SERVICE MANUAL
HOME CINEMA CONTROL CENTER
No.21085
Apr. 2002
COPYRIGHT 2002 VICTOR COMPANY OF JAPAN, LTD.
RX-E112RSL
RX-E112RSL/RX-E111RSL
Contents
Safety precautions --------------------------------------------------------1- 2
Disassembly method -----------------------------------------------------1- 3
Adjustment method -------------------------------------------------------1- 8
Description of major ICs -------------------------------------------------1- 9~22
RX-E111RSL
Each difference points
Source indication lens color
GRAY SMOKE
CLEAR LIGHT GREEN
MODEL
RX-E112RSL
RX-E111RSL
Area suffix
B ------------------------ U.K.
E ---- Continental Europe
EN ----- Northern Europe
EV ------- Eastern Europe
RM-SRXE111R REMOTE CONTROL
HOME CINEMA CONTROL CENTER
CONTROL
CHANNEL VOLUMETV VOL
TUNING
STOP PAUSE
FF/
/REW
DIMMER
TV/VIDEO
VCR
MUTING
REC
PLAY
DOWN UP
DVD
SLEEP TV DIRECT
DVD STB VCR TV
ANALOG/DIGITAL TAPE FM
BASS + CENTER
TEST BASS
Ð REAR-L
BASS BOOST TREBLE
+ REAR-R
EFFECT TREBLE
Ð SUBWOOFER
RETURN FMMODE
ENTER DISPLAYMODE
RDS
MODE
ON/OFF
AM
123
456
789
10
0
+10
+100
DVD
MENU
VCR TVSTB
INPUT
SURROUND
TA/NEWS/INFO
PTY SEARCH
PTY PTY
AUDIO
DVD MENU
SURROUND
SOUND
SOUND
+
Ð
+
Ð
+
Ð
+
Ð
DVD STB VCR TV TAPE FM/AM
DVD STB VCR TV TAPE FM/AM
HOME CINEMA CONTROL CENTER
TV DIRECT
MEMORY
CONTROL
ADJUST
SETTING
STANDBY
INPUT
ANALOG/DIGITAL
INPUT ATT
MASTER VOLUME
SURROUND
ON/OFF SURROUND
MODE
STANDBY/ON
PHONES
ANALOG PL
SUBWFR LFE
SLEEP MODE TA STTUNED INFONEWS AUTOMUTING
MH
Z
KH Z
VOL
AUTO
AUTO SR
INPUT ATT
DSP HP
LCR
LS S RS
LPCM
DOLBY D
DTS
RDS

RX-E112RSL/RX-E111RSL
1-2
1. This design of this product contains special hardware and many circuits and components specially for safety
purposes. For continued protection, no changes should be made to the original design unless authorized in
writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services
should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product
should not be made. Any design alterations or additions will void the manufacturer`s warranty and will further
relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics. These
characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily
be obtained by using replacement components rated for higher voltage, wattage, etc.Replacement parts which
have these special safety characteristics are identified in the Parts List of Service Manual. Electrical
components having such features are identified by shading on the schematics and by ( ) on the Parts List in
the Service Manual. The use of a substitute replacement which does not have the same safety characteristics
as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or
other hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be
separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of
electric shock and fire hazard. When service is required, the original lead routing and dress should be
observed, and it should be confirmed that they have been returned to normal, after re-assembling.
5. Leakage currnet check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts of the product
(antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the
product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage
current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground.Any leakage current must not exceed 0.5mA AC (r.m.s.).
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more
sensitivity in the following manner.Connect a 1,500 10W resistor paralleled by a 0.15 F AC-type capacitor
between an exposed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path to
the chassis, and meausre the AC voltage across the resistor.
Now, reverse the plug in the AC outlet and repeat each
measurement.Voltage measured any must not exceed 0.75 V
AC (r.m.s.).This corresponds to 0.5 mA AC (r.m.s.).
1.This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
Burrs formed during molding may
be left over on some parts of the
chassis. Therefore, pay attention to
such burrs in the case of
preforming repair of this system.
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
(This regulation does not correspond to J and C version.)

1-3
RX-E112RSL/RX-E111RSL
Remove the four screws Aattaching the top cover on
both sides of the body.
Remove the three screws Bon the back of the body.
Remove the top cover from behind in the direction of
the arrow while pulling both sides outward.
1.
2.
3.
Disassembly method
Removing the top cover (See Fig.1)
Prior to performing the following procedure, remove
the top cover.
Remove the power cord stopper from the rear panel
by moving it in the direction of the arrow.
Remove the nineteen screws F& Gattaching the
each boards to the rear panel.
Remove the four screws Hattaching the rear panel
on the back of the body.
1.
2.
3.
Removing the rear panel (See Fig.4)
Prior to performing the following procedure, remove
the top cover.
Cut off the tie band fixing the harness, if needed.
Disconnect the card wire from the connector CN411
on the audio board, CN412 on the input board and
CN204 on the power supply board.
Disconnect the harness form the connector CN209
on the power supply board.
Remove the three screws Cattaching the front
panel assembly.
Remove the screw Dattaching the headphone jack
board.
Remove the four screws Eattaching the front panel
assembly on the bottom of the body. Detach the front
panel assembly toward the front.
1.
2.
3.
4.
5.
6.
Removing the front panel assembly
(See Fig.2 and 3)
Fig.1
Fig.2
Fig.3
Fig.4
A (both sides)
B
Top cover
CC
Power supply
board
Audio board
CN411
Main board
Tie band
GF
F
FHHHH
Power cord
stopper
Front panel assembly
Front panel assembly
(Bottom side)
D (attaching the
headphone jack board)
Rear panel
CN204
CN209
E
CN412 Input board
E

