DLA-RS46U
Note: Optional 3D Glasses (PK-AG3) and 3D Synchro Emitter (PK-EM2) are required for viewing images in 3D.
3D Enabled D-ILA
Home Theater Projector
• 1080p three chip 3D enabled D-ILA projector
• Native contrast ratio of 50,000:1
• 1.4 to 2.8:1 motorized zoom lens with Horizontal
and Vertical offset
• Highly customizable built-in 2D to 3D converter
creates dynamic 3D images from 2D video content
• Lens memory function memorizes 5 positions for
focus, zoom and shift
• Three screen adjustment modes for color
optimization on various screen types
• Accepts all modern 3D formats (Blu-ray, side-by-side,
top-and-bottom)
• Control: LAN / RS-232C / IR / 12 V Screen Trigger
Output / Remote control with 3D functions
• New Remote Control App for smartphones and tablets
• 230 Watt NSH Illumination System (lamp life up to
4,000 hours in Low mode)
• 2 Year Warranty
The affordable entry level DLA-RS46 makes it possible for anyone to enjoy the
thrilling realism of a D-ILA home theater projector. With a native contrast ratio of
50,000:1 and renowned D-ILA image quality, the DLA-RS46 is unquestionably
JVC's best value 3D projector to date.

50,000:1 Native Contrast Ratio for High Impact Images
JVC’s D-ILA device and advanced optical system projects a high dynamic range image
with a Native Contrast Ratio of 50,000:1. The DLA-RS46 produces exceptional images
even in higher ambient light conditions making it ideal for media rooms and great room
areas. Viewers can enjoy bright, vivid, and crystal clear image reproduction.
Lens Memory Function
The upgraded Lens Memory Function stores up to five separate lens adjustments for
zoom, focus and horizontal and vertical shift that can be easily recalled when needed.
Focus, zoom (size) and shift (displayed position) characteristics can be recorded for
video content in various aspect ratios such as a Cinema Scope (2.35:1), 1.85:1 or
standard 16:9. The settings can be recalled via the remote control.
Three Screen Adjustment Modes*
Screen Adjustment modes on the DLA-RS46 are developed by analyzing the RGB
reflective characteristics of a variety of screen surfaces to ensure optimum correction
levels. Viewers can select from one of three parameters to achieve a more accurate
picture with natural color balance.
*Please refer to the JVC website for a comparison table of primary screens and adjustment modes.
Go after that car, don’t lose him!
Lens memory examples (when using CinemaScope screen)
Memory 1: Standard 16:9 Memory 2: CinemaScope size Memory 3: CinemaScope size
w/subtitles outside of the screen
D-ILA 3D Projection*
JVC’s D-ILA driving method reproduces superlative 3D images with vivid colors and
reduced L/R crosstalk, and we’ve improved the conversion accuracy of the optical
engine and 3D glasses to achieve a 20% increase in brightness over previous models.
• Crosstalk Canceling: The innovative Crosstalk Canceling function significantly
reduces crosstalk from critical intensity levels that are likely to cause this phenomenon.
The video signal is analyzed for the
left and right eyes and then a
correctionis applied which levels via
JVC advanced proprietary algorithms
ensuring a better 3D experience.
• 2D-3D Conversion: The real-time 2D-3D converter featured on JVC’s Broadcast
Quality IF-2D3D1 Professional 3D Image Processor has been ported over for home
projector use and is featured on the DLA-RS46. This means that 2D video recorded on
camcorders and TV broadcasts can be converted into 3D video instantaneously for home
stereoscopic viewing enjoyment. Other
adjustment functions are available such
as Depth Adjustment for matching 3D
effects to the original source or viewer
preferences, and adjustment of subtitle
distortion can be chosen during 2D-3D conversion.
*The optional 3D Synchro Emitter and 3D glasses are required to view 3D images.
Crosstalk Canceling OFF Crosstalk Canceling ON
DISTRIBUTED BY referenceseries.com
Printed in the U.S.A.
