SERVICE MANUAL
AUDIO/VIDEO CONTROL RECEIVER
No.20881
Oct. 2000
COPYRIGHT 2000 VICTOR COMPANY OF JAPAN, LTD.
RX-7001PGD
A
UF
US
Australia
China
Singapore
Area Suffix
Contents
Safety precautions --------------------------------------------------------1-2
Disassembly method -----------------------------------------------------1-3
Adjustment method -------------------------------------------------------1-9
Description of major ICs -------------------------------------------------1-10
–+
RX-7001P AUDIO/VIDEO CONTROL RECEIVER
SPEAKERS
12
PHONES
SURROUND ON/OFF
DSP MODE
BALANCE/SURROUND
ADJUST
SEA MODE
SEA ADJUST SETTING
MULTI JOG
MASTER VOLUME
SOURCE SELECTOR
THEATER LIVE CLUB DANCE CLUB HALL PAVILION
INPUT
ANALOG/DIGITAL FM/AM TUNING TUNER PRESET
TUNER/SEA MEMORY FM MODE
DVD
TV SOUND/DBS PHONO
TAPE/MDVCR
FM
AM
CD
SOUND SELECT
INPUT ATT.
BASS BOOST ONETOUCHOPERATION
SOURCENAME
COMPULINK
Remote
STANDBY
STANDBY/ON
RM-SRX7001P REMOTE CONTROL
CONTROL
CHANNEL VOLUMETV VOL
STOP PAUSE
FF/
/REW
VCR
TV/VIDEO TAPE/MD MUTING
REC
PLAY
DVD DVD MUILTI CD TAPE/MD
TV/DBS PHONO FM/AM
VCR
ANALOG/DIGITAL
SURROUND CENTER
SURROUND
TEST REAR-L
CD-DISC
MODE
ON/OFF
EFFECT REAR-R
SOUND SEA MODE
SUBWOOFER
RETURN
SET
MENU
AUDIO/
TV/VCR
EXIT
TEXT
DISPLAY
SLEEP
123
456
7
/P 89
10
0
+10
100+FM MODE
CATV/DBS
MENUMENU
ENTERENTER
TV/CATV/DBS VCR
TUNING DOWN UP
RX-7001PGD

RX-7001PGD
Safety Precautions
1.This design of this product contains special hardware and many circuits and components specially
for safety purposes. For continued protection, no changes should be made to the original design
unless authorized in writing by the manufacturer. Replacement parts must be identical to those
used in the original circuits. Services should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of
the product should not be made. Any design alterations or additions will void the manufacturer`s
warranty and will further relieve the manufacture of responsibility for personal injury or property
damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics.
These characteristics are often not evident from visual inspection nor can the protection afforded
by them necessarily be obtained by using replacement components rated for higher voltage,
wattage, etc. Replacement parts which have these special safety characteristics are identified in
the Parts List of Service Manual. Electrical components having such features are identified by
shading on the schematics and by ( ) on the Parts List in the Service Manual. The use of a
substitute replacement which does not have the same safety characteristics as the recommended
replacement parts shown in the Parts List of Service Manual may create shock, fire, or other
hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the
like to be separated from live parts, high temperature parts, moving parts and/or sharp edges
for the prevention of electric shock and fire hazard. When service is required, the original lead
routing and dress should be observed, and it should be confirmed that they have been returned
to normal, after re-assembling.
5. Leakage currnet check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts
of the product (antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control
shafts, etc.) to be sure the product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure
the leakage current from each exposed metal parts of the cabinet , particularly any exposed
metal part having a return path to the chassis, to a known good earth ground. Any leakage
current must not exceed 0.5mA AC (r.m.s.)
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms
per volt or more sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by
a 0.15 F AC-type capacitor between an exposed
metal part and a known good earth ground.
Measure the AC voltage across the resistor with the
AC voltmeter.
Move the resistor connection to eachexposed metal
part, particularly any exposed metal part having a
return path to the chassis, and meausre the AC
voltage across the resistor. Now, reverse the plug in
the AC outlet and repeat each measurement. voltage
measured Any must not exceed 0.75 V AC (r.m.s.).
This corresponds to 0.5 mA AC (r.m.s.).
Warning
1.This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
CAUTION
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
1-2

