JVC KW-R910BT User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ENGLISH
ESPAÑOL
FRANÇAIS
KW-R910BT
CD RECEIVER
INSTRUCTION MANUAL
RECEPTOR CON CD
MANUAL DE INSTRUCCIONES
RÉCEPTEUR CD
MANUEL D’INSTRUCTIONS
Please read all instructions carefully before
operation to obtain the best possible performance
from the unit.
Por favor lea detenidamente este manual para
comprender a fondo todas las instrucciones y
obtener un máximo disfrute de esta unidad.
Veuillez lires les instructions attentivement avant
d’utiliser l’appareil afin d’obtenir les meilleures
performances possibles de l’appareil.
For customer Use:
Enter below the Model No. and Serial No. which are
located on the top or bottom of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
GET0950-001A [J]
JS_JVC_KW_R910BT_J_01_EN.indd 1JS_JVC_KW_R910BT_J_01_EN.indd 1 6/12/2013 4:59:35 PM6/12/2013 4:59:35 PM

i
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CAUTION
Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
In compliance with Federal Regulations, following are reproductions of labels on, or inside
the product relating to laser product safety.
JVC KENWOOD Corporation
2967-3, ISHIKAWA-MACHI,
HACHIOJI-SHI, TOKYO, JAPAN
THIS PRODUCT COMPLIES WITH DHHS RULES 21CFR
SUBCHAPTER J IN EFFECT AT DATE OF MANUFACTURE.
Location : Top Plate
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications
to this equipment may cause harmful interference unless the modifications are expressly
approved in the instruction manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made.
FCC NOTE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment may
cause harmful interference to radio communications, if it is not installed and used in
accordance with the instructions. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CALIFORNIA, USA ONLY
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material—
special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate
Información acerca de la eliminación de equipos eléctricos y electrónicos al final de
la vida útil (aplicable a los países que hayan adoptado sistemas independientes de
recogida de residuos)
Los productos con el símbolo de un contenedor con ruedas tachado no
podrán ser desechados como residuos domésticos. Los equipos eléctricos y
electrónicos al final de la vida útil, deberán ser reciclados en instalaciones
que puedan dar el tratamiento adecuado a estos productos y a sus
subproductos residuales correspondientes. Póngase en contacto con su
administración local para obtener información sobre el punto de recogida
más cercano. Un tratamiento correcto del reciclaje y la eliminación de
residuos ayuda a conservar los recursos y evita al mismo tiempo efectos
perjudiciales en la salud y el medio ambiente.
Informação sobre a eliminação de pilhas
Este produto não deve ser eliminado como lixo doméstico geral. Devolva a pilha usada
ao revendedor ou entidade autorizada para que a mesma seja devolvida ao fabricante ou
importador.
A reciclagem e a eliminação de lixo de maneira apropriada ajudarão a conservar os recursos
naturais ao mesmo tempo que prevenirão os efeitos prejudicais à nossa saúde e ao meio
ambiente.
JS_JVC_KW_R910BT_J_01_EN.indd iJS_JVC_KW_R910BT_J_01_EN.indd i 6/12/2013 4:59:36 PM6/12/2013 4:59:36 PM

ii
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CAUTION
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C
to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very
low levels of RF energy that it deemed to comply without maximum permissive exposure
evaluation (MPE). But it is desirable that it should be installed and operated keeping the
radiator at least 20cm or more away from person’s body (excluding extremities: hands,
wrists, feet and ankles). Under Industry Canada regulations, this radio transmitter may
only operate using an antenna of a type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for successful communication.
ATTENTION
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées
pour un environnement non contrôlé et respecte les règles d’exposition aux fréquences
radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet une énergie RF très faible qui
est considérée conforme sans évaluation de l’exposition maximale autorisée. Cependant,
cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre
le dispositif rayonnant et le corps (à l’exception des extrémités : mains, poignets, pieds et
chevilles). Conformément à la réglementation d’Industrie Canada, le présent émetteur radio
peut fonctionner avec une antenne d’un type et d’un gain maximal (ou inférieur) approuvé
pour l’émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l’intensité nécessaire à l’établissement d’une communication satisfaisante.
• Contains Bluetooth Module FCC ID: XQN-BTR60X
• Contains Bluetooth Module IC: 9688A-BTR601
IC (Industry Canada) Notice
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
The term “IC: ” before the certification/ registration number only signifies that the Industry
Canada technical specification were met.
Note de IC (Industrie Canada)
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
L’expression “IC:” avant le numéro d’homologation/ enregistrement signifie seulement que
les specifications techniques d’Industrie Canada ont été respectées.
Para cumplimiento de la COFETEL:
“La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y
(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda
causar su operación no deseada”
JS_JVC_KW_R910BT_J_01_EN.indd iiJS_JVC_KW_R910BT_J_01_EN.indd ii 6/12/2013 4:59:36 PM6/12/2013 4:59:36 PM

