INSTRUCTION MANUAL
AMS-224EN4530R / IP-420
* "CompactFlash(TM)" is the registered trademark of SanDisk Corporation, U.S.A.

i
CONTENTS
I. MECHANICAL SECTION (WITH REGARD TO THE SEWING MACHINE) .. 1
1. SPECIFICATIONS ................................................................................................................. 1
2. CONFIGURATION ................................................................................................................. 2
3. INSTALLATION ..................................................................................................................... 3
3-1. Installing the throat plate auxiliary cover..................................................................... 3
3-2. Installing the panel ......................................................................................................... 4
3-3. Installing the thread stand ............................................................................................. 5
3-4. Installing the air hose..................................................................................................... 5
3-5. Installing the eye protection cover ............................................................................... 5
3-6. Changing the height of the table and stand................................................................. 6
4. PREPARATION OF THE SEWING MACHINE ...................................................................... 7
4-1. Lubrication ...................................................................................................................... 7
4-2. Attaching the needle....................................................................................................... 7
4-3. Threading the machine head ......................................................................................... 8
4-4. Installing the bobbin....................................................................................................... 8
4-5. Installing and removing the bobbin case ..................................................................... 8
4-6. Adjusting the thread tension ......................................................................................... 9
4-7. Intermediate presser height........................................................................................... 9
4-8. Adjusting the thread take-up spring ........................................................................... 10
5. OPERATION OF THE SEWING MACHINE......................................................................... 10
5-1. Sewing ........................................................................................................................... 10
II. OPERATION SECTION (WITH REGARD TO THE PANEL) .....................11
1. PREFACE ............................................................................................................................ 11
2. WHEN USING IP-420 .......................................................................................................... 15
2-1. Name of each section of IP-420................................................................................... 15
2-2. Buttons to be used in common ................................................................................... 16
2-3. Basic operation of IP-420............................................................................................. 17
2-4. LCD display section at the time of sewing shape selection..................................... 19
(1) Sewing shape data input screen ................................................................................................19
(2) Sewing screen ............................................................................................................................ 21
2-5. Performing sewing shape selection ........................................................................... 23
2-6. Changing item data ...................................................................................................... 25
2-7. Checking pattern shape ............................................................................................... 27
2-8. Performing modication of needle entry point.......................................................... 28
(1) Editing the thread tension...........................................................................................................28
(2) Editing the intermediate presser height ...................................................................................... 29
2-9. How to use temporary stop ......................................................................................... 30
(1) To continue performing sewing from some point in sewing ........................................................ 30
(2) To perform re-sewing from the start............................................................................................31
2-10. When setting of sewing product is difcult because of interruption of needle tip ... 32
2-11. Winding bobbin thread............................................................................................... 33
(1) When performing winding bobbin thread while performing sewing ............................................ 33
(2) When performing winding bobbin thread only ............................................................................ 33
2-12. Using counter.............................................................................................................. 34
(1) Setting procedure of the counter ................................................................................................34