RX-E112RSL/RX-E111RSL
1-4
Prior to performing the following procedure, remove
the top cover and rear panel.
Disconnect the card wire from the connector CN412
and CN512 on the input board.
1.
Removing the input board (See Fig.5)
Prior to performing the following procedure, remove
the top cover and rear panel.
Disconnect the connector CN111 and CN112 on the
tuner board and draw out the tuner board in the
direction of the arrow (see fig.5).
Disconnect the connector CN513 and CN514 on the
relay board (tuner) and draw out the relay board
(tuner) in the direction of the arrow (see fig. 6).
1.
2.
Removing the tuner board
(See Fig.5 and 6)
Prior to performing the following procedure, remove
the top cover and rear panel.
Disconnect the connector CN681 on the DSP board
and draw out the DSP board in the direction of the
arrow (see fig.5).
Disconnect the connector CN511 on the relay board
(DSP) and draw out the relay board (DSP) in the
direction of the arrow (see fig.6).
1.
2.
Removing the DSP board (See Fig.5 and 6)
Removing the audio board (See Fig.7)
Prior to performing the following procedure, remove
the top cover, rear panel, input board, tuner board,
DSP board and relay boards (tuner & DSP).
Remove the harness band[1] fixing the harness.
Disconnect the card wire from the connector CN411
on the audio board.
Disconnect the harness from the connector CN224
/CN225 on the audio board.
Disconnect the harness from the connector CN515,
CN516 and CN517 on the main board.
Remove the three screws Iattaching the audio board.
1.
2.
3.
4.
5.
Fig.5
Fig.6
Fig.7
DSP board
Input board
Tuner board
CN111
CN681
CN512
CN513
CN516
CN515
CN517
CN411
CN224
/CN225
Harness band[1]
CN412
Relay board(tuner)
Relay board(DSP)
Main board
Audio board
CN112
CN514
CN511
I

1-5
RX-E112RSL/RX-E111RSL
Prior to performing the following procedure, remove
the top cover, main board and each amp. board.
Remove the four screws Rattaching the two
brackets to the heat sink and remove the two
brackets.
1.
Removing the Heat sink (See Fig.11)
Prior to performing the following procedure, remove
the top cover, rear panel, input board, DSP board
and relay board (DSP).
Disconnect the harness from the connector CN515,
CN516 and CN517 on the main board (see fig.7).
Remove the harness band[1] (see fig.7) and harness
band[2] fixing the harness.
Disconnect the harness from the connector CN707
on the power supply board .
Disconnect the harness from the connector CN202
and CN226/CN227 on the main board .
Remove the five screws Jand two screws K
attaching the main board.
Remove the two screws Lattaching the heat sink to
the main board.
Disconnect the connector of each amp. board.
1.
2.
3.
4.
5.
6.
7.
Removing the main board with speaker
board (See Fig.8 to 10)
Prior to performing the following procedure, remove
the top cover and main board.
Remove the two screws Mattaching the Cch amp.
board and remove the Cch amp. board.
Remove the two screws Nattaching the Lch amp.
board and remove the Lch amp. board.
Remove the two screws Oattaching the Rch amp.
board and remove the Rch amp. board.
Remove the two screws Pattaching the SLch amp.
board and remove the SLch amp. board.
Remove the two screws Qattaching the SRch amp.
board and remove the SRch amp. board.
1.
2.
3.
4.
5.
Removing the each amp. board of Cch,
Lch, Rch, SLch and SRch (See Fig.11)
Fig.8
Fig.9
Fig.11
Fig.10
power supply
board
Speaker board
Speaker board
Rch amp. board Lch amp. board
Cch amp. board
SLch amp. board
SRch amp. board
Main board (reverse side)
Main
board
Heat sink
Heat sink
Bracket Bracket
CN226/CN227
CN707
CN705
CN701
CN704
CN703
CN702
J
J
K
L
R
M
(Cch)
N (Lch)
O (Rch)
Q (SRch)
P (SLch) R
CN202
Harness
band[2]
Main board