2
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CONTENTS BEFORE USE
Warning
Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of
the output level.
General:
• Avoid using the USB device or iPod/iPhone if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded
data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short
circuit.
• If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to
evaporate.
Remote control (RM-RK52):
• Do not leave the remote control in hot places such as on the dashboard.
• The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or
equivalent type.
• The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
• Keep the battery out of reach of children and in its original packaging when not in used. Dispose of used
batteries promptly. If swallowed, contact a physician immediately.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
CD / USB / iPod 5
RADIO 7
AUX 8
Pandora® 9
iHeartRadio® 10
BLUETOOTH® 11
AUDIO SETTINGS 16
DISPLAY SETTINGS 18
MORE INFORMATION 19
TROUBLESHOOTING 20
SPECIFICATIONS 22
INSTALLATION /
CONNECTION 24
How to read this manual
• Operations are explained mainly
using buttons on the faceplate.
•
[XX] indicates the selected items.
•
( XX) indicates references are
available on the stated page.
Maintenance
Cleaning the unit: Wipe off dirt on the faceplate with a dry silicone or soft cloth.
Handling discs:
• Do not touch the recording surface of the disc.
• Do not stick tape etc. on the disc, or use a disc with tape stuck on it.
• Do not use any accessories for the disc.
• Clean from the center of the disc and move outward.
• Clean the disc with a dry silicone or soft cloth. Do not use any solvents.
• When removing discs from this unit, pull them out horizontally.
• Remove burrs from the center hole and disc edge before inserting a disc.
JS_JVC_KW_R910BT_J_01_EN.indd 2JS_JVC_KW_R910BT_J_01_EN.indd 2 6/12/2013 4:59:36 PM6/12/2013 4:59:36 PM

3
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Remote control (RM-RK52)
To Do this (on the faceplate) Do this (on the remote control)
Turn on the power Press B/SOURCE.
• Press and hold to turn off the power. ( not available )
Adjust the volume Turn the volume knob. Press VOL + or VOL –.
Press the volume knob to mute the sound or pause playback.
• Press again to cancel. Press to mute the sound or pause playback.
• Press again to cancel.
Select a source • Press B/SOURCE repeatedly.
• Press B/SOURCE, then turn the volume knob within 2 seconds.
Press SOURCE repeatedly.
Change the display
information
Press DISP repeatedly.
( 20)
• Press and hold to scroll the current display information. ( not available )
BASICS
How to reset
Your preset adjustments
will also be erased.
Volume knob
(turn/press)
Loading slot Display window
Faceplate
ENGLISH |
Pull out the insulation sheet
when using for the first time.
How to replace the battery
Remote sensor
(Do not expose to bright sunlight.)
JS_JVC_KW_R910BT_J_01_EN.indd 3JS_JVC_KW_R910BT_J_01_EN.indd 3 6/12/2013 4:59:36 PM6/12/2013 4:59:36 PM

4
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Cancel the demonstration
1 Press and hold MENU.
2 Turn the volume knob to select [DEMO] , then press the knob.
3 Turn the volume knob to select [DEMO OFF] , then press the knob.
4 Press MENU to exit.
Set the clock
1 Press and hold MENU.
2 Turn the volume knob to select [CLOCK] , then press the knob.
3 Turn the volume knob to select [CLOCK SET] , then press the knob.
4 Turn the volume knob to make the settings, then press the knob.
Day Hour Minute
5 Turn the volume knob to select [24H/ 12H] , then press the knob.
6 Turn the volume knob to select [12 HOUR] or [24 HOUR] , then press the
knob.
7 Press MENU to exit.
1
2
Set the basic settings
1 Press and hold MENU.
2 Turn the volume knob to make a selection (see the following table),
then press the knob.
3 Press MENU to exit.
To return to the previous setting item or hierarchy, press PTY.
Default: XX
CLOCK
CLOCK ADJ AUTO
:The clock time is automatically set using the Clock Time (CT) data in
FM Radio Broadcast Data System signal.;
OFF :Cancels.
CLOCK DISP ON :The clock time is shown on the display even when the unit is turned
off.;
OFF :Cancels.
SETTINGS
BEEP ON
:Activates the keypress tone.; OFF :Deactivates.
SRC SELECT
AM
* ON :Enables AM in source selection.; OFF :Disables.
PANDORA * ON :Enables PANDORA in source selection.; OFF :Disables.
IHEART * ON :Enables IHEARTRADIO in source selection.; OFF :Disables.
AUX * ON :Enables AUX in source selection.; OFF :Disables.
F/W UPDATE
SYSTEM / BLUETOOTH
F/W xxxx YES
:Starts upgrading the firmware.; NO :Cancels (upgrading is not
activated).
For details on how to update the firmware, see:
<http://www.jvc.net/cs/car/>.
* Not displayed when the corresponding source is selected.
3
JS_JVC_KW_R910BT_J_01_EN.indd 4JS_JVC_KW_R910BT_J_01_EN.indd 4 6/12/2013 4:59:37 PM6/12/2013 4:59:37 PM

5
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD / USB / iPod
To Do this
Select a track/file Press S/T(or press H/Ion RM-RK52).
Select a folder *3Press J/K(or press J/Kon RM-RK52).
Reverse/
Fast-forward Press and hold S/T(or press and hold H/Ion RM-RK52).
Repeat play *4Press 3Brepeatedly to make a selection.
• Audio CD or JVC Playlist Creator (JPC) / JVC Music Control (JMC) file ( 20) :
TRACKRPT, RPT OFF
• MP3/WMA/WAV file: TRACKRPT, FOLDER RPT, RPT OFF
• iPod: ONE RPT, ALL RPT, RPT OFF
Random play *4Press 2Arepeatedly to make a selection.
• Audio CD: ALL RND, RND OFF
• MP3/WMA/WAV file or JPC / JMC file: FOLDERRND, ALL RND, RND OFF
• iPod: SONG RND, ALL RND, RND OFF
*1Do not leave the cable inside the car when not using.
*2You can still play/pause, file skip, fast-forward or reverse files from the unit.
*3Only for MP3/WMA/WAV files. This does not work for iPod.
*4For iPod: Applicable under
[HEAD MODE] only.
Start playback
The source changes automatically and
playback starts.
CD
USB
iPod/iPhone
Press 5 iPod MODE repeatedly to select the
control mode (
[HEAD MODE] / [IPHONE MODE] ).
HEAD MODE : From the unit.
IPHONE MODE : From the iPod/iPhone. *2
Eject disc Label side
USB input terminal
(Accessory of the iPod/iPhone)
*1
USB input terminal
USB 2.0 cable
*1
(commercially available)
JS_JVC_KW_R910BT_J_02_EN.indd 5JS_JVC_KW_R910BT_J_02_EN.indd 5 13/12/2013 4:31:01 PM13/12/2013 4:31:01 PM