ii
(2) Count-up releasing procedure .................................................................................................... 36
(3) How to change the counter value during sewing........................................................................36
2-13. Performing new register of users’ pattern ............................................................... 37
2-14. Naming users’ pattern ................................................................................................ 38
2-15. Performing new register of pattern button............................................................... 39
2-16. LCD display section at the time of pattern button selection .................................. 40
(1) Pattern button data input screen ................................................................................................40
(2) Sewing screen ............................................................................................................................ 42
2-17. Performing pattern button No. selection.................................................................. 44
(1) Selection from the data input screen .......................................................................................... 44
(2) Selection by means of the shortcut button .................................................................................45
2-18. Changing contents of pattern button ....................................................................... 46
2-19. Copying pattern button .............................................................................................. 47
2-20. Changing sewing mode ............................................................................................. 48
2-21. LCD display section at the time of combination sewing ........................................ 49
(1) Pattern input screen ...................................................................................................................49
(2) Sewing screen ............................................................................................................................ 51
2-22. Performing combination sewing ............................................................................... 53
(1) Selection of combination data ....................................................................................................53
(2) Creating procedure of the combination data ..............................................................................54
(3) Deleting procedure of the combination data...............................................................................55
(4) Deleting procedure of the step of the combination data ............................................................. 55
(5) Setting of the skip of steps .........................................................................................................56
2-23. Using the simple operation mode ............................................................................. 56
2-24. LCD display when the simple operation is selected ............................................... 57
(1) Data input screen (individual sewing).........................................................................................57
(2) Sewing screen (individual sewing) .............................................................................................60
(3) Data input screen (combination sewing) ....................................................................................63
(4) Sewing screen (combination sewing) ......................................................................................... 65
2-25. Changing memory switch data.................................................................................. 67
2-26. Using information ....................................................................................................... 68
(1) Observing the maintenance and inspection information.............................................................68
(2) Releasing procedure of the warning...........................................................................................69
2-27. Using communication function ................................................................................. 70
(1) Handling possible data ...............................................................................................................70
(2) Performing communication by using the media..........................................................................70
(3) Performing communication by using USB .................................................................................. 70
(4) Take-in of the data ...................................................................................................................... 71
(5) Taking in plural data together......................................................................................................72
2-28. Performing formatting of the media.......................................................................... 74
2-29. Using 2-step stroke function ..................................................................................... 75
(1) Setting of 2-step stroke function ................................................................................................. 75
(2) Setting of 2-step stroke position ................................................................................................. 75
(3) Motion of 2-step stroke function .................................................................................................77
2-30. Operation at the time of X/Y motor position slip ..................................................... 79
(1) When the error is displayed during sewing.................................................................................79
(2) When the error is displayed after end of sewing ........................................................................ 80
(3) When the rest switch is not displayed ........................................................................................80
3. MEMORY SWITCH DATA LIST........................................................................................... 81
3-1. Data list.......................................................................................................................... 81

iii
3-2. Initial value list .............................................................................................................. 87
4. ERROR CODE LIST ............................................................................................................ 89
5. MESSAGE LIST .................................................................................................................. 96
III. MAINTENANCE OF SAWING MACHINE............................................ 99
1. MAINTENANCE................................................................................................................... 99
1-1. Adjusting the height of the needle bar ....................................................................... 99
1-2. Adjusting the needle-to-shuttle relation ..................................................................... 99
1-3. Adjusting the height of the feeding frame................................................................ 101
1-4. Adjusting the vertical stroke of the intermediate presser ...................................... 102
1-5. The moving knife and counter knife ......................................................................... 102
1-6. Thread breakage detector plate ............................................................................... 103
1-7. Draining waste oil ....................................................................................................... 103
1-8. Adjusting the amount of oil supplied to the hook ................................................... 103
1-9. Replacing the fuse...................................................................................................... 104
1-10. Changing the voltage of 100 ⇔200V ...................................................................... 105
1-11. Replenishing the designated places with grease .................................................. 106
(1) Points to be applied with JUKI Grease A..................................................................................107
(2) Points to be applied with JUKI Grease B..................................................................................108
1-12. Troubles and corrective measures (Sewing conditions) ...................................... 109
2. OPTIONAL..........................................................................................................................111
2-1. Gauge list .....................................................................................................................111
2-2. Silicon oil tank ............................................................................................................111
2-3. Bar code reader .......................................................................................................... 112