RX-E112RSL/RX-E111RSL
1-6
Prior to performing the following procedure, remove
the top cover.
Remove the screw Gattaching the power/fuse board
to the rear panel (see fig. 4).
Disconnect the harness from the connector CN217
on the power/fuse board (If necessary, cut off the
band fixing the harness on the side of the base
chassis).
Remove the screw U attaching the power/fuse
board.
Unsolder the power cord and other harness
connected to the power/fuse board.
1.
2.
3.
4.
Removing the power/fuse board
(See Fig.13)
Prior to performing the following procedures, remove
the top cover.
Cut off the tie band.
Disconnect the harness from the connector CN217
on the power/fuse board.
Disconnect the harness from the connector CN201
on the power supply board and CN202 on the main
board.
Remove the one screw Jand remove the earth wire.
Remove the four screws Rattaching the power
transformer.
1.
2.
3.
4.
5.
Removing the power transformer
(See Fig.12 and 13)
Prior to performing the following procedure, remove
the top cover.
Disconnect the card wire from the connector CN204
on the power supply board.
Disconnect the harness from the connector CN201,
CN209 and CN707 on the power supply board.
Disconnect the harness from the connector CN226
/CN227 on the main board
Remove the three screws Sattaching the power
supply board and pull out the power supply board
removing the hook.
Unsolder the three harness connected to the power
supply board (If necessary, cut off the band fixing the
harness on the side of the base chassis).
1.
2.
3.
4.
5.
Removing the power supply board
(See Fig.12)
Fig.12
Fig.13
Power supply
board
CN707
Power
transformer
Solder
Solder
(on the reverse side)
Solder
Power/fuse board
Power cord
Tie band
Tie band
Power
transformer
board
PW201
PW203
CN204
CN209
PW202
S
S
R
J
(fixing the
earth wire)
S
CN201
U
CN217
Hook
CN226
/CN227
CN202

1-7
RX-E112RSL/RX-E111RSL
Prior to performing the following procedure, remove
the top cover and front panel assembly.
Remove the two screws Aattaching the power
switch board.
Remove the eight screws Battaching the system
control board.
Disconnect the card wire from the connector CN401,
CN402 and CN412 on the system control board.
Remove the switch buttons and indicator esc., if
needed.
1.
2.
3.
4.
Removing the system control board with
power switch board (See Fig.1 to 3)
Prior to performing the following procedure, remove
the top cover and front panel assembly.
Remove the screw Cattaching the headphone jack
board to the front panel assembly.
1.
Removing the headphone jack board
(See Fig.1)
<Front panel assembly>
Fig.1
Fig.2
Fig.3
System control board
System control board (forward side)
Switch button
Indicator esc.
CN401CN412 CN402
Headphone jack board
Headphone
jack board
Power switch board
Power switch board (forward side)
Front panel assembly (inner side)
Front panel assembly (inner side)
BBA
C
C

RX-E112RSL/RX-E111RSL
1-8
Adjustment method
<Adjustment method>
1. Prior to turning the power ON, fully turn the adjusting resistor (VR301(Lch),VR302(Rch)) counterclockwise
direction and connect the DC voltmeter to the measuring terminal(B451-B452(Lch) , B453-B454(Rch)).
2. Set the surround mode OFF.
3. Adjust the resistor so that the measured value becomes 3.2mV immediately after turning the power ON.
4. When the idling current has been stable (about 30 minutes after the power is turned ON),
confirm that the measured value falls within 1.0mV 10mV(2.7mV).
Power amplifier section
B453-B454 (Rch)
Rch amp. board
Lch amp. board
VR301 (Lch)
VR302 (Rch)
Heat sink
Adjustment of idling current
Measurement terminal B451-B452(Lch) , B453-B454(Rch)
Adjustment volume VR301(Lch) , VR302(Rch)
Attention
This adjustment does not obtain a correct adjustment value immediately after the amplifier is
used (state that an internal temperature has risen).
Please adjust immediately after using the amplifier after turning off the power supply of the
amplifier and falling an internal temperature.
* It is not abnormal though the idling current might not become 0mA even if it is finished to turn variable
resistance (VR301VR302) in the direction of counterclockwise.
B451-B452 (Lch)

1-9
RX-E112RSL/RX-E111RSL
Pin No.
1~8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25~32
33
34,35
36
37,38
39
40
41
42
43
44
45,46
47
48
49
50
51,52
53
54~63
64,65
66
67
68
69,70
71
72
73~80
81
82,83
84
85
86
87
88
89
90~93
94
95~100
Symbol
VDD
X2
X1
VSS
XT2
XT1
RESET
AUTODATA
LOCK
DIGITAL0
FORMAT
CHANNEL
ERR
RSTDET
AVDD
AVREF0
AVSS
AV REF1
RX,TX
DSPCOM
DSPSTS
DSPCLK
DSPRDY
MIDIO_IN/OUT
MICK
MICS
MILP
MIACK
DSPRST
CDTI/CDTO
CCLK
CS
XTS
PD
GND
VDD
ANA/T-TONE
LEF-MIX
S.MUTE
ASW1~4
TEST
I/O
-
-
O
I
-
O
I
I
I
I
I
I
I
I
I
-
-
-
-
-
-
-
-
I
O
I
I
-
I/O
O
O
O
O
-
O
-
I/O
O
O
O
-
O
-
-
-
-
O
O
-
O
O
-
O
-
-
Function
Non connect
Power supply terminal
Connecting the crystal oscillator for system main clock
Connecting the crystal oscillator for system main clock
Connect to GND
Connecting the crystal oscillator for system sub clock
Connecting the crystal oscillator for system sub clock
System reset signal input
Output of DSP to general-purpose port
Output of DSP to general-purpose port
Output of DSP to general-purpose port
Output of DSP to general-purpose port
Output of DSP to general-purpose port
Output of DSP to general-purpose port
Reset signal input
Power supply terminal
Connect to GND
Connect to GND
Connect to GND
Non connect
Power supply terminal
Not use
Non connect
Communication port
Status communication port
Clock input
Ready signal input
Non connect
Interface I/O terminal with microcomputer
Interface I/O terminal with microcomputer of clock signal
Interface I/O terminal with microcomputer of chip select
Interface I/O termonal with microcomputer
Interface I/O termonal with microcomputer
Non connect
Reset signal output of DSP
Non connect
Interface I/O terminal with microcomputer
Interface I/O terminal with microcomputer of clock signal
Interface I/O terminal with microcomputer of chip select
OSC Select
Non connect
Reset signal output
Connect to GND
Non connect
Power supply
Non connect
Test tone control
Control at output destination of LFE channel
Non connect
Mute of the digital out terminal is controlled
Mute of the audio signal is controlled
Non connect
Selection of digital input selector
Test terminal
Non connect
75 ~ 51
1 ~ 25
76
100
~
50
26
~
1.Pin layout
2.Pin function
UPD784215AGC (IC671) : Unit CPU
Description of major ICs

