JTS US-901D User manual

Instruction Manual
UHF PLL
WIRELESS SYSTEMS
US-901D

ank you for choosing the JTS wireless system. In order to obtain the best eciency from the system,
you are recommended to take few minutes to read this instruction manual carefully.

1. Important Caution
2. Features
3. Specication
3-1 Receiver// US-901D
3-2 Handheld Transmitter // Mh-950 Mh-960
3-3 Body-pack Transmitter // PT-950B(mi)
3-4 Optional Condenser Microphone
4. Part Identication & Accessories
4-1 Receiver // US-901D
4-2 Handheld Transmitter // Mh-950 Mh-960
4-3 Body-pack Transmitter // PT-950B(mi)
4-4 Optional Condenser Microphone
4-5 Accessories
5. Preparing Procedures & Basic Operation
5-1 Receiver// US-901D
5-2 Handheld Transmitter // Mh-950 Mh-960
5-3 Body-pack Transmitter // PT-950B(mi)
6. Recommendation
7. Important notice
1
1
2
2
3
4
4
7
7
8
9
9
12
13
13
16
18
22
23
INDEX

WIRELESS MICROPHONE SYSTEM
1
1. Important Caution
2. Features
Always make all connections before plugging the unit into an AC power outlet.•
Do not leave the devices in a place neither with high temperature nor high humidity.•
Always do not handle the power cord with wet hands !•
Keep the devices away from re and heat sources.•
Operated in UHF band where there is less RF interference than the VHF band.•
Due to the PLL synthesized technology, the system can oer up to 961 selectable frequencies for•
choosing simultaneously.
e true diversity reception with 2 independent RF receivers ensure the stable transmission and•
reception.
Adjustable Pilot tone squelch control can eectively reduce the noise.•
Equipped with S.A.W. lter benets the interference-resistant.•
Tuned antennas can benet the stable RF reception.•
Built-in Noise Squelch circuity & Mute function are available to restrain the interference for•
signals.
Compact half-rack receiver design is considerable for the space saving.
•
Rugged metal housing can pass through the dicult environment.•
Equipped with balanced XLR and unbalanced output allow great convenience.•
Anti-interference design is available to work with every computer device.•

2
3. Specication
3-1 Receiver // US-901D
Frequency Preparation......
Carrier Frequency Range
S/N Ratio...................................
T.H.D..................................
Display..............................
Display Contents...................
Controls............................
Audio Output Level............
AF Output Impedance......
Squelch.............................
Operation Voltage.................
Output Connector................
Dimension(m/m)...............
PLL Synthesized Control
502~960 MHz
> 105dB
<0.6%@1KHz
LCD
Frequency, Antenna A/B, Mute Display, RF/AF Level Meter,
Baery Fuel Gauge
Power On/O, Frequency Up/Down, Frequency
Scan, Audio Level, Lock-on
-12dB
600Ω
Pilot Tone & Noise Mute
12-18 VDC, 200 mA
1 XLR Balanced Socket
1 Ø6.3mm Unbalanced phone jack
211mm (W)* 40mm (H)* 125mm (D)

WIRELESS MICROPHONE SYSTEM
3
3-2 Handheld Transmitter // Mh-950 Mh-960
Frequency Preparation............
Carrier Frequency Range......
RF Outputs.....................................
Stability...............................................
Frequency Deviation................
LCD Display...................................
Controls.............................................
Spurious Emissions...................
Audio Frequency Response
Baery..................................................
PLL Synthesized Control
502~960 MHz
10mW
±10KHz
±48KHz
Frequency, Baery Fuel Gauge, Sensitivity
Power On/O, Mode Seing, AF Level,
Frequency Up/Down, Lock-on Mode
<-50 dBC
50~16,000 Hz
UM3, AA 1.5V*2

4
3-3 Body-pack Transmitter // PT-950B(mi)
3-4 Optional Condenser Microphone
Frequency Preparation............
Carrier Frequency Range......
RF Outputs......................................
Stability.................................
Frequency Deviation................
LCD Display...................................
Controls................................
Spurious Emissions...................
Audio Frequency Response
Battery...................................
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
PLL Synthesized Control
502~960 MHz
10mW
±10KHz
±48KHz
Frequency, Baery Fuel Gauge
Power On/O, AF Level,
Frequency Up/Down, Lock-on Mode
<-50 dBC
40~18,000 Hz
UM3, AA 1.5V*2
CM-501
4P Mini XLR
100~15,000 Hz
Cardioid
-60±3 dB
2.2kΩ
130dB
Ø10.1mm(W)
* 26.4mm(H)
21.5g
CM-201
4P Mini XLR
60~15,000 Hz
Omni-directional
-60±3 dB
2.2kΩ
130dB
Ø5mm(W)*
9mm(H)
20.7g
CM-125
4P Mini XLR
50~18,000 Hz
Omni-directional
-53±3 dB
4.4kΩ
130dB
Ø4mm(W)*
11mm(H)
7g (cable excluded)
Lavaliere Microphone // CM-501 CM-201 CM-125

