CONTENTS
SPECIFICATIONS................................................1
1. INSTALLATION ............................................2
2. ADJUSTING THE HEIGHT OF THE KNEE
LIFTER..........................................................4
3. INSTALLING THE THREAD STAND............4
4. LUBRICATION (DDL-9000B-S , -M ) ........5
5. ATTACHING THE NEEDLE..........................6
6. SETTING THE BOBBIN INTO THE BOB-
BIN CASE ........................................................ 6
7. ADJUSTING THE AMOUNT OF OIL (OIL
SPLASHES) IN THE HOOK
(DDL-9000B-S , -M )..................................7
(1) How to conrm the amount of oil (oil splash-
es).................................................................... 7
(2) Sample showing the appropriate amount of oil 7
8. ADJUSTING THE AMOUNT OF OIL IN
THE HOOK (DDL-9000B-S , -M )..............8
9. THREADING THE MACHINE HEAD............9
10. THREAD TENSION ......................................9
(1) Adjusting the needle thread tension ................ 9
(2) Adjusting the bobbin thread tension ............... 9
11. WINDING THE BOBBIN THREAD.............10
12. PRESSER FOOT PRESSURE ...................11
13. ADJUSTING THE STITCH LENGTH .........11
14. ADJUSTING THE THREAD TAKE-UP
SPRING AND THE THREAD TAKE-UP
STROKE...........................................................12
15. ADJUSTING THE NEEDLE STOP POSI-
TION............................................................13
(1) Stop position after thread trimming................ 13
(2) Adjusting procedure of the needle up/down
stop position .................................................. 13
16. PEDAL PRESSURE AND PEDAL
STROKE .....................................................14
(1) Adjusting the pressure required to depress
the front part of the pedal .............................. 14
(2) Adjusting the pressure required to depress
the back part of the pedal ............................. 14
(3) Adjusting the pedal stroke ............................ 14
17. ADJUSTMENT OF THE PEDAL ................14
(1) Installing the connecting rod.......................... 14
(2) Adjusting the pedal angle .............................. 14
18. PEDAL OPERATION ..................................15
19. NEEDLE-TO-HOOK RELATIONSHIP ........16
20. ONE-TOUCH TYPE REVERSE FEED
STITCHING MECHANISM..........................17
21. ADJUSTING THE POSITION OF THE
WIPER (DDL-9000B- -WB, -0B) ..........18
22. COUNTER KNIFE.......................................19
23. HEIGHT AND TILT OF THE FEED DOG....20
(1) Standard value of the height of the feed dog. 20
(2) Adjusting the height and tilt of the feed dog... 20
24. ADJUSTING THE FEED TIMING ...............21
25. THREAD TENSION RELEASE RELEAS-
ING MECHANISM.......................................21
26. MICRO-LIFTING MECHANISM OF THE
PRESSER FOOT ........................................22
27. SEWING CONDENSED STITCHES...........23
28. FEED CONVERSION SPRING MECHA-
NISM (DDL-9000B-S , -M )......................23
29. CARE ..........................................................24
(1) Conrmation of the amount of oil in the hook
oil tank. .......................................................... 24
(2) Cleaning ....................................................... 24
30. APPLYING GREASE ..................................25
(1) Sections to which grease is to be replen-
ished .............................................................. 25
(2) Releasing procedure of the grease-up warn-
ing for SC-920 ............................................... 26