– 1 –
1. SPECIFICATIONS
I. MECHANICAL SECTION (WITH REGARD TO THE SEWING MACHINE)
1 Sewing area X (lateral) direction Y (longitudinal) direction
450 mm ×300 mm
2 Max. sewing speed 2,500 sti/min (When sewing pitch is 3 mm or less)
3 Settable stitch length 0.1 to 12.7 mm (Min. resolution : 0.05 mm)
4
Feed motion of feeding frame Intermittent feed (2-shaft drive by stepping motor)
5 Needle bar stroke 41.2 mm
6 Needle DP × 17
7 Lift of feeding frame Max. 30mm
8
Intermediate presser stroke 4 mm (Standard) (0 to 10 mm)
9 Lift of intermediate
presser
20 mm
10 Intermediate presser
DOWN position
variable
Standard 0 to 3.5 mm (Max. 0 to 7.0 mm)
11 Shuttle Double-capacity full-rotary hook
12 Lubricating oil New Defrix Oil No. 2 (Supplied by oiler)
13 Memory of pattern
data
• Main body : Max. 999 patterns (Max. 50,000 stitches/pattern)
• External media : Max. 999 patterns (Max. 50,000 stitches/pattern)
14 Temporary stop facility Used to stop machine operation during a stitching cycle.
15 Enlarging / Reducing
facility
Allows a pattern to be enlarged or reduced on the X axis and Y axis independently
when sewing a pattern. Scale : 1% to 400% times (0.1% steps)
16 Enlarging / Reducing
method
Pattern enlargement / reduction can be done by increasing / decreasing either stitch
length or the number of stitches. (Increasing/decreasing stitch length only can be
performed when pattern button is selected.)
17
Max. sewing speed
limitation
200 to 2,500 sti/min (Scale : 100 sti/min steps)
18 Pattern selection
facility
Pattern No. selection method
19 Bobbin thread counter UP/DOWN method (0 to 9,999)
20 Sewing counter UP/DOWN method (0 to 9,999)
21 Memory back-up In case of a power interruption, the pattern being used will automatically be stored in
memory.
22 2nd origin setting
facility
Using jog keys, a 2nd origin (needle position after a sewing cycle) can be set in the
desired position within the sewing area. The set 2nd origin is also stored in memory.
23 Sewing machine motor Servo-motor
24 Dimensions 1,703mm (W) × 1,370mm (L) × 1,200mm (H) (Excluding thread stand)
25 Mass (gross mass) 401 kg
26 Power consumption 550 VA
27
Operating temperature
range
5˚C to 35˚C
28
Operating humidity range 35 % to 85 % (No dew condensation)
29 Line voltage Rated voltage ±10% 50 / 60 Hz
30 Air pressure used 0.5 to 0.55 MPa (Max. 0.55 MPa)
31 Air consumption 1.8 dm3 / min (ANR)
32 Needle highest
position stop facility
After the completion of sewing, the needle can be brought up to its highest position.
33 Noise - Equivalent continuous emission sound pressure level (LpA) at the workstation :
A-weighted value of 83.5 dB ; (Includes KpA = 2.5 dB) ; according to ISO 10821- C.6.2
-ISO 11204 GR2 at 2,500 sti/min.
- Sound power level (LWA) :
A-weighted value of 92.5 dB ; (Includes KWA = 2.5 dB) ; according to ISO 10821- C.6.2
-ISO 3744 GR2 at 2,500 sti/min.

– 2 –
Air regulator
2. CONFIGURATION
󰿿Machine head
󱀀Wiper switch
󱀁Temporary stop switch
󱀂Feeding frame
󱀃Intermediate presser
󱀄Thread stand
󱀅Operation panel (IP-420)
󱀆Power switch
(also used as the emergency stop switch)
󱀇 Control box
󱢳Foot pedal
󰿿
󱀀
󱀁
󱀂
󱀄
󱀅
󱀇
󱢳
󱀃
󱀆

