2ENGLISH
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and
to obtain the best possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1.CLASS 1 LASER PRODUCT
2.CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3.CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4.REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
[European Union only]
Warning:
If you need to operate the unit while driving,
be sure to look around carefully or you may be
involved in a traffic accident.
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• Stop the car before performing any
complicated operations.
Temperature inside the car...
If you have parked the car for a long time in
hot or cold weather, wait until the temperature
in the car becomes normal before operating
the unit.
How to read this manual
The following icons/symbols are used to
indicate:
Press and hold the button(s)
until the desired operation
begins.
Turn the control dial.
Turn the control dial
to make a selection,
then press to confirm.
( XX) Reference page number
<XXXX> Menu setting item
Continued on the next page
[Hold]
EN02-09_KD-R516_001A_1.indd 2EN02-09_KD-R516_001A_1.indd 2 11/4/09 12:52:15 PM11/4/09 12:52:15 PM

3ENGLISH
CONTENTS
2 How to read this manual
3 How to attach/detach the control
panel
3 How to reset your unit
3 How to forcibly eject a disc
4 Canceling the display
demonstration
4 Setting the clock
5 Preparing the remote controller
(RM-RK50)
6 Basic operations
7 Listening to the radio
9 Listening to a disc
10 Listening to the USB device
11 Listening to the other external
components
12 Selecting a preset sound mode
13 Menu operations
18 Maintenance
19 More about this unit
21 Troubleshooting
24 Specifications
How to attach/detach the control
panel
How to reset your unit
Your preset adjustments
will also be erased.
How to forcibly eject a disc
• You can forcibly eject the loaded disc even
if the disc is locked. To lock/unlock the disc,
9.
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
[Hold]
EN02-09_KD-R516_001A_1.indd 3EN02-09_KD-R516_001A_1.indd 3 11/4/09 12:52:16 PM11/4/09 12:52:16 PM

4ENGLISH
1 Turn on the power.
2
3
Setting the clock
1 Turn on the power.
2
3 Select <CLOCK>.
4 Select <CLOCK SET>.
5 Adjust the hour.
6 Adjust the minute.
7 Finish the procedure.
4 Select <DEMO OFF>.
5
6 Finish the procedure.
Canceling the display demonstration
(Initial setting)
[Hold]
(Initial setting)
[Hold]
EN02-09_KD-R516_001A_1.indd 4EN02-09_KD-R516_001A_1.indd 4 11/4/09 12:52:16 PM11/4/09 12:52:16 PM

5ENGLISH
Warning (to prevent accidents and
damage):
• Do not install any battery other than CR2025
or its equivalent.
• Do not leave the remote controller in a place
(such as dashboards) exposed to direct
sunlight for a long time.
• Store the battery in a place where children
cannot reach.
• Do not recharge, short, disassemble, heat the
battery, or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
• Do not poke the battery with tweezers or
similar tools.
• Wrap the battery with tape and insulate when
throwing away or saving it.
This unit is equipped with the steering wheel
remote control function.
Before operating, connect an exclusive remote
adapter (not supplied) which matches your car
to the steering wheel remote input terminal on
the rear of the unit.
• For details, refer also to the instructions
supplied with the remote adapter.
Preparing the remote controller (RM-RK50)
When you use the remote controller for the first
time, pull out the insulation sheet.
If the effectiveness of the remote controller
decreases, replace the battery.
Replacing the lithium coin battery
CR2025
Caution:
• Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
• Battery shall not be exposed to excessive heat
such as sunshine, fire, or the like.
Insulation sheet
EN02-09_KD-R516_001A_1.indd 5EN02-09_KD-R516_001A_1.indd 5 11/4/09 12:52:17 PM11/4/09 12:52:17 PM

6ENGLISH
Basic operations
Control dial
Ejects the disc Loading slot USB (Universal Serial Bus) input jack Display window
Auxiliary
input jack
Detaches the panel
When you press or hold the following button(s)...
Main unit Remote
controller General operation
Turns on.
• When the power is on, pressing /I/ATT on the remote controller
also mutes the sound or pauses. Press /I/ATT again to cancel
muting or resume playback.
Turns off if pressed and held.
Selects the available sources (if the power is turned on).
• If the source is ready, playback also starts.
Adjusts the volume level.
— Selects items.
—
• Mutes the sound while listening to a source. If the source is “CD”
or “USB,” playback pauses. Press the control dial again to cancel
muting or resume playback.
• Confirms selection.
Selects the sound mode.
• Enters tone level adjustment directly ( 12) if pressed and held
EQ/BASS-TRE on the main unit.
Remote sensor
• DO NOT expose to bright sunlight.
EN02-09_KD-R516_001A_3.indd 6EN02-09_KD-R516_001A_3.indd 6 11/25/09 9:07:40 AM11/25/09 9:07:40 AM