RX-E112RSL/RX-E111RSL
1-10
1
2
3
4
5
6
7
8
9
10
11
33
32
31
30
29
28
27
26
25
24
23
12 13 14 15 16 17 18 19 20 21 22
44 43 42 41 40 39 38 37 36 35 34
SDOS
I2C
SMUTE
BICK
LRCK
SDTI1
SDTI2
SDTI3
SDTO
DAUX
DFS
DZF2/OVF
RIN+
RIN-
LIN+
LIN-
ROUT1
LOUT1
ROUT2
LOUT2
ROUT3
LOUT3
NC DZFE TVDD DVDD DVSS PDN TST NC ADIF CAD1 CAD0
LOOP1 LOOP0/SDA/CDTI DIF1/SCL/CCLK DIF0/CSN P/S MCLK DZF1 AVSS AVDD VREFH VCOM
1.Pin layout
AK4527B (IC601) : A/D,D/A Converter
AK4527BVQ
Top View
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Pin name
SDOS
I2C
SMUTE
BICK
LRCK
SDTI1
SDTI2
SDTI3
SDTO
DAUX
DFS
NC
DZEF
TVDD
DVDD
DVSS
PDN
TST
SDTO Source Select Pin (Note 1)
"L" : Internal ADC output, "H" : DAUX input
Control Mode Select Pin
"L" : 3-wire Serial, "H" : I
2 C Bus
Soft Mute Pin (Note 1)
When this pin goes to "H", soft mute cycle is initialized.
When returning to "L", the output mute releases.
Audio Serial Data Clock Pin
Input Channel Clock Pin
DAC1 Audio Serial Data Input Pin
DAC2 Audio Serial Data Input Pin
DAC3 Audio Serial Data Input Pin
Audio Serial Data Output Pin
Sub Audio Serial Data Input Pin
Double Speed Sampling Mode Pin (Note 1)
"L" : Normal Speed, "H" : Double Speed
No Connect
No internal bonding.
Zero Input Detect Enable Pin
"L" : mode 7 (disable) at parallel mode,
zero detect mode is selectable by DZFM2-0 bits at serial mode.
"H" : mode 0 (DZF is AND of all six channels)
Output Buffer Power supply Pin, 2.7V~5.5V
Digital Power Supply Pin, 4.5V~5.5V
De-emphasis Pin, 0V
Power-Down & Reset Pin
When "L", the AK4527B is powered-down and the control registers are reset to default
state.If the state of P/S or CAD0-1 changes, then the AK4527B must be reset by PDN.
Test Pin
This pin should be connected to DVSS.
Function
I/O
I
I
I
I
I/O
I
I
I
O
I
I
-
I
-
-
-
I
I
2. Pin function (1/2)

1-11
RX-E112RSL/RX-E111RSL
No.
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
Pin name
NC
ADIF
CAD1
CAD0
LOUT3
ROUT3
LOUT2
ROUT2
LOUT1
ROUT1
LIN-
LIN+
RIN-
RIN+
DZF2
OVF
VCOM
VREFH
AVDD
AVSS
DZF1
MCLK
P/S
DIF0
CSN
DIF1
SCL/CCLK
LOOP0
SAD/CDTI
LOOP1
No Connect
No internal bonding.
Analog Input Format Select Pin
"H" : Full-differential input, "L" :Single-ended input
Chip Address 1 Pin
Chip Address 0 Pin
DAC3 Lch Analog Output Pin
DAC3 Rch Analog Output Pin
DAC2 Lch Analog Output Pin
DAC2 Rch Analog Output Pin
DAC1 Lch Analog Output Pin
DAC1 Rch Analog Output Pin
Lch Analog Negative Input Pin
Lch Analog Positive Input Pin
Rch Analog Negative Input Pin
Rch Analog Positive Input Pin
Zero Input Detect 2 Pin (Note 2)
When the input data of the group 1 follow total 8192LRCK cycles with "0" input data,
this pin goes to "H".
Analog Input Overflow Detect Pin (Note 3)
This pin goes to "H" if the analog input of Lch or Rch is overflows.
Common Voltage Output Pin,AVDD/2
Large external capacitor around 2.2uF is used to reduce power-supply noise.
Positive Voltage Reference Input Pin,AVDD
Analog Power Supply Pin,4.5V~5.5V
Analog Ground Pin,0V
Zero Input Detect 1 Pin (Note 2)
When the input data of the group 1 follow total 8192 LRCK cycles with "0" input data,
this pin goes to "H".
Master Clock Input Pin
Parallel / Serial Select Pin
"L" : Serial control mode, "H" :Parallel control mode
Audio Data Interface Format 0 Pin in parallel mode
Chip select pin in 3-wire serial control mode
This pin should be connected to DVDD at I2C bus control mode
Audio Data Interface Format 1 Pin in parallel mode
Control Data Clock Pin in serial control mode
I2C = "L" : CCLK(3-wire Serial), I2C = "H" : SCL(I2CBus)
Loopback Mode 0 Pin in parallel control mode
Enables digital loop-back from ADC to 3 DACs.
Control Data Input Pin in serial control mode
I2C = "L" : CDTI(3-wire Serial), I2C = "H" : SDA(I2CBus)
Loopback Mode 1 Pin (Note 1)
Enable all 3 DAC channels to be input from SDTII.
Function
I/O
-
I
I
I
O
O
O
O
O
O
I
I
I
I
O
O
O
I
-
-
O
I
I
I
I
I
I
I
I/O
I
2. Pin function (2/2)
Notes : 1. SDOS, SMUTE, DFS, and LOOP1 pins are ORed with register data if P/S = "L".
2.The group 1 and 2 can be selected by DZFM2-0 bit if P/S = "L" and DZFME = "L".
3.This pin becomes OVF pin if OVFE bit is set to "1" at serial control mode.
4. All input pins should not be left floating.

