Jura IMPRESSA XS95 User manual

The IMPRESSA XS95/XS90 One Touch Manual
The ‘IMPRESSA Manual’ has been awarded the seal of
approvalbytheindependentGermanTechnicalInspection
Agency, TÜV SÜD, due to its easy-to-understand style, its
thoroughness and coverage of safety aspects.

2
Important Safeguards
These safeguards apply for machines with UL safety test (see rating
plate and chapter 10, ‘Technical data’).
When using electrical appliances, basic safety precautions should
always be followed, to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:
ZRead all instructions.
ZDo not touch hot surfaces. Use handles or knobs.
ZToprotectagainstfire,electricshockandinjurytopersons,do
notimmersecord,plugs,orbodyofmachineinwaterorother
liquid.
ZClose supervision is necessary when any appliance is used by
or near children.
ZUnplug from outlet when not in use and before cleaning.
Allow to cool before putting or taking off parts, and before
cleaning the appliance.
ZDonotoperateanyappliancewitha damagedcordorplugor
aftertheappliancemalfunctions,orhasbeendamagedinany
manner. Return appliance to the nearest authorized service
facility for examination, repair or adjustment.
ZTheuseofanaccessoryattachmentnotrecommendedbythe
appliance manufacturer may result in fire, electric shock, or
injury to persons.
ZDo not use outdoors.
ZDo not let the cord hang over the edge of a table or counter,
or touch hot surfaces.
ZDo not place on or near a hot gas or electric burner, or in a
heated oven.
ZAlways attach plug to appliance first, then plug cord into the
wall outlet. To disconnect, turn any control to ‘OFF’ then
remove plug from wall outlet.
ZDo not use appliance for other than intented use.
ZUse extreme caution when dispensing hot steam.
ZFor household use only.
Follow the basic safety
precautions
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS

3
Important Safeguards
a. A short power supply cord is provided to reduce the risk
resulting from becoming entangled in or tripping over a long
cord.
Your IMPRESSA has a 3-pin grounded plug.
b. Longer extension cords are available and may be used if care
is exercised in their use.
c. If an extension cord is used,
1. themarkedelectricalratingoftheextensioncordshouldbe
at least as great as the electrical rating of the appliance,
and
2. if the appliance is of the grounded type, the extension
courd should be a grounding type 3-wire cord, and
3. the longer cord shall be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over.
ZAs a safety feature, this plug will fit in a polarized outlet only
one way.
ZIfthe plug does not fitfullyin the outlet, reverse the plug.Ifit
still does not fit, contact a qualified electrician.
ZDo not modify the plug in any way or attempt to defeat this
safety feature.
Toreducetheriskoffireorelectricshock,donotremoveanyservice
covers. No user serviceable parts inside. Repair should be done by
authorized personnel only.
This appliance is for household use. Any servicing other than clean-
ing and user maintenance should be performed by an authorized
service representative:
ZDo not immerse base in water or try to disassemble.
ZTo reduce the risk of fire or electric shock, do not remove the
base. No user serviceable parts inside. Repair should be done
by authorized service personnel only.
ZCheck voltage to be sure that the voltage indicated on the
name plate agreees with your voltage.
ZNever use warm or hot water to fill the water container! Use
cold water only.
Special cord set instructions
Warning
Caution

4
Important Safeguards
ZKeep your hands and the cord away from hot parts of the
appliance during operation.
ZNever clean with scouring powders or hard implements.
ZNever fill instant coffee, chocolate mix etc. into the grinder or
ground coffee funnel (grinder by-pass). It will damage the
functioning of the brewing chamber.
ZNever fill sugar coated coffee beans into the bean hopper. In
case of doubt, call your dealer.
ZNeverfillanything other thancoffeebeansinto the beancon-
tainer(nochocolate,norice,nonuts,nospices,nothingother
than roasted coffee beans).
ZNeverdoanythingwiththemachinewhichisnotdescribedin
the User‘s Manual. In case of doubt, call your dealer.
NEVER DO
(or you will void your
warranty protection):