7ENGLISH
Manual search
“M” flashes, then press
the button repeatedly.
When an FM stereo broadcast is
hard to receive
1
2
] <TUNER> ] <MONO> ]
<MONO ON>
Reception improves, but stereo effect
will be lost.
To restore the stereo effect, repeat the same
procedure to select <MONO OFF>.
Automatic presetting (FM)—
SSM (Strong-station Sequential Memory)
You can preset up to 18 stations for FM.
While listening to a station...
1
2
] <TUNER> ] <SSM> ]
<SSM 01 – 06> / <SSM 07 – 12> /
<SSM 13 – 18>
“SSM” flashes and local stations with
the strongest signals are searched and
stored automatically.
To preset another 6 stations, repeat the above
procedure by selecting one of the other 6 SSM
setting ranges.
Main unit Remote
controller General operation
—• Enters <COLOR> setting directly ( 16).
• Enters <COLOR SETUP> setting directly ( 17) if pressed and held.
— Returns to the previous menu.
—Power off : Checks the current clock time.
Power on : Changes the display information.
[Hold]
[Hold]
[Hold]
Listening to the radio
~
] “FM” or “AM”
Ÿ
“ST” lights up when receiving an FM stereo broadcast
with sufficient signal strength.
EN02-09_KD-R516_001A_1.indd 7EN02-09_KD-R516_001A_1.indd 7 11/4/09 12:52:18 PM11/4/09 12:52:18 PM

8ENGLISH
Manual presetting (FM/AM)
You can preset up to 18 stations for FM and 6
stations for AM.
Ex.: Storing FM station of 92.50 MHz into preset
number “04.”
1
] “92.50MHz”
2
“PRESET MODE” flashes.
3
] Selects preset number “04.”
“P04” flashes and “MEMORY” appears.
Selecting a preset station
or
1
2
Changing the display information
Station name * = Frequency =
Clock = (back to the beginning)
* If no title is assigned to a station, “NO NAME”
appears for a few seconds.
Using the remote controller
5 U / D ∞ : Changes the preset
stations
2 R / F 3 : Searches for stations
[Hold]
Title assignment
You can assign titles up to 30 station
frequencies (FM and AM) using 8 characters
(maximum) for each title.
• If you try to assign titles to more than 30
station frequencies, “NAME FULL” appears.
Delete unwanted titles before assignment.
1
] “FM” or “AM”
2
] Show the title entry screen.
3
] Select a character.
4
] Move to the next (or previous)
character position.
5Repeat steps 3and 4until you have
finished entering the title.
6
To erase the entire title, press and hold DISP
after step 2, then press the control dial.
Available characters
ABCDEFGH I
JKLMNOPQR
STUVWXYZ0
123456789
—/ <> Space
[Hold]
EN02-09_KD-R516_001A_3.indd 8EN02-09_KD-R516_001A_3.indd 8 11/25/09 9:08:41 AM11/25/09 9:08:41 AM

9ENGLISH
Caution on volume setting:
Discs produce very little noise compared
with other sources. Lower the volume before
playing a disc to avoid damaging the speakers
by the sudden increase of the output level.
Stopping playback and ejecting
the disc
“NO DISC” appears.
Press / SOURCE to listen to
another playback source.
Prohibiting disc ejection
To cancel the prohibition, repeat the same
procedure.
Selects folder of the MP3/WMA
Selects track
Fast-forwards or
reverses the track
Selecting a track/folder
For MP3/WMA discs, select the desired folder,
then the desired track by repeating the control
dial procedures.
• To return to the previous menu, press BACK .
Selecting the playback modes
You can use only one of the following playback
modes at a time.
1
2
] “REPEAT” j “RANDOM”
3
REPEAT
TRACK RPT : Repeats current track
FOLDER RPT : Repeats current folder
RANDOM
FOLDER RND : Randomly plays all tracks
of current folder, then
tracks of next folders
ALL RND : Randomly plays all tracks
To cancel repeat play or random play, select
“RPT OFF” or “RND OFF.”
Listening to a disc
~
] Turn on the power.
Ÿ
All tracks will be played repeatedly until you change
the source or eject the disc.
[Hold]
[Hold]
[Hold]
EN02-09_KD-R516_001A_1.indd 9EN02-09_KD-R516_001A_1.indd 9 11/4/09 12:52:18 PM11/4/09 12:52:18 PM

