JVC KD-DV4402 User manual

ENGLISH
DVD/CD RECEIVER
KD-DV4402/KD-DV4401
For installation and connections, refer to the separate manual.
INSTRUCTIONS
BEDIENUNGSANLEITUNG
GET0514-001A
[E]
For canceling the display demonstration, see page 5.
Downloaded from Caradio-Manual.com Manuals

ENGLISH
2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
This product incorporates copyright protection
technology that is protected by U. . patents and
other intellectual property rights. Use of this
copyright protection technology must be authorized
by Macrovision, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• top the car before performing any complicated
operations.
Temperature insi e the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
[European Union only]
WARNINGS:
(To prevent acci ents an amage)
• DO NOT install any unit or wire any cable in
a location where;
– it may obstruct the steering wheel an
gearshift lever operations.
– it may obstruct the operation of safety
evices such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while riving.
• If you nee to operate the unit while
riving, be sure to look aroun carefully.
• The river must not watch the monitor
while riving.
If the parking brake is not engage ,
“DRIVER MUST NOT WATCH THE MONITOR
WHILE DRIVING.” appears on the monitor,
an no playback picture will be shown.
– This warning appears only when the
parking brake lea is connecte to the
parking brake system built in the car
(refer to the Installation/Connection
Manual).
EN02-05_DV4402_001A_f.indd 2EN02-05_DV4402_001A_f.indd 2 12/12/07 11:54:47 AM12/12/07 11:54:47 AM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
3
How to reset your unit
• Your preset adjustments will also be erased.
How to forcibly eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
How to use functions mode
If you press M MODE, the unit goes into functions mode,
then the number buttons and 5/∞ buttons work as
different function buttons.
Caution on volume setting
Discs produce very little noise compared with other
sources. ower the volume before playing a disc to
avoid damaging the speakers by the sudden increase of
the output level.
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not be recommended.
CONTENTS
INTRODUCTIONS
Playable disc type ........................................ 4
Preparation .................................................. 5
OPERATIONS
Basic operations
• Using the control panel ............................... 6
• Using the remote controller (RM-RK252) .... 7
istening to the radio ................................... 10
Searching for FM RDS programme
—PTY Search ........................................... 11
Disc operations ............................................. 13
• Operations using the control panel ............. 14
• Operations using the remote controller
(RM-RK252) ................................................ 16
EXTERNAL DEVICES
istening to the other external
components .............................................. 22
SETTINGS
Selecting a preset sound mode .................... 22
General settings — PSM ............................. 24
Disc setup menu ........................................... 26
REFERENCES
More about this unit .................................... 28
Maintenance ................................................ 33
Troubleshooting ........................................... 34
Specifications ............................................... 36
[Within 5 seconds...]
For security reasons, a numbered ID card is provided
with this unit, and the same ID number is imprinted on
the unit’s chassis. Keep the card in a safe place, as it will
help the authorities to identify your unit if stolen.
EN02-05_DV4402_001A_f.indd 3EN02-05_DV4402_001A_f.indd 3 12/12/07 5:46:08 PM12/12/07 5:46:08 PM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
4
Playable disc type
Disc type Recor ing format, file type, etc Playable
DVD DVD-Video (Region Code : 2) *1
DVD-Audio
DVD-ROM
DVD Recor able/Rewritable
(DVD-R/-RW *2, +R/+RW *3)
• DVD Video: UDF bridge
• DVD-VR
• DivX/MPEG-1/MPEG-2/MP3/
WMA/WAV: I O 9660 level 1,
level 2, Romeo, Joliet
DVD-Video
DVD-VR
DivX/MPEG1/MPEG2
MP3/WMA/WAV
AAC
JPEG/MPEG4
DVD+VR
DVD-RAM
Dual Disc DVD side
Non-DVD side
CD/VCD Audio CD/CD Text (CD-DA)/DT -CD *4
VCD (Video CD)
VCD ( uper Video CD)
CD-ROM
CD-I (CD-I Ready)
CD Recor able/Rewritable
(CD-R/-RW)
• I O 9660 level 1, level 2, Romeo,
Joliet
CD-DA
VCD (Video CD)
DivX/MPEG1/MPEG2
MP3/WMA/WAV
AAC
JPEG/MPEG4
*1 If you insert a DVD Video disc of an incorrect Region ode, “REGION ODE ERROR” appears on the monitor.