5
Important Safeguards

6
Your IMPRESSA Xs95/Xs90 One Touch
IMPORTANT SAFEGUARDS 2
Control elements 8
Proper use 10
For your safety 10
The IMPRESSA XS95/XS90 One Touch Manual 12
Symbol description......................................................................................................................................12
1 IMPRESSA XS95/XS90 One Touch 13
Connector System©....................................................................................................................................14
JURA on the Internet....................................................................................................................................14
Knowledge Builder.......................................................................................................................................14
2 Preparing and using for the first time 15
Setting up......................................................................................................................................................15
Filling the water tank...................................................................................................................................15
Bean container filling...................................................................................................................................15
First-time use................................................................................................................................................16
Using and activating filter..........................................................................................................................17
Determining and adjusting the degree of water hardness..................................................................18
Adjusting grinder........................................................................................................................................20
Switching on................................................................................................................................................20
Switching off (standby)...............................................................................................................................21
3 Familiarising yourself with the control options 22
Preparation at the touch of a button.......................................................................................................22
One-off settings before and during preparation...................................................................................23
Entering a permanent setting for the amount of water for a cup size..............................................24
Permanent settings in programming mode..........................................................................................25
Viewing information and maintenance status......................................................................................27
4 Preparation at the touch of a button 28
Espresso........................................................................................................................................................28
Coffee............................................................................................................................................................28
Coffee à la Carte..........................................................................................................................................29
Cappuccino...................................................................................................................................................29
Latte macchiato............................................................................................................................................31
Pre-ground coffee.......................................................................................................................................32
Hot milk and milk foam.............................................................................................................................33
Hot water .....................................................................................................................................................35
Table of contents

7
Table of contents
5 Permanent settings in programming mode 36
Products........................................................................................................................................................36
Energy-saving mode..................................................................................................................................38
Time and weekday......................................................................................................................................39
Programmable switch-on and switch-off time......................................................................................40
Automatic switch-off...................................................................................................................................41
Rinses............................................................................................................................................................42
Unit amount of water / time format........................................................................................................43
Language......................................................................................................................................................44
6 Maintenance 45
Maintenance tips.........................................................................................................................................45
Rinsing the machine...................................................................................................................................45
Changing the filter......................................................................................................................................46
Cleaning the machine................................................................................................................................48
Descaling the machine...............................................................................................................................50
Rinsing the cappuccino frother................................................................................................................52
Cleaning the cappuccino frother..............................................................................................................53
Disassembling and rinsing the Professional Cappuccino Frother......................................................55
Disassembling and rinsing the Easy Cappuccino Frother....................................................................55
Cleaning the bean container.....................................................................................................................56
Descaling the water tank...........................................................................................................................56
7 Display messages 57
8 Troubleshooting 59
9 Transport and environmentally neutral disposal 61
Transport / Emptying the system..............................................................................................................61
Disposal..........................................................................................................................................................61
10 Technical data 62
Index 63
JURA contact details / Legal information 68

8
Control elements
Figure: IMPRESSA XS95 One Touch
Control elements
1 Bean container cover
2 Bean container with aroma preservation
cover
3 Water tank with handle
4 Power switch and power cable
(back of machine)
5 Coffee grounds container
6 Cup platform
7 Drip tray
8 Fineness of grind switch
9 Cup tray
10 Cover of filler funnel for pre-ground coffee
11 Filler funnel for pre-ground coffee
12 Connector System©
for removable frothers
13 Professional Cappuccino Frother
14 Height-adjustable coffee spout
15 Hot water spout
12
1
2
3
13
14
4
8
11
10
15
9
5
6
7

9
Control elements
Front left
1Display
2Rotary Switch cover
3f Rotary switch
Q On/off button
c Maintenance button
i 1 Espresso button
4 2 Espressi button
o 1 Coffee button
d 2 Coffees button
e Coffee à la Carte button
vPre-ground coffee button
Front right
4 öSelector switch
5 Professional Cappuccino Frother
6 Easy Cappuccino Frother
a Hot water portion symbol
m Hot water symbol
p Cappuccino button
z Milk portion symbol
n Milk symbol
qLatte Macchiato button
The Connector System©permits the use of different frothers. These are available from stockists.
2
3
4
1
5
56