6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Select a track/file from a list
For iPod: Applicable only when [HEAD MODE] is selected. ( 5)
1 Press MENU
2 Turn the volume knob to make a selection, then press the knob.
• MP3/WMA/WAV file: Select the desired folder, then a file.
• iPod or JPC / JMC file: Select the desired file from the list (PLAYLISTS,
ARTISTS, ALBUMS, SONGS, PODCASTS*, GENRES, COMPOSERS*,
AUDIOBOOKS*).
*
Only for iPod.
If you have many files....
You can search through them quickly (on step 2above) by turning the
volume knob quickly.
• Not applicable for iPod.
Select a song by name
While listening to the iPod and [HEAD MODE] is selected ( 5) ....
If you have many folders or tracks/files, you can search through them
quickly according to the first character (A to Z, 0 to 9 and OTHERS).
• “OTHERS” appear if the first character is other than Ato Z, 0 to 9.
1 Press MENU.
2 Turn the volume knob to select the desired list, then press the
knob.
3 Press J/Kor turn the volume knob quickly to select the desired
character.
4 Turn the volume knob to select the desired folder or track/file, then
press the knob.
Change the USB drive
When a smartphone (Mass Storage Class) is connected to the USB input
terminal, you can select its internal memory or external memory (such as an
SD card) to playback the stored songs.
You can also select the desired drive to playback when a multiple drives
device is connected.
Press number button 5 iPod MODE repeatedly to select the desired
drive.
(or)
1 Press and hold MENU.
2 Turn the volume knob to select [USB/IPOD] , then press the knob.
3 Turn the volume knob to select [USB] , then press the knob.
4 Press the volume knob to select [DRIVECHANGE] .
The next drive is selected automatically.
Repeat steps 1to 4to select the following drives.
Selectable items:
[DRIVE  1] to [DRIVE  5]
Change the playback speed of the Audiobook
While listening to the iPod and [HEAD MODE] is selected ( 5) ....
1 Press and hold MENU.
2 Turn the volume knob to select [USB/IPOD] , then press the knob.
3 Turn the volume knob to select [IPOD] , then press the knob.
4 Turn the volume knob to make a selection, then press the knob.
BOOK NORMAL / BOOK FASTER / BOOK SLOWER : Select the desired playback
speed of the Audiobooks sound file in your iPod/iPhone.
(Default: Depends on your iPod/iPhone setting.)
• To return to the previous setting item or hierarchy, press PTY.
• To cancel, press MENU.
CD / USB / iPod
JS_JVC_KW_R910BT_J_01_EN.indd 6JS_JVC_KW_R910BT_J_01_EN.indd 6 6/12/2013 4:59:37 PM6/12/2013 4:59:37 PM

7
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
“ST” lights up when receiving an FM stereo broadcast with sufficient
signal strength.
Search for a station
1 Press B/SOURCE to select FM or AM.
2 Press S/T(or press H/Ion RM-RK52) to search for a station
automatically.
(or)
Press and hold S/T(or press and hold H/Ion RM-RK52) until
“M” flashes, then press repeatedly to search for a station manually.
Store a station
You can store up to 18 stations for FM and 6 stations for AM.
While listening to a station....
Press and hold one of the number buttons (1to 6) to store.
(or)
1 Press and hold the volume knob until “PRESETMODE” flashes.
2 Turn the volume knob to select a preset number, then press the
knob.
The preset number flashes and “MEMORY” appears.
• To select a stored station: Press J/Kor one of the number buttons
(1to6).
(or)
Press MENU, then turn the volume knob to select a preset number and
press the knob to confirm.
Search for your favorite program (PTY Search)
Available only for FM source.
1 Press and hold PTY.
2 Turn the volume knob to select a PTY code, then press the knob to
start searching.
If there is a station broadcasting a program of the same PTY code as
you have selected, that station is tuned in.
PTY code: NEWS , INFORM (information), SPORTS , TALK , ROCK , CLS ROCK (classic rock),
ADLT HIT (adult hits), SOFT RCK (softrock), TOP 40 , COUNTRY , OLDIES , SOFT , NOSTALGA
(nostalgia),
JAZZ , CLASSICL (classical), R & B (rhythm and blues), SOFT R&B (soft rhythm
and blues),
LANGUAGE , REL MUSC (religious music), REL TALK (religious talk), PERSNLTY
(personality),
PUBLIC , COLLEGE , HABL ESP (Spanish talk), MUSC ESP (Spanish music),
HIP HOP , WEATHER
Other settings
1 Press and hold MENU.
2 Turn the volume knob to select [TUNER] , then press the knob.
3 Turn the volume knob to make a selection ( 8) , then press the
knob.
4 Press MENU to exit.
To return to the previous setting item or hierarchy, press PTY.
JS_JVC_KW_R910BT_J_01_EN.indd 7JS_JVC_KW_R910BT_J_01_EN.indd 7 6/12/2013 4:59:37 PM6/12/2013 4:59:37 PM