*2 DVD-R recorded in multi-border format is also playable (except for dual layer discs). DVD-RW dual layer discs are not
playable.
*3 It is possible to play back finalized +R/+RW (Video format only) discs. +RW double layer discs are not playable.
*4 To reproduce DTS sound, use the DIGITAL OUT terminal (see also pages 27 and 31).
EN02-05_DV4402_001A_f.indd 4EN02-05_DV4402_001A_f.indd 4 12/12/07 11:54:58 AM12/12/07 11:54:58 AM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
5INTRODUCTIONS
Preparation
Cancel the isplay emonstration an set the clock
• ee also page 24.
1Turn on the power.
2Enter the PSM settings.
3Cancel the isplay emonstrations
elect “DEMO,” then “DEMO OFF.”
Set the clock
elect “CLOCK HOUR,” then adjust the hour.
elect “CLOCK MIN” (minute), then adjust the minute.
elect “24H/12H,” then “24 HOUR” or “12 HOUR.”
4Finish the proce ure.
When the power is turned off: Check the current clock time
When the power is turned on: Change the display information
In ication language:
In this manual, English indications are used for purposes of explanation. You can select the indication language
on the monitor on the “LANGUAGE” setting (see page 26).
Detaching the control panel Attaching the control panel
EN02-05_DV4402_001A_f.indd 5EN02-05_DV4402_001A_f.indd 5 12/12/07 11:55:00 AM12/12/07 11:55:00 AM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
6
Basic operations
Using the control panel
r • Adjust the sound mode.
• Enter the PSM settings [Hold].
t Enter functions mode.
• Press M MODE, then one of the following uttons
(within 5 seconds)...
EQ : Select the sound mode.
MO : Turn on/off monaural reception.
SSM : Automatic station presetting [Hold].
RPT : Select repeat play.
RND : Select random play.
5/∞ : Skip 10 chapters/tracks.
y • FM/AM: Select preset station.
• DISC: Select chapter/title/program/folder/track.
u AUX (auxiliary) input jack
* You cannot select “DISC” as the playback source if there
is no disc in the unit.
1 DISC: Select title/program/playlist/folder.
2 Eject disc.
3 • Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
4 Volume control [Turn].
5 Remote sensor
6 • FM/AM: Select the and.
• DISC: Start/pause play ack.
7 Loading slot
8 Display window
9 • Activate/deactivate TA Stand y Reception.
• Enter RDS programme search [HOLD].
p Change the display information.
q Detach the panel.
w Select the source.
FM/AM = DISC * = AUX IN = INE IN
= ( ack to the eginning)
e • FM/AM: Search for station.
• DISC: Select chapter/track.
EN06-13_DV4402_001A_f.indd 6EN06-13_DV4402_001A_f.indd 6 12/12/07 11:56:33 AM12/12/07 11:56:33 AM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
7OPERATIONS
Installing the battery
Insert the atteries into the remote controller y
matching the polarity (+ and –) correctly.
Caution:
Battery shall not e exposed to excessive heat such as
sunshine, fire, or the like.
Continued on the next page
Display window
1 Tr (track) indicator
2 Source display / Track num er / Folder num er /
Disc num er / Title num er / PBC indicator / Time
countdown indicator
3 DISC indicator
4 RDS indicators—AF, REG, TP, PTY
5 Play ack mode / item indicators— RND (random),
(disc), (folder), RPT (repeat)
6 Tuner reception indicators—ST (stereo),
MO (monaural)
7 Sound mode (c-EQ: custom equalizer) indicators
—CLASSIC, HIP HOP, JAZZ, ROCK, POPS, USER
8 LOUD (loudness) indicator
9 EQ (equalizer) indicator
p Disc information indicators—
TAG (Tag information), (folder), (track/file)
q Main display (Time, menu, play ack information)
Using the remote controller (RM-RK252)
R03/LR03/AAA
• If the effectiveness of the remote controller
decreases, replace oth atteries.
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to right light
(direct sunlight or artificial lighting).
EN06-13_DV4402_001A_f.indd 7EN06-13_DV4402_001A_f.indd 7 12/12/07 11:56:40 AM12/12/07 11:56:40 AM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
8
1 button
• Turns the power on if pressed riefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
2 5/∞ buttons
• FM/AM: Selects the preset stations.