10 ENGLISH
Listening to the USB device
This unit can play MP3/WMA tracks stored in a USB device.
~
] Turn on the power.
Ÿ
All tracks will be played repeatedly until you change the
source or detach the USB device.
Caution on volume setting:
USB devices produce very little noise compared
with other sources. Lower the volume before
playing a USB to avoid damaging the speakers
by sudden increase of the output level.
If you have turned off the power (without
detaching the USB device)...
Pressing /SOURCE turns on the power and
playback starts from where it has been stopped
previously.
• If a different USB device is currently attached,
playback starts from the beginning.
USB input jack
USB memory
Changing the display information
Disc title/Album name/performer (folder
name)* = Track title (file name)* = Current
track number with the elapsed playing time
= Current track number with the clock
time
= (back to the beginning)
* If the current disc is an audio CD, “NO NAME”
appears.
If an MP3/WMA file does not have Tag
information or <TAG DISPLAY> is set to
<TAG OFF> ( 13), folder name and file name
appear.
Using the remote controller
5 U / D ∞ : Selects folder of the
MP3/WMA
2 R / F 3 : Selects track
2 R / F 3
[Hold]
: Fast-forwards or
reverses the track
Stop playing and detaching the
USB device
Straightly pull it out from the unit.
“NO USB” appears. Press /SOURCE to listen to
another playback source.
You can operate the USB device in the same
way you operate the files on a disc. ( 9)
EN10-17_KD-R516_001A_3.indd 10EN10-17_KD-R516_001A_3.indd 10 11/25/09 9:09:49 AM11/25/09 9:09:49 AM

11ENGLISH
Cautions:
• Avoid using the USB device if it might hinder
your safety driving.
• Do not pull out and attach the USB device
repeatedly while “READING” is shown on the
display.
• Do not start the car engine if a USB device is
connected.
• This unit may not be able to play the files
depending on the type of USB device.
• Operation and power supply may not work as
intended for some USB devices.
• You cannot connect a computer to the USB
input terminal of the unit.
• Make sure all important data has been backed
up to avoid losing the data.
• Do not leave a USB device in the car, expose
to direct sunlight, or high temperature to
avoid deformation or cause damages to the
device.
• Some USB devices may not work immediately
after attaching USB device or turn on the
power.
• For more details about USB operations,
20, 21.
~
] “AUX IN”
ŸTurn on the connected component
and start playing the source.
!
] Adjust the volume.
⁄Adjust the sound as you
want. ( 12)
Connecting an external component to the AUX input jack
3.5 mm stereo mini plug
(not supplied)
Portable audio player,
etc.
Listening to the other external
components
You can connect an external component to the
AUX (auxiliary) input jack on the control panel.
Preparation: Make sure <AUX ON> is selected
for the <SRC SELECT> = <AUX IN> setting.
( 15)
• For details, refer also to the instructions
supplied with the adapter or external
components.
EN10-17_KD-R516_001A_1.indd 11EN10-17_KD-R516_001A_1.indd 11 11/4/09 12:51:30 PM11/4/09 12:51:30 PM