RX-E112RSL/RX-E111RSL
1-12
M61501FP (IC501) : Analog sound processor
1. Block diagram
2. Pin function (1/2)
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
I/O
-
I
O
O
O
I
I
I
I
I
O
O
-
I
I
O
O
I
-
I
I
Symbol
NC
ING1
RECOUT1B
RECOUT1A
SELOUT1
TINA1
TINB1
TCC
TCB1
TCA1
TONEOUT1
SWOUT
AGND
RchAIN
RchBIN
RchOUT
RchBBO
RchBBI
AGND
SRchAIN
SRchBIN
Function
No connect
G signal input of right side input selector
B through signal output of right side
A through signal output of right side
Signal output after 0/-6dB of right side
Tone A signal input of right side
Tone B signal input of right side
Tone C control of right side
Tone B control of right side
Tone A control of right side
Tone signal output of right side
L+R+C signal output
Analog ground for Rch
A select signal input of Rch
B select signal input of Rch
Signal output of Rch
Bus boost control output of Rch
Bus boost control input of Rch
Analog ground for SRch
A signal input of SRch
B signal input of SRch
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25
MCU I/F
B
AM
B
AM
B
A
B
A
B
SW2
SW1
A+
M
Cch Vol
SLch Vol
Lch Vol
BYPASS
TONE
Bus boost
0/6/10dB
0/6/10dB
0/6/10dB
L+R+C
0/-6dB
ATT
10/2dB
B
A
M
BA
M
BA
B
A
BSW2
SW1
A
M
SWch Vol
SRch Vol
Rch Vol
BYPASS
TONE
Bus boost
0/6/10dB
0/6/10dB
0/6/10dB
0/-6dB
ATT 10/2dB
65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

1-13
RX-E112RSL/RX-E111RSL
2. Pin function (2/2)
Pin No.
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
I/O
O
-
-
-
I
I
O
-
-
I
I
I
-
-
-
O
I
I
-
-
-
O
I
I
-
I
O
O
I
I
-
-
O
I
I
I
I
I
O
O
O
I
-
-
I
I
I
I
I
I
-
-
I
I
I
I
I
I
-
Symbol
SRchOUT
AGND
NC
NC
SWchAIN
SWchBIN
SWchOUT
AVSS
DVDD
CLOCK
DATA
LATCH
DGND
AGND
AGND
CchOUT
CchBIN
CchAIN
NC
NC
AGND
SLchOUT
SLchBIN
SLchAIN
AGND
LchBBI
LchBBO
LchOUT
LchBIN
LchAIN
AGND
NC
TONEOUT2
TCA2
TCB2
TCC2
TINB2
TINA2
SELOUT2
RECOUT2A
RECOUT2B
ING2
NC
NC
INF2
INE2
IND2
INC2
INB2
INA2
AVDD
AVDD
INA1
INB1
INC1
IND1
INE1
ING1
NC
Function
Signal output of SRch
Analog ground for SWch
No connect
No connect
A select signal input of SWch
B select signal input of SWch
Signal output of SWch
Analog power supply
Digital power supply
Digital clock input
Digital data input
Digital latch input
Digital ground
Analog ground
Analog ground
Signal output of Cch
B select signal input of Cch
A select signal input of Cch
No connect
No connect
Analog ground for Cch
Signal output of SLch
B select signal input of SLch
A select signal input of SLch
Analog ground for SLch
Bus boost control input of Lch
bus boost control output of Lch
Signal output of Lch
B select signal input of Lch
A select signal input of Lch
Analog ground for Lch
No connect
Tone signal output of left side
Tone A control of left side
Tone B control of left side
Tone C control of left side
Tone B signal input of left side
Tone A signal input of left side
Signal output after 0/-6dB of left side
A through signal output of left side
B through signal output of left side
G signal input of left side input selector
No connector
No connector
F signal input of left side input selector
E signal input of left side input selector
D signal input of left side input selector
C signal input of left side input selector
B signal input of left side input selector
A signal input of left side input selector
Analog power supply
Analog power supply
A signal input of right side input selector
B signal input of right side input selector
C signal input of right side input selector
D signal input of right side input selector
E signal input of right side input selector
F signal input of right side input selector
No connect