RX-7001PGD
1-3
Remove the four screws A attaching the top cover
on both sides of the body.
Remove the three screws B on the back of the body.
Remove the top cover from behind in the direction of
the arrow while pulling both sides outward.
1.
2.
3.
Disassembly method
Removing the top cover (See Fig.1)
Prior to performing the following procedure, remove
the top cover.
Remove the power cord stopper from the rear panel
by moving it in the direction of the arrow.
Remove the twenty-eight screws E attaching the
each boards to the rear panel on the back of the
body.
Remove the three screws F attaching the rear panel
on the back of the body.
1.
2.
3.
Removing the rear panel (See Fig.4)
Prior to performing the following procedure, remove
the top cover.
Disconnect the card wire from connector CN400 on
the main board and CN402 on the power supply
board in the front panel assembly.
Cut off the tie band fixing the harness.
Disconnect the harness from connector CN202 on
the video board.
Remove the three screws C attaching the front
panel assembly.
Remove the five screws D attaching the front panel
assembly on the bottom of the body. Detach the front
panel assembly toward the front.
1.
2.
3.
4.
5.
Removing the front panel assembly
(See Fig.2 and 3)
Fig.1
Fig.2
Fig.3
Fig.4
A 2A 2
B
Top cover
C
Power supply
board
CN402
Main board
CN400
Tie band
Video board
CN202
D
E 3E 3
E 5
E 3
E 3E 2E
E
FE
E
F
F
Cord stopper
C
Front panel assembly
Front panel assembly
D
Rear panel
E

RX-7001PGD
1-4
Prior to performing the following procedure, remove
the top cover and the rear panel.
Cut off the tie band fixing the harness.
Disconnect the harness from connector CN202 on
the video board.
Disconnect the tuner board from connector CN101
on the main board.
Disconnect the SEA board and the audio board from
connector CN452, CN301and CN302 on the main
board.
Disconnect the V-audio board from connector CN303
on the main board.
Disconnect the relay board 4.Then, disconnect the
video board and the S-video board from connector
CN201 and CN241 on the main board.
Disconnect the DSP board from connector CN501
and CN601 on the main board while removing the
DSP board from the bracket fixing the lower part of
the DSP board at the same time.
Disconnect the compulink board from connector
CN255 on the main board.
1.
2.
3.
4.
5.
6.
7.
8.
Removing each board connected to the
rear side of the main board
(See Fig.5 to 9)
Fig.5
Fig.6
Fig.7
Fig.8
Fig.8
Fig.8
Fig.9
CN202
Main board
CN101
Tie band
V-audio board
S-video board
Video board
Tuner board Audio board
SEA board
Main board
CN452 Main board
CN302,CN301
Audio board
V-audio board
Main board
CN303
CN301
CN452
CN302
Relay board 4
S-video board
Video board
Main board
CN241
CN303 Main board
CN201
Compulink board
Main board
CN255
Main board
CN601
DSP board
Main board
CN501
CN241
CN201
Bracket

RX-7001PGD
1-5
Prior to performing the following procedure, remove
the top cover and the rear panel.
Removing the main board / regulator
board (See Fig.10 to 12)
It is not necessary to remove the
boards connected to the back of the
main board. But to disassemble the
main board and the power supply
board efficiently, remove them.
ATTENTION:
Disconnect the card wire from connector CN400 on
the main board.
Cut off the three tie bands fixing the harnesses.
Disconnect the harness from connector CN811 on
the power transformer board.
Disconnect the relay board 1,2 and 3 from the main
board and the power supply board.
Disconnect the harness from connector CN704,
CN821, CN901, CN711, CN712, CN931 and CN932.
Remove the screw G attaching the regulator board
to the heat sink cover.
Remove the four screws H attaching the main board
to the heat sink cover.
Remove the five screws I and the screw J attaching
the main board to the chassis base (The resistor
board will come off at the same time).
1.
2.
3.
4.
5.
6.
7.
8.
Prior to performing the following procedure, remove
the top cover.
Disconnect the harness from connector CN881 on
the resistor board.
Remove the screw J attaching the resistor board.
1.
2.
Removing the resistor board (See Fig.13)
Fig.10
Fig.11
Fig.12
Fig.13
Power supply
board
Tie band
Relay board 1
Main board
CN400
Relay board 2
Tie band
Main board
Relay
board 3
CN811
CN932 CN961
CN931
CN712
CN711
CN901 CN821 CN704
HHG
Regulator board
Resistor board
I
J
I
I
Main board
Power
transformer
Power
transformer
J
Resistor board
CN881
Main board
CN953