10
Important information
Themachineshouldonlybeusedtopreparecoffeeandtoheatmilk
andwater.Useforanyotherpurposewillbedeemedimproper.JURA
Elektroapparate AG cannot accept any responsibility for the conse-
quences of improper use.
Before using the machine always carefully read and comply with all
these instructions. Keep this manual close to the IMPRESSA and, if
appropriate, pass it on to the next user.
Please read and note carefully the following important safety infor-
mation.
By doing this, you can avoid the life-threatening danger of electric
shock:
ZNever use a machine which has been damaged or with a
defective power cable.
ZForinformationonwhattodoincaseofdamage,forexample
ifthereisasmellofburning,unplugthemachineimmediately
from the mains supply and contact the JURA service centre.
ZIf the power cable for this machine is damaged, it must be
repairedeitherdirectlybyJURAor byaJURAapprovedservice
centre.
ZMake sure that the IMPRESSA and the power cable are not
located close to hot surfaces.
ZBecarefultoensure thatthepowercabledoesnotgetcaught
and does not rub against sharp edges.
ZNever open and repair the machine yourself. Do not modify
themachineinanywaythat isnotdescribedinthe IMPRESSA
Manual. The machine contains live parts. If opened, there is a
danger of serious injury. Repairs may only be carried out by
JURA approved service centres, using original spare parts and
accessories.
There is a risk of scalds or burns on the spouts or in the nozzle:
ZPlace the machine out of the reach of children.
ZDo not touch any hot parts. Use the handles provided.
ZBe careful to ensure that the appropriate nozzle is installed
and clean. The nozzle or parts of the nozzle might come off if
the parts are not assembled correctly or a blockage occurs.
Proper use
For your safety

11
Important information
A defective machine is not safe and could cause injury or fire. To
avoid damage and any associated risk of injury or fire:
ZNeverallowthepowercabletolooselyhangdown.Thepower
cable can be tripped over or damaged.
ZProtect your IMPRESSA from environmental influences such
as rain, frost and direct sunlight.
ZDo not put the IMPRESSA, cable or connections in water.
ZDo not put the IMPRESSA or any individual parts in the dish-
washer.
ZTurn your IMPRESSA off at the power switch before starting
any cleaning operation. Always wipe your IMPRESSA with a
damp cloth rather than a wet one, and protect it from pro-
longed water splash.
ZOnly connect the machine to a power supply in accordance
with the information on the rating plate. The rating plate is
locatedontheundersideofyourIMPRESSA.Further technical
data is given in Chapter 10 ‘Technical Data’.
ZUse only original JURA care products. Use of accessories that
are not explicitly recommended by JURA could damage the
IMPRESSA.
ZDonotuseanycoffeebeanstreatedwithadditivesorcaramel-
ised coffee beans.
ZAlways fill the water tank with cold, fresh mains water.
ZIfyouwillbeabsentforanextendedperiod,turnthemachine
off and unplug.
Risk to children and persons with limited capabilities in operating
machines:
ZThe machine is not designed to be operated by children and
persons with limited capabilities.
ZThe machine may only be used by persons who are able to
operate the machine safely.
Safe handling of the CLARIS filter cartridges:
ZFilter cartridges should be kept out of the reach of children.
ZStore filter cartridges dry in the sealed package.
ZProtect filter cartridges from heat and direct sunlight.
ZDo NOT use damaged filter cartridges.
ZDo NOT open filter cartridges.

12
The IMPRESSA XS95/XS90 One Touch Manual
You are holding the manual for your IMPRESSA XS95/XS90 One
Touch in your hand. It will help you to familiarize yourself with your
IMPRESSAsafelyandquicklyandteachyouthefullrangeoffacilities
it offers.
Chapter 2, ‘Preparing and using your IMPRESSA for the first time’,
explains step-by-step how to set up and prepare the IMPRESSA.
Chapter 3, ‘Familiarising yourself with the control options’ is impor-
tant for you to read as you are familiarising yourself with your
IMPRESSA. It invites you to actively explore all the different coffee
experiences that it offers.
Alltheotherchaptersareintendedtohelpyouwhenyouhaveaspe-
cific query.
If you use the IMPRESSA XS95/XS90 One Touch Manual, you will
become a master at preparing exciting coffee specialities, you will
be a Barista!
@ You can download the short operating instructions for your
machine from the JURA website (www.jura.com).
The IMPRESSA XS95/XS90 One Touch Manual
Symbol description
Warnings
CAUTION
AlwaystakenoteofanyinformationmarkedwiththeCAUTIONorWARNINGsymbol.
The signal word WARNING points out potential risk of serious injury, and the signal
word CAUTION potential risk of slight injury.
CAUTION The CAUTION symbol is used to draw attention to circumstances which could cause
the machine to become damaged.
Symbols used
EInformation and tips to make things easier for you as you use your IMPRESSA.
@References to the online JURA website, where you can find interesting further infor-
mation: www.jura.com.
TPrompttotakeaction. Thissymbolmeansthat youare beingpromptedtoperform
some action.