– 3 –
3. INSTALLATION
3-1. Installing the throat plate auxiliary cover
1. The throat plate auxiliary cover is very heavy and perform the installing work with two
persons or more.
 2.Thestayandthelikearesettothethroatplateauxiliarycoverandthettingscrewsand
washers to the bed are packed together with the accessories at the time of delivery.
3. When using the cover sheet supplied as accessories, paste it to the throat plate auxiliary
cover before installing.
1) Move the cloth feed base to the rear and place throat plate auxiliary cover (asm.) 󱀁from between
lower plate 󰿿and throat plate 󱀀.
At this time, be careful not to bend lower plate 󰿿.
2) Temporarily x throat plate auxiliary cover (asm.) 󱀁with throat plate auxiliary cover support set-
screws 󱀃and washers 󱀂.
3) Temporarily x throat plate auxiliary cover support 󱀄to the machine bed with setscrews (M6) 󱀅.
4) Fix throat plate auxiliary cover (asm.) 󱀁on the machine bed with two counter-sunk screws
󱀆
.
5) Insert spacer 󱢵between cloth feed base cover 󱢳and throat plate auxiliary cover (asm.) 󱀁 and x it
with setscrew 󱢴.
6) Securely tighten setscrews
󱀅
.
7) Fix throat plate auxiliary cover setscrew 󱀃.
8) Referring to the caution below, perform positioning of the throat plate auxiliary cover. When the po-
sitioning is not performed enough, perform the positioning after loosening once throat plate auxiliary
cover setscrew 󱀃and throat plate auxiliary cover base setscrews 󱀇.
󱀁
󱀀
󰿿
󱢳
󱀆
󱀁
󱀀
󱢴
󱢵
󱀂󱀃
󱀁
󱀄
󱀅
󱀂󱀃
󱀅󱀅
󱀇󱀇󱀇

– 4 –
Within 0.3 mm
1. Fix the throat plate auxiliary
cover 󱀁so that is higher
than the throat plate 󱀀(within
0.3 mm). When it is lower
than the throat plate 󱀀, nee-
dle breakage or the like due
to the defective feed will be
caused.
 2.Conrmbyputtingaruleror
the like that the throat plate
auxiliary cover 󱀁is horizon-
tally installed. If not, throat
plate auxiliary cover 󱀁and
lower plate 󰿿come in con-
tact partially with each other,
and abnormal worn-out will
be caused.
󱀁
󱀁
󱀀
󱀁
󰿿
3-2. Installing the panel
1) Open cover 󰿿and remove cable 󱀀once.
Then connect it again to the panel on the top
surface of the table after passing it through the
hole in the table.
2) Fix operation panel installing plate 󱀁to an op-
tional place on the table with two wood screws
󱀂.
Install the panel at the position where
X-move cover or head grip does not
interfere with it since breakage of the
panel will be caused.
1) Installing the IP-420
󱀂
󱀁
󰿿
󱀀

– 5 –
3-3. Installing the thread stand
1) Assemble the thread stand. Then, put it in thread-stand mounting hole Aor Bin the machine table.
2) Tighten locknut 󰿿 to x the thread stand.
3) When ceiling wiring is possible, pass the power cord through spool rest rod 󱀀.
4) If thread sags, use thread stand guide arm (asm.) 󱀁.
󰿿
󱀀
A
B
Table
3-4. Installing the air hose
1) Connecting the air hose
Connect the air hose to the regulator .
2) Adjustment of air pressure
Open air cock 󰿿, pull up and turn air adjust-
ment knob 󱀀and adjust so that air pressure
indicates 0.5 to 0.55 MPa (Max. 0.55 MPa).
Then lower the knob and x it.
* Close air cock 󰿿to expel air.
3-5. Installing the eye protection cover
WARNING :
Be sure to attach this cover to protect the eyes from the disperse of needle breakage.
Use eye protection cover 󰿿after securely attach-
ing it on face plate cover 󱀁with screw 󱀀.
To prevent interference with the feed-
ing frame, be sure to install the thread
stand guide arm (asm.) with the eye
protection cover pressed in the direc-
tion of A.
Close
Open
󰿿
󱀀
󰿿
󱀁
󱀀