– 1 –
S : Micro-quantity lubrication
M : Semi-dry
D : Dry
S : Medium-weight materials
H : Heavy-weight materials
A : Light weight materials
DDL-9000B-
-SS -MS -DS -SH -MA*3
Max. sewing
speed 5,000sti/min 4,000 sti/min 4,500 sti/min 5,000 sti/min
Thread trimming
speed 500 sti/min (100 to 500 sti/min)
Stitch length 5 mm *1 4mm
Presser foot lift
(by knee lifter) 10 mm (standard) 15 mm (max.)
Needle *2
1738 Nm65 to 110
(DB×1 #9 to 18)
1738 Nm125 to 160
(DB×1 #20 to 23)
1738 SAN10 Nm60 to 75
(DB×1 SF#8 to 11)
134 Nm65 to 110
(DP×5 #9 to 18)
134 Nm125 to 160
(DP×5 #20 to 23)
134 Nm60 to 75
(DP×5 #8 to 11)
Lubricating oil JUKI NEW DEFRIX OIL No. 1
or JUKI MACHINE OIL #7
- JUKI NEW DEFRIX OIL No. 1
or JUKI MACHINE OIL #7
Noise
SS, MS, MA ;
'- Equivalent continuous emission sound pressure level (LpA) at the workstation:
A-weighted value of 77 dBA ; (Includes KpA = 2.5 dBA) ; according to ISO 10821- C.6.2 -ISO 11204
GR2 at 4,000 sti/min.
SH ;
'- Equivalent continuous emission sound pressure level (LpA) at the workstation:
A-weighted value of 77 dBA ; (Includes KpA = 2.5 dBA) ; according to ISO 10821- C.6.2 -ISO 11204
GR2 at 4,000 sti/min.
DS ;
'- Equivalent continuous emission sound pressure level (LpA) at the workstation:
A-weighted value of 79 dBA ; (Includes KpA = 2.5 dBA) ; according to ISO 10821- C.6.2 -ISO 11204
GR2 at 4,000 sti/min.
SPECIFICATIONS
• The sewing speed will vary depending on the sewing conditions. The sewing speed preset at the time of shipping is 4,000sti/
min. The thread trimming speed can be changed within the range of ( ). The thread trimming speed preset at the time of
shipping is 420 sti/min.
*1 : When stitch length exceeds 4 mm or more, set the max. sewing speed to 4,000 sti/min or less for use.
*2 : Needle used depends on the destination.
*3 : MA type is for light-weight materials. In the case the sewing machine is used with its speed of stitch set at 4,000 sti/min or
higher, the presser regulating spring and thread tension spring should be changed with S type ones.

– 2 –
1. INSTALLATION
1) Carry the sewing machine with two persons as
shown in the gure above.
(Caution) Do not hold the handwheel.
23.5 mm 19.5 mm
❶
❷
❹
❸
AB
❺
C
❶❶
❸
❸
❽
2) Do not put protruding articles such as the screw-
driver and the like at the location where the sewing
machine is placed.
3) The under cover should rest on the four corners
of the machine table groove. Mount rubber hinge
seat ❽ on the table and x it on the table with a
nail.
4) Fix two rubber seats ❶ on side A (operator’s
side) using nails ❷ as illustrated above. Fix two
cushion seats ❸ on side B (hinged side) using a
rubber-based adhesive. Then place under cover
❹ on the xed seats.
5) Remove air vent cap ❺ attached to the machine
bed.
(Caution)
1. If the sewing machine is operated without
removing air vent cap ❺, oil leakage from
gear box portion C may occur.
2. Be sure to attach cap ❺ when transporting
the machine head in the state that the ma-
chine head is removed from the machine
table.

– 3 –
❾
❼
❻
󱢳
󱢴
󱢵󱢵
󱢴
󱢶
󱢵
❼
❽
❹
󱢷
6) Fit knee lifter pressing rod ❻. Fit hinge ❼ into the
opening in the machine bed, and t the machine
head to table rubber hinge ❽ before placing the
machine head on cushions ❾ on the four corners.
7) Securely attach head support rod 󱢳 to the table
until it goes no further. Regarding the control
panel 󱢴, remove two side plate xing screws 󱢵,
place the rubber packing 󱢶, which is one of the
accessories of the control panel 󱢴, between the
head section and control panel 󱢴, then x them
together.
(Caution)
1. Do not use the screws supplied as accesso-
ries of control panel 󱢴.
2. Be sure to mount the machine head support
rod 󱢳 on the machine table so that its height
from the table surface becomes 55 to 60 mm.
For the sewing machine provided with the AK
device, be sure to mount the support rod 󱢳
on the table so that its height from the table
surface becomes 38 to 43 mm.
8) Bundle cable clip band 󱢷 supplied as accessories
of the machine head at the root of the cable.
9) Check to be sure that the table and the safety
switch arm 󱢸 are engaged with each other by 2.0
mm to 3.5 mm, with the sewing machine slightly
tilted.
(Caution) If the engagement between the table and
the safety switch arm is 2 mm or less, Error
302 may occur at the time of startup. Or, if the
aforementioned engagement is 3.5 mm or more,
safety switch arm 󱢸may break.
10) If the engagement between the table and safety
switch arm 󱢸 is outside the range of 2.0 mm and
3.5 mm, loosen safety switch mounting screw 󱢹
and tilt safety switch 󱢺 in the direction of the arrow
to adjust the engagement of safety switch arm 󱢸
with the table.
󱢺
󱢹
󱢸
2.0 to 3.5 mm