RX-7001PGD
1-6
Prior to performing the following procedure, remove
the top cover.
Cut off the four tie bands fixing the harnesses.
Disconnect the harnesses from connector CN711,
CN712, CN704 and CN901 on the main board
respectively.
Disconnect the harnesses from connector CN953 on
the SP terminal board.
Remove the four screws K and six screws L
attaching the amplifier board.
1.
2.
3.
4.
Removing the amplifier board
(See Fig.10 and 14)
Prior to performing the following procedure, remove
the top cover and the rear panel.
Unsolder the six harnesses connected to the Voltage
selector board.
1.
Removing the Voltage selector board
(See Fig.16)
Prior to performing the following procedures, remove
the top cover.
Unsolder the seven harnesses connected to the
power transformer.
Disconnect the harness from connector CN811 and
the harnesses connected to connector CN55 and
CN56 on the power transformer board.
Remove the four screws M attaching the power
transformer.
1.
2.
3.
Removing the power transformer
(See Fig.15)
Prior to performing the following procedure, remove
the top cover and the rear panel.
Remove the screw N attaching the power / fuse
board.
Unsolder the power cord and other harnesses
connected to the power / fuse board.
1.
2.
Removing the power / fuse board
(See Fig.17)
Fig.10
Fig.14
Fig.15
Fig.17
Power supply
board
Tie band
Relay board 1
Main board
CN400
Relay board 2
Tie band
Main board
Relay
board 3
CN811
CN932 CN961
CN931
CN712
CN711
CN901 CN821 CN704
Power
transformer
Amplifier board
LLL
KK
CN711 CN712 Tie band
M
M
Solder
CN55
CN56
CN811
Power
transformer
Solder
Power
transformer
N
Solder
Power / fuse board
Power cord
CN953
Fig.16
Power
transformer
Solder
Voltage selector board

RX-7001PGD
1-7
Prior to performing the following procedure, remove
the top cover and the front panel.
Remove the one nut attaching the headphone jack of
the power supply board on the front side of the body.
Disconnect the relay board 1, 2 and 3 from the
power supply board and the main board respectively.
Disconnect the harness connected to connector
CN55 and CN56 on the power transformer board (If
necessary, cut off the band fixing the harness on the
side of the base chassis).
Remove the four screws O attaching the power
supply board and pull out the power supply board
from the front bracket backward.
Unsolder the three harnesses connected to the
power supply board.
1.
2.
3.
4.
5.
Removing the power supply board
(See Fig.18 and 19)
Prior to performing the following procedure, remove
the top cover and the front panel assembly.
Pull out the volume knob on the front side of the front
panel and remove the nut attaching the system
control board.
Remove the six screws P attaching the system
control board on the back of the front panel and
disconnect the harness from connector CN422 on
the system control board.
Disconnect the harness from connector CN430 on
the power switch board.
Remove the five screws Q attaching the power
switch board.
1.
2.
3.
4.
Removing the system control board /
power switch board (See Fig.20 to 21)
Fig.18
Fig.19
Fig.20
Fig.21
Power supply board
Nut
Headphone jack
Tie band
Tie band
Relay board 1
Relay board 2
Relay board 3 Power transformer
Solder
O
O
O
Headphone jack
Solder
Power supply board
Front panel
Nut
Volume knob
System control board Power switch board
Front panel assembly
PQ
CN430
CN422
Q
P
P
CN55
CN56