13
1 IMPRESSA XS95/XS90 One Touch
Anyone thinking of coffee today no longer only conjures up visions
of espresso and café crème, but also of contemporary coffee speci-
alitiessuchaslattemacchiatoorcappuccino.Thisdevelopmentalso
calls for a solution for small shops, offices and catering establish-
ments.AlldemandsaremorethanmetbytheIMPRESSAXS95/XS90
OneTouchwhichpreparestwelvedifferentproducts–includingthe
trend beverage latte macchiato – at the touch of a button. The cus-
tomary JURA portability is not, however, affected by this versatility,
and with its compact design and low weight of 13.8 kg the machine
can be placed just where it is needed.
ZDesign: A great deal of attention was paid to the machine
design during its development to ensure that it looks just as
good as the freshly prepared coffee specialities accentuated
by the cup lighting. Control elements such as the selector
switch with the pictograms and background lighting, the
Rotary Switch and the graphic display not only make an out-
standing visual impression, but effectively lead the way
through the simple navigation.
ZEcological intelligence: The IMPRESSA XS95/XS90 One Touch
helps you protect the environment and save your money.
With the energy-saving mode (Energy Save Mode, E.S.M.©)
the machine requires up to 60% less energy and, if required,
automatically switches to standby mode after a certain time.
Ifitisnotusedforprolongedperiods,forexampleduringhol-
idays, the machine can be simply disconnected from the
mains by means of the integrated mains switch.
ZTime management: The enjoyment of coffee specialities has
become a regular part of our everyday life. The IMPRESSA
XS95/XS90OneTouchdoesfulljusticetothisfact, andwithits
integratedtimemanagementsystemensuresthatno(coffee)
highlightisforgotten.Themachineautomaticallyswitcheson
and off at the programmed time, ensuring that your coffee is
ready when you want it – naturally only on the weekdays you
have chosen.
Coffee that fulfils your
wildest dreams
1 IMPRESSA XS95/XS90 One Touch

14
1 IMPRESSA XS95/XS90 One Touch
ZAll-round coffee solution: Together with an optionally avail-
able cup warmer, a matching milk cooler or a vending inter-
face,themachinecanbeextendedmodule-by-moduletocre-
atean all-round coffeesolutionand can also beoptimised for
self-service applications. Machine operation is then also easy
for inexperienced users, as the use of the control elements is
intuitive and the programming buttons are discreetly con-
cealed behind a hinged panel. If necessary, these can even be
blocked.
The Connector System©permits the use of different cappuccino
frothers:
ZProfessional Cappuccino Frother
UCappuccino / latte macchiato
UHot milk
ZEasy Cappuccino Frother
UCappuccino / latte macchiato
Visit us on the Internet.
@ At www.jura.com you will find interesting and up-to-date
information on your IMPRESSA and on every aspect of cof-
fee.
You can familiarize yourself with your IMPRESSA XS95/XS90 One
Touch in a fun way on the PC.
@ The Knowledge Builder awaits you at www.jura.com. The
interactive assistant, LEO, will support you and explain the
benefits of and how to use your IMPRESSA.
Connector System©
JURA on the Internet
Knowledge Builder