RX-E112RSL/RX-E111RSL
1-14
2. Pin function
Pin
No. Symbol I/O Function Function
I/O
Symbol
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
FM IN
AM MIX
FM IF
AM IF
GND
TUNED
STEREO
VCC
FM DET
AM SD
FM VSM
AM VSM
MUTE
FM/AM
MONO/ST O
I
I/O
O
O
I
O
I
I
I
O
O
III
II
This is an input terminal of FM IF
signal.
This is an out put terminal for AM
mixer.
Bypass of FM IF
Input of AM IF Signal.
This is the device ground terminal.
When the set is tuning, this terminal
becomes "L".
Stereo indicator output. Stereo "L",
Mono: "H"
This is the power supply terminal.
FM detect transformer.
This is a terminal of AM ceramic filter.
Adjust FM SD sensitivity.
Adjust AM SD sensitivity.
When the signal of IF REQ of IC121(
LC72131) appear, the signal of FM/AM
IF output. //Muting control input.
Change over the FM/AM input.
"H" :FM, "L" : AM
Stereo : "H", Mono: "L"
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30 OSC BUFFER
AM OSC
REG
AM RF
AFC
AM AGC
O
I
O
I
I
I
AM Local oscillation Signal output.
This is a terminal of AM Local
oscillation circuit.
Register value between pin 26 and pin28
desides the frequency width of the
input signal.
AM RF signal input.
This is an output terminal of voltage
for FM-AFC.
This is an AGC voltage input terminal
for AM
O
O
I
O
AM detection output.
FM detection output.
Mpx input terminal
O
O
I
Left channel signal output.
Right channel signal output.
Input terminal of the left channel post
AMP.
Input terminal of the right channel
post AMP.
I
O
Mpx Left channel signal output.
Mpx Right channel signal output.
L OUT
R OUT
L IN
R IN
RO
LO
IF IN
FM OUT
AM DET
1. Block diagram
ALC
BUFF
AM
OSC
REG
AM
MIX FM
RF.AMP
AGC
AM IF DET
SD
COMP AM
S-METER
FM
S-METER
FM IF PM
DET
S-CLRVE AM/FM
IF-BUFF TUNING
DRIVE
GND VCC
STEREO
DRIVE
MUTE
DECODER
ANIT-BIRDIE
STEREO
5N
SW
P-DET
PILOT
DET
FF
19k
FF
19k
FF
38k
VCO
384KHz /
2/
LS
30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
1234678910 11 12 13 14 15
5
LA1838(IC102) : FM AM IF amp. & detector, FM MPX decoder

1-15
RX-E112RSL/RX-E111RSL
1. Pin layout 1
2
3
4
5
6
7
8
9
10
11
22
21
20
19
18
17
16
15
14
13
12
XT
FM/AM
CE
DI
CLOCK
DO
FM/ST/VCO
AM/FM
SDIN
XT
GND
LPFOUT
LPFIN
PD
VCC
FMIN
AMIN
IFCONT
IFIN
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
Pin
No.
12
13
14
15
16
17
18
19
20
21
22
Symbol
XT
FM/AM
CE
DI
CLOCK
DO
FM/ST/VCO
AM/FM
LW
MW
SDIN
Symbol
IFIN
IFCONT
AMIN
FMIN
VCC
PD
LPFIN
LPFOUT
GND
XT
Function
X'tal oscillator connect (75kHz)
LOW:FM mode
When data output/input for 4pin(input) and
6pin(output): H
Input for receive the serial data from
controller
Sync signal input use
Data output for Controller
Output port
"Low": MW mode
Open state after the power on reset
Input/output port
Input/output port
Data input/output
Function
IF counter signal input
IF signal output
Not use
AM Local OSC signal output
FM Local OSC signal input
Power suplly(VDD=4.5-5.5V)
When power ON:Reset circuit move
PLL charge pump output(H: Local OSC
frequency Height than Reference frequency.
L: Low Agreement: Height impedance)
Input for active lowpassfilter of PLL
Output for active lowpassfilter of PLL
Connected to GND
X'tal oscillator(75KHz)
I/O
I
O
I
I
I
O
O
O
I/O
I/O
I/O
I/O
I
O
-
I
I
-
O
I
O
-
I
Reference
Driver Phase
Detector
Charge Pump
Unlock
Detector
Universal
Counter
Swallow Counter
1/16,1/17 4bit
12bit
Programmable
DriverS
Swallow Counter
1/16,1/17 4bit
Data Shift Register & Latch
Power
on
Reset
C2B
I/F
1/2
782 11 13
21
17
6
5
4
3
15
16
22
118
19
20
12
2. Block diagram
3. Pin function
LC72136N (IC121) : PLL frequency synthesizer