WIRELESS MICROPHONE SYSTEM
5
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-225
4P Mini XLR
50~18,000 Hz
Omni-directional
-53±3 dB
4.4kΩ
130dB
155mm(W)
* 134mm(H)
* 157mm(D)
17g (cable excluded)
CX-504
4P Mini XLR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
285mm(W)
* 55mm(H)
* 111.3mm(D)
56.3g
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-204
4P Mini XLR
60~15,000 Hz
Omni-directional
-60±3 dB
2.2kΩ
130dB
125mm(W)
* 134mm(H)
* 157mm(D)
32.9g
CM-204U
4P Mini XLR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
205mm(W)
* 134mm(H)
* 157mm(D)
38.4g
CM-204UL
801C3 (3 pin mini XLR)
801C4 (4 pin mini XLR)
801CS (3.5 stereo plug)
100 ~ 18,000Hz
Cardioid
-75±3 dB
1.5kΩ
120dB
125mm(W)* 134mm(H)
* 157mm(D)
18g (cable excluded)
Headset Microphone // CM-204 CM-204U CM-204UL CM-225 CX-504

6
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
CX-508W
4P Mini XLR
50~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
CX-516W
4P Mini XLR
50~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
Instrument Microphone // CX-508W CX-516W
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
CM-801/CM-804i
801C3 (3 pin mini XLR)
801C4 (4 pin mini XLR)
801CS (3.5 stereo plug)
60 ~ 15,000Hz
Omni-directional
-64±3 dB
1.8kΩ
130dB
CM-8015/CM-825i
801C3 (3 pin mini XLR)
801C4 (4 pin mini XLR)
801CS (3.5 stereo plug)
50 ~ 18,000Hz
Omni-directional
-53±3 dB
1.2kΩ
130dB
Ear-hook Microphone // CM-801 CM-804i CM-8015 CM-825i

WIRELESS MICROPHONE SYSTEM
7
4. Parts Identication & Accessories
4-1 Receiver // US-901D
Power On/O switch
Up buon (frequency adjustment)
Down buon (frequency adjustment)
Set buon (frequency adjustment)
LCD Display
Volume control
DC socket for connection of main unit
AF output, jack socket (AF UNBAL)
Balanced XLR socket
Antenna input socket
Antenna
1
4
7
10
11
2
5
8
3
6
9
14
11 2
53
6
200
1856
POWER
SET
MIN. MAX.
DIVERSITY RECEIVER
US-901D
710 108 9

8
Interchangeable dynamic capsule
LCD display
Down buon
UP buon
Set buon
Baery tray buon
Baery tray
Power On/O switch
Mute On/O switch
4-2 Handheld Transmitter // Mh-950 Mh-960
12
15
13
16
18
14
17
19
20 Mh-950
Mh-960
17
12
18
13 14
15
19
16
17
12
18
13
14
16
15
19

WIRELESS MICROPHONE SYSTEM
9
Mic. input
Power On/o switch
Antenna
LCD display
Set buon
Up buon
Down buon
Baery tray buon
AF level control
Belt clip
Baery tray
Aenuation pad
Clip
4 Pin Mini XLR
Windscreen
4-3 Body-pack Transmitter // PT-950B(mi)
21
33
23
35
25
30
27
32
22
34
24
29
26
31
28
4-4 Optional Condenser Microphone
Lavaliere Microphone // CM-501 CM-201 CM-125
CM-501 CM-201 CM-125
35 35 35
34
33
33 33
21
23
30
32
22
29
31
28
25
27
24
26

10
Gooseneck
Headband
4 Pin Mini XLR
Windscreen
36
38
39
39 39
39
39
39
37
Headset Microphone // CM-204 CM-204U CM-204UL CM-225 CX-504
38
36
36
36
36
36
37 3737
3737
CM-204 CM-204U
CM-225
CM-204UL
CX-504

WIRELESS MICROPHONE SYSTEM
11
Boom
Adjustable Headband
Adjustable ear hook
Detchable Cable
Cable Clip
Windscreen
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
Gooseneck
Clip
4 Pin Mini XLR
Windscreen
40
49
43
52
46
42
51
45
48
41
50
44
47
Instrument Microphone // CX-508W CX-516W
Ear-hook Microphone // CM-801 CM-804i CM-8015 CM-825i
CX-508W CX-516W
CM-801
CM-8015
CM-804i
CM-825i
45
43
44
42
40
40
45
46 47 48 43
44
42
40
45
42
40
45
43
44
41
42
41
43
44
49 49
52 52
50
51