– 4 –
1) Assemble the thread stand unit, and insert it in the hole in the machine table.
2) Tighten nut ❶.
3) For ceiling wiring, pass the power cord through spool rest rod ❷.
❷
❶
❸
❷
❶
❹
The standard height of the presser foot lifted using the
knee lifter is 10 mm.
You can adjust the presser foot lift up to 15 mm using
knee lifter adjust screw ❶.
(Caution)
1. Do not operate the sewing machine in the
state that the presser foot ❸ is lifted by 10
mm or more since the needle bar ❷comes
in contact with the presser foot ❸.
2. Knee lifter initial position
If the adjustment screw ❹is over tightened,
the sewing machine will operate in a state
where the presser foot is lifted up, causing
defective sewing or noise.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
2. ADJUSTING THE HEIGHT OF THE KNEE LIFTER
3. INSTALLING THE THREAD STAND

– 5 –
Fill the oil tank with oil for hook lubrication before op-
erating the sewing machine.
1) Remove oil hole cap ❶ and ll the oil tank with
JUKI NEW DEFRIX OIL No.1 (Part No. : MD-
FRX1600C0) or JUKI MACHINE OIL #7 (Part No.
: MML007600CA) using the oiler supplied with the
machine.
2) Fill the oil tank with the oil until the top end of oil
amount indicating rod ❸ comes between the upper
engraved marker line A and the lower engraved
marker B line of oil amount indicating window ❷ .
If the oil is lled excessively, it will leak from the
air vent hole in the oil tank or proper lubrication
will be not performed. In addition, when the oil is
vigorously lled, it may overow from the oil hole.
So, be careful.
❶
❷
❸Upper
engraved
marker line
3) When you operate the sewing machine, rell oil if the top end of oil amount indicating rod ❸ comes down
to the lower engraved marker line of oil amount indicating window ❷ .
(Caution)
1. When you use a new sewing machine or a sewing machine after an extended period of disuse,
use the sewing machine after performing break-in at 2,000 sti/min or less.
2. For the oil for hook lubrication, purchase JUKI NEW DEFRIX OIL No. 1 (Part No. : MDFRX1600C0)
or JUKI MACHINE OIL #7 (Part No. : MML007600CA).
3. Be sure to lubricate clean oil.
4. Do not operate the machine with the oil hole cap ❶ removed. Never remove cap ❶ from the oil
inlet in any case other than oiling. In addition, take care not to lose it.
WARNING :
1. Do not connect the power plug until the lubrication has been completed so as to prevent
accidents due to abrupt start of the sewing machine,
2. To prevent the occurrence of an inammation or rash, immediately wash the related portions if oil
adheres to your eyes or other parts of your body.
3. If oil is mistakenly swallowed, diarrhea or vomitting may occur. Put oil in a place where children
cannot reach.
Upper
engraved
marker line
4. LUBRICATION (DDL-9000B-S , -M )