12 ENGLISH
Selecting a preset sound mode
You can select a preset sound mode suitable
for the music genre.
FLAT = NATURAL = DYNAMIC = VOCAL
BOOST
= BASS BOOST = USER = (back to
the beginning)
While listening, you can adjust the tone level of
the selected sound mode.
1
2
Adjust the level (–06 to +06) of the
selected tone (BASS / MID / TRE).
The sound mode is automatically stored
and changed to “USER.”
Tone Sound element
Frequency Level Q
BASS 60 Hz
80 Hz
100 Hz
200 Hz
–06 to +06 Q1.0
Q1.25
Q1.5
Q2.0
MIDDLE 0.5 kHz
1.0 kHz
1.5 kHz
2.5 kHz
–06 to +06 Q0.75
Q1.0
Q1.25
TREBLE 10.0 kHz
12.5 kHz
15.0 kHz
17.5 kHz
–06 to +06 Q FIX
Storing your own sound mode
You can store your own adjustments in
memory.
1
2
] <PRO EQ> ] <BASS> / <MIDDLE> /
<TREBLE>
3
Adjust the sound elements of the
selected tone. ( table on the left)
4Repeat steps 2and 3to adjust other
tones.
The adjustments made will be stored
automatically in “USER.”
The current sound mode changes to “USER”
automatically.
[Hold]
[Hold]
EN10-17_KD-R516_001A_1.indd 12EN10-17_KD-R516_001A_1.indd 12 11/4/09 12:51:31 PM11/4/09 12:51:31 PM

13ENGLISH
Menu operations
1 2 3 Repeat step 2if necessary.
• To return to the previous menu,
press BACK .
• To exit from the menu, press DISP
or MENU .
Category Menu item Selectable setting, [Initial: Underlined]
DEMO
DEMO
Display
demonstration
• DEMO ON
• DEMO OFF
: Display demonstration will be activated
automatically if no operation is done for about
20 seconds.
: Cancels. ( 4)
CLOCK
CLOCK SET
Clock setting
—
[1:00]
: Adjust the hour, then the minute. ( 4)
PRO EQ
BASS —: For settings, 12.
MIDDLE
TREBLE
DISPLAY
DIMMER • DIMMER ON
• DIMMER OFF
: Dims the display and button illumination.
: Cancels.
SCROLL *1• SCROLL ONCE
• SCROLL AUTO
• SCROLL OFF
: Scrolls the displayed information once.
: Repeats scrolling (at 5-second intervals).
: Cancels.
Pressing
DISP for more than one second can scroll the display
regardless of the setting.
TAG DISPLAY • TAG ON
• TAG OFF
: Shows the Tag information while playing MP3/
WMA tracks.
: Cancels.
TUNER
SSM *2
Strong-station
Sequential
Memory
• SSM 01 – 06
• SSM 07 – 12
• SSM 13 – 18
: For settings, 7.
MONO *2
Monaural mode
• MONO ON
• MONO OFF
: Activate monaural mode to improve FM
reception, but stereo effect will be lost. ( 7)
: Restore the stereo effect.
*1Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*2Displayed only when the source is “FM.”
[Hold]
EN10-17_KD-R516_001A_1.indd 13EN10-17_KD-R516_001A_1.indd 13 11/4/09 12:51:31 PM11/4/09 12:51:31 PM

14 ENGLISH
Category Menu item Selectable setting, [Initial: Underlined]
TUNER
IF BAND
Intermediate
frequency band
• AUTO
• WIDE
: Increases the tuner selectivity to reduce
interference noises between adjacent stations.
(Stereo effect may be lost.)
: Subject to interference noises from adjacent
stations, but sound quality will not be
degraded and the stereo effect will remain.
COLOR
BUTTON ZONE COLOR 01 —
COLOR 29, USER
: For settings, 16.
DISP ZONE
Display zone
ALL ZONE
COLOR SETUP
DAY COLOR • BUTTON ZONE
• DISP ZONE
: For settings, 17.
NIGHT COLOR
MENU COLOR • ON
• OFF
: Changes the display and buttons (except for
EQ/BASS-TRE / DISP ) illumination during menu,
list search and playback mode operations.
: Cancels.
AUDIO
FADER *3R06 – F06
[00]
: Adjust the front and rear speaker output
balance.
BALANCE *4L06 – R06
[00]
: Adjust the left and right speaker output
balance.
LOUD
Loudness
• LOUD ON
• LOUD OFF
: Boost low and high frequencies to produce a
well-balanced sound at a low volume level.
: Cancels.
VOL ADJUST
Volume adjust
VOL ADJ –05 —
VOL ADJ +05
[VOL ADJ 00]
: Preset the volume adjustment level of
each source (except FM), compared to the
FM volume level. The volume level will
automatically increase or decrease when you
change the source.
• Before making an adjustment, select the
source you want to adjust.
• “VOL ADJ FIX” appears on the display if “FM”
is selected as the source.
*3If you are using a two-speaker system, set the fader level to “00.”
*4This adjustment will not affect the subwoofer output.
EN10-17_KD-R516_001A_2.indd 14EN10-17_KD-R516_001A_2.indd 14 11/9/09 4:44:44 PM11/9/09 4:44:44 PM

