Jungheinrich AM 22 SH User manual

Hand pallet truck
AM 22 SH / 22 NH
Lift height: 122 mm / Load capacity: 2200 kg

AM 22 SH / 22 NH

Stand-on: 08/2023
VDI table
1.1
Manufacturer
(abbreviated
description)
Jungheinrich
1.2
Manufacturer’s
type
designation
AM 22 NH AM 22 SH
1.3 Drive Manual
1.4 Operation Manual
1.5 Load capacity/
load Q kg 2200 1700 1200 500 2200 1700 1200 500 2200
1.6 Load centre
distance c mm 300 400 500 600 700 800 900 1200 500 600 400 500 600 800 900 1200 500
1.9 Wheelbase y mm 560 755 910 1110 1320 1560 1860 2360 910 1110 755 910 1110 1560 1860 2360 910
2.1 tare weight kg 50 52 56 60 61 70 82 90 59 63 52 56 60 82 90 59
3.1 Tyres C-BV
3.2 Tyre size, front Ø 170x50
3.3 Tyre size, rear Ø 82x96
3.5
Wheels,
number front/
back
(x=driven)
2/4
3.6 Tread width,
front b10 mm 109
3.7 Tread width,
rear b11 mm 370
4.4 Lift (h3) h3mm 122
4.9
Height of tiller
handle in drive
position min./
max.
mm 359 / 1237
4.14 Stand height,
elevated h12 mm 205
4.15 Height,
lowered h13 mm 83
4.19 total length l1mm 973 1168 1323 1523 1733 1973 2273 2773 1323 1523 1168 1323 1523 1973 2273 2773 1323
4.20
Length
including fork
shank
l2mm 373
4.21.1 total width b1mm 520 680 520 680
4.22 Fork
dimensions
s/
e/l mm
53
x
150
x
600
53 x
150
x
795
53 x
150
x
950
53 x
150
x
1150
53 x
150
x
1207
53 x
150
x
1360
53 x
150
x
1600
53 x
150
x
1900
53 x
150 x
2400
53 x
150
x
950
53 x
150
x
1150
53 x
150
x
795
53 x
150
x
950
53 x
150
x
1150
53 x
150
x
1600
53 x
150
x
1900
53 x
150 x
2400
53 x
150
x
950
4.25 Width across
forks b5mm 520 680 520 680
4.32
Ground
clearance
centre of
wheelbase
m2mm 30
4.34.1
Aisle width
(pallet
1000×1200
sideways)
Ast mm 1584 1734 1933 2173 2473 2973 1584 1734 1584 1734 2173 2473 2973 1584
4.34.2
Aisle width
(pallet
800x1200
length)
Ast mm 1784 1933 2173 2473 2973 1784 2173 2473 2973 1784
CharacteristicWeightsWheels/suspension systemBasic dimensions

4.35 Turning radius Wamm 724 919 1074 1274 1484 1724 2024 2524 1074 1274 919 1074 1274 1724 2024 2524 1074
5.3
Lowering
speed laden/
unladen
m/s 0.09 / 0.02
- This data sheet according to VDI guideline 2198 only states the technical values of the standard truck. Different tyres, other masts, additional equipment
etc. may result in different values.
Note. The tables do not represent all tyre variants. Not all tyre variants are available for all fork lengths.
Available tyres:
Steering wheels: N = nylon, C = rubber, V = polyurethane.
Load rollers: GN = single nylon, GV = single polyurethane, BN = tandem nylon, BV = tandem polyurethane.
Performance
data

The German production facilities in
Norderstedt, Moosburg and Landsberg
are certified as well as our Genuine Parts
Center in Kaltenkirchen.
Jungheinrich fork lift trucks meet
European safety requirements.