RX-E112RSL/RX-E111RSL
1-16
1
2
3
4
5
6
7
8
9
18
17
16
15
14
13
12
11
10
P5
P6
P7
P8
Vss
P9
P10
p11
P12
VDD
P4
P3
P2
P1
CLR
STB
CLK
DATA
1~4
5
6~9
10
11
12
13
14
15
16~17
18
P5, P6, P7, P8
Vss
P9, P10, P11, P12
DATA
CLK
STB
CLR
P1
P2
P3, p4,
V
DD
O
-
O
O
I
I
I
O
O
O
-
Parallel conversion data output terminal.
Connect to GND.
Parallel conversion data output terminal.
Serial data input terminal.
Clock signal input terminal.
Strobe signal input terminal.
Clear signal input terminal.
Parallel conversion data output terminal.
Parallel conversion data output terminal.
Parallel conversion data output terminal.
Power supply terminal.
PIN No. I/O Function
3.Pin function
1.Pin layout
Symbol
NJU3713 (IC402) : L.E.D. driver
DATA
CLK
STB
CLR
P1
P2
P3
P4
P5
P11
P12
Shift
resistor Latch
circuit
Control Circuit
2.Block diagram

1-17
RX-E112RSL/RX-E111RSL
3. Block diagram
1. Pin layout 2. Pin function
SAA6588 (IC191) : RDS detector
MRO
NC
GND
OSCO
OSCI
VSSD
VDDD
DAVN
SDA
SCL
NC
CIN
SCOUT
Vref
MPX
VSSA
VDDA
NC
GND
NC
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
57 kHz
8th ORDER
BAND-PASS
CLOCK
COMPARATOR RDS/RDBS
DEMODULATOR RDS/RDBS DECODER
PAUSE
DETECTOR MULTI-PATH DETECTOR SIGNAL QUALITY
DETECTOR INTERFACE
REGISTER
POWER
SUPPLY
AND RESET
TEST
CONTROL OSCILLATOR
AND CLOCK IC-BUS SLAVE TRANSCEIVER
16
13
20
14
15 17
18 19
3154612
8
11
2
9
10
7
MPX
AFIN
LVIN
VDDA
VSSA Vref TCON MRO OSCI OSCO VSSD MAD
SCL
SDA
MPTH
PSWN
DAVN
VDDDCIN
SCOUT
MRO
NC
GND
OSCO
OSCI
VSSD
VDDD
DAVN
SDA
SCL
NC
GND
NC
VDDA
VSSA
MPX
Vref
SCOUT
CIN
NC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
FunctionI/OSymbol
Pin
No.
Multi-path rectifier output
Non connect
Test control input pin
Oscillator output
Oscillator input
Digital ground (0V)
Digital power supply (5V)
Data available output (active LOW)
IC-bus serial data I/O
IC-bus serial clock input
Non connect
Connect to ground
Non connect
Analog power supply (5V)
Connect to ground
Multiplex input signal
Reference voltage output
Band-pass filter output
Comparator output
Level input
O
-
I
O
I
-
-
O
I/O
I
-
-
-
-
-
I
O
O
O
I

RX-E112RSL/RX-E111RSL
1-18
1. Block diagram
2. Pin function
DLCKS pin
L
L
H
H
DLON pin
L
H
L
H
DLL clock setting
SCKI input (DLL circuit OFF)
Four times XI clock
Three times XI clock
Six times XI clock
Pin No.
1
2
3
4
5
6
7
8~11
12
13
14
15
16~19
20
21
22, 23
24
25
26
27, 28
29
30
31
32,33
34
35
36
37
38
39
40
Symbol
RST
MIMD
MICS
MILP
MIDIO
MICK
MIACK
FI0~3
IRQ
VSS
LRCKA
BCKA
SDO0~3
LRCKB
BCKB
SDI0, 1
VDD
LRCKOA
BCKOA
TEST0,1
LRCKOB
BCKOB
TXO
TEST2,3
RX
VSS
TSTSUB0
FCONT
TSTSUB1
TSTSUB2
PDO
I/O
I
I
I
I
I/O
I
O
I
I
-
I
I
O
I
I
I
-
O
O
I
O
O
O
I
I
-
I
O
I
O
Function
Reset signal input terminal
(L:reset H:nomal operation)
Mode select input for MCU interface
(L:serial H:IC bus)
Chip select input for MCU interface
Latch pulse input for MCU interface
Data I/O for MCU interface
Clock input for MCU interface
Acknowledge output for MCU interface
Flag input 0~3
Interrupt input
Digital ground
LR clock input-A for audio interface
Bit clock input-A for audio interface
Data output-0~3 for audio interface
LR clock input-B for audio interface
Bit clock input-B for audio interface
Data input-0, 1 for audio interface
Digital power supply
LR clock output-A for audio interface
Bit clock output-A for audio interface
Test input-0, 1 (L:test H:nomal operation)
LR clock output-B for audio interface
Bit clock output-B for audio interface
SPDIF output
Test input-2, 3 (L:test H:nomal operation)
SPDIF input
Digital ground
Test sub input-0 (L:test H:nomal operation)
Frequency control output forVCO circuit
Test sub input-1, 2
(L:test H:nomal operation)
Phase detect signal output
Pin No.
41
42
43
44
45
46
47
48
49
50
51
52
53
54~61
62
63~70
71
72~80
81
82~89
90
91
92
93
94
95
96
97
98, 99
100
Symbol
VDDA
PLON
AMPI
AMPO
CKI
VSSA
CKO
LOCK
VSS
WR
OE
CE
VDD
IO7~0
VSS
AD0~7
VDD
AD8~16
VSS
PO0~7
VDDDL
LPFO
DLON
DLCKS
SCKO
VSSDL
SCKI
VSSX
XO,XI
VDDX
I/O
-
I
I
O
I
-
O
O
-
O
O
O
-
I/O
-
O
-
O
-
O
-
O
I
O
-
I
-
I/O
-
Function
Analog power supply
Clock selection input
(L:external clock H:VCO clock)
AMP.input for LPF
AMP.output for LPF
External clock input
Analog ground
DIR clock output
VCO lock output
Gigtal ground
Writing signal output for extrenal SRAM
Enable signal output for external SRAM
Chip enable signal output for external SRAM
Digital power supply
Data I/O-7~0 for external SRAM
Digital ground
Address output-0~7 for external SRAM
Digital power supply
Address output-8~16 for external SRAM
Digital ground
General output port-0~7
Power supply for DLL circuit
LPF output for DLL circuit
*
ASP clock output
Ground for DLL circuit
External system clock input
Ground for crysoal oscillator
Crystal oscillator I/O
Digital power supply
TC9446F-025 (IC631) : Audio digital processor
*
Program
Program
Instruction
control Instruction
Detector
Interrupt
Audio
Interface
DIR
DLL
Timer
Timing
MCU interface
40 bit
1 bus
MX MY
MAC ALU
MZ AX
A1
Round/Limiter Round/Limiter
A0 A2 A3
AY
X bus
Y bus
4
4
8POn
FIn
TXO
8
3
17
2
ROM
4k word x3 XRAM
4k word YRAM
4k word ERAM
4k word
Address Operater
x2
X pointer
register
Register
X0, X1, X2
Y0,Y2, Y3
Y pointer
register C pointer
register
Bus switch
External SRAM
interface
CE, OE, WR
ADn
IOn
SCKO
SCKI
DLON
LPFO
SDIn
SDOn
L
RCK/BCK
RX
LOCK
RST
MIMD
MICS
MILP
MIDIO
MICK
MIACK
IRQ
General output
port
Flag
DIT
CROM
4k word
RAM
128 word