15ENGLISH
Category Menu item Selectable setting, [Initial: Underlined]
AUDIO
L/O MODE
Line output
mode
• SUB.W
• REAR
: Select if the REAR LINE OUT terminals are
used for connecting a subwoofer (through
an external amplifier).
: Select if the REAR LINE OUT terminals are
used for connecting the speakers (through
an external amplifier).
SUB.W FREQ *5
Subwoofer cutoff
frequency
• LOW
• MID
• HIGH
: Frequencies lower than 72 Hz are sent to the
subwoofer.
: Frequencies lower than 111 Hz are sent to
the subwoofer.
: Frequencies lower than 157 Hz are sent to
the subwoofer.
SUB.W LEVEL *5
Subwoofer level
SUB.W 00 —
SUB.W 08
[SUB.W 04]
: Adjust the subwoofer output level.
BEEP
Keytouch tone
• BEEP ON
• BEEP OFF
: Activates the keypress tone.
: Deactivates the keypress tone.
AMP GAIN *6
Amplifier gain
control
• LOW POWER
• HIGH POWER
: VOLUME 00 – VOLUME 30 (Select if the
maximum power of each speaker is less than
50 W to prevent damaging the speakers.)
: VOLUME 00 – VOLUME 50
SRC SELECT
AM *7
AM station
• AM ON
• AM OFF
: Enable “AM” in source selection.
: Disable “AM” in source selection.
AUX IN *8
Auxiliary input
• AUX ON
• AUX OFF
: Enable “AUX IN” in source selection.
: Disable “AUX IN” in source selection.
*5Displayed only when <L/O MODE> is set to <SUB.W>.
*6The volume level automatically changes to “VOLUME 30” if you change to <LOW POWER> with the
volume level set higher than “VOLUME 30.”
*7Displayed only when any source other than “AM” is selected.
*8Displayed only when any source other than “AUX IN“ is selected.
EN10-17_KD-R516_001A_1.indd 15EN10-17_KD-R516_001A_1.indd 15 11/4/09 12:51:31 PM11/4/09 12:51:31 PM

16 ENGLISH
Selecting the variable buttons and display color illumination
You can select your preferred color for buttons illumination (except for EQ/BASS-TRE / DISP ) and
display color separately.
1or
2
] <COLOR> ] <BUTTON ZONE> /
<DISP ZONE> / <ALL ZONE>
• Pressing COLOR in step 1will enter
zone selection menu (BUTTON ZONE /
DISP ZONE / ALL ZONE) directly.
3
] Select your preferred color from one
of the 29 preset colors or <USER> color.
Button zone
All zone
Display zone
[Hold] 4Repeat steps 2and 3to select a
different zone and your preferred color.
• If <ALL ZONE> is selected in step 2,
the buttons and display illumination
changed to the current/selected
<BUTTON ZONE> color.
You can also change the <ALL ZONE>
color to one of your preferred color by
performing step 3.
5or
] Exit from the setting.
EN10-17_KD-R516_001A_4.indd 16EN10-17_KD-R516_001A_4.indd 16 12/2/09 12:20:42 PM12/2/09 12:20:42 PM