"JVC" is the trademark or registered trademark of JVC KENWOOD Corporation.
Specifications
• The projector is equipped with a new super-high pressure mercury lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time. • Please note that, depending on how the
projector is used, there can be considerable difference between individual lamps regarding how many hours they will operate before requiring replacement. • An additional payment is required for installation of a new lamp, if necessary.
• The projector lamp requires periodic replacement and is not covered by warranty. • Please be aware that, because the D-ILA device is manufactured using highly advanced technologies, 0.01% or fewer of the pixels may be non-performing
(always on or off).
Design and specifications are subject to change without notice. All pictures on this brochure are simulated. Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the U.S. and/or other countries. HDMI, the HDMI
logo and High-Definition Multimedia Interface are registered trademarks of HDMI Licensing LLC. All other brand or product names may be trademarks and/or registered trademarks of their respective owners. Any rights not expressly granted
herein are reserved.
Copyright © 2014, JVC KENWOOD Corporation. All Rights Reserved.
Notes about viewing 3D video content
• The optional 3D Synchro Emitter and 3D glasses are required to view 3D images from the D-ILA projectors. 3D video
software (3D media or output of 3D broadcasts) and a 3D-compatible video player are also required. • Perception of 3D
images will vary with individual viewers. • Stop viewing 3D images immediately if any discomfort such as headaches,
dizziness, eye fatigue, etc. occurs. • Viewing of 3D images by children under the age of ve is not recommended. • Read
the Safety Precautions in the User Manual carefully before viewing any 3D source.
Optional Equipment Connectors
PK-EM2
RF 3D Synchro
Emitter
PK-L2312U
User replaceable Lamp
PK-AG3
RF 3D Glasses
Battery-operated
18 1/2" | 472
3/16" | 5
17 7/8" | 455
13 1/4" | 337
11 7/16" | 290
3 9/16"
91
4 9/16"
117
2 1/4" | 58
3 1/8" | 79 1 7/8" | 48
1 9/16" | 41 1 1/2" | 37
2
1
/
8
" | 55
1 1/4"
45 1 1/4" 45
7
/
16
" | 11 5" | 128
3
1
/
2
"
80
18 9/16" | 472
ø60
1"
24
7" | 179
Top
Front
Bottom
Side
External Dimensions (unit: inches | mm) DLA-RS46
Imaging device 0.7 inch Full HD D-ILA (1920 x 1080) x3
Resolution 1920 x 1080
Lens 2X Zoom & Focus: Motorized
f=21.4-42.8mm / F=3.2-4
Lens Shift ±80% Vertical and ±34% Horizontal (motorized)
Light Source NSH 230W Lamp
(lamp life: approx. 4000 hours when the lamp is in Low mode)
Contrast Ratio Native: 50,000:1
Connectors
HDMI
3D Sync
2 (3D/Deep Color/CEC compatible)
Component 1 (RCA: Y, Pb/Cb, Pr/Cr)
LAN (RJ-45) 1
RS-232C 1 (D-sub 9pin)
1 (Mini DIN 3pin)
Control and Firmware Upgrade 1
Trigger 1 (Mini jack, DC12V/100mA)
Remote 1 (Stereo Mini Jack)
3D Sync 1 (Mini DIN 3pin)
Video Input
Signal Format
Digital
Analog
480i/p, 576i/p, 720p 60/50, 1080i 60/50, 1080p 60/50/24
Dimensions (WxHxD-inches) 17 7/8 x 7 x 18 9/16
32.63
480i/p, 576i/p, 720p 60/50, 1080i 60/50
PC Input Signal
Format
HDMI VGA/SVGA/XGA/WXGA/WXGA+/SXGA/
WSXGA+/WUXGA
Weight (net) (lbs)
Smart-phone Remote Control App
Now, JVC D-ILA projectors can be controlled from your smartphone
or tablet with a free remote control app. This app features an intuitive
graphical UI and exclusive controls that make operations even easier.
Additionally, there are built-in help functions for smoother operation.
