Jung 1701 SE User manual

LB management
Relay switch insert 1-channel
Relay switch insert 1-channel
Art. no.: 1701 SE
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the device or load. In
so doing, take all the circuit breakers into account, which support dangerous voltages to the
device and or load.
These instructions are an integral part of the product, and must remain with the end customer.
2 Intended use
– Switching of lighting and motors
– Operation with suitable cover from LB management
– Controlling of electric underfloor heating systems and electrothermal valve drives in com-
bination with a room temperature controller cover
– Mounting in appliance box according to DIN 49073
Product characteristics
– Connection of extensions possible
– Run-on times adjustable
3 Operation
These instructions describe operation with a button cover. Operation with a different cover is de-
scribed in the instructions for the cover in question. The operation on the main device and the 2-
wire extension is identical.
Switch load
￭ Press the button.
The load switches on or off.
4 Information for electrically skilled persons
DANGER!
Mortal danger of electric shock.
Disconnect the device. Cover up live parts.
1 / 4
82597433 20.05.2020
J0082597433

LB management
Relay switch insert 1-channel
Connecting and fitting the device
Figure1: Connection diagram with optional extensions
Figure2: Terminal-specific cable cross-section:
￭ Connect the switch insert (2) according to the connection diagram (Figure 1). Note clamp-
able cable cross-sections (Figure 2).
￭ Connect the 2-wire extension (3), the 3-wire extension (4) and as an option, the push-but-
ton with NO contact (5).
Lit push-buttons must have a separate N terminal.
￭ Fit the switch insert in the appliance box, the connection terminals must be at the bottom.
Do not attach or replace the cover under voltage, otherwise this might cause a malfunc-
tion.
￭ Attach the frame and the cover.
￭ Switch on mains voltage.
The load can be switched by briefly pressing the TEST button (1).
2 / 4
82597433 20.05.2020
J0082597433

LB management
Relay switch insert 1-channel
Set run-on time
For the automatic switching-off of the load, run-on times can be set, see table.
During the run-on time it cannot be restarted by pressing again.
￭ Press the TEST button (1) for more than 4 seconds.
LED lights up in the colour of the set run-on time, see table.
LED signalling
LED colour Set run-on time
green Switching without run-on time
white Run-on time: 1 minute
blue Run-on time: 5 minutes
yellow Run-on time: 30 minutes
red Run-on time: 60 minutes
￭ Release the TEST button (1) briefly and press it repeatedly until the LED lights up in the
colour of the desired run-on time.
The set run-on time is automatically saved after 30 seconds or after pressing the TEST
button (1) for approx. 4 seconds. When the LED goes out, the saving process was suc-
cessful.
Connecting and mounting the device as a room temperature controller (Figure 3)
Recommended installation height: 1.50 m.
Figure3: Connection diagram in combination with room temperature controller cover
(6) Switching contact for switching to cooling mode
(7) Electric underfloor heating (max. 16 A) or electrothermal valve drives
If 230 V is applied to extension input 1, cooling mode is active.
5 Technical data
Rated voltage AC 230 V~
3 / 4
82597433 20.05.2020
J0082597433

LB management
Relay switch insert 1-channel
Mains frequency 50 / 60 Hz
Standby load depending on the cover approx. 0.1 ... 0.5W
Switching current at 35 °C
Ohmic 16 A (AC1)
Minimum switching current AC 100 mA
Connected load
Incandescent lamps 2300 W
HV halogen lamps 2300 W
Electronic transformers 1500 W
Inductive transformers 1000 VA
HV-LED lamps typ. 400 W
Compact fl lamp. typ. 500 W
Fluorescent lamps, uncompensated 1200 VA
Switching current motors 6 A
Capacitive load 920 VA (115 μF)
Power reduction
per 5°C in excess of 35°C -5%
when installed in wooden or dry construction walls -15%
when installed in multiple combinations -20%
Ambient temperature -25 ... +45 °C
Storage/transport temperature -20 ... +70 °C
Number of extension units
2-wire, push-button unlimited
3-wire, rotary dimmer extension 10
6 Warranty
The warranty is provided in accordance with statutory requirements via the specialist trade.
ALBRECHT JUNG GMBH & CO. KG
Volmestraße 1
58579 Schalksmühle
GERMANY
Telefon: [phone]
Telefax: [phone]
[email protected]
www.jung.de