RX-7001PGD
1-8
Prior to performing the following procedure, remove
the top cover, the front panel assembly and the
system control board.
Remove the six screws R attaching the operation
switch board on the back of the front panel.
On the back of the front panel, release the four joints
by pushing the joint tabs inward. Remove the
operation switch board toward the front.
Pull out the multi jog knob and the source selector
knob.
Remove the two screws S attaching the operation
switch board.
1.
2.
3.
4.
Removing the operation switch board
(See Fig.22 to 24)
Fig.22
Fig.23
Fig.24
Front panel R
R
RJoint
Multi jog knob
Source selector knob
S
Operation switch board

RX-7001PGD
1-9
Adjustment method
<Adjustment method>
1.Set the volume control to minimum during this adjustment.(No signal & No load)
2.Set the surround mode OFF.
2.Turn VR787 and VR788 fully counterclockwise to warm up before adjustment.
If the heat sink is already warm from previous use the correct adjustment can not be made.
3.For L-ch,connect a DC voltmeter between TP781's pin1 and pin2 (Lch)
And,connect it between pin3 and pin4(Rch).
4.30 minutes later after power on, adjust VR787 for L-ch, or VR788 for R-ch so that the DC voltmeter
value has 1mV~10mV.
1.Tuner range
FM 87.5MHz~108.0MHz
AM(MW) 530kHz~1710kHz
Tuner section
Power amplifier section
TP781
4321
Lch
Rch
VR787 (Lch)
VR788 (Rch)
Heat sink Main board
Adjustment of idling current
Measurement location TP781
Adjustment part VR787(Lch) , VR788(Rch)
Attention
This adjustment does not obtain a correct adjustment value immediately after the amplifier is
used (state that an internal temperature has risen).
Please adjust immediately after using the amplifier after turning off the power supply of the
amplifier and falling an internal temperature.
* It is not abnormal though the idling current might not become 0mA even if it is finished to turn variable
resistance (VR787,VR788) in the direction of counterclockwise.

RX-7001PGD
1-10
1
2
3
4
5
6
7
8
9
10
11
33
32
31
30
29
28
27
26
25
24
23
12 13 14 15 16 17 18 19 20 21 22
44 43 42 41 40 39 38 37 36 35 34
SDOS
OCKS
MIS
BCLK
LRCK
SDTI1
SDTI2
SDTI3
SDTO
DAUX
DFS
VREFL
RIN+
RIN-
LIN+
LIN-
ROUT1
LOUT1
ROUT2
LOUT2
ROUT3
LOUT3
DEM1 DEM0 MCKO DVDD DVSS PD XTS ICKS1 ICKS0 CAD1 CAD0
CDTO CDTI CCLK CS PIS XTO XTI AVSS AVDD VREFH VCOM
1.Pin layout
LIN+
LIN-
RIN+
RIN-
LOUT1
ROUT1
LOUT2
ROUT2
LOUT3
ROUT3
LPF
LPF
LPF
LPF
LPF
LPF
DAC
DAC
DAC
DAC
DAC
DAC
DATT
DATT
DATT
DATT
DATT
DATT
ADC
ADC
HPF
HPF
Audio
I/F
MCLK
BICK
LRCK
SDOUT
SDIN1
SDIN2
SDIN3
SDTO
SDTI1
SDTI2
SDTI3
SDOS
DAUX
Format
Converter
Block Diagram (DIR and AC-3) DSP are external parts)
2.Block diagram
AK4527 (IC601) : A/D,D/A Converter
Description of major ICs