8
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Use a portable audio player
1 Connect a portable audio player (commercially available).
2 Select [ON] for [AUX] in [SRC SELECT] . ( 4)
3 Press B/SOURCE to select AUX.
4 Turn on the portable audio player and start playback.
Use a 3-core plug head stereo mini plug for optimum audio
output.
AUX
3.5mm (1/8") stereo mini plug with “L”
shaped connector (commercially available) Portable audio player
Auxiliary input jack
Default: XX
RADIO TIMER Turns on the radio at a specific time regardless of the current source.
1 ONCE / DAILY / WEEKLY / OFF :Select how often the timer will be turned
on.
2 FM / AM :Select the FM or AM band.
3 01 to 18 (for FM)/ 01 to 06 (for AM):Select the preset station.
4 Set the activation day* and time.
• “
M ” lights up when complete.
* Selectable only when
[ONCE] or [WEEKLY] is selected in step 1 .
Radio Timer will not activate for the following cases.
• The unit is turned off.
•
[OFF] is selected for [AM] in [SRC SELECT] after Radio Timer for AM is
selected.
( 4)
SSM SSM 01 – 06
/ SSM 07 – 12 / SSM 13 – 18 : Automatically presets up to
18 stations for FM. “SSM” stops flashing when the first 6 stations are stored.
Select
SSM 07 – 12 / SSM 13 – 18 to store the following 12 stations.
IF BAND AUTO :Increases the tuner selectivity to reduce interference noises from
adjacent FM stations. (Stereo effect may be lost.);
WIDE :Subjects to
interference noises from adjacent FM stations, but sound quality will not be
degraded and the stereo effect will remain.
MONO Displayed only when the source is FM.
ON :Improves the FM reception, but the stereo effect will be lost.;
OFF :Cancels.
AREA AREA US : For North/Central/South America, AM/FM intervals:
10kHz/200kHz.;
AREA EU :For any other areas, AM/FM intervals:
9kHz/50kHz.;
AREA SA :For some South American countries, AM/FM
intervals: 10kHz/50kHz.
JS_JVC_KW_R910BT_J_02_EN.indd 8JS_JVC_KW_R910BT_J_02_EN.indd 8 13/12/2013 4:31:20 PM13/12/2013 4:31:20 PM

9
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pandora®
Preparation:
Install the latest version of the Pandora application onto your device
(iPhone/ iPod touch), then create an account and log in to Pandora.
• Select
[ON] for [PANDORA] in [SRC SELECT] . ( 4)
Start listening
1 Open the Pandora application on your device.
2 Connect your device to the USB input terminal.
The source changes to PANDORA and broadcast starts.
* Do not leave the cable inside the car when not using.
To Do this
Pause or resume
playback Press the volume knob (or press on
RM-RK52).
Thumbs up or
thumbs down
Press J /K (or press J/Kon RM-RK52).
• If thumbs down is selected, the current track is
skipped.
Skip a track Press T(or press Ion RM-RK52).
Create a new station
1 Press MENU.
2 Turn the volume knob to select [NEW STATION] , then press the knob.
3 Turn the volume knob to select [FROM TRACK] or [FROM ARTIST] , then
press the knob.
A new station is created based on the current song or artist.
Search for a registered station
1 Press MENU.
2 Turn the volume knob to make a selection, then press the knob.
[BY DATE] : According to the registered date.
[A-Z] : Alphabetical order.
3 Turn the volume knob to the desired station, then press the knob.
Bookmark a song or artist information
1 Press and hold the volume knob.
2 Turn the volume knob to select [THIS TRACK] or [THIS ARTIST] , then
press the knob.
“BOOKMARKED” appears and the information is stored to your device.
The bookmark is available on your Pandora account but not on this
unit.
USB input terminal
(Accessory of the iPod/iPhone)
*
JS_JVC_KW_R910BT_J_02_EN.indd 9JS_JVC_KW_R910BT_J_02_EN.indd 9 13/12/2013 4:31:36 PM13/12/2013 4:31:36 PM

10
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iHeartRadio®
Preparation:
Install the latest version of iHeart Link for JVC application onto your
device (iPhone/ iPod touch), then create an account and log in to
iHeartRadio.
• Select
[ON] for [IHEART] in [SRC SELECT] . ( 4)
Start listening
1 Open the iHeart Link application on your device.
2 Connect your device to the USB input terminal.
* Do not leave the cable inside the car when not using.
3 Press B/SOURCE to select IHEARTRADIO.
Broadcast starts automatically
To Do this
Pause or resume playback Press the volume knob (or press
on RM-RK52).
Thumbs up or thumbs down
for custom station
Press J /K (or press J/Kon
RM-RK52).
• If thumbs down is selected, the
current track is skipped.
Skip a track for custom station Press T(or press Ion RM-RK52).
Create a new/custom station Press and hold the volume knob.
Add to favorite stations for
live station
Press and hold 3.
Scan for live station Press 3.
Search for a station
1 Press MENU.
2 Turn the volume knob to select a category, then press the knob.
3 Turn the volume knob to the desired station, then press the knob.
When a city list appears, you can skip cities in alphabetical order.
4 Press MENU to exit.
Skip cities by alphabetical order
While a city list appears during search...
1 Turn the volume knob quickly to enter character search.
You can search through the list quickly according to the first character
(A to Z).
2 Turn the volume knob or press J /K to select the character to
be search for.
3 Press the volume knob to start searching.
USB input terminal
(Accessory of the iPod/iPhone)
*
JS_JVC_KW_R910BT_J_01_EN.indd 10JS_JVC_KW_R910BT_J_01_EN.indd 10 6/12/2013 4:59:38 PM6/12/2013 4:59:38 PM