– 6 –
6. SETTING THE BOBBIN INTO THE BOBBIN CASE
Use the specied needle for the machine. Use the
proper needle in accordance with the thickness of
thread used and the kinds of the materials.
1) Turn the handwheel until the needle bar reaches
the highest point of its stroke.
2) Loosen screw ❷, and hold needle ❶ with its
indented part A facing exactly to the right in di-
rection B.
3) Insert the needle fully into the hole in the needle
bar in the direction of the arrow until the end of
hole is reached.
❶
❷
C
DB
A
1) Install the bobbin in the bobbin case so that the
thread wound direction is clockwise.
2) Pass the thread through thread slit A, and pull
the thread in direction C. By so doing, the thread
will pass under the tension spring and come out
from notch B.
3) Check that the bobbin rotates in the direction of
the arrow when thread is pulled.
A
B
C
4) Securely tighten screw ❷.
5) Check that long groove C of the needle is facing exactly to the left in direction D.
(Caution) When polyester lament thread is used, if the indented part of the needle is tilted toward oper-
ator's side, the loop of thread becomes unstable. As a result, hangnail of thread or thread breakage
may occur. For the thread that such phenomenon is likely to occur, it is effective to attach the needle
with its indented part slightly slanting on the rear side.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
5. ATTACHING THE NEEDLE

– 7 –
(1) How to conrm the amount of oil (oil splashes)
7. ADJUSTING THE AMOUNT OF OIL (OIL SPLASHES) IN THE HOOK
(DDL-9000B-S , -M )
❶Amount of oil (oil splashes) conrmation paper
* When carrying out the procedure described below in 2), conrm the state that the needle thread
from the thread take-up lever to the needle and the bobbin thread are removed, the presser foot is
lifted and the slide plate is removed. At this time, take extreme caution not to allow your ngers to
come in contact with the hook.
1) If the machine has not been sufciently warmed up for operation, make the machine run idle for approxi-
mately three minutes. (Moderate intermittent operation)
2) Place the amount of oil (oil splashes) conrmation paper under the hook while the sewing machine is in
operation.
3) Conrm that oil exists in the oil tank.
4) Conrmation of the amount of oil should be completed in ve seconds. (Check the period of time with a
watch.)
❷Position to conrm the amount of oil (oil splashes)
(2) Sample showing the appropriate amount of oil
1) The state given in the gure above shows the appropriate amount of oil (oil splashes). It is necessary to nely
adjust the amount of oil in accordance with the sewing processes. However, do not excessively increase/de-
crease the amount of oil in the hook. (If the amount of oil is too small, the hook will be seized (the hook will be
hot). If the amount of oil is too much, the sewing product may be stained with oil.)
2) Check the oil amount (oil splashes) three times (on the three sheets of paper), and adjust so that it should
not change.
• DDL-9000B-SS, -M : 0.5 to 1 mm
• DDL-9000B-SH : 1 to 3 mm
• DDL-9000B-SS, -M : 1 to 1.5 mm
• DDL-9000B-SH : 2 to 4 mm
WARNING :
Be extremely careful about the operation of the machine since the amount of oil has to be checked
by turning the hook at a high speed.
Closely fit the
paper against the
wall surface of
the bed.
Hook Hook driving shaft front bushing
Bed
Oil splashes conrmation paper
* Place the amount of oil (oil splashes) conrmation paper under
the hook and keep it from the hook by 3 to 10 mm to conrm
the amount.
* Use any paper available regardless of the material.
Approx. 70 mm
Approx. 25 mm
Splashes of oil from the hook
Appropriate amount of oil (small) Appropriate amount of oil (large)
Splashes of oil from the hook
3 - 10mm

– 8 –
8. ADJUSTING THE AMOUNT OF OIL IN THE HOOK (DDL-9000B-S , -M )
Tighten (turn clockwise) oil amount adjustment screw ❶ to increase the amount of oil in the hook, or loosen
(turn counterclockwise) to decrease it.
(Caution)
[When using RP hook (hook for dry head) for S or -M type]
1. Remove hook driving shaft oil wick setscrew ❷ and attach hook driving shaft stopper screw ❸
(Part No. : 11079506) and rubber ring ❹(Part No. : R0036080200).
2. Loosen oil amount adjustment screw ❶ up to the minimum so as to reduce the oil amount in the
hook. However, do not completely stop the oil and be careful not to allow oil adjustment screw
❶ to come off.
3. Never drain the oil in the oil tank even when RP hook (hook for dry head) is used.
❶
❷
❹
❸
Decrease Increase
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.