RX-7001PGD
1-11
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Pin name
SDOS
OCKS
MIS
BICK
LRCK
SDTI1
SDTI2
SDTI3
SDTO
DAUX
DFS
DEM1
DEM0
MCKO
DVDD
DVSS
PD
XTS
ICKS1
ICKS0
CAD1
CAD0
LOUT3
ROUT3
LOUT2
ROUT2
LOUT1
ROUT1
LIN-
LIN+
RIN-
RIN+
SDTO Source select pin
"L" : Internal ADC output, "H" : DAUX input
ORed with serial control register if P/S="L".
MCKO Clock frequency select pin
"L" : MCLK, "H" : MCLK/2. ORed with serial control register if P/S= "L".
Connect to GND
Audio serial data clock pin
Input/Output channel clock pin
DAC1 Audio serial data input pin
DAC2 Audio serial data input pin
DAC3 Audio serial data input pin
Audio serial data output pin
AUX Audio serial data input pin
Double speed sampling mode pin
"L" : Normal speed, "H" : Double speed, the ADC is powered down.
ORed with serial control register if P/S="L".
De-emphasis pin
ORed with serial control register if P/S="L"
De-emphasis Pin
ORed with serial control register if P/S="L"
Master clock output pin
Digital power supply pin
Digital ground pin
Power-down & Reset pin
When "L", the AK4527 is powered-down and the control registers are reset
to default state.If the state of CAD0-1 changes, then the AK4527
must be reset by PDN.
X'tal oscillator Select/Test mode pin
"H" : X'tal Oscillator selected
"L" : External clock source selected
Input clock select 1 pin
Input clock select 0 pin
Chip address pin
Used during the serial control mode.
Chip address pin
Used during the serial control mode.
Lch #3 analog output pin
Rch #3 analog output pin
Lch #2 analog output pin
Rch #2 analog output pin
Lch #2 analog output pin
Rch #1 analog output pin
Lch analog negative Input Pin
Lch analog positive Input Pin
Rch analog negative Input Pin
Rch analog positive Input Pin
Function
AK4527(1/2)
I/O
I
I
I
I
I/O
I
I
I
O
I
I
I
I
O
-
-
I
I
I
I
I
I
O
O
O
O
O
O
I
I
I
I
3. Pin function (1/2)

RX-7001PGD
1-12
No.
33
34
35
36
37
38
39
40
41
42
43
44
Negative voltage reference Input pin, AVSS
Common voltage output pin,AVDD/2
Large external capacitor around 2.2uF is used to reduce power-supply noise
Positive voltage reference input pin,AVDD
Analog power supply pin
Analog ground pin
X'tal input pin
X'tal output pin if XTS="H"
External master clock input pin if XTS="L"
Parallel/Serial select pin
"L" : Serial control mode, "H" : Parallel control mode
Audio data interface format pin in parallel mode
Chip select pin in serial mode
Audio data interface format pin in parallel mode
Control data clock pin in serial mode
Loop back mode pin in parallel mode
Enables digital loop-back from ADC to 3 DACs.
Control data input pin in serial mode
Loop back mode pin in parallel mode
Enable all 3 DAC channels to be input from SDTII.
Control data output pin in serial mode
Pin Name
VREFL
VCOM
VREFH
AVDD
AVSS
XTI
XTO
MCKI
P/S
DIF0
CS
DIF1
CCLK
LOOP0
CDTI
LOOP1
CDTO
Function
I/O
I
O
I
-
-
I
O
I
I
I
I
I
I
I
I
I
O
AK4527(2/2)
3.Pin function (2/2)

RX-7001PGD
1-13
1OUT1
2-IN1
3+IN1
4
8
7
6
5VEE
VCC
OUT2
-IN2
+IN2
2
1
-
+-
+
BA15218F(IC303):OP AMP.
BA15218N (IC501, IC510, IC511) : Dual Ope. Amp.
1 2 3 4 5 6 7 8
OUT1 +IN1 +IN1 GND +IN2 -IN2 OUT2 Vcc
1+
-2
+
-
IN1
CTL A
VOUT 1
VCC
IN2
CTL B
logic
logic
MONITOR OUT
GND
IN5
GND
IN4
CTL E
IN3
CTL D
16
15
14
13
12
11
VOUT 2
CTL C
1
2
3
4
5
6
7
8
A B E MONITOR OUT
LL*IN1
HL*IN2
LH*IN3
HHL IN4
HHH IN5
C D E VOUT1
LL*--
HL*IN2
LH*IN3
HHL IN4
HHH IN5
C D E VOUT2
LL*IN1
HL*--
LH*IN3
HHL IN4
HHH IN5
10
11
BA7625 (IC242,IC201) / BA7626 (IC241): Video selector