11
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
Pair a Bluetooth device
When connecting a Bluetooth device to the unit for the first time, perform pairing between
the unit and the device. Once the pairing is completed, the Bluetooth device will remain
registered in the unit even if you reset the unit.
• Up to five devices can be registered (paired) in total.
• A maximum of two Bluetooth phones and one Bluetooth audio device can be connected at
any time.
•
This unit supports Secure Simple Pairing (SSP).
• Some Bluetooth devices may not automatically connect to the unit after pairing. Connect
the device to the unit manually. Refer to the instruction manual of the Bluetooth device for
more information.
1 Press B/SOURCE to turn on the unit.
2 Search and select “JVC UNIT” on the Bluetooth device.
“BTPAIRING” flashes on the display.
• For some Bluetooth devices, you may need to enter the Personal Identification Number
(PIN) code immediately after searching.
3 Perform (A) or (B) depending on what scrolls on the display.
• For some Bluetooth devices, pairing sequence may vary from the steps described below.
(A) “[Device Name]” “XXXXXX” “VOL–YES” “BACK–NO”
• “XXXXXX” is a 6-digit passkey randomly generated during each pairing.
Ensure that the passkey which appears on the unit and Bluetooth device is the same.
Press the volume knob to confirm the passkey.
Operate the Bluetooth device to confirm the passkey.
(B) “[Device Name]” “VOL–YES” “BACK–NO”
Press the volume knob to start pairing.
• If “PAIRING” “PIN 0000” scrolls on the display, enter the PIN code “0000” into the
Bluetooth device.
You can change to a desired PIN code before pairing.
( 15)
• If only “PAIRING” appears, operate the Bluetooth device to confirm pairing.
“PAIRING COMPLETED” appears when pairing is completed.
• “ ” will light up when a Bluetooth mobile phone is connected.
• “ ” will light up when a Bluetooth audio player is connected.
You can operate Bluetooth devices using this unit.
Connect the microphone
If you turn off the unit during a phone call
conversation, the Bluetooth connection is
disconnected. Continue the conversation using your
mobile phone.
Supported Bluetooth profiles
– Hands-Free Profile (HFP1.5)
– Advanced Audio Distribution Profile (A2DP)
– Audio/Video Remote Control Profile (AVRCP1.3)
– Object Push Profile (OPP)
– Phonebook Access Profile (PBAP)
– Serial Port Profile (SPP)
Adjust the
microphone angle
Secure using cord clamps (not
supplied) if necessary.
Microphone input jack
Microphone
(supplied)
Rear panel
JS_JVC_KW_R910BT_J_03_EN.indd 11JS_JVC_KW_R910BT_J_03_EN.indd 11 23/12/2013 4:19:16 PM23/12/2013 4:19:16 PM

12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Bluetooth mobile phone
To Do this
Receive a call Press or the volume knob.
On RM-RK52: Press J/K/ H/I.
• When
[AUTO ANSWER] is set to the selected
time, the unit answers incoming call
automatically.
( 13)
Reject an incoming
call Press and hold or the volume knob.
On RM-RK52: Press and hold J/K/ H/I.
End a call Press and hold or the volume knob.
On RM-RK52: Press and hold J/K/ H/I.
Activate or deactivate
hands-free mode
Press the volume knob during a call.
•
Operations may vary according to the
connected Bluetooth mobile phone.
Adjust the phone
volume
Turn the volume knob during a call.
Phone volume:
[00] to [50] (Default: [15] )
• This adjustment will not affect the volume
of the other sources.
Switch between two
connected phones Press repeatedly.
• Not applicable during a call.
Improve the sound quality during a call
While talking on the phone....
1 Press and hold MENU.
2 Turn the volume knob to make a selection ( 13 ), then press the
knob.
3 Press MENU to exit.
To return to the previous setting item or hierarchy, press GPTY.
BLUETOOTH®
Bluetooth compatibility check mode
You can check the connectivity of the supported profile between the
Bluetooth device and the unit.
• Make sure there is no Bluetooth device connected.
1 Press and hold .
“BLUETOOTH” “CHECK MODE” appears. “SEARCH NOW USING
PHONE” “PIN IS 0000” scrolls on the display.
2 Search and select “JVC UNIT” on the Bluetooth device within
3minutes.
3 Perform (A), (B) or (C) depending on what appears on the display.
(A) “PAIRING” “XXXXXX” (6-digit passkey): Ensure that the same
passkey appears on the unit and Bluetooth device, then operate
the Bluetooth device to confirm the passkey.
(B) “PAIRING” “PIN IS 0000”: Enter “0000” on the Bluetooth device.
(C) “PAIRING”: Operate the Bluetooth device to confirm pairing.
After pairing is successful, “PAIRING OK” “[Device Name]” appears and
Bluetooth compatibility check starts.
If “CONNECT NOW USING PHONE” appears, operate the Bluetooth device
to allow phonebook access to continue.
The connectivity result flashes on the display.
“PAIRING OK” and/or “H.FREE OK”*1and/or “A.STREAM OK”*2and/or
“PBAP OK”*3: Compatible
*1Compatible with Hands-Free Profile (HFP)
*2Compatible with Advanced Audio Distribution Profile (A2DP)
*3Compatible with Phonebook Access Profile (PBAP)
After 30 seconds, “PAIRING DELETED” appears to indicate that pairing has
been deleted, and the unit exits check mode.
• To cancel, press and hold B/SOURCE to turn off the power, then turn
on the power again.
JS_JVC_KW_R910BT_J_02_EN.indd 12JS_JVC_KW_R910BT_J_02_EN.indd 12 13/12/2013 4:32:39 PM13/12/2013 4:32:39 PM