– 9 –
10. THREAD TENSION
(1) Adjusting the needle thread tension
1) Turn thread tension No. 1 nut ❶ clockwise (in di-
rection A ), to shorten the thread length remaining
on the needle after thread trimming or counter-
clockwise (in direction B ), to lengthen the thread
length.
2) Turn thread tension nut ❷ clockwise (in direction
C ) to increase or counterclockwise (in direction D )
to reduce the needle thread tension.
❶
❷
❺
❹
❸
❻
❼
❽
❾
󱢳
󱢴
󱢵
󱢶
A
(Note) Do not pass
this thread
through
section A.
❶
❷
A
B
❸
EF
C
D
(2) Adjusting the bobbin thread tension
1) Turn tension adjusting screw ❸ clockwise (in
direction E ) to increase or counterclockwise (in
direction F ) to reduce the bobbin thread tension.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
9. THREADING THE MACHINE HEAD

– 10 –
1) Insert the bobbin deep into the bobbin winder
spindle ❶ until it will go no further.
2) Pass the bobbin thread pulled out from the spool
rested on the right side of the thread stand follow-
ing the order as shown in the gure on the left.
Then, wind clockwise the end of the bobbin thread
on the bobbin several times.
(In case of the aluminum bobbin, after winding
clockwise the end of the bobbin thread, wind coun-
terclockwise the thread coming from the bobbin
thread tension several times to wind the bobbin
thread with ease.)
3) Press the bobbin winder trip latch ❷ in the di-
rection of A and start the sewing machine. The
bobbin rotates in the direction of C and the bobbin
thread is wound up. The bobbin winder spindle ❶
automatically as soon as the winding is nished.
4) Remove the bobbin and cut the bobbin thread with
the thread cut retainer ❸.
5) When adjusting the winding amount of the bob-
bin thread, loosen setscrew ❹ and move bobbin
winding lever ❷ to the direction of A or B. Then
tighten setscrew ❹.
To the direction of A : Decrease
To the direction of B : Increase
D
E
B
❸
❶
❻
❼
❻
❺
❻
A
C
❽
❹
❷
11. WINDING THE BOBBIN THREAD
6) In case that the bobbin thread is not wound evenly on the bobbin, remove the handwheel, loosen screw
❺ and adjust the height of bobbin thread tension ❽.
• It is the standard that the center of the bobbin is as high as the center of thread tension disk ❻.
• Adjust the position of thread tension disk ❻ to the direction of D when the winding amount of the bobbin
thread on the lower part of the bobbin is excessive and to the direction E when the winding amount of the
bobbin thread on the upper part of the bobbin is excessive.
After the adjustment, tighten screw ❺.
7) To adjust the tension of the bobbin winder, turn the thread tension nut ❼.
(Caution)
1. When winding the bobbin thread, start the winding in the state that the thread between the bobbin
and thread tension disk ❻is tense.
2. When winding the bobbin thread in the state that sewing is not performed, remove the needle
thread from the thread path of thread take-up and remove the bobbin from the hook.
3. There is the possibility that the thread pulled out from the thread stand is loosened due to the
inuence (direction) of the wind and may be entangled in the handwheel. Be careful of the direc-
tion of the wind.

– 11 –
1) Loosen nut ❷. As you turn presser spring regula-
tor ❶ clockwise (in direction A), the presser foot
pressure will be increased.
2) As you turn the presser spring regulator count-
er-clockwise (in direction B), the pressure will be
decreased.
3) After adjustment, tighten nut ❷.
The standard value of the addition C of the height of
presser spring regulator is as follows :
• S type : 31.5 to 29 mm (Approximately 40 to 45N/4
to 4.5kg)
• H type : 31.5 to 28 mm (Approximately 50 to 60N/5
to 6kg)
• A type : 22 mm (Approximately 20N/2kg)
A
B
C
❶
❷
* The dial calibration is in millimeters.
1) Turn stitch length dial ❶ in the direction of the
arrow, and align the desired number to marker
dot A on the machine arm.
2) To change over the feed scale mark from "large"
to "small", turn stitch dial ❶ while pressing feed
lever ❷ in the direction of the arrow and pressing
stopper ❸ in the direction of arrow B (toward the
back of the arm).
3) To change over the feed scale mark from "small"
to "large", turn stitch dial ❶ while pressing stopper
❸ in the direction of arrow B (toward the back of
the arm).
4) Release stopper ❸ to x stitch dial ❶.
12. PRESSER FOOT PRESSURE
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
A
B
❸
❶
❷
13. ADJUSTING THE STITCH LENGTH