󱀁

– 6 –
A
A
󰿿
󱀀
󱀁
󱀂
󱀃
󱀄
󱀅
󱀆
󱀇
󱢳
󱢴
󱢸
󱢵
󱢻
󱢷
󱢶
󱢹
󱢺
3) Loosen bolts of 󰿿through 󱢸.
4) Lift the claw of forklift, release bolts of 󱀁, 󱀇and 󱢶from the regulating grooves, move stands 󱢹,
󱢺and 󱢻in the directions of both arrow marks, and lower the claw of forklift at the positions where
the respective groove positions meet with one another.
At this time, make sure that bolts of 󱀁, 󱀇and 󱢶have been securely set in the grooves.
5) Securely tighten bolts of 󰿿through 󱢸with tightening torque of 45 ± 2 N•m.
3-6. Changing the height of the table and stand
1) Insert the claw of forklift up to the transverse beam Ain front of the upper stand from the position as
shown in the gure in the rear of the sewing machine.
2) Lift the claw of the forklift up to the position where the claw of forklift comes in contact with the bot-
tom surface of the upper stand and the upper stand does not fall.
* Take care not to allow the forklift claw to crush the cable.
Regulating grooves
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
Theheightofthetable(measuredfromtheoortothetable)isadjustabletosixdifferentheights.
󰴤870mm 󰴥897mm 󰴦922mm 󰴧945mm 󰴨967mm 󰴩988mm
Ithasbeenfactory-adjustedto󰴥at the time of delivery.

– 7 –
4. PREPARATION OF THE SEWING MACHINE
4-1. Lubrication
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
1) Check that the place between lower line Band upper line Ais
lled with oil. Fill there with oil using the oiler supplied with the
machine as accessories when oil is short.
1. Do not lubricate to the places other than the oil tank and the hook of Caution 2 below.
Trouble of components will be caused.
 2. Whenusingthesewingmachineforthersttimeorafteranextendedperiodofdisuse,
use the machine after lubricating a small amount of oil to the hook portion.
3. Do not put your foot or climb on the sewing machine table or table stand during lubrication.
2) Apply one drop of oil to the
hook race 󰿿part to spread
on it.
The oil tank to lubricate is for lubricating to the hook portion and the gear box portion.
For the hook portion, the oil amount can be decreased when the number of revolutions used is
low and the oil amount is large. (Refer to "III-1-8.Adjustingtheamountofoilsuppliedtothe
hook" p.103 .)
4-2. Attaching the needle
󰿿
󱀀
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
Loosen setscrew 󰿿and hold needle 󱀀with the long
groove facing toward you. Then fully insert it into the
hole in the needle bar, and tighten setscrew 󰿿.
When tightening setscrew 󰿿, be sure
to use the screwdriver (Part No. :
40032763) supplied as accessories.
Do not use L-shaped hexagon wrench
key. There is a danger of breaking set-
screw 󰿿.
1.5 mm
A
B
A
B
󰿿

– 8 –
4-3. Threading the machine head
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
4-5. Installing and removing the bobbin case
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
1) Open hook cover 󰿿.
2) Raise latch 󱀁of bobbin case 󱀀, and remove
the bobbin case.
3) When entering bobbin case, insert it with the
latch tilted until "click" sounds.
If it is not fully inserted, bobbin case
󱀀may slip off during sewing.

※Threading of L-type thread
guide in case of large re-
turn of twist.
4-4. Installing the bobbin
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
1) Set the bobbin 󰿿into bobbin case 󱀀in the direction
shown in the gure.
2) Pass the thread through thread slit 󱀁of bobbin case
󱀀, and pull the thread as it is. By so doing, the thread
will pass under the tension spring and be pulled out
from thread hole 󱀂.
3) Pull out the thread by 4 cm from thread opening 󱀂 .
4 cm
󱀁
󱀀
󰿿
󱀂
󰿿
󱀀
󱀁
If the bobbin is installed in the bobbin case ori-
enting the reverse direction, the bobbin thread
pulling out will result in an inconsistent state.