13
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
DIAL NUMBER 1 Turn the volume knob to select a number (0 to 9) or character ( , #, +).
2 Press S/ T to move the entry position.
Repeat steps
1 and 2 until you finish entering the phone number.
3 Press the volume knob to call.
VOICE Speak the name of the contact you want to call or the voice command to
control the phone functions.
( 14, Use Voice Recognition)
SETTINGS Default: XX
AUTO
ANSWER
01 SEC — 30 SEC :The unit answer incoming call automatically in the
selected time (seconds).;
OFF :Cancels.
RING TONE IN UNIT: The unit rings to notify you when a call/text message comes in.
(Default ring tone is different according to the paired device.)
•
CALL: Selects your preferred ring tone ( TONE 1 — 5 ) for incoming calls.
•
MESSAGE: Selects your preferred ring tone ( TONE 1 — 5 ) for incoming
text messages.
IN PHONE: The unit uses the connected phones’ ring tone to notify you
when a call/text message comes in. (The connected phone will ring if it
does not support this feature.)
RING COLOR COLOR  01 — COLOR  29 ( COLOR 06 ): Display zone will change to
the selected color during a call or when a text message comes in.;
OFF :Cancels.
MSG NOTICE* ON: The unit rings and “RCV MESSAGE” appears to notify you of an
incoming text message.;
OFF :Cancels.
* Functionality depends on the type of the phone used.
Text message notification
When the phone receives a text message, the unit rings and “RCV
MESSAGE” appears.
• You cannot read, edit, or send a message through the unit.
• To clear the message, press any button.
Default: XX
MIC LEVEL –20 — +08 ( 0 ):The sensitivity of the microphone increases as the
number increased.
NOISE RDCT –05 —– 20 ( –10 ):Adjust the noise reduction level until the least noise is
being heard during a phone conversation.
ECHO CANCEL 1 — 10 ( 4 ):Adjust the echo cancellation delay time until the least echo is
being heard during a phone conversation.
Bluetooth mode operations
1 Press to enter Bluetooth mode.
2 Turn the volume knob to make a selection (see the following table),
then press the knob.
3 Press MENU to exit.
To return to the previous setting item or hierarchy, press PTY.
RECENT
CALL
1 Press the volume knob to select a name or a phone number.
• “>” indicates call received, “<“ indicates call made, “M” indicates call
missed.
• “NO HISTORY” appears if there is no recorded call history or call number.
2 Press the volume knob to call.
PHONEBOOK
1 Turn the volume knob to select a name, then press the knob.
2 Turn the volume knob to select a phone number, then press the knob to
call.
•
If the phone supports PBAP, the phonebook of the connected phone is
automatically transferred to the unit when pairing. If the phone does not
support PBAP, “SEND P.BOOK MANUALLY” appears. Transfer the phonebook
manually.
(15, P.BOOK WAIT)
• This unit can display only non-accent letters. (Accent letters such as “Ú” is
showns as “U”.)
• If the phonebook contains many contacts,
(  14, Select a contact by
name).
JS_JVC_KW_R910BT_J_01_EN.indd 13JS_JVC_KW_R910BT_J_01_EN.indd 13 6/12/2013 4:59:38 PM6/12/2013 4:59:38 PM

14
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Use Voice Recognition
1 Press and hold .
The connected phone (which has been paired the earliest) is activated. However,
if priority device is connected, pressing and holding activate the priority
device.
( 15, PRIORITY)
2 Speak the name of the contact you want to call or the voice command to
control the phone functions.
• Supported Voice Recognition features vary for each phone. Refer to the instruction
manual of the connected phone for details.
•
This unit also supports the intelligent personal assistant function of iPhone.
Select a contact by name
• You can search through the contacts quickly according to the first letter (A to Z, 0 to
9, and OTHERS).
• “OTHERS” appears if the first character is other than A to Z, 0 to 9.
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [PHONEBOOK] , then press the knob.
3 Press J/Kto select the desired letter.
4 Turn the volume knob to select a name, then press the knob.
5 Turn the volume knob to select a phone number, then press the knob to call.
To return to the previous setting item or hierarchy, press GPTY.
Store a contact in memory
You can store up to 6 contacts.
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [RECENT CALL] , [PHONEBOOK] , or [DIAL NUMBER] , then
press the knob.
3 Turn the volume knob to select a contact or enter a phone number.
If a contact is selected, press the volume knob to show the phone number.
4 Press and hold one of the number buttons (1to 6).
“MEMORY P(selected preset number)” appears when the contact is stored.
To erase a contact from the preset memory, select [DIAL NUMBER] in step 2 and store
a blank number.
BLUETOOTH®
Make a call from memory
1 Press to enter Bluetooth mode.
2 Press one of the number buttons (1to 6).
3 Press the volume knob to call.
“NO PRESET” appears if there is no contacts stored.
Delete a contact
Not applicable for mobile phone that supports PBAP.
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [RECENT CALL] or
[PHONEBOOK] , then press the knob.
3 Turn the volume knob to select a contact or a phone
number.
4 Press and hold GPTY.
5 Turn the volume knob to select [DELETE] or [DELETE ALL] ,
then press the knob.
DELETE : Selected name or phone number in step 3is
deleted.
DELETE ALL : All names or phone numbers from the
selected menu in step 2is deleted.
6 Turn the volume knob to select [YES] or [NO] , then press
the knob.
Bluetooth mode settings
1 Press and hold MENU.
2 Turn the volume knob to select [BLUETOOTH] , then press
the knob.
3 Turn the volume knob to make a selection ( 15) , then
press the knob.
4 Press MENU to exit.
To return to the previous setting item or hierarchy, press
GPTY.
JS_JVC_KW_R910BT_J_01_EN.indd 14JS_JVC_KW_R910BT_J_01_EN.indd 14 9/12/2013 10:45:59 AM9/12/2013 10:45:59 AM

