Jung FMST50UP User manual

eNet radio push-button controller 1-10 V 1-gang mini
eNet radio push-button controller 1-10 V 1-gang mini
Art. No. : FMST50UP
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled
persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the devise or
load. In so doing, take all the circuit breakers into account, which support dangerous
voltages to the device and or load.
Danger of electric shock. Device is not suitable for disconnection from supply voltage.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Device components
Figure 1: Device components
(1) Operating mode switch
(2) Button Prog
(3) Status LED
(4) Measuring points for voltage measurement, terminals rear-mounted
3 Function
Intended use
- Switching and brightness setting of luminaires with 1-10 V interface
- Operation with suitable radio transmitters
- Mounting in appliance box according to DIN 49073 in combination with a suitable cover
- Installation in surface-mounted housing or panel-mounted housing (accessories) for
suspended ceilings
Product characteristics
- Switch-on brightness can be saved permanently
- Minimum brightness can be saved permanently
1/12
82581023
J0082581023 29.03.2017

- Scene operation possible
- Status indicator of the 1-10 V subscribers via LED
- Status feedback to radio transmitter
- 1-10 V subscribers switchable with Prog button
- 1-10 V interface is protected against reverse polarity
Can be set with eNet server:
- Maximum brightness
- Dimming speed
- Switch-on delay / switch-off delay
- Dim up/dim down ramp
- Switch-off warning
- Operation locks
- Continuous on, Continuous off
- Hotel function
- Run-on time
- Light control
iIf settings are changed with the eNet server, operation and signalling could vary from what
is described here.
iThe parameter list is in the Internet in the documentation for this device.
Supplementary functions with eNet server:
- Update of the device software
- Repeater function
- Reading of error memory
Response after mains voltage return
The response after mains voltage return can be configured with the eNet Server. Default
setting: Off.
4 Operation
Operation with radio transmitters
Operation is with radio transmitters, please observe the radio transmitter instructions.
5 Information for electrically skilled persons
5.1 Fitting and electrical connection
DANGER!
Electrical shock when live parts are touched.
Electrical shocks can be fatal.
Before carrying out work on the device or load, disengage all the
corresponding circuit breakers. Cover up live parts in the working environment.
Mounting and connecting actuator
To ensure good transmission quality, keep a sufficient distance from any possible sources of
interference, e.g. metallic surfaces, microwave ovens, hi-fi and TV systems, ballasts or
transformers.
2/12
82581023
J0082581023 29.03.2017
eNet radio push-button controller 1-10 V 1-gang mini

Figure 2: Connection example
iEnsure that the control cable is of the appropriate type, cross-section and routing for the
VDE specifications for 250 V cable, control voltage has basic insulation.
iThe control cable and load cable can be run in a shared cable, e.g. NYM J 5×1.5.
oConnect actuator (5) and 1-10 V ballasts (6) as shown in the connection example
(figure 2). At the same time, note the information given by the manufacturers of the ballast.
oIf multiple circuit breakers supply dangerous voltages to the device or load, couple the
miniature circuit breakers or label them with a warning, to ensure disconnection is
guaranteed.
oInsert the actuator in the appliance box in such a way that the Prog button (2) and status-
LED (3) are visible.
Figure 3: Operating mode switch
Position Description
PC Operating mode, parameter set with eNet
server *)
G1-10 V operation
min. Setting of the minimum brightness
*) If the operating mode switch is turned from the position PC, the operating mode and
parameters are set to the default setting. The settings made with the eNet Server will be
lost.
oSet the operating mode switch (1).
3/12
82581023
J0082581023 29.03.2017
eNet radio push-button controller 1-10 V 1-gang mini

oSwitch on mains voltage.
iThe 1-10 V ballasts can be switched by briefly pressing the Prog button.
Status-LED (3) lights up: switched on
Status LED (3) off: switched off
oPerform commissioning.
oMount the cover.
5.2 Commissioning
DANGER!
Electrical shock when live parts are touched.
Electrical shocks can be fatal.
During commissioning, cover the parts carrying voltage on radio transmitters
and actuators and in their surrounding area.
iThe actuator can also be commissioned with eNet Server as an alternative to the
commissioning described here.
Connecting to radio transmitters
Load is switched off.
oPress the Prog button for longer than 4 seconds.
The status LED (4) flashes after 3 seconds. The actuator is in programming mode for
approx. 1 minute.
oSwitch radio transmitter to programming mode (see radio transmitter instructions).
oTrigger telegram on the radio transmitter.
The status LED lights up for 5 seconds.
The actuator is connected to the radio transmitter. The actuator and radio transmitter exit
the programming mode automatically.
iIf the status LED of the control unit flashes 3 times at 1-second intervals for
approx. 5 seconds, then the programming operation was not successful. All the memory
locations in the actuator or radio transmitter are occupied.
iAll On and All Off buttons of a radio transmitter are connected to the actuator automatically
as soon as the first connection to the radio transmitter takes place. Scene buttons must be
connected separately.
Disconnecting connection to a radio transmitter
oCarry out the same steps as when connecting (see Connecting to radio transmitter).
The status LED (3) flashes quickly for 5 seconds. The actuator is disconnected from the
radio transmitter. The actuator and radio transmitter exit the programming mode
automatically.
iIf there several connections or scene buttons for a radio transmitter, all connections must
be disconnected individually.
iAll On and All Off buttons of a radio transmitter are disconnected automatically as soon as
the last connection to the radio transmitter is disconnected. Manual disconnection is not
possible.
Resetting actuator to default setting
All connections to radio transmitters are disconnected and parameters are reset to default
setting.
iThe connections in the radio transmitters are preserved and must be deleted separately.
Load is switched off.
oPress the Prog button for at least 20 seconds.
The status LED flashes after 4 seconds. After 20 seconds the status LED flashes faster.
oRelease Prog button and press briefly once again within 10 seconds.
The status LED flashes more slowly for approx. 5 seconds.
4/12
82581023
J0082581023 29.03.2017
eNet radio push-button controller 1-10 V 1-gang mini

The actuator is reset to default setting.
Setting the minimum brightness
The minimum brightness can be set within a range of approx. 1...67 %, if, e.g. the light flickers
at low brightness or to compensate for differences in brightness.
oTurn operating mode switch (1) to the min. position.
oAdjust brightness with the radio transmitter.
oTurn operating mode switch to the original position again.
When leaving the position min., the minimum brightness is saved.
Save switch-on brightness
oSwitch on light.
oAdjust brightness with the radio transmitter.
oPress button Prog (2) for longer than 4 seconds.
The light switches off briefly and then switches on again to the new switch-on brightness.
Switch-on brightness is saved.
iAlternatively, the switch-on brightness can be saved with a radio transmitter, e.g. wall
transmitter.