– 9 –
󰿿
4-6. Adjustingthethreadtension
If thread tension controller No. 1 󰿿is turned
clockwise, the length of remaining thread on the
needle after thread trimming will be shorter. If it is
turned counterclockwise, the length will be longer.
Shorten the length to an extent that the thread is
not slipped off.
Adjust needle thread tension from the operation
panel and bobbin thread tension with 󱀀.
Longer
Shorter
[Adjustingtheneedlethreadtension]
1) Select THREAD TENSION button
󱤨in the sewing screen.
2) Set needle thread tension with SCROLL
button 󱤩. There is a setting range of 0
to 200. When the set value is increased,
the tension becomes higher.
* When the set value is 50 at the time of
standard delivery, the thread tension is
adjusted to 2.35N (spun thread #50).
(When thread tension No. 1 is released)
4-7. Intermediate presser height
Press INTERMEDIATE PRESSER SET-
TING button 󱤨and adjust with TEN keys
󱤩so that the clearance between the
bottom end of intermediate presser and the
cloth is 0.5 mm (thickness of thread used).
1. Setting range of the intermediate presser is up to the standard of 3.5 mm.
However, the setting range can be changed up to max. 7 mm with memory switch .
2. When increasing the height of intermediate presser or making the needle size thicker, con-
rmtheclearancebetweenthewiperandthecomponents.Wipercannotbeusedunlessthe
clearance is secured. Turn OFF the wiper switch. Besides, note that the wiper is set so as to
sweep at the position where the intermediate presser is in the lowest position in spite of the
setting of intermediate presser height at the time of delivery. (Memory switch )
When raising the intermediate presser height, turn the pulley by hand to lower the needle bar,
andconrmthattheneedlebardoesnotinterferewiththeintermediatepresser.
0.5 mm
󱤩
󱤨󱤩
󱤨
󱤩
󱀀

– 10 –
4-8. Adjustingthethreadtake-upspring
󱀁
󱀀
󰿿
󱀂
1) Adjusting the stroke
Loosen setscrew 󱀀, and turn thread tension
asm. 󱀁. Turning it clockwise will increase the
moving amount and the thread drawing amount
will increase.
2) Adjusting the pressure
To change the pressure of the thread take-
up spring
󰿿
, insert a thin screwdriver into the
slot of thread tension post
󱀂
while screw
󱀀
is
tightened, and turn it. Turning it clockwise will
increase the pressure of the thread take-up
spring. Turning it counterclockwise will de-
crease the pressure.
Decrease
Increase
5. OPERATION OF THE SEWING MACHINE
󱤨
󱤩
󱤪
1) 2)
3)
5-1. Sewing
[Incaseofthemechanicalvalvepedal]
1) Set a workpiece under the feeding frame and
depress pedal 󱤨of the pedal switch. Then the
feeding frame comes down.
When the foot is detached, the feeding frame
returns to its home position.
The lowering speed of the feeding frame
changes according to the depressing amount.
This is used when positioning the parts.
2) When positioning the workpiece and depress-
ing pedal 󱤩, the feeding frame comes down to
the bottom and holds the workpiece.
3) Depress pedal 󱤪when the feeding frame
comes down to the bottom and sewing starts.
[Forthe2-stepstrokepedal(PK47)]
* Refer to "II-2-29. Using 2-step stroke function" p.75.

