JVC KD-R740BT Owner's manual

Headunits
KD-R740BT
Bluetooth®Wireless Technology USB/CD Receiver with AUX
The built-in Bluetooth®Wireless Technology provides audio entertainment and full-time connection for 2 phones, as well as
the latest Siri Eyes-Free-Mode for safe driving via voice control. In addition to easy song browsing from Android™, JVC
Smart Music Control lets you use your device as a remote, complete with finger gestures and voice control. By connection to
1A USB, a USB memory stick becomes your playlist library with JVC Playlist Creator software. For Pandora, not only control, but
thumbs-up/down is also available from the headunit, via Bluetooth®for Android™/BlackBerry®, and USB for iPhone®. MOS-FET power
amp and 24-bit DAC provide quality sound. The unit also comes with front AUX input, 3-band parametric iEQ, and Radio Timer, and is
Steering Wheel Remote Ready.
Front AUX
AUDIO
MOS-FET
50W x 4
Recommended Features
Key Benefits
2-Way Control
for iPod/iPhone
iPod Headunit
Full Digital
Full Speed Charging
1.0A
Support
iPod/iPhone
USB G3
Bluetooth®
Wireless
Technology
Phone Book
Access Profile
Audio
Streaming
& Control
Radio Broadcast
Data System
2 Phones
Full-Time
Connection
MP3/WMA
External Mode
for
iPod/iPhone
(Front+Rear/Subwoofer)
2 Pre-Output
JVC Apps
for
Android
SiriusXM
Ready
Application
Control for
Smartphone
What you can do:
Via Bluetooth
• Bluetooth®Music Player
• Control from headunit
• Mood Play / Mood Blender
• Gesture Control / Voice Control
• Source Info Viewer
• SMS Read Out
• Post/Tweet Preset Messages on Facebook/Twitter
• Equalizer
• Wallpaper Change
• Control from headunit
• Title Browsing
• Mood Play
Via USB
Mood Blender: Move the ball to
change the mood and generate
playlists in tune with you.
Versatile control with
11 gesture recognition
✹JVC Smart Music Control (for Android™)*
Use your Android phone as a remote control, complete
with finger gesture operation. Let the Mood Blender
generate a playlist that matches the way you feel. And
with voice control, you can activate and access
functions just by saying what you want.
* Smartphones with Android™ 2.2 and above.
JVC Smart
Music Control
for Android™
JVC Playlist
Creator
for USB
JVC Music
Control
for Android™
Free

NTK-0929-09
KD-R740BT Bluetooth®Wireless Technology USB/CD Receiver with AUX
Dimensions (W × H × D)
Installation Size 7 3/16” × 2 1/8” × 6 5/16” 181.7 × 52.7 × 159 mm
Panel Size 7 7/16” × 2 3/8” × 9/16” 188 × 58.5 × 12.6 mm
Detachable Face Plate 6 3/4” × 1 13/16” × 7/8” 169.8 × 46.4 × 22 mm
Maximum Power Output 50W × 4
LPF (Subwoofer) off/55/85/120Hz/Through (-12dB/oct)
Line Pre-Output Terminals 2 (Front + Rear/Subwoofer Selectable)
Subwoofer Output with
Level/Frequency Control ✔
Line Output Level 2.5V
Subwoofer Output Level 2.5V
Subwoofer Gain Control -15dB – +15dB
Load Impedance 4Ω(4 - 8Ωallowable)
Line Output Impedance ; 600Ω
Key Specifications Connections
Android*
Mass Storage
Audio Streaming
AVRCP
Apps Control
iPhone
Audio Streaming
AVRCP
Apps Control
Mass Storage
Audio Streaming
AVRCP
BlackBerry®*
* Compatibility
depends on model
iPodPortable
Audio Players
AUX-IN
Front
USB Memory
USB Cable
HDD*
Rear Panel
✹Steering Wheel Remote Ready
With an optional adapter, you can control an advanced JVC
headunit from the steering wheel remote control that comes
factory standard with your car.
✹Bluetooth®Compatible Functions
In addition to hands-free calling, voice recognition dialing,
audio streaming/control, and remote control features with
your smartphone, you can transfer up to 400 contact
numbers to the headunit. With PBAP compatible cell
phones, you can access your phone book without
transferring to the headunit. Two phones can
remain connected continuously.
The features are also available for smartphones.
Hands-Free Calls
Audio Streaming
& Control
Phone Book
Access
Phone Book
Transfer
2 Phones
Full-Time Connection
✔
✔
✔
✔
✔
So Many Features!
Wired MIC
included
✹1A USB Audio for iPod/iPhone and Smartphones
Connect your iPod/iPhone or other smartphones to the unit’s 1A USB
port, and enjoy music in clear, digital sound with full-speed transfer.
Your device’s battery will be charged
during connection.
1A Support
✹Speed Dial with 6-Key Presets
Numbers stored in preset for
2 connected phones can be easily
dialed from the headunit’s 6 keys.
Maximum 30 numbers for 5 phones
can be registered.
Easy to Call
What you can do:
• Control from headunit
• Title Browsing
• Mood Play
✹JVC Original Apps/Software for Smartphone/Devices
JVC Music Control (for Android™)*
JVC Music Control is a free download app that
allows Android users to listen to favorite songs
through an iPod like browsing experience via USB
Mass Storage Mode. Browse music by Artist, Album or Song Title through the headunit.
Also generates playlists based on a particular Mood, much like a personal DJ.
* Smartphones with Android™ 2.2 and above.
JVC Playlist Creator
Use PC software (for Windows®) to create a Playlist of
tunes on USB memory which can be used in your car. USB memory
✹Easy/Pro EQ Setting (3-Band Parametric iEQ)
Adjusts the center frequency, bandwidth and levels at each of 3 bands. Plus 5 initial
and 1 user EQ presets. With Pro mode, the EQ can customize the sound for your
ears. A separate setting for the subwoofer level is also available.
Initial Presets
• DYNAMIC
• FLAT
• NATURAL
• VOCAL BOOST
• BASS BOOST
Control Range Bass: 60Hz, 80Hz, 100Hz, 200Hz
Mid-range :500Hz, 1kHz, 1.5kHz, 2.5kHz
Treble: 10kHz, 12.5kHz, 15kHz, 17.5kHz
Bass/Middle/Treble Level -6 – +6 level
Q (Band with) 0.75~2.0Q
✹Apps Control for iPod Mode
Song information display and
certain control features are
available on the headunit for some
apps, when the app is launched
during iPod Mode. iPod Mode
Speed Trap Area!
Add the buttons for
Thumbs-up/down
✹Pandora via Bluetooth®(for Android™/BlackBerry®)
Via Bluetooth®connection with your Android™/BlackBerry®device, you
can listen to as well as control the Pandora app on the headunit.
Thumbs-up/down, forward skip, pause/play, and search station/bookmark
can all be controlled with the unit’s keys.
✹Siri Eyes-Free-Mode for iPod/iPhone
This function allows access to the “Siri” voice-activated
personal assistant while keeping your hands on the steering
wheel and eyes on the road. No need to watch or touch the
iPhone screen as you play back music stored on iPhone, and make calls to registered
phone numbers via Bluetooth-equipped car receiver, with the safety of voice control.
Moreover, “Siri Eyes-Free-Mode” can be easily accessed using the Bluetooth/Voice
Button as is the case with Voice Guidance.
* Depending on the in-car environment or iPhone/iPod environment being used, there may be cases where smooth
operation is not attainable.
USB
Front
*Not compatible with NTFS format.