17ENGLISH
1or
2
] <COLOR SETUP> ] <DAY COLOR>
] <BUTTON ZONE>
• Pressing COLOR in step 1will enter
zone selection menu (BUTTON ZONE /
DISP ZONE) directly.
3
] Select a primary color.
RED j GREEN j BLUE j (back to
the beginning)
[Hold] 4
] Adjust the level of the selected
primary color.
00 to 31
5Repeat steps 3and 4to adjust other
primary colors.
6or
] Exit from the setting.
If “00” is selected for all the primary colors (as
in step 4) for <DISP ZONE>, nothing appear on
the display.
Creating your own day and night colors—USER
You can create your own colors for <DAY COLOR> and <NIGHT COLOR> to apply to button zone
and display zone.
• <DAY COLOR> Displayed when <DIMMER> is set to <DIMMER OFF>.
• <NIGHT COLOR> Displayed when <DIMMER> is set to <DIMMER ON>.
Menu hierarchy Operation
COLOR
SETUP
DAY
COLOR
• BUTTON
ZONE
Follow example below.
• DISP ZONE Press
BACK after step 5, then select DISP ZONE in step 2.
NIGHT
COLOR
• BUTTON
ZONE
Press
BACK after step 5, then select NIGHT COLOR in
step 2.
• DISP ZONE
Ex.: Creating <USER> color for <BUTTON ZONE> in <DAY COLOR>.
[Hold]
EN10-17_KD-R516_001A_1.indd 17EN10-17_KD-R516_001A_1.indd 17 11/4/09 12:51:32 PM11/4/09 12:51:32 PM

18 ENGLISH
To keep discs clean
A dirty disc may not play
correctly. If a disc does become
dirty, wipe it with a soft cloth
in a straight line from center to
edge.
• Do not use any solvents (for example,
conventional record cleaner, spray, thinner,
benzine, etc.) to clean discs.
To play new discs
New discs may have some
rough spots around the inner
and outer edges. If such a disc
is used, this unit may reject the
disc.
To remove these rough spots, rub the edges
with a pencil or ball-point pen, etc.
Do not use the following discs:
Single CD (8 cm disc) Warped disc
Sticker and sticker
residue Stick-on label
Unusual shape
C-thru Disc
(semitransparent
disc)
Transparent or
semitransparent
parts on its recording
area
Maintenance
How to clean the connectors
Frequent detachment will deteriorate the
connectors.
To minimize this possibility, periodically wipe
the connectors with a cotton swab or cloth
moistened with alcohol, being careful not to
damage the connectors.
Moisture condensation
Moisture may condense on the lens inside the
unit in the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
Should this occur, the unit may malfunction.
In this case, eject the disc and leave the unit
turned on for a few hours until the moisture
has evaporated.
How to handle discs
When removing a disc
from its case, press down
the center holder of the case
and lift the disc out, holding
it by the edges.
• Always hold the disc by the edges. Do not
touch its recording surface.
When storing a disc in its case, gently insert
the disc around the center holder (with the
printed surface facing up).
• Make sure to store discs in cases after use.
Connectors
Center holder
EN18-25_KD-R516_001A_1.indd 18EN18-25_KD-R516_001A_1.indd 18 11/4/09 12:52:25 PM11/4/09 12:52:25 PM

19ENGLISH
More about this unit
Basic operations
General
• If you turn off the power while listening to
a track, playback will start from where it had
been stopped previously next time you turn
on the power.
• If no operation is done for about 60 seconds
after pressing
MENU button, the operation will
be canceled.
Tuner operations
Storing stations in memory
• During SSM search...
–All previously stored stations are erased and
the stations are stored anew.
–When SSM is over, the station stored in the
lowest preset number will be automatically
tuned in.
• When storing a station manually, the
previously preset station is erased when
a new station is stored in the same preset
number.
Disc/USB operations
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does not
comply with the “Compact Disc Digital Audio”
standard. Therefore, the use of Non-DVD side
of a DualDisc on this product may not be
recommended.
General
• This unit has been designed to reproduce
CDs/CD Texts, and CD-Rs (Recordable)/CD-
RWs (Rewritable) in audio CD (CD-DA), MP3
and WMA formats.
• If you change the source while listening to a
disc, playback stops. Next time you select “CD”
as the playback source, playback will start
from where it had been stopped previously.
• When a disc is inserted upside down, “PLEASE”
and “EJECT” appear alternately on the display.
Press 0 to eject the disc.
• If the ejected disc is not removed within
15 seconds, it is automatically inserted into
the loading slot again to protect it from dust.
Playback starts automatically.
• MP3 and WMA “tracks” (words “file” and “track”
are used interchangeably) are recorded in
“folders.”
• While fast-forwarding or reversing on an MP3
or WMA disc, you can only hear intermittent
sounds.
Playing a CD-R or CD-RW
• Use only “finalized” CD-Rs or CD-RWs.
• This unit can only play back files of the same
type as those detected first if a disc includes
both audio CD (CD-DA) files and MP3/WMA
files.
• This unit can play back multi-session discs;
however, unclosed sessions will be skipped
while playing.
• Some CD-Rs or CD-RWs may not play back on
this unit because of their disc characteristics,
or for the following reasons:
–Discs are dirty or scratched.
–Moisture condensation has occurred on the
lens inside the unit.
–The pickup lens inside the unit is dirty.
–The files on the CD-R/CD-RW are written
using the “Packet Write” method.
–There are improper recording conditions
(missing data, etc.) or media conditions
(stained, scratched, warped, etc.).
• CD-RWs may require a longer readout time
since the reflectance of CD-RWs is lower than
that of regular CDs.
EN18-25_KD-R516_001A_4.indd 19EN18-25_KD-R516_001A_4.indd 19 12/2/09 12:21:21 PM12/2/09 12:21:21 PM