– 11 –
1. PREFACE
The operation panel for the AMS-224EN4530R comes in the following one types.
1) Kind of sewing data handled with IP-420
Sewing data that each panel handles are as shown below.
Pattern name
Users' pattern
Vector format data
M3 data
Sewing standard
format
Description
Pattern that can be stored in the body.
Max. 999 patterns can be registered.
File that extension is ".VDT"
Read from media. Max. 999 patterns can be used.
Pattern data of AMS-210D series
Used by copying from oppy disk of AMS-210D series to media.
Max. 999 patterns can be used.
File that extension is ".DAT"
Read from media. Max. 999 patterns can be used.
2) Using the data (M3 data) of AMS-210D series with AMS-224EN
There are two ways to use M3 data with AMS-224EN.
󰴤Reading by using IP-420
Use PC (personal computer) and copy le (¥AMS¥AMS00xxx.M3) of M3 from oppy disk of AMS-
210D to ¥AMS of media. Insert the media to IP-420, and select Pattern No.xxx from M3 data.
󰴥Changing to vector format data using PM-1
Change to the vector format data with PM-1. (For the details, refer to Help of PM-1.)
Copy the changed vector format data to ¥VDATA folder of the media.
Insert the media to IP-420 and select Pattern No.
II. OPERATION SECTION (WITH REGARD TO THE PANEL)
Kind
Area H Type
4530
ø 60 Pitch 3.0mm
Pattern No. 106

– 12 –
3) Folder structure of the media
Store each le in the folders below of the media.
Data that are not stored in the directories above cannot be read. So, be careful.
Media drive
Store sewing standard data.
Store M3 data.
Store vector format data.
SD00 . DAT
SD00 . DAT
AMS00 . M3
AMS00 . M3
VD00 . VDT
VD00 . VDT
Vector format data :
Store in ¥VDATA.
M3 data :
Store in ¥AMS.
Sewing standard
format :
Store in ¥SDATA.
VDATA
AMS
SDATA
4) CompactFlash (TM)
1) Turn the label side of the CompactFlash(TM)
to this side (place the notch of the edge to
the rear. ) and insert the part that has a small
hole into the panel.
2) After completion of setting of the media, close
the cover. If the cover cannot be closed since
the memory media comes in contact it, check
the following:
・ Check that the media is securely pressed
until it goes no further.
・ Check that the inserting direction of the
media is proper.
1. When the inserting direction is wrong, panel or media may be damaged.
2. Do not insert any item other than the CompactFlash (TM).
3. The media slot in the IP-420 accommodates to the CompactFlash (TM) of 2 GB or less.
4. The media slot in the IP-420 supports the FAT16 which is the format of the CompactFlash
(TM). FAT32 is not supported.
5. Be sure to use the CompactFlash (TM) which is formatted with IP-420. For the formatting pro-
cedure of the CompactFlash (TM), see "II-2-28. Performing formatting of the media" p.74.
Media
Inserting the CompactFlash (TM)

– 13 –
Cautions when using the media
• Do not wet or touch it with wet hands. Fire or electric shock will be caused.
• Do not bend, or apply strong force or shock to it.
• Never perform disassembling or remodeling of it.
• Do not put the metal to the contact part of it. Data may be disappeared.
• Avoid storing or using it in the places below.
Place of high temperature or humidity / Place of dew condensation /
Place with much dust / Place where static electricity or electrical noise is likely to occur
5 USB port
■Inserting a device into the USB port
■Removing the CompactFlash (TM)
1) Hold the panel by hand, open the cover, and
press the media 󱀀removing lever 󰿿. The
media is eject.
When the lever 󰿿is strongly pressed,
the media 󱀀may be broken by pro-
truding and falling.
2) When the media 󱀀is drawn out as it is, re-
moving is completed.
Disconnecting a device from the USB port
Slide the top cover and insert the USB device into
the USB port. Then, copy data to be used from the
USB device onto the main body.
After completion of copying the data, remove the
USB device.
Remove the USB device. Put the cover back in
place.
To protect the USB terminal, do not
perform sewing by 10 times or more
with the USB thumb drive connected
to the sewing machine.
󰿿
󱀀