RX-7001PGD
1-14
1
2
3
4
5
6
7
8
910
11
12
13
14
15
16
17
18
Vss
DATA
CLOCK
LCK
Q0
Q1
Q2
Q3
Q4
Vdd
OE
Q11
Q10
Q9
Q8
Q7
Q6
Q5
CONTROL
CIRCUIT
OUTPUT BUFFER(OPEN DRAIN)
12BIT STRAGE RESISTER
12BIT SHIFT RESISTER
1.Terminal Layout
1
2
3
4
5~16
17
18
Vss
DATA
CLOCK
LCK
Q0~Q11
OE
Vdd
-
I
I
I
O
I
-
Connect to GND
Serial Data input
Shift Clock of Data
Latch Clock of Data
Parallel Data Output
Output Enable
Power Supply
Pin No. Symbol I/O Function
Latch Data L H
OUTPUT ON OFF
2.Pin Function
BU2092(IC402,IC405):LED Controller

RX-7001PGD
1-15
14 13 12 11 10 9 8
1 2 3 4 5 6 7
I/O 1 O/I 1 O/I 2 I/O 2
C2 C3
VSS
VDD C1 C4 I/O 4 O/I 4 O/I 3 I/O 3
14 13 12 11 10 9 8
1 2 3 4 5 6 7
2.Block Diagram
1.Pin Layout
BU4066BCF (IC602,IC611) : Switch
A0~A16
I/O1~I/O8
CS
WE
OE
Vdd
Vss
Address inputs
Data inputs/outputs
Chip select inputs
Write enable input
Output enable input
Power supply
Ground
Symbol Description
A0
A1
A2
A3
CS
I/O1
I/O2
VDD
VSS
I/O3
I/O4
WE
A4
A5
A6
A7
A16
A15
A14
A13
OE
I/O8
I/O7
VSS
VDD
I/O6
I/O5
A12
A11
A10
A9
A8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
Vdd
Vss
A0
A16
CS
OE
WE
I/O1
I/O8
DECODER CORE
ARRAY
CONTROL DATA I/O
W24L011AJ-15(IC641):SDRAM
1.Pin layout 2.Block diagram 3.Pin function

RX-7001PGD
1-16
2. Pin Function
Pin
No. Symbol I/O Function Function
I/O
Symbol
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
FM IN
AM MIX
FM IF
AM IF
GND
TUNED
STEREO
VCC
FM DET
AM SD
FM VSM
AM VSM
MUTE
FM/AM
MONO/ST O
I
I/O
O
O
I
O
I
I
I
O
O
III
II
This is an input terminal of FM IF
signal.
This is an out put terminal for AM
mixer.
Bypass of FM IF
Input of AM IF Signal.
This is the device ground terminal.
When the set is tunning,this terminal
becomes "L".
Stereo indicator output. Stereo "L",
Mono: "H"
This is the power supply terminal.
FM detect transformer.
This is a terminal of AM ceramic filter.
Adjust FM SD sensitivity.
Adjust AM SD sensitivity.
When the signal of IF REQ of IC121(
LC72131) appear, the signal of FM/AM
IF output. //Muting control input.
Change over the FM/AM input.
"H" :FM, "L" : AM
Stereo : "H", Mono: "L"
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30 OSC BUFFER
AM OSC
REG
AM RF
AFC
AM AGC
O
I
O
I
I
I
AM Local oscillation Signal output.
This is a terminal of AM Local
oscillation circuit.
Register value between pin 26 and pin28
besides the frequency width of the
input signal.
AM RF signal input.
This is an output terminal of voltage
for FM-AFC.
This is an AGC voltage input terminal
for AM
O
O
I
O
AM detection output.
FM detection output.
Mpx input terminal
O
O
I
Right channel signal output.
Left channel signal output.
Input terminal of the Right channel post
AMP.
Input terminal of the Left channel
post AMP.
I
O
Mpx Left channel signal output.
Mpx Right channel signal output.
R OUT
L OUT
R IN
L IN
RO
LO
IF IN
FM OUT
AM DET
1. Block Diagram
ALC
BUFF
AM
OSC
REG
AM
MIX FM
RF.AMP
AGC
AM IF DET
SD
COMP AM
S-METER
FM
S-METER
FM IF PM
DET
S-CLRVE AM/FM
IF-BUFF TUNING
DRIVE
GND VCC
STEREO
DRIVE
MUTE
DECODER
ANIT-BIRDIE
STEREO
5N
SW
P-DET
PILOT
DET
FF
19k
FF
19k
FF
38k
VCO
384KHz /2/LS
30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
1234678910 11 12 13 14 15
5
LA1838(IC102): FM AM IF AMP&detector, FM MPX Decoder

