1
KD-R434
Installation/Connection Manual
0911DTSSANJEIN
EN
© 2011 JVC KENWOOD Corporation
GET0771-002A
[UI]
Bracket *
Pocket
Flat head screws (M5 × 8 mm)*
INSTALLATION
When installing the unit without using the sleeve
In-dash mounting
WARNINGS
Removing the unit
Release the rear section first...
Do the required electrical connections.
Bend the appropriate tabs to hold the sleeve
firmly in place.
Install the unit at an
angle of less than 30˚.
*Not supplied for this unit.
Part list
A
Hard case (×1)
B
Control panel (×1)
C
Sleeve (×1)
D
Trim plate (×1)
E
Power cord (×1)
F
Handles (×2)
• Mounting and wiring this product requires skills and experience. For safety’s sake, leave this work to professionals. If you experience problems during installation, consult your JVC car audio dealer.
• The unit can only be installed in a car with a 12 V DC power supply, negative ground.
• Disconnect the battery’s negative terminal and make all electrical connections before installing the unit.
• Connect speakers with a maximum power of more than 50 W (impedance of 4 Ω to 8 Ω). Otherwise, change the <AMP GAIN> setting. (See page 11 of the INSTRUCTIONS.)
• Insulate unconnected wires with vinyl tape or other similar material. To prevent a short circuit, do not remove the caps on the ends of the unconnected wires or the terminals.
• If the fuse blows, first make sure the wires are not touching to cause a short circuit, then replace the old fuse with one that has the same rating.
• Install this unit in the console of your vehicle.
• Mount the unit so that the mounting angle is 30° or less.
• Be sure to ground this unit to the car's chassis again after installation.
• After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are working properly.
• Do not touch the metal part of this unit during and shortly after the use of the unit. Metal part such as the heat sink and enclosure become hot.
PRECAUTIONS on power supply and speaker connections
• DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the unit will be seriously damaged.
• BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in your car.
• The fuse blows.
h
Are the red and black leads connected correctly?
• Power cannot be turned on.
h
Is the yellow lead connected?
• No sound from the speakers.
h
Is the speaker output lead short-circuited?
• “MISWIRING CHK WIRING THEN RESET UNIT” / “WARNING CHK WIRING THEN RESET UNIT” appears on the display and no operation can be done.
h
Is the speaker output lead short-circuited or touches the
chassis of the car/head unit? ; Have you reset your unit?
• Sound is distorted.
h
Is the speaker output lead grounded? ; Are the “–” terminals of L and R speakers grounded in common?
• Noise interfere with sounds.
h
Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?
• This unit becomes hot.
h
Is the speaker output lead grounded? ; Are the “–” terminals of L and R speakers grounded in common?
• This unit does not work at all.
h
Have you reset your unit?
TROUBLESHOOTING
Install_KD-R434_EN.indd 1Install_KD-R434_EN.indd 1 9/16/2011 12:42:22 PM9/16/2011 12:42:22 PM
2
ELECTRICAL CONNECTIONS
Black
Black
Strip lead ends
Twist ends together
Solder
Tape
Fuse block
Ignition switch
Blue
Blue (white stripe)
Vehicle-specific Wiring Harness
(separately purchased)
Join the same color leads together.
To join the open-ends of the leads:
Yellow
For your reference:
Metra Electronics:
www.metraonline.com
Scosche Industries:
www.scosche.com
Front speaker (left)
White
White (black stripe)
Front speaker (right)
Gray
Gray (black stripe)
Rear speaker (left)
Green
Green (black stripe)
Rear speaker (right)
Purple
Amp Turn-on (200 mA max.)
Red
12 V Ignition Switch
12 V Battery
Ground
Illumination
Telephone Muting
Purple (black stripe)
Signal cord* 1
Extension lead *1
Remote lead
Rear speakers or
subwoofer *3
Rear ground terminal 10 A fuse
Antenna terminal
*1Not supplied for this unit.
*2Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint.
*3Make the <L/O MODE> setting accordingly, see page 10 of the INSTRUCTIONS.
Reset the unit.
JVC Amplifier
Recommended connection
Connecting the Bluetooth adapter or portable audio player
Orange (white stripe)
Brown
Brown To the brown lead of the supplied power cord
E
To the blue (white stripe) lead of the supplied power cord
E
Ground
E
Power cord
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – or – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
KS-BTA100
(separately purchased)
Portable audio player, etc.* 1
3.5 mm stereo mini plug* 1
Make the <SRC SELECT> setting accordingly, see
pages 8 and 11 of the INSTRUCTIONS.
If your vehicle factory wiring harness does not
have “12 V ignition switch” lead, connect the
red lead of the supplied power cord,
E
, to the
vehicle fuse block (through a separate red lead
provided with the fuse tap).
Factory wiring harness (vehicle)
Power cannot be turned on?
Separate red lead
Caution
Blue (white stripe)
Automatic antenna (250 mA max.)
Install_KD-R434_EN.indd 2Install_KD-R434_EN.indd 2 9/16/2011 12:42:23 PM9/16/2011 12:42:23 PM