– 12 –
(1) Adjusting the stroke of thread take-up spring ❶
1) Loosen setscrew ❷.
2) Turn tension post ❸ clockwise (in direction A ), the stroke of the thread take-up spring will be increased,
and turn the post ❸ counterclockwise (in direction B ), the stroke will be decreased.
(2) Adjusting the pressure of thread take-up spring ❶
1) Loosen setscrew ❷, and remove thread tension (asm.) ❺.
2) Loosen tension post setscrew ❹.
3) Turn tension post ❸ clockwise (in direction A), the pressure will be increased, and turn the post ❸ counter-
clockwise (in direction B), the pressure will be decreased.
* Standard state of the thread take-up spring
The engraved marker line ❻ on the machine arm is almost aligned with the top of thread take-up spring.
(It is necessary to adjust in accordance with materials and processes.)
(Caution) For the Model DDL-9000B- DS, the fully-dry hook is adopted. Comparing with the sewing machine
using the existing hook, the sewing machine tends to be affected by the adjustment of the thread take-up
spring. If the thread take-up spring does not work sufciently, thread running increases. As a result, thread
breakage, balloon stitching, etc. may occur.
To check how the thread take-up spring works, draw out the needle thread in direction F after having
adjusted the thread take-up spring pressure to check whether the thread take-up spring exerts force to
the thread up to the last moment (state G) just before the thread comes out from E. If the spring fails to
exert force to the spring until the last moment (state H), decrease the thread take-up spring pressure. In
addition, the stroke of the thread take-up spring is excessively small, the spring does not work properly.
For the general fabrics, a stroke of 10 to 13 mm is proper.
(3) Adjusting The Thread Take-up Stroke
1) When sewing heavy-weight materials, move thread guide ❽ to the left (in direction C) to increase the length
of thread pulled out by the thread take-up.
2) When sewing light-weight materials, move thread guide ❽ to the right (in direction D) to decrease the
length of thread pulled out by the thread take-up.
* Standard state of the thread guide
・- S, -MA: Marker line ❾ on the thread guide aligns with the center of the setscrew.
・ -SH: Marker line ❾ on the thread guide aligns with the center of the marker line on the machine arm.
14. ADJUSTING THE THREAD TAKE-UP SPRING AND THE THREAD TAKE-UP STROKE
❺
❶
❹
G
H
FE
D
C
A
B
❻❶
❸
❾
❽
[DDL-9000B- S, -MA] [DDL-9000B-SH]
❷
A
B
❻❶
❸
❷
❾
❽

– 13 –
15. ADJUSTING THE NEEDLE STOP POSITION
(1) Stop position after thread trimming
B
A
❸
❷
❶
C
D
EF
❺
❹
5) Specify the setting contents F within the range of -15 to 15 with switch ❸ or switch ❹.
(Standard is "0". The numeric of set value indicates the approximate rotating angle.)
When the numeric is set to the "+" direction, the needle UP stop position is lowered. (Direction C)
When the numeric is set to "–" direction, the needle UP stop position is raised. (Direction D)
6) After completion of the setting, press switch ❶ or switch ❷ to determine the updated value. (When turning
OFF the power to the machine before performing this work, the contents are not updated.)
7) After completion of the operation, turn OFF the power to the machine. The normal operation can be performed
by turning ON the power to the machine again.
(2) Adjusting procedure of the needle up/down stop position
* When the panel other than CP-18 is used, refer to the explanation of each panel.
1) Turn OFF the power to the machine.
2) Turn the power ON while pushing the switch ❺
on the operation panel.
3) The screen display E indicates the setting No.
96 and F indicates the number of revolution.
(When the screen display is not changed, operate
again steps 1) and 2).
4) Update the setting No. by switch ❶ or switch ❷.
Setting No. 121 : Needle UP stop position
Setting No. 122 : Needle DOWN stop position
1) The standard needle stop position is obtained by
aligning marker dot A on the pulley cover with
white marker dot B on the handwheel
* For the details, refer to the Instruction Manual for
the control box together.
WARNING :
1. Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
2. Do not perform switch operations other than those described in the following explanations.
3. Be sure to re-turn the power switch ON after one second or more has passed. If the power is turned ON
immediately after turning it OFF, the sewing machine may not work normally. In this case, turn ON the
power again.