RX-7001PGD
1-17
1. Pin layout 1
2
3
4
5
6
7
8
9
10
11
22
21
20
19
18
17
16
15
14
13
12
XT
FM/AM
CE
DI
CLOCK
DO
FM/ST/VCO
AM/FM
SDIN
XT
GND
LPFOUT
LPFIN
PD
VCC
FMIN
AMIN
IFCONT
IFIN
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
Pin
No.
12
13
14
15
16
17
18
19
20
21
22
Symbol
XT
FM/AM
CE
DI
CLOCK
DO
FM/ST/VCO
AM/FM
LW
MW
SDIN
Symbol
IFIN
IFCONT
AMIN
FMIN
VCC
PD
LPFIN
LPFOUT
GND
XT
Function
X'tal oscillator connect (75kHz)
LOW:FM mode
When data output/input for 4pin(input) and
6pin(output): H
Input for receive the serial data from
controller
Sync signal input use
Data output for Controller
Output port
"Low": MW mode
Open state after the power on reset
Input/output port
Input/output port
Data input/output
Function
IF counter signal input
IF signal output
Not use
AM Local OSC signal output
FM Local OSC signal input
Power suplly(VDD=4.5-5.5V)
When power ON:Reset circuit move
PLL charge pump output(H: Local OSC
frequency Height than Reference frequency.
L: Low Agreement: Height impedance)
Input for active lowpassfilter of PLL
Output for active lowpassfilter of PLL
Connected to GND
X'tal oscillator(75KHz)
I/O
I
O
I
I
I
O
O
O
I/O
I/O
I/O
I/O
I
O
-
I
I
-
O
I
O
-
I
Reference
Driver Phase
Detector
Charge Pump
Unlock
Detector
Universal
Counter
Swallow Counter
1/16,1/17 4bit
12bit
Programmable
DriverS
Swallow Counter
1/16,1/17 4bit
Data Shift Register & Latch
Power
on
Reset
C2B
I/F
1/2
782 11 13
21
17
6
5
4
3
15
16
22
118
19
20
12
2. Block diagram
3. Pin function
LC72136N (IC121) : PLL Frequency synthesizer

RX-7001PGD
1-18
Power Supply terminal for Audio signal +7V(typ)
Power Supply terminal 0V
Power Supply terminal for Audio signal. Single channel use, joint VSS.
Power Supply terminal +5V(typ)
Pin No. Symbol Function
1
18
14
15
28 NC No use
16 D1 Data input terminal from CPU
Shumit inverter style
VDD
VSS
VEE
VCC
Audio signal Input terminal
IN1 joint opposite input of Operation amp.
IN2 joint inapposite input of Operation amp.
It have Right and Left.
2,27
3,26
17 CLK Clock input terminal from CPU
Shumit inverter style
4~10
19~25 f1~f7 Joint terminal of B.P.F. f1~f7 X Right, Left Total 14 terminal
11
12 TEST1 TEST2 Internal test terminal of IC It can use open condition
IN 1
IN 2
Select terminal for 2 tip use
"1" input, key code 7C3 - VDD joint
"0" input, key code 7C2 - VEE joint
13 S
2IN1
+
–
3IN2 27 IN126 IN2
19
20
21
22
23
24
25
f1
f2
f3
f4
f5
f6
f7
10
f1 9
f2 8
f3 7
f4 6
f5 5
f6 4
f7
16
D1
Network
Resistor Network Resistor
Latch Circuit
17
CLK 13
S4
TEST1
12 TEST2
18
Vss
1
Vdd 15 Vcc
14
Vee
+
–
Control Shift Resistor
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
3.Pin function
LC7522 (IC451) : SEA Control
1.Pin layout 2.Block diagram