• DISC:
– DVD-Video: Selects the title.
– DVD-VR: Selects the program/playlist.
– DivX/MPEG Video/MP3/WMA/WAV: Selects
the folders if included.
4 / ¢ buttons
• FM/AM:
– Searches for stations automatically if pressed
riefly.
– Searches for stations manually if pressed and
held.
• DISC:
– Reverse skip/forward skip if pressed riefly.
– Reverse search/forward search if pressed and
held.
3 VO (volume) + / – buttons
• Adjusts the volume level.
2nd VO (volume) buttons
• Not applica le for this unit.
4 * ASPECT button
• Not applica le for this unit.
5 PHONE button
• Not applica le for this unit.
6 * SETUP button
• Enters disc setup menu (during stop).
7 * TOP M (menu) button
• DVD-Video/DivX: Shows the disc menu.
• DVD-VR: Shows the Original Program screen.
• VCD: Resumes PBC play ack.
8 * OSD (on-screen display) button
• Shows the on-screen ar.
9 SHIFT button
• Functions with other uttons.
EN06-13_DV4402_001A_f.indd 8EN06-13_DV4402_001A_f.indd 8 12/12/07 11:56:41 AM12/12/07 11:56:41 AM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
9OPERATIONS
i * DUA button
• Not applica le for this unit.
o SURROUND button
• Not applica le for this unit.
DIRECT button
• DISC: Enters direct search mode for chapter/
title/program/playlist/folder/track when pressed
with SHIFT utton (see page 16 for details).
C R (clear) button
• DISC: Erases the misentry when pressed with
SHIFT utton.
* Functions as number buttons * (asterisk) # (hatch)
when pressed with SHIFT button.
– FM AM: Selects the preset stations (1 – 6).
– DISC: Enters chapter title program playlist
folder track number after entering search
mode by pressing SHIFT and DIRECT (see
page 16 for details).
p DISP (display) button
• Changes the display information.
q 1 / ¡ buttons
• DVD-Video/VCD: Slow motion play ack (during
pause).
• DivX/MPEG Video/MP3/WMA/WAV: Reverse
search/forward search.
w SOURCE button
• Selects the source.
e 3 (play) / 8 (pause) button
• DISC: Starts/pauses play ack.
r (end call) button
• Not applica le for this unit.
BAND / 7 (stop) buttons
• FM/AM: Selects the ands.
• DISC: Stops play ack.
t * RETURN button
• VCD: Returns to the PBC menu.
y * MENU button
• DVD-Video/DivX: Shows the disc menu.
• DVD-VR: Shows the Playlist screen.
• VCD: Resumes PBC play ack.
u * % / fi buttons
• DVD-Video: Makes selection/settings.
@ / # buttons
• DVD-Video: Makes selection/settings.
• DivX/MPEG Video: Skips ack or forward y
a out five minutes.
ENT (enter) button
• Confirms selection.
EN06-13_DV4402_001A_f.indd 9EN06-13_DV4402_001A_f.indd 9 12/12/07 11:56:42 AM12/12/07 11:56:42 AM
Downloaded from Caradio-Manual.com Manuals

ENGLISH
10
When an FM stereo broadcast is
hard to receive
Reception improves, ut stereo effect will e lost.
• “MO” lights up on the display.
To restore the stereo effect, repeat the same
procedure. “MONO OFF” appears and the MO indicator
goes off.
FM station automatic presetting
— SSM (Strong-station Sequential
Memory)
You can preset up to six stations for each and.
1 While listening to an FM station...
2
Local FM stations with the strongest signals are
searched and stored automatically in the selected
FM and.
Listening to the radio
1Select “FM/AM.”
2Select the bands.
3Search for a station to listen—Auto Search.
Manual Search: Hold either one of the uttons until “M” flashes on the display, then press
it repeatedly.
• When receiving an FM stereo roadcast with sufficient signal strength, “ST” lights up
on the display.
Manual presetting
Ex.: Storing FM station of 92.50MHz into preset num er
4 of the FM1 and.
1
2
3
To listen to a preset station
Preset num er flashes for a while.
EN06-13_DV4402_001A_f.indd 10EN06-13_DV4402_001A_f.indd 10 12/12/07 11:56:43 AM12/12/07 11:56:43 AM
Downloaded from Caradio-Manual.com Manuals