20 ENGLISH
• Do not use the following CD-Rs or CD-RWs:
–Discs with stickers, labels, or a protective seal
stuck to the surface.
–Discs on which labels can be directly printed
by an ink jet printer.
Using these discs under high temperature
or high humidity may cause malfunctions or
damage to the unit.
Playing an MP3/WMA disc
• This unit can play back MP3/WMA files with
the extension code <.mp3> or <.wma>
(regardless of the letter case—upper/lower).
• This unit can show the names of albums,
artists (performer), and Tag (Version 1.0, 1.1,
2.2, 2.3, or 2.4) for MP3 files and for WMA files.
• This unit can display only one-byte characters.
No other characters can be correctly
displayed.
• This unit can play back MP3/WMA files
meeting the conditions below:
–Bit rate of MP3/WMA: 32 kbps — 320 kbps
–Sampling frequency of MP3:
32 kHz, 44.1 kHz, 48 kHz (for MPEG-1)
16 kHz, 22.05 kHz, 24 kHz (for MPEG-2)
–Sampling frequency of WMA:
22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz
–Disc format: ISO 9660 Level 1/Level 2,
Romeo, Joliet, Windows extension
• The maximum number of characters for
file/folder names (includes 4 extension
characters—<.mp3> or <.wma>).
– ISO 9660 Level 1: up to 12 characters
– ISO 9660 Level 2: up to 31 characters
– Romeo: up to 64 characters
– Joliet: up to 32 characters
– Windows extension: up to 64 characters
• This unit can recognize a total of 512 files, 255
folders, and 8 hierarchical levels.
• This unit can play back files recorded in VBR
(variable bit rate).
Files recorded in VBR have a discrepancy
in the elapsed time display, and do not
show the actual elapsed time. In particular,
this difference becomes noticeable after
performing the search function.
• This unit cannot play back the following files:
–MP3 files encoded in MP3i and MP3 PRO
format.
–MP3 files encoded in an inappropriate
format.
–MP3 files encoded with Layer 1/2.
–WMA files encoded in lossless, professional,
and voice format.
–WMA files which are not based upon
Windows Media® Audio.
–WMA files copy-protected with DRM.
–Files which have data such as AIFF, ATRAC3,
etc.
• The search function works but search speed is
not constant.
Playing MP3/WMA tracks from a USB
device
• While playing from a USB device, the playback
order may differ from other players.
• This unit may be unable to play back some
USB devices or some files due to their
characteristics or recording conditions.
• Depending on the shape of the USB devices
and connection ports, some USB devices may
not be attached properly or the connection
might be loose.
• Connect one USB mass storage class device to
the unit at a time. Do not use a USB hub.
• If the connected USB device does not have
the correct files, “CANNOT PLAY” appears.
• This unit can show Tag (Version 1.0, 1.1, 2.2,
2.3, or 2.4) for MP3 files and for WMA files.
• This unit can play back MP3/WMA files
meeting the conditions below:
–Bit rate of MP3/WMA: 32 kbps — 320 kbps
–Sampling frequency of MP3:
32 kHz, 44.1 kHz, 48 kHz (for MPEG-1)
16 kHz, 22.05 kHz, 24 kHz (for MPEG-2)
–Sampling frequency of WMA:
22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz
• This unit can play back MP3 files recorded in
VBR (variable bit rate).
EN18-25_KD-R516_001A_1.indd 20EN18-25_KD-R516_001A_1.indd 20 11/4/09 12:52:26 PM11/4/09 12:52:26 PM