RX-7001PGD
1-19
M5243AP12(IC452):S.E.A.Graphic equalizer
IN1-2 NF1-2 IN2-2 NF2-2 IN3-2 NF3-2 IN-2 IN-2 OUT-2 VDD
IN1-1 NF1-1 IN2-1 NF2-1 IN3-1 NF3-1 IN-1 IN-1 OUT-1 GND
20 19 18 17 16 15 14 13 12 11
1 2 3 4 5 6 7 8 9 10
Vref. Vref.
V+
INPUT +
V-
OUTPUT
A OUT
A -IN
A +IN
V-
1
2
3
4
AB
(TOP VIEW)
8
7
6
5
V+
B -IN
B +IN
B OUT
1.Terminal layout
2.Block diagram
NJM4580D (IC301, IC302, IC306) : LPF, Mic and H.phone Amp.

RX-7001PGD
1-20
1. Pin layout
2. Pin function
80 61
21 40
1
20
60
41
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
Pin
No Pin No
Symbol Symbol
Functions Functions
GND
DVD-S/C
VCR1-S/C
VIDEO-S/C
TV-S/C
4/8-IN
GND
PROTECT
GND
VDD
OSC 12
OSC 11
VSS
X1
X0
GND
TEXT-OUT
TEXT-IN
MASTER
DSP-COMMAND
DSP-STATUS
DSP-CLK
RESET-IN
TUNER-CE
TUNER-CLK
TUNER-DATA
TUNER-MUTE
TUNER-IN
STEREO-IN
RDS-ST
M-BUSY
INH
OSD-DATA
OSD-STB
OSD-CLK
VIDEO1
VIDEO2
VIDEO3
VIDEO4
S.MUTE
RDS-DATA
RDS-CLK
DSP-READY
DSP-RESET
M/CS
M-RESET
M-STATUS
M-COMMAND
M-CLK
SEA-CLK
SEA-DATA
VL/VH
4/8 OUT
SW-DATA
SW-CLK
VOL-STB
VOL-DATA
VOL-CLK
SW-STB
FR1-RELAY
FR2-RELAY
CNTR-RELAY
SUR-RELAY
SUB-MUTE
LED-LCK2
C.TONE3
C.TONE2
C.TONE1
LED-LCK1
LED-DATA
LED-CLK
Ground
DVD S/C signal select terminal
VCR1 S/C signal select terminal
VIDEO S/C signal select terminal
TV S/C select terminal
4 ohm / 8 ohm select signal terminal
Ground
Protect
Ground
Power supply
Oscillation terminal
Oscillation terminal
Ground
Ground
Ground
Ground
Text signal output terminal
Text signal input terminal
Master signal terminal
DSP control signal terminal
DSP control signal terminal
DSP control signal terminal
No use
Reset signal input terminal
Tuner chip enable
Tuner clock signal terminal
No use
Tuner control signal terminal
Tuner mute signal terminal
Tuner signal input terminal
Stereo signal input terminal
No use
Busy signal from IC400
No use
OSD data signal input terminal
OSD standby signal terminal
OSD clock signal terminal
VIDEO 1 signal terminal
VIDEO 2 signal terminal
VIDEO 3 signal terminal
VIDEO 4 signal terminal
Source mute control terminal
No use
No use
No use
RDS control signal terminal
No use
RDS control signal clock
DSP control signal clock
DSP reset signal terminal
Control signal from IC400
Reset signal from IC400
Status signal from IC400
Command signal from IC400
Clock signal from IC400
SEA clock signal from terminal
SEA data signal terminal
Connect to power supply board
4 ohm / 8 ohm select signal terminal
Switch data signal terminal
Switch clock signal terminal
Volume strobe signal terminal
Volume data signal terminal
Volume clock signal terminal
Switch strobe signal terminal
No use
No use
Relay 1 signal terminal
Relay 2 signal terminal
Center speaker relay terminal
Surround speaker relay terminal
SUB woofer out mute control
LED latch clock signal terminal
Center tone 3 signal terminal
Center tone 2 signal terminal
Center tone 1 signal terminal
LED latch clock signal terminal
LED data signal terminal
LED clock signal terminal
MN101C15FDE (IC401) : System control micon