15
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
Default: XX
PHONE
Selects the phone or audio device to connect or disconnect. “ ” appears in
front of the device name.
AUDIO
APPLICATION
Shows the connected phone name using the JVC Smart Music Control * 1
app. “ ” appears in front of the device name.
DELETE PAIR 1 Turn the volume knob to select a device to delete, then press the knob.
2 Turn the volume knob to select [YES] or [NO] , then press the knob.
PRIORITY Selects a device to be connected as priority device. “ ” appears in front of
the device name set as priority.
•
“NO PAIR” appears if there is no registered device found.
P.BOOK
WAIT
* 2
Copies up to 400 numbers from the phonebook memory of a connected
phone.
SET PINCODE
(0000)
Changes the PIN code (up to 6 digits).
1 Turn the volume knob to select a number.
2 Press S/ T to move the entry position.
Repeat steps
1 and 2 until you finish entering the PIN code.
3 Press the volume knob to confirm.
AUTO CNNCT ON :The unit automatically reconnect when the Bluetooth device is within
range.;
OFF :Cancels.
INITIALIZE YES :Initializes all the Bluetooth settings (including stored pairing,
phonebook, and etc.).;
NO :Cancels.
INFORMATION MY  BT  NAME : Displays the unit name (JVCUNIT).; MY  ADDRESS : Shows
address of this unit.
*1JVC Smart Music Control is designed to view JVC car receiver status
and perform simple control operations on Android smart phones. For
JVC Smart Music Control operations, visit JVC website:
<http://www.jvc.net/cs/car/>.
*2Selectable only when the connected phone supports OPP.
Internet radio via Bluetooth
Listen to Pandora
Preparation:
Select
[ON] for [PANDORA] in [SRC SELECT] . ( 4)
You can listen to Pandora on your smart phone (Android OS) through
Bluetooth on this unit.
1 Open the Pandora application on your device.
2 Connect to Bluetooth audio player. ( 11)
3 Press B/SOURCE to select PANDORA.
The source switches and broadcast starts automatically.
• You can operate Pandora in the same way as Pandora for iPod/iPhone.
( 9)
Listen to iHeartRadio
Preparation:
Select
[ON] for [IHEART] in [SRC SELECT] . ( 4)
You can listen to iHeartRadio on your smart phone (Android OS) through
Bluetooth on this unit.
1 Open the iHeart Link application on your smart phone.
2 Connect your smart phone via Bluetooth connection. ( 11)
3 Press B/SOURCE to select IHEARTRADIO.
The source switches and broadcast starts automatically.
• You can operate iHeartRadio in the same way as iHeartRadio for iPod/
iPhone.
( 10)
JS_JVC_KW_R910BT_J_03_EN.indd 15JS_JVC_KW_R910BT_J_03_EN.indd 15 23/12/2013 4:21:41 PM23/12/2013 4:21:41 PM

16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
To Do this
Select a preset
equalizer
Press EQ repeatedly.
(or)
Press EQ, then turn the volume knob within 2seconds.
FLAT (default), HARD ROCK, JAZZ, POP, R&B, TALK, USER1,
USER2, VOCAL BOOST, BASS BOOST, CLASSICAL, DANCE
Store your
own sound
settings
Default:
00
1 Press and hold EQ.
2 Turn the volume knob to select [EASY EQ] , then press the
knob.
3 Turn the volume knob to select [USER1] or [USER2] , then press
the knob.
4 Turn the volume knob to make a selection, then press the
knob.
SUB.W
*: –08 to +08
BASSLVL: –06 to +06
MIDLVL:–06to+06
TRELVL: –06 to +06
• To return to the previous setting item, press PTY.
• To exit, press EQ.
* Displayed only when
[L/O  MODE] is set to [SUB.W] and [SUB.W] is set to [ON] . ( 17)
Other settings
1 Press and hold MENU.
2 Turn the volume knob to make a selection ( 17 ), then press the knob.
Repeat step 2until the desired item is selected.
3 Press MENU to exit.
To return to the previous setting item or hierarchy, press PTY.
Bluetooth audio player
Operations and display indications may differ according to their
availability on the connected device.
To Do this
Playback 1 Press B/SOURCE to select BTAUDIO.
2 Operate the Bluetooth audio player to
start playback.
Pause or resume
playback Press MENU (or press on
RM-RK52).
Select group or
folder
Press J/K(or press J/Kon
RM-RK52).
Reverse/forward
skip
Press S/T(or press H/Ion
RM-RK52).
Reverse/
fast-forward
Press and hold S/T(or press and
hold H/Ion RM-RK52).
Repeat play Press 3repeatedly to make a
selection.
TRACKRPT, ALLRPT, RPTOFF
Random play Press 2repeatedly to make a
selection.
GROUPRND, ALLRND, RNDOFF
BLUETOOTH®
JS_JVC_KW_R910BT_J_01_EN.indd 16JS_JVC_KW_R910BT_J_01_EN.indd 16 6/12/2013 4:59:39 PM6/12/2013 4:59:39 PM