– 14 –
16. PEDAL PRESSURE AND PEDAL STROKE
(1) Adjusting the pressure required to depress the front part of the pedal
1) When the pedal pressure spring ❶ is hooked to the lower side, the pedal pressure will decrease, and when
hooked to the upper side, the pedal pressure will increase.
(2) Adjusting the pressure required to depress the back part of the pedal
1) The pressure increases as you turn reverse depressing regulator screw ❷ in, and decreases as you turn
the screw out.
(3) Adjusting the pedal stroke
1) The pedal stroke decreases when you insert connecting rod ❸ into the left hole ❹.
❸
❶
❹
❷
17. ADJUSTMENT OF THE PEDAL
(1) Installing the connecting rod
1) Move pedal ❸ to the right or left as illustrated
by the arrows so that motor control lever ❶and
connecting rod ❷ are straightened.
(2) Adjusting the pedal angle
1) The pedal tilt can be freely adjusted by changing
the length of the connecting rod ❷.
2) Loosen adjust screw ❹, and adjust the length of
connecting rod ❷.
❷
❹
❷
❶
❸
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
Lower side
Upper side

– 15 –
18. PEDAL OPERATION
The pedal is operated in the following four steps:
1) The machine runs at low sewing speed when you
lightly depress the front part of the pedal. B
2) The machine runs at high sewing speed when
you further depress the front part of the pedal. A
(If the automatic reverse feed stitching has been
preset, the machine runs at high speed after it
completes reverse feed stitching.)
3) The machine stops (with its needle up or down)
when you reset the pedal to its original position.
C
4) The machine trims threads when you fully depress
the back part of the pedal. E
* When the auto-lifer (AK device) is used, one more
operating switch is provided between the sewing
machine stop switch and thread trimming switch.
The presser foot goes up when you lightly depress
the back part of the pedal D, and if you further de-
press the back part, the thread trimmer is actuated.
When starting sewing from the state that the
presser foot has been lifted with the Auto-lifter
and you depress the back part of the pedal, the
presser foot only comes down.
• If you reset the pedal to its neutral position during
the automatic reverse feed stitching at seam start,
the machine stops after it completes the reverse
feed stitching.
• The machine will perform normal thread trimming
even if you depress the back part of the pedal
immediately following high or low speed sewing.
• The machine will completely perform thread
trimming even if you reset the pedal to its neutral
position immediately after the machine started
thread trimming action.
A
C
E
D
B