12
AC/DC adaptor
Switching Power Supply(100V~240V , 50~60Hz)
Linear Power Supply (220V , 50Hz)
Linear Power Supply (220V , 60Hz)
Screwdriver
DR-900 Dual Rack Adaptor
RP-900 Panel Cover
AF output cable (with Φ6.3 plug at both ends)
GC-80/GC-100 Guitar Cable
GC-80L/GC-100L Guitar Cable
4-5 Accessories
56
58
59
55
57
54
53
56
55
58 5957
54
53
Option
Option
Option
Option
A
B
C
A
B C

WIRELESS MICROPHONE SYSTEM
13
5. Preparing Procedures & Basic Operation
5-1 Receiver // US-901D
(1) Power output connector
Plug in one end of AC/DC adaptor cable to DC input socket in the rear panel of receiver, and
plug another end into an AC outlet.(Step 1)
(2) Audio Output Connector
Connect one end of the AF output cable to the AF output socket in the rear panel, then plug
another end to the “MIC IN” input socket of a mixer or amplier.(Step 2)
Receiver equipped with balanced XLR output and Unbalanced φ6.3mm output, choose the
proper way for use.
MIXER
AC/DC ADAPTOR
AC POWER SOCKET
AUDIO OUTPUT
DC INPUT
2
1
250
1856

14
(3) LCD panel
AF signal
RF signal
Display for SCAN mode
Display for set FREQ. mode
Main display
Diversity display (A or B antenna)
Baery display for the transmier
(4) Seing the rubber pad
Four self-adhesive rubber pads are provided
to ensure the stability.
ey are to be placed on the boom side of
the receiver.
(5) Connecting the antennas
e user-friendly receiver antenna comes
with easy mount on socket for eortless
connection. Connect two antennas on the
back of the receiver and align them upward.
(6) Connecting the main unit
Plug in the DC connector on the back of the
receiver (DCV INPUT).
(7) Connecting the amplier/mixer console
Plug in the amplier/mixer console to the
(AF OUT UNBAL / BAL ) sockets.
62
64
61
63
66
60
65
61
62
65
63
65
64
6660
250
1856
250
1856
250
1856
ANT.1 / ANT.2
DCV INPUT
AF OUT UNBAL/BAL

WIRELESS MICROPHONE SYSTEM
15
POWER
SET
MIN. MAX.
DIVERSITY RECEIVER
US-901D
(8) Turning the receiver on/o
Turn the receiver on by pressing the
(POWER) buon.
(9) Adjusting the AF output level
Use the AF output level control located on
the front side of the receiver to adjushe AF
signal level that appears at output.
(10) Dual Rack Adaptor set
e dual rack adaptor is available to unify the
half rack space into a standard EIA size with
single or dual units.
AF OUTPUT LEVEL POWER
POWER
SET
MIN. MAX.
DIVERSITY RECEIVER
US-901D
POWER

16
(1) Turning the transmier on/o
e on/o switch is located on the boom of the microphone.
(2) Inserting and changing the baery
1. Loosen the microphone head counter-clockwise. (Figure 1)
2. Hold on to both baery tray buons to release it. (Figure 2)
3. Insert 2 pieces of UM-3 1. 5 V baeries, remember to match
correct polarity. (step1 of Figure3)
4. Directly push the baery tray back. (step2 of Figure3)
5. Aim the connectors exactly for screwing on the microphone
head clockwise. (Figure 4)
(3) LCDpanel
Main display
Baery indicator
5-2 Handheld Transmitter // Mh-950 Mh-960
2
1
Figure 1
Figure 2
Figure 3
Figure 4
69
70
69
70

WIRELESS MICROPHONE SYSTEM
17
(4) Mh-950 Press the SET buon to select between frequency and sensitivity.
1. Frequency adjusting
Press the UP or DOWN buon to adjust the seing of a menu.
1-1 Hold SET buon for 3 seconds to activate frequency.
1-2 Once you see ”MHz” blanking , you are ready to select your desired frequency
by using UP and DOWN buons.
1-3 Press the SET buon again to store your changes.
2. Sensitivity adjusting
2-1 Press the SET buon twice to select sensitivity. Lasting for 3 seconds at the rst
press, then 1 second for the second press, and the display appears .
2-2 Use UP and DOWN buons to adjust changes.
2-3 Finally press EET buon again to store your changes.
(5) Mh-960 Press the SET buon to select between frequency and sensitivity.
1. Frequency adjusting
Press the UP or DOWN buon to adjust the seing of a menu.
1-1 Hold SET buon for 3 seconds to activate frequency.
1-2 Once you see ”MHz” blanking , you are ready to select your desired frequency
by using UP and DOWN buons.
1-3 Press the SET buon again to store your changes.
2. Sensitivity adjusting
2-1 Press the SET buon twice to select sensitivity. Lasting for 3 seconds at the rst
press, then 1 second for the second press, and the display appears .
2-2 Use UP and DOWN buons to adjust changes.
2 -3 Finally press SET buon again to store your changes.
UpSetDown
Up
Set
Down