15
2 Preparing and using your IMPRESSA for the first time
Thischapterprovidesyouwiththeinformationyouneedtouseyour
IMPRESSA without any problems. You will prepare your IMPRESSA
step-by-step for your first coffee experience.
KeepthepackagingforyourIMPRESSA.Itshouldbeusedtoprotect
the machine during transportation.
When setting up your IMPRESSA, please note the following:
ZSet the IMPRESSA down on a horizontal surface that is not
sensitive to water.
ZChoose a spot for your IMPRESSA which is protected against
overheating. Ensure that the ventilation slots are not covered.
To enjoy perfect coffee we recommend changing the water every
day.
Milk, mineral water or other liquids can damage the water tank or
the machine.
TOnly fill the water tank with fresh, cold water.
TRemove the water tank and rinse it with cold water.
TFill the water tank with fresh, cold water and reinsert.
Thebeancontainerhasanaromapreservationcover.Thiswillensure
that your coffee beans retain their aroma for longer.
Coffee beans which have been treated with additives (e.g. sugar),
pre-ground or freeze-dried coffee will damage the grinder.
TOnly use untreated coffee beans to refill the bean container.
TOpenthecoverofthebeancontainerandremovethearoma
preservation cover.
TRemove any dirt or foreign objects inside the bean con-
tainer.
TFill the bean container with coffee beans, then close the
aroma preservation cover and the bean container cover.
2 Preparing and using for the first time
Setting up
Filling the water tank
CAUTION
Bean container filling
CAUTION

16
2 Preparing and using your IMPRESSA for the first time
If the machine is operated with a defective power cable, there is a
danger of electric shock.
TNever use a machine which has a defective power cable.
Precondition: The water tank and bean container are full.
TInsert the mains plug into a power socket.
3 T SwitchontheIMPRESSAusingthepowerswitchontheback
of the machine.
The on/off button Qlights up (standby).
Q T Press the on/off button to switch the IMPRESSA on.
The pre-set language appears on the display.
TOpen the cover of the Rotary Switch.
g T Turn the Rotary Switch until the desired language is dis-
played. For Example: LANGUAGE ENGLISH
k T Press the Rotary Switch to confirm the language.
CONFIRMED √ appears briefly on the display to confirm
the setting.
TIME --:--
g T Turn the Rotary Switch to set the hour.
TIME 12:00 (Example)
k T Press the Rotary Switch to confirm the hour setting.
TIME 12:00
g T Turn the Rotary Switch to set the minutes.
TIME 12:45 (Example)
k T Press the Rotary Switch to confirm the minute setting.
CONFIRMED √ appears briefly on the display.
WEEKDAY MONDAY
g T Turn the Rotary Switch to set the weekday.
WEEKDAY WEDNESDAY (Example)
k T Press the Rotary Switch to confirm the setting.
CONFIRMED √ appears briefly on the display.
FILL SYSTEM / PRESS RINSE, the maintenance
button clights up.
First-time use
WARNING

17
2 Preparing and using your IMPRESSA for the first time
TPlace a receptacle under the hot water spout and another
under the frother.
c T Press the maintenance button.
SYSTEM FILLS, the system fills up with water and the
maintenance button flashes. A small amount of water flows
from the frother and the hot water spout.
This operation stops automatically. WELCOME TO JURA
appears on the display.
HEATING UP
PRESS RINSE, the maintenance button clights up.
TPlace a receptacle under the coffee spout.
c T Press the maintenance button.
The machine rinses itself, stopping automatically.
COFFEE READY appears on the display. Your IMPRESSA
is ready to use.
EAfter first-timeusedo not disconnect theIMPRESSA from the
power supply for 24 hours to ensure that it is in the optimum
operating condition.
EWhen a coffee speciality has been prepared for the first time,
it is possible that FILL BEANS is shown on the display as
the grinder has not yet been completely filled with coffee
beans. In this case prepare a different coffee speciality.
EIfyouhavenotbeenabletousethemachineforthefirsttime
correctly and fully, contact customer support in your country
(see Chapter ‘JURA contact details / Legal information’).
YourIMPRESSAnolongerhastobedescaledifyouareusingCLARIS
filter cartridges.
@ You can also tryout the ‘Usingandactivatingfilter’ operation
online. Visit the Knowledge Builder at www.jura.com.
EPerformthe‘Insertandactivatefilter’operationwithoutinter-
ruptions. This will ensure that your IMPRESSA always pro-
duces its best.
Precondition: COFFEE READY is displayed.
TOpen the cover of the Rotary Switch.
k T Keep the Rotary Switch pressed until MAINTENANCE
appears on the display.
Using and
activating filter