– 16 –
19. NEEDLE-TO-HOOK RELATIONSHIP
Adjust the timing between the needle and the hook
as follows :
1) Adjusting the needle bar height. Turn the hand-
wheel to bright the needle bar down to the lowest
point of its stroke, and loosen setscrew ❶.
2) Adjusting the needle bar height. Align marker line
(For a DB needle : marker line A, For a DA needle
: marker line C) on needle bar ❷ with the bottom
end of needle bar lower bushing ❸, then tighten
setscrew ❶.
3) Position the needle and the hook A.
Loosen the three hook setscrews, turn the hand-
wheel in normal rotation and align marker line (For
a DB needle : marker line B, For a DA needle :
marker line D) on ascending needle bar ❷ with
the bottom end of needle bar lower bushing ❸.
4) In this state, align hook blade point ❺ with the
center of needle ❹. Provide a clearance of 0.04
mm to 0.1 mm (reference value) between the
needle and the hook, then securely tighten the
three hook setscrews.
(Caution) If the clearance between the blade point
of hook and the needle is smaller than the
specied value, the blade point of hook will
be damaged. If the clearance is larger, stitch
skipping will result.
• RP hook (dry hook) is used for the hook of
DDL-9000B-DS type. When replacing, use the
part No. described below. There are two kinds
of Part Nos. of the hooks classied by the
regions.
22890206
22890404 (For Europe)
❶
C
D
A
B
B
❸
A
❷
A
0.04 to 0.1 mm
❹
❺
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
(Caution) Periodically clean RP hook (dry hook) since the hook rolls up thread waste or cloth waste and
failure of the machine or defective sewing may be caused.
(Caution) Because the needle bar ❷ of DDL-9000B-MS and DS is black colored, sometimes it is hard to
see the engraved lines. Make the working area bright by bringing a light or by other method.

– 17 –
20. ONE-TOUCH TYPE REVERSE FEED STITCHING MECHANISM
The moment switch lever ❶ is pressed, the machine
performs reverse feed stitching.
The machine resumes normal feed stitching the mo-
ment the switch lever is released.
[Adjusting the position of switch]
1) Loosen setscrew ❷ and move the switch itself up
and down to adjust the height.
2) Switch ❶ can be used in two positions by turning
it.
3) In addition, when you desire to lower the position
of switch ❶, loosen setscrew ❸ located in the
back of the machine head and lower switch base
❹.
❶
❷
❸
❹
The following functions can be performed by one-touch operation using optional switch (23632656) ❺.
❺
❻
❼
❽
❾
[Connection of the optional switch]
Insert the cord of the optional switch into ❼ and ❽ of 4P connector ❻ coming from the machine head. (There
is no polarity.)
The pin is provided with the inserting direction. Insert it with protruding portion ❾ upward.
1. Needle up/down compensating stitching
... Every time the switch is pressed, needle up/
down compensating stitching is performed.
2. Back compensating stitching
... Every time the switch is pressed, reverse feed
stitching is performed at low speed. (It is effec-
tive only when a constant-dimension stitching
pattern is selected on the panel.)
3. Function to cancel once reverse feed stitching at
the end of sewing
... When the switch is pressed, the next automatic
reverse feed stitching at the end of sewing only
can be canceled once.
4. Thread trimming function
... When the switch is pressed, thread trimming
is performed.
5. Presser lifting function
... When the switch is pressed, automatic presser
lifting can be executed.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
WARNING :
Turn OFF the power before starting the
work so as to prevent accidents caused
by abrupt start of the sewing machine.
Optional switch (separately-available)
6. One stitch compensating stitching ... Every time the switch is pressed, one stitch compensating stitching
is performed.
* When using the optional switch, it is necessary to set the function with the control box. For the
details, see the Instruction Manual for the control box.

– 18 –
21. ADJUSTING THE POSITION OF THE WIPER (DDL-9000B- -WB, -0B)
❸
❹
1mm
2mm
❶
❷
❾
❽
❼
EF
❺󱢳
❻
Adjust the position of the wiper ❻ according to the
thickness of the material sewn.
1) Turn the handwheel in the normal direction of rota-
tion to align white marker dot ❶ on the handwheel
with marker dot ❷ on the machine arm.
2) Adjust so that a clearance of 1 mm is provided
between the at section of the wiper and the side
face of the needle. Tighten wiper adjust screw ❸
so that the wiper ❻ is pressed and xed by wiper
collar ❹.
* When there is no need to use the wiper, set the wiper operation OFF according to the following procedure.
This setting can be made while the power is being turned ON. (One touch setting function.)
1) Keep pushing switch ❺ for 2 seconds. The display
will change to the function setting mode.
2) Change the setting No. Eto using switch ❼
or switch ❽.
3) Change the setting of F from “ ” to “ ” using
switch ❾ or switch 󱢳.
4) In order to return to normal sewing state, push
switch ❺.
(Caution) When switch ❺ is pushed, the setting
made will be conrmed.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