17
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Default: XX
EQ SETTING
EQ PRESET FLAT
/ HARD ROCK / JAZZ / POP / R&B / TALK / USER1 / USER2 /
VOCAL BOOST / BASS BOOST / CLASSICAL / DANCE :Selects a preset
equalizer.
EASY EQ
Default: 00
1 USER1 / USER2 :Select a preset name.
2 Adjust your own sound settings.
SUB.W
*1
: –08 to +08
BASS
 LVL : –06 to +06
MID
 LVL: –06 to +06
TRE
 LVL : –06 to +06
PRO EQ
1 USER1 / USER2 :Select a preset name.
2 BASS / MIDDLE / TREBLE :Select a sound tone.
3 Adjust the sound elements of the selected sound tone.
BASS Frequency: 60 / 80 / 100 / 200 Hz Default: ( 80 Hz )
Level:
–06 to +06 ( 00 )
Q:
Q1.0 / Q1.25 / Q1.5 / Q2.0 ( Q1.0 )
MIDDLE Frequency: 0.5 / 1.0 / 1.5 / 2.5 kHz Default: ( 1.0 kHz )
Level:
–06 to +06 ( 00 )
Q:
Q0.75 / Q1.0 / Q1.25 ( Q1.25 )
TREBLE Frequency: 10.0 / 12.5 / 15.0 / 17.5 kHz Default: ( 10.0 kHz )
Level:
–06 to +06 ( 00 )
Q:
Q FIX ( Q FIX )
AUDIO
BASS BOOST +01
/ +02 : Selects your preferred bass boost level.; OFF :Cancels.
LOUD 01 / 02 :Boosts low or high frequencies to produce a well-balanced sound
at low volume.;
OFF :Cancels.
SUB.WLEVEL
*1
–08 — +08 ( 0 ):Adjusts the subwoofer output level.
SUB.W
*2
ON / OFF : Turns on or off the subwoofer output.
SUB.W  LPF
*1
THROUGH :All signals are sent to the subwoofer. ; LOW  55Hz /
MID  85Hz / HIGH 120Hz :Audio signals with frequencies lower than
55Hz/ 85Hz/ 120Hz are sent to the subwoofer.
FADER
*3
*4
R06 — F06 ( 00 ):Adjusts the front and rear speaker output balance.
BALANCE
*3
L06 — R06 ( 00 ):Adjusts the left and right speaker output balance.
VOL  ADJUST –05 — +05 ( 00 ):Presets the volume adjustment level of each source
(compared to the FM volume level). Before adjustment, select the source
you want to adjust. (“VOLADJFIX” appears if FM is selected.)
AMP  GAIN LOW  POWER :Limits the maximum volume level to 30. (Select if the
maximum power of each speaker is less than 50W to prevent damaging
the speakers.);
HIGH POWER :The maximum volume level is 50.
D.T.EXP
(Digital Track
Expander)
ON :Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression.;
OFF :Cancels.
L/O  MODE SUB.W / REAR :Selects whether rear speakers or a subwoofer are
connected to the REAR/SW line out terminals on the rear panel (through
an external amplifier).
*1Displayed only when
[L/O  MODE] is set to [SUB.W] and [SUB.W] is set to
[ON] .
*2Displayed only when
[L/O  MODE] is set to [SUB.W] .
*3This adjustment will not affect the subwoofer output.
*4If you are using a two-speaker system, set the fader level to
[00] .
AUDIO SETTINGS
JS_JVC_KW_R910BT_J_02_EN.indd 17JS_JVC_KW_R910BT_J_02_EN.indd 17 13/12/2013 4:34:21 PM13/12/2013 4:34:21 PM

18
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Default: XX
COLOR
PRESET
You can select a color for [ ALL ZONE ], [ ZONE 1 ], [ DISP ZONE ], or
[
ZONE 2 ] separately. For [ ALL ZONE ], you can also select a color
pattern.
Default color:
ALL ZONE : [ COLOR 06 ], ZONE 1 : [ COLOR 06 ],
DISP ZONE : [ COLOR 01 ], ZONE 2 : [ COLOR 27 ]
1 Select a zone for setting. ( Illustration on the left column)
2 Select a color for the selected zone.
•
COLOR 01 to COLOR 29
• USER : The color you have created for [ DAY COLOR ] or
[
NIGHT COLOR ] is shown.
•
COLOR FLOW 01 to COLOR FLOW 03 : Color changes at
different speeds.
•
SPECTRUM / GROOVE / TECHNO / EMOTION / RELAX /
NIGHT SWEEP : The selected color pattern is shown.*
(Selectable only when [
ALL ZONE ] is selected in step 1 .)
* If one of these color pattern is selected, the [ ZONE 1 ], [ DISP ZONE ],
[
ZONE 2 ] illumination color will change to the default color.
DAY COLOR Store your own day and night colors for different zone.
1 Select a zone for setting. ( Illustration on the left column)
2 RED / GREEN / BLUE :Select a primary color.
3 00 to 31 :Select the level.
Repeat steps
2 and 3 for all the primary colors.
• Your setting is stored to
[USER] in [PRESET] .
• If
[00] is selected for all primary colors for [DISP ZONE] , nothing
appears on the display.
NIGHT COLOR
COLOR GUIDE ON
:Changes the button, display and USB input terminal illumination
when settings are performed on menu and list search. Display zone
will automatically change depending on volume level.;
OFF :Cancels.
[NIGHT COLOR] or [DAY COLOR] is changed by turning on or off your car’s
headlight.
1 Press and hold MENU.
2 Turn the volume knob to make a selection (see the following table),
then press the knob.
Repeat step
2until the desired item is selected.
3 Press MENU to exit.
To return to the previous setting item or hierarchy, press PTY.
Default: XX
DISPLAY
DIMMER
Selects the display and button illumination adjusted in the [BRIGHTNESS]
setting.
AUTO :Changes between the day and night adjustments when you turn off or
on the car headlights.*
1
; ON :Selects the night adjustments.; OFF :Selects the
day adjustments.
BRIGHTNESS Sets the button, display and USB input terminal brightness for day and night
separately.
1 DAY / NIGHT :Select day or night.
2 Select a zone for setting. ( Illustration above)
3 Set the brightness level ( 00 to 31 ).
(Default:
DAY : 31 ; NIGHT : 15)
SCROLL
* 2 ONCE :Scrolls the display information once.; AUTO :Repeats scrolling at
5-second intervals.;
OFF :Cancels.
*1
The illumination control wire connection is required. ( 25)
*2
Some characters or symbols will not be shown correctly (or will be blanked).
DISPLAY SETTINGS
JS_JVC_KW_R910BT_J_01_EN.indd 18JS_JVC_KW_R910BT_J_01_EN.indd 18 6/12/2013 4:59:39 PM6/12/2013 4:59:39 PM