1-19
RX-E112RSL/RX-E111RSL
BA033LBSG (IC683) : Standard voltage power supply
1. Block diagram
1. Block diagram
1. Block diagram 2.Truth table
Standard voltage
Vcc 1
5 OUT
4 C
CLT 3
GND 2
Current restriction
circuit
Temperature
protection circuit
IN1
CTL A
VOUT 1
V
CC
IN2
CTL B
logic
logic
MONITOR OUT
GND
IN5
GND
IN4
CTL E
IN3
CTL D
16
15
14
13
12
11
VOUT 2
CTL C
1
2
3
4
5
6
7
8
A B E MONITOR OUT
LL
*
IN1
HL
*
IN2
LH
*
IN3
H H L IN4
HHH IN5
C D E VOUT1
LL
*
--
HL
*
IN2
LH
*
IN3
H H L IN4
HHH IN5
C D E VOUT2
LL
*
IN1
HL
*
--
LH
*
IN3
H H L IN4
H H H IN5
10
11
1OUT1
2-IN1
3+IN1
4
8
7
6
5V
EE
V CC
OUT2
-IN2
+IN2
2
1
-
+-
+
BA15218F (IC503, IC609, IC610, IC650, IC651, IC661, IC690, IC691) : OP amp.
BA7625 (IC514) : Video selector

RX-E112RSL/RX-E111RSL
1-20
TC74HC08AF (IC611) : AND gate
2.Truth table
2.Truth table
1A
1B
1Y
2A
2B
2Y
GND
A
L
L
H
H
B
L
H
L
H
Y
L
L
L
H
1
2
3
4
5
6
7
14
13
12
11
10
9
8
Vcc
4B
4A
4Y
3B
3A
3Y
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
1Y
0Y
1Z
Z-COM
0Z
INH
V
EE
GND
Vcc
Y-COM
X-COM
1X
0X
A
B
C
TC74HC4053A (IC515) : Multiplexer
INHIBIT
L
L
L
L
L
L
L
L
H
C
L
L
L
L
H
H
H
H
X
B
L
L
H
H
L
L
H
H
X
A
L
H
L
H
L
H
L
H
X
0X, 0Y, 0Z
1X, 0Y, 0Z
0X, 1Y, 0Z
1X, 1Y, 0Z
0X, 0Y, 1Z
1X, 0Y, 1Z
0X, 1Y, 1Z
1X, 1Y, 1Z
NONE
CONTROL INPUTS "ON" CHANNEL
X: Don't Care.
TC74HC4072AF (IC612) : OR gate
1. Pin layout
1. Pin layout
1. Pin layout
2.Truth table
1Y
1A
1B
1C
1D
NC
GND
A
H
X
X
X
L
B
X
H
X
X
L
C
X
X
H
X
L
D
X
X
X
H
L
Y
H
H
H
H
L
1
2
3
4
5
6
7
14
13
12
11
10
9
8
Vcc
2Y
2D
2C
2B
2A
NC
X : Don't care