– 14 –
󰴤Precautions to be taken when handling USB devices
• Do not leave the USB device or USB cable connected to the USB port while the sewing machine is in opera-
tion. The machine vibration can damage the port section resulting in loss of data stored on the USB device or
breakage of the USB device or sewing machine.
• Do not insert/remove a USB device during reading/writing a program or sewing data.
It may cause data breakage or malfunction.
• When the storage space of a USB device is partitioned, only one partition is accessible.
• Some type of the USB device may not be properly recognized by this sewing machine.
• JUKI does not compensate for loss of data stored on the USB device caused by using it with this sewing ma-
chine.
• When the panel displays the communication screen or pattern data list, the USB drive is not recognized even
if you insert a medium into the slot.
• For USB devices and media such as CF cards, only one device/medium should be basically connected/insert-
ed to/into the sewing machine. When two or more devices/media are connected/inserted, the machine will
only recognize one of them. Refer to the USB specications.
• Insert the USB connector into the USB terminal on the IP panel until it will go no further.
• Do not turn the power OFF while the data on the USB ash drive is being accessed.
󰴥 USB specications
• Conform to USB 1.1 standard
• Applicable devices *1���� Storage devices such as USB memory, USB hub, FDD and card reader
• Not-applicable devices��CD drive, DVD drive, MO drive, tape drive, etc.
• Format supported �����FD (oppy disk) FAT 12
Others (USB memory, etc.), FAT 12, FAT 16, FAT 32
• Applicable medium size �FD (oppy disk) 1.44MB, 720kB
Others (USB memory, etc.), 4.1MB ~ (2TB)
• Recognition of drives ��For external devices such as a USB device, the device which is recognized rst
is accessed. However, when a medium is connected to the built-in media slot, the
access to that medium will be given the highest priority. (Example: If a medium is in-
serted into the media slot even when the USB memory has already been connected
to the USB port, the medium will be accessed.)
• Restriction on connection � Max. 10 devices (When the number of storage devices connected to the sewing
machine has exceeded the maximum number, the 11th storage device and beyond
will not be recognized unless they are once disconnected and re-connected. )
• Consumption current ���The rated consumption current of the applicable USB devices is 500 mA at the maxi-
mum.
*1: JUKI does not guarantee operation of all applicable devices. Some device may not operate due to a compati-
bility problem.

– 15 –
2. WHEN USING IP-420
2-1. Name of each section of IP-420
󰴤Touch panel・LCD display section
󰴥READY key → Changeover of the data input screen and
the sewing screen can be performed.
󰴦INFORMATION key → Changeover of the data input screen and
the information screen can be performed.
󰴧 COMMUNICATION key → Changeover of the data input screen and
the communication screen can be performed.
󰴨MODE key →Changeover of the data input screen and
the mode changeover screen which
performs various detail settings can be performed.
󰴩 Contrast control
󰴪Brightness control
󰴫 CompactFlash (TM) eject button
󰴬 CompactFlash (TM) slot
󰴭 Cover detection switch
󰴮 Connector for external switch
󰴯 Connector for control-box connection
(Front) (Right side)
󰴤
󰴦
󰴥
󰴧 󰴨
󰴮
󰴪
󰴯
󰴫
󰴬
󰴩
󰴭

– 16 –
2-2. Buttons to be used in common
The buttons which perform common operations in each screen of IP-420 are as follows :
CANCEL button →This button closes the pop-up screen.
In case of the data change screen, the data being
changed can be cancelled.
ENTER button → This button determines the changed data.
UP SCROLL button → This button scrolls the button or the display in the
upward direction.
DOWN SCROLL button → This button scrolls the button or the display in the
downward direction.
RESET button → This button performs the release of error.
NUMERAL INPUT button → This button displays ten keys and input of numerals
can be performed.
CHARACTER INPUT button → This button displays the character input screen.
→
Refer to "II-2-14. Naming users’ pattern" p.38.
INTERMEDIATE PRESSER DOWN button → Lowers the intermediate presser and displays the
PRESSER DOWN screen.
Bobbin winder button → Bobbin thread winding is performed.
→Refer to "II-2-11. Winding bobbin thread" p.33.