18
2 Preparing and using your IMPRESSA for the first time
g T Turn the Rotary Switch until FILTER NO is displayed.
k T Press the Rotary Switch to enter the programme item.
FILTER NO
g T Turn the Rotary Switch until FILTER YES is displayed.
k T Press the Rotary Switch to confirm the setting.
CONFIRMED w appears briefly on the display to confirm
the setting.
INSERT FILTER / PRESS RINSE, the maintenance
button clights up.
TRemove a CLARIS filter cartridge and the filter cartridge
extension from the Welcome Pack.
TFit the extension on top of the filter cartridge.
TRemove the water tank and empty it.
TLift the cartridge holder and insert the filter cartridge into
the water tank, applying slight pressure.
TClose the cartridge holder. It will click into place audibly.
TFill the water tank with fresh, cold water and reinsert.
TPlace a receptacle (at least 500 ml) under the frother.
EIfyouare using the Professional CappuccinoFrother, set the
selection lever of the frother to the steam position n.
c T Press the maintenance button.
FILTER RINSING, water flows out of the frother.
EYou can interrupt rinsing of the filter at any time by pressing
any button.
EThe water may be slightly discoloured. This is not harmful to
health and does not affect the taste.
Filter rinsing stops automatically after approx. 500 ml.
COFFEE READY appearsonthedisplay.Thefilteris now
activated.
Theharderthewateris,themorefrequentlytheIMPRESSAneedsto
be descaled. It is therefore important to adjust the water hardness.
Determining and
adjusting the degree
of water hardness

19
2 Preparing and using your IMPRESSA for the first time
The water hardness can be adjusted on a continuous scale between
1° dH and 30° dH. This can also be deactivated, which means that
the IMPRESSA will not let you know when it has to be descaled.
EHowever, if you are using the CLARIS filter cartridge and have
activated it, you will not be able to adjust the water hard-
ness.
You can find out what the water hardness is by using the Aquadur®
test strip supplied as standard.
THold the test strip briefly (for one second) under flowing
water. Shake off the water.
TWait for about one minute.
TYou will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
You can now adjust the water hardness.
Example: To change the water hardness from 16°dH to 25°dH,
proceed as follows:
Precondition: COFFEE READY is displayed.
TOpen the cover of the Rotary Switch.
k T Keep the Rotary Switch pressed until MAINTENANCE
appears.
g T Turn the rotary switch until HARDNESS 16°dH is
displayed.
k T Press the Rotary Switch to enter the programme item.
16°dH
g T Turn the Rotary Switch until 25°dH is displayed.
k T Press the Rotary Switch to confirm the setting.
CONFIRMED w appears briefly on the display.
HARDNESS 25°dH
g T Turn the Rotary Switch until EXIT is displayed.
k T Press the Rotary Switch to exit programming mode.
COFFEE READY is shown on the display.

20
2 Preparing and using your IMPRESSA for the first time
You can adjust the grinder continuously to suit the roast of your
coffee.
Ifyouadjustthefinenessofgrindwhenthegrinderisnotoperating,
the grinding wheel could be damaged.
TOnly adjust the fineness of grind when the grinder is run-
ning.
The fineness of grind setting is correct if the coffee flows regularly
from the coffee spout. A fine, thick crema is also formed.
Our recommendations:
ZSelect a fine setting for a light roast.
UIf the fineness of grind setting is too fine, the coffee only
drips from the coffee spout.
ZSelect a coarse setting for a darker roast.
UIf the fineness of grind is too coarse, the coffee flows too
quickly from the coffee spout.
Example:Tochangethefinenessofgrindduringcoffeepreparation,
proceed as follows:
TOpen the cover of the bean container.
TPlace a cup under the coffee spout.
o T Press the 1 Coffee button.
The grinder starts and 1 COFFEE is displayed.
TTurn the fineness of grind switch to the desired position
while the grinder is running.
The coffee will be prepared and the fineness of grind is
adjusted.
WhentheIMPRESSAisswitchedon,apromptfortherinseoperation
automatically appears which is initiated by pressing the mainte-
nance button.
Adjusting grinder
CAUTION
Switching on
