Mh-36G2
14
17
15
18
20
16
19
21
14
19
15
18
16
17
20
21

8
4-3 Body-pack Transmitter // PT-36BG2
LCD Display
Ba er y Tray
Set buon: set the conguration of bodypack transmier
Up buon: select the seings of transmier
Down buon: select the seings of transmier
4 Pin mini XLR mic. input
Power Switch / Mute
Antenna
Belt Clip
LCD Panel of the Body-Pack Transmitter
Baery status: display baery status
Group & Channel
32
31
30
29
22
23
25
26
27
28
24
MHz
UHF PLL Transmitter
POWER
/MUTE
22
23
30
27
29
25
28
24
26
32
31

WIRELESS MICROPHONE SYSTEM
9
Clip
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
4Pin Hirose connecter
Windscreen
33
35
36
37
38
34
4-4 Optional Condenser Microphone
Lavaliere Microphone // CM-501 CM-201i CM-125i
CM-501 CM-201i CM-125i
38 38 38
33
33 33
34 35 36 37
Option
Option
Option

10
Headset Microphone // CM-214i / CM-214Ui / CM-214ULi / CM-235i /
CX-504
Gooseneck
Adjustable headband
Headband
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
4Pin Hirose connecter
Windscreen
40
42
43
46
44
45
39
41
Standard :
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
CM-214i CM-214Ui
CM-235i
CM-214ULi
CX-504
40 40 40
46 46 46
39 39 39
40 41
46
46
39
39
Option
Option
Option
43 4442 45

WIRELESS MICROPHONE SYSTEM
11
Boom
Adjustable Headband
Adjustable ear hook
Detchable Cable
Cable Clip
Windscreen
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
4Pin Hirose connecter
Ear-hook Microphone // CM-801 / CM-804i / CM-8015 / CM-825i
52
54
53
55
56
49
51
50
47
48
Option
Option
Option
48
52
49
51
50
47
52 49
51
50
47
48
52
49
51
50
47
52 49
51
50
47
CM-801
CM-804i
CM-8015
CM-825i
54 5553 56

12
Gooseneck
Clip
Bracket
Volume Control
Windscreen
4 Pin Mini XLR
60
61
62
59
58
57
Compatible Instrument Microphone // CX-500 / CX-500F / CX-520 /
CX-508W / CX-516W
CX-508W CX-516W
57 57
58
62
59
61
61
61
61 CX-500F
CX-500
57
58
CX-520
60

WIRELESS MICROPHONE SYSTEM
13
AC/DC adaptor
Switching Power Supply(100V~240V , 50~60Hz)
Linear Power Supply (220V , 50Hz)
Linear Power Supply (220V , 60Hz)
Screwdriver
DR-900 Dual Rack Adaptor
RM-901 Rack Mount Kit
RP-900 Panel Cover
AF output cable (with Φ6.3 plug at both ends)
GC-80/GC-100 Guitar Cable
GC-80L/GC-100L Guitar Cable
4-5 Accessories
66
68
69
70
65
67
64
63
Option
Option
Option
Option
Option
Option
Option
A
B
C
63
65
64
67
66
A
B C
68 69 70

14
5. Preparing Procedures
Receiver // US-36G2
(1) Power output connector
Plug in one end of AC/DC adaptor cable to DC input socket in the rear panel of receiver, and
plug another end into an AC outlet.(Step 1)
(2) Audio Output Connector
Connect one end of the AF output cable to the AF output socket in the rear panel, then plug
another end to the “MIC IN” input socket of a mixer or amplier.(Step 2)
Receiver equipped with balanced XLR output and Unbalanced
Ø 6.3mm output, choose the
proper way for use.
MIXER
AC/DC ADAPTOR
AC POWER SOCKET
AUDIO OUTPUT
DC INPUT
2
1
500
1856

WIRELESS MICROPHONE SYSTEM
15
6. Basic Operation
6-1 Receiver // US-36G2
1. Power on: Press 【POWER 】key once to turn power on.
Shut down: press and hold power key for 2 seconds.
2. Group adjusting
2-1 Press down SET buon for 3 seconds.
2-2 the group (G) will ash.
(1)Press ▲or ▼buon to select a desired group(1~6), Press SET key to set.
(2)e Channel ash, Press▲or ▼buon to select a desired channel, Press SET key to set
Number of channels for each group:
Group 1→ Channel 1~21；Group 2→ Channel 1~22
Group 3→ Channel 1~18；Group 4→ Channel 1~21
Group 5→ Channel 1~21；Group 6→ Channel 1~21
3. Frequency adjusting
3-1 Press down SET buon for 3 seconds.
3-2 Press SET key twice, With the 3 digits of the LCD blinking.
VOL.
MIN. MAX.
DIVERSITY RECEIVER US-36G2
SQ.
CH
MHz
MUTE
GROUP
1POWER
SQ.
CH
MHz
MUTE
GROUP
SQ.
CH
MHz
MUTE
GROUP
SQ.
CH
MHz
MUTE
GROUP

16
(1)Press ▲or ▼keys to change the frequency at an increment of “+/-” 1MHz . Press SET
key to set.
(2)e 3 digits on the right of the LCD blinking；press ▲or ▼keys to change the
frequency at an increment of “+/-” 0.025MHz,Press SET key to set.
4. SCAN
4-1 Press down SET buon for 3 seconds.
4-2 Press the SET buon several times until the”Sc ON” or “Sc OFF” is displayed on screen.
(1)press ▲: Sc ON -- Turn on the channel scan; e receiver will automatically scan the
environment and identify the frequencies that have been occupied, and will skip
to next available frequency.
(2)press▼ : Sc OFF -- Turn o the channel scan.
(3)Press SET key to save the seing.
SQ.
CH
MHz
MUTE
GROUP
When “Sc ON”:
When enter group and channel menu,
the receiver will start to scan when
“SCAN” display on LCD.
Receiver will scan every channel in the
selected group.
Scan funtion will stop at rst channel
that is available.
When displayed:
Means there is no available channel in
this group, please select another group
to scan.
CH
MHz
MUTE
